DAWN HOUSE BED | OWNER'S MANUAL
Customer Service: www.dawnhouseliving.com | 1-888-DAWNHSE (1-888-329-6473)
Actual product appearance and functionality may vary from photographs, illustrations and descriptions included in this manual.

TABLE OF CONTENTS
Safety Precautions and Usage Statements .......................................................................1-3
Parts List ......................................................................................................... 4
Base Overview ....................................................................................................5
Electronic Overviews ...........................................................................................6-8
Installation Guide .............................................................................................. 9-10
Dawn House Headboard Installation ................................................................................11
Placing the Bed into Your Own Furniture ...........................................................................12
Remote Control...................................................................................................13
Pairing the Remote Control........................................................................................14
The Puck Voice Activated System Overview .......................................................................15
The Puck Voice Activated System Installation......................................................................16
The Puck Voice Commands .......................................................................................17
Syncing Two Twin Long Bases (Optional) ..........................................................................18
Emergency Battery Backup Strap .................................................................................19
Troubleshooting ................................................................................................. 20
Notes.............................................................................................................21
For customer support, visit www.dawnhouseliving.com or call: 1-888-DAWNHSE (1-888-329-6473)

1
TO REDUCE THE RISK OF SHOCK, BURNS, FIRE OR
INJURY:
For optimal safety and operation, plug bed base into a surge protector
(not included). The bed base should only be plugged directly into a wall
outlet or surge protector (strongly recommended). Always unplug the
base from the electrical outlet before servicing any part of the base.
To reduce risk of electric shock, unplug the base before cleaning. To
safely disconnect, ensure the base is in a at position with all motors
off, and unplug from power source. Keep the power cord away from
heated surfaces. Never operate the base when the air openings are
blocked. Keep air openings free of lint, hair and the like. Do not drop or
insert any object into any opening. Discontinue use of the bed base
and contact a qualied service center if: it has a damaged cord or plug,
if it is not working properly, or it has been dropped into water. Only
use this bed base for its intended use as described in this manual. Do
not use accessories/attachments that are not recommended by the
manufacturer. Close supervision is required when the bed base is used
by or near children, convalescents, disabled persons or pets. Improper
connection of the equipment can result in the risk of electrical shock,
electrical re or faulty operation of this bed base. If the plug does
not t your outlet, contact a qualied electrician to install a suitable
outlet. Unauthorized modication or failure to use a wall outlet or surge
protector could void the electrical portion of your warranty.
CHILDREN AND PETS:
Immediately dispose of all packing materials as it may pose a
smothering risk to small children and pets. To avoid injury, it is not
advised to allow children and small pets to play on or under the bed.
Children should not operate the bed base without adult supervision.
SAFETY FEATURES:
Manual operation – If something gets caught in the platform when
attened, you can manually raise the platform up by lifting at either the
head or foot to relieve pressure and allow for release.
Emergency stop – Stop the motion of the platform by pressing any
button on the remote control.
Power outage – Use the “Emergency Battery Backup Strap” as a
temporary power source to get the base to a desired position.
Instructions on how to operate the Battery Backup Strap are on the
Emergency Battery Backup page(s).
PACEMAKERS:
Some products contain Neodymium MAGNETS which may interfere
with devices such as pacemakers, ICD’s and any other device sensitive
to magnetic elds. It is STRONGLY recommended that owners of
such medical devices consult their physician prior to using products
that contain Neodymium MAGNETS. It is also possible that some
pacemakers may falsely interpret the optional massage feature
vibrations as movement/exercise. This is a common occurrence with
any product that creates a vibrating movement and may affect the
pacemaker. Please consult your physician before using the massage
feature.
IN-HOME USE AND HOSPITAL STANDARDS:
Ergo adjustable bed bases are designed solely for in-home use. This
base was not designed as a hospital bed and is not designed to meet
hospital standards. Do not use this base with TENT TYPE oxygen therapy
equipment or near explosive gases.
ADDITIONAL SAFETY FEATURES
Casters (optional leg accessory) are equipped with locking wheels to
prevent unwanted movement. Even when locked and unable to roll, it is
possible for the casters to slide. Free release head and foot motors are
designed to lower the mattress by retracting only with gravity, never
pulling downwards, which minimizes pinch points
ATTENTION: IMPORTANT SAFETY DISCLAIMERS
READ THE FOLLOWING INFORMATION BEFORE USING THIS PRODUCT. FAILURE TO USE A SURGE PROTECTION
DEVICE COULD COMPROMISE SAFETY OR CAUSE PRODUCT MALFUNCTION AND COULD VOID THE ELECTRICAL
PORTION OF YOUR WARRANTY.
SAFETY PRECAUTIONS AND USAGE STATEMENTS

2
LIFTING/LOWERING MECHANISMS
The lift/lower feature will emit a minimal humming sound during
operation. This is normal. During operation, the lift arm wheels make
contact with the platform support of the base. This contact may
result in metal on metal or metal on plastic contact. This applies slight
tension on the moving components and resonance is reduced to a
minimum level. If excessive noise or vibration is experienced, reverse
the movement action (up or down) of the base with the remote control.
This should realign the base’s activating mechanisms to the proper
operational position. In normal base operation, the wheels, which allow
the bed to maintain its distance from the wall, will make contact with
the steel platform supports of the base creating a contact noise. When
entering, exiting or shifting weight on the base, this contact noise may
be audible as the wheels make contact. This is normal.
MATERIALS
Ergo adjustable bases are constructed from various materials including
woods, metals, plastics and fabrics. Tension, pressure or movement
applied to the frame, platform or shroud through general use may create
an audible sound.
MASSAGE OPERATION AND LOCATION ENVIRONMENT
The massage feature will emit a tone during operation. This is normal.
As the massage intensity level is increased, the tone will intensify. The
volume of this tone is directly related to the location environment.
For example, when demonstrated in a show room, the surrounding
environmental noise will cover some of the massage noise. However,
when installed in a home setting with wooden oors, carpeted or
not, the massage volume will be more noticeable. To minimize this
resonance, place a piece of carpet, or rubber caster cups, under each
leg or caster of the base. It is possible to experience vibration or
noise from the exterior bed frame, headboard brackets, headboards or
footboards if mounting bolts are not rmly tightened.
Levels 1-3 of massage intensity represent the revolutions of the motor
per minute. Level 3 provides the maximum number of RPMs. However,
this does not mean that the feeling of vibration is the strongest.
Depending on the mattress material, thickness, and positioning of the
user, the feeling of vibrations will differ. We encourage the user to nd
the massage intensity setting that suits them best. It is important to
understand the physics of vibrations. Just as an engine may run rough
during idle, as the RPMs increase, the vibrations change concurrently.
TOLERANCE
All Ergo adjustable foundations, depending on make and model, are
designed and manufactured to perform and function within designated
quality control parameters. Bases are subject to meticulous and rigorous
inspections during the quality control process to ensure bases will
operate within these standards during normal operating use. Normal
operating use is dened as the following: Adjustable foundation is to be
operated with a mattress and load. Testing procedures require lifetime
cycle tests with up to 120kg distributed load. The angle (designated “α”
in gure 1) between the back section and the at section for various
congurations of the mattress support platform shall be ± 3°, which
translates to a tolerance of up to 1 ½”.
The angle (designated “β” in gure 1) between the at section and foot
section for various congurations of the
mattress support platform shall be ± 3°,
which translates to a tolerance of up to
¾”.
Any adjustable foundation deemed
to be within these allocated
tolerances is considered to have met
the manufacturer’s quality control
standards.
THAT “NEW PRODUCT” SMELL:
Some people notice a slight odor to their new adjustable base—this can
come from our material manufacturing process. This smell is normal
and usually disappears before the product reaches you. Sometimes,
however, this smell may still be noticeable. It usually disappears after
a few weeks, providing adequate ventilation of the product and the
environment.
SAFETY PRECAUTIONS AND USAGE STATEMENTS
Adjustable
Bed Tolerance
Ergomotion Inc. | ph 1-888-550-3746 | fx 805-979-9399 | www.ergomotion.com
All Ergomotion adjustable foundations, depending on make and model, are designed and manufactured to perform and
function within designated quality control parameters. Bases are subject to meticulous and rigorous inspections during
the quality control process to ensure bases will operate within these standards during normal operating use.
Normal operating use is defined as the following:
-Adjustable foundation is to be operated with a mattress and load. Testing procedures require lifetime cycle
tests with up to 120kg distributed load.
The angle (designated “α” in figure 1) between the back section and the flat section for various configurations of the
mattress support platform shall be ± 3°, which translates to a tolerance of up to 1 ½”.
The angle (designated “β” in figure 1) between the flat section and foot section for various configurations of the mattress
support platform shall be ± 3°, which translates to a tolerance of up to ¾”.
Any adjustable foundation deemed to be within these allocated tolerances is considered to have met the manufacturer’s
quality control standards.
(α°)
(β°)
When operating a "paired" split base setup there may be a time latency up to 1.5 seconds between each bases articulation.
Blake Pettit
Quality Assurance Manager
Ph 805-979-3875
Fx 805-979-9399
www.ergomotion.com

3
BREAK IN PERIOD:
You can speed up the break-in period by simply spending time in
the adjustable bed through activities such as reading, watching TV or
playing with the kids or grandkids. The extra movement will help the
adjustable base respond to weight and temperature changes. Some
of the materials in our adjustable bases such as the woods, metals and
plastics used in the platform, frame and components are sensitive to
moisture content and temperature and may make sounds in colder
environments.
PAIRED OPERATION:
When operating a “paired” split base setup there may be a time latency
up to 1.5 seconds between each bases articulation.
WEAR AND TEAR:
Wear and tear is damage that naturally and inevitably occurs as a result
of normal use or aging.
FABRIC CARE:
To prolong the life of your fabric, protect from direct sunlight whenever
possible. For spot cleaning, wipe area with a light damp sponge or
vacuum with a soft brush attachment to remove particles. Keep at a
minimum of 30cm (12 inches) away from direct heat sources. For a
deeper cleaning, blot liquid spills with a clean dry cloth. Wipe with a
clean cloth dampened with warm water. Do not wet excessively. A soft
bristle brush may be used to remove ingrained soil. Avoid scratching by
gentle brushing. Wipe with a clean cloth dampened with warm water to
remove residues. Dry in shade away from direct heat. If persistent marks
remain visible after cleaning, seek professional advice.
PRODUCT RATINGS:
The lift motors are not designed to operate continuously for more than
[2] minutes in an [18] minute time period or approximately 10% duty
cycle. Attempting to circumvent or exceed this rating will shorten the
life expectancy of the product and may void the warranty. The massage
motors are not designed to operate continuously for more than 30
minutes at a time. Please allow the massaging system to rest for 30
minutes after automatic massage shut off before restarting.
WEIGHT LIMITS:
This product is not rated to support weights in excess of 750 pounds for
Queen/Full sizes and 450 pounds for TL sizes. The base will structurally
support this weight, provided it is evenly distributed across the bed
base. The adjustable base is not designed to support or lift this amount
in the head or foot sections alone. Exceeding this weight restriction
could damage the bed and/or cause injury and will void the warranty.
SAVE THESE INSTRUCTIONS.
SAFETY PRECAUTIONS AND USAGE STATEMENTS
FCC COMPLIANCE:
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

4
A B* C
D E F ‡
G H I
PARTS LIST
A. Wireless Remote Control & AAA Batteries (2)
B. Mattress Retainer Bar*
C. Legs Pads (4)
D. Power Cord
E. Power Supply
F. Sync Cord ‡
G. Battery Backup Strap
(2) 9V Batteries (not included)
H. Puck Voice Activated System
I. Input Cord
MISC PARTS RECOMMENDED(NOT INCLUDED):
Surge Protector
BEFORE DISCARDING THE PACKING MATERIALS - ENSURE ALL THE PARTS ARE ACCOUNTED FOR.
ALL ELECTRONICS AND COMPONENTS THAT NEED TO BE INSTALLED ARE LOCATED IN BOXES UNDER THE
BASE OR ATTACHED TO THE FRAME.
* These items are attached to the base for shipping purposes.
Carefully remove from base and set aside.
‡ Only included in Twin Long and Cal King Split bases.

5
BASE OVERVIEW
Control
Box
Foot
Motor
Head
Motor
Motion
Detector
Underbed
Lights
Health
Sensor
Health
Sensor
Foot
Massage
Motors
Head
Massage
Motors
Bed Lift
Motor #2
WiFi
Motion
Detector
Bed Lift
Motor #1

6
Head Massage
Motors
Foot Massage
Motors
Bed Lift Motor
Bed Lift Motor
Control Box
Head Motor
Foot Motor
Power Cord
Underbed Lights
Power Supply
Extension Cord
WiFi Health
Sensors
Motion
detectors
Puck
Emergency Battery
Backup Strap
Remote Control
NOT TO SCALE. FOR ILLUSTRATION PURPOSES ONLY. READ ALL INSTRUCTIONS BEFORE BEGINNING
INSTALLATION.
QUEEN SIZE ELECTRONIC OVERVIEW

7
Foot Massage
Motor
Bed Lift Motor
Bed Lift Motor
Control Box
Head Motor
Foot Motor
Power Cord
Underbed Lights
Power Supply
Sync
Cable
Extension
Cord
Health
Sensor
Motion
detectors
WiFi
Puck
Emergency Battery
Backup Strap
Remote Control
If installing a split unit
(Two TLs) see page 18.
NOT TO SCALE. FOR ILLUSTRATION PURPOSES ONLY. READ ALL INSTRUCTIONS BEFORE BEGINNING
INSTALLATION.
TWIN LONG SIZE ELECTRONIC OVERVIEW

8
Head Massage
Motor
Foot Massage
Motor
Bed Lift Motor
Bed Lift Motor
Control Box
Head Motor
Foot Motor
Power Cord
Underbed Lights
Power Supply
Extension
Cord
Puck
Emergency Battery
Backup Strap
Remote Control
NOT TO SCALE. FOR ILLUSTRATION PURPOSES ONLY. READ ALL INSTRUCTIONS BEFORE BEGINNING
INSTALLATION.
FULL SIZE ELECTRONIC OVERVIEW
Health
Sensor
Motion
detectors
WiFi

9
INSTALLATION GUIDE
ALWAYS USE TWO PEOPLE WHEN SETTING UP THE BASE.
With the help of an able-bodied assistant, place the carton on the
oor in its desired location with the bottom side facing up. Remove all
tape and binding straps, being careful not to puncture the box with
any sharp objects.
Open the box and remove the plastic bag. Cut the zip ties and set
aside any accessories and electronics. Ensure that all items from the
parts list on page 4 are set aside before proceeding to Step 3.
To install the mattress retainer bar, insert each end of the bar into the
holes at the foot of the base. Rotate the bar so that it is resting on the
edge of the base.
Screw in the leg pads on all four corners of the frame.
Using two people, carefully ip the base to an upright position and move
it to its desired location.
Plug the Puck wireless charger into the extension cord located on the
underside of the bed at the head section. See pages 15-17 for more
information.
STEP 1
STEP 2
STEP 6
STEP 5
STEP 3
STEP 4

10
Install the remote batteries and test all functions to verify proper setup
before placing mattress on base. Return the base to a at position
before placing the mattress on top.
Download the Dawn House App from the App Store (Apple) or Google
Play Store (Android). Follow the in-app instructions. To connect your
base to the app, scan the QR code located under the head section of
the adjustable base.
Plug the power cord into a power source.
A surge protector is recommended.
If you received the Dawn House mattress with your order, remove it from
its carton and and unroll the mattress. Carefully cut open the vacuum
sealed packaging and place the mattress on the base.
Locate the input cord under the base and
plug it into the power supply.
Insert the power cord into the power
supply.
INSTALLATION GUIDE (CONTINUED)
STEP 10
STEP 11 (Optional: For Dawn House mattress orders only)
STEP 12
STEP 7
STEP 8
STEP 9
u To assemble the Dawn House headboard, proceed to the
next page for installation.
u For instructions regarding the use of your own furniture,
see page 12.
u If not installing headboard or placing in furniture, setup is
complete.

11
DAWN HOUSE HEADBOARD INSTALLATION
With the help of an able-bodied assistant, place the headboard
carton on the oor in its desired location. Remove all tape and binding
straps, being careful not to puncture the box with any sharp objects.
Open the box and remove the plastic bag. Be sure to locate and set
aside any hardware.
Use the remote control to raise the head of the adjustable base all the
way. Unplug the power cord from the power source.
Align the headboard to the headboard mounting points on the frame.
Secure the headboard to the base with included screws. (At least two
screws are needed per mounting point.)
Feed the power cord through the hole in the headboard and plug it
into the power source.
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
CONTINUE WITH THE STEPS BELOW TO INSTALL YOUR DAWN HOUSE HEADBOARD.

12
PLACING THE BED INTO YOUR OWN FURNITURE
The Dawn House bed is slightly narrower than the standard bed frame size and can work with most existing bed frames.
The Dawn House bed needs to rest directly on the oor. Do not place it on slats or box springs.
PLACING THE BED INTO YOUR OWN FURNITURE
IF YOU WOULD LIKE TO KEEP USING YOUR FAVORITE FURNITURE SET, YOU'RE IN LUCK. DAWN HOUSE BED
WORKS WITH MOST EXISTING FURNITURE.
Note: If your bed frame is taller than Dawn House bed,
3" legs are offered (sold separately).
To purchase legs, visit Dawnhouseliving.com
WARNING: Keep hands and ngers clear of pinch points.

13
REMOTE CONTROL
A
B
C
H
J
L
K
I
E
D
G
F
A. Light: Turn the underbed lights On/Off.
B. Motion Detector Switch: Motion activated underbed lighting:
On(Up)/Off(Down)
Note: Press the Flat button to conrm selection.
C. Relax: Massage cycle (Low > Medium > High > Off)
After 10 minutes, massage timer will automatically turn off.
D. Zero-G®: Preset position that adjusts your legs to a higher level
than your heart helping to relieve pressure off the lower back
and promote circulation.
E. Head Articulation: Raises and lowers the head end of the
adjustable base.
F. Foot Articulation: Raises and lowers the foot end of the
adjustable base.
G. *Anti-Snore: Programmable preset position raises the head
section of the base slightly to help reduce snoring.
H. *Read: Programmable preset position ideal for reading a book or
watching TV.
I. **In: Programmable bed-height preset position.
J. **Out: Programmable bed-height preset position.
K. Bed: Raises and lowers the bed height.
L. Flat: Return the adjustable base to a at position.
BUTTON FUNCTIONS
Download the Dawn House app for an in-app remote control tutorial.
*TO PROGRAM A NEW HEAD/FOOT ARTICULATION PRESET: Articulate the head
and foot to your desired position. Press and hold one of the preset buttons [Snore,
Read] for 7 seconds. The position is now saved.
**TO PROGRAM A NEW BED HEIGHT PRESET: Raise or lower the bed to your
desired bed height. Press and hold one of the preset buttons [In, Out] for 7
seconds. The position is now saved.
NOTE: To restore the preset buttons back to their original factory settings, hold
FLAT and ZERO-G® simultaneously for at least 5 seconds. The original presets will
be restored.

14
THE REMOTE THAT COMES IN THE BOX IS ALREADY PAIRED TO THE ADJUSTABLE BASE. NO FURTHER ACTION IS
REQUIRED. IN THE EVENT THAT THE REMOTE IS NOT PAIRED WITH THE BASE, FOLLOW THE STEPS BELOW.
PAIRING THE REMOTE CONTROL
Power Cord
Power Supply
Disconnect the base from its power outlet. Wait 10 seconds, then plug
it back in.
Remove the battery cover on the back of the remote control. Press and
hold the PAIR button for about 5 seconds until the PAIR button stops
ashing. Once it stops ashing, the remote has been successfully
paired.
PAIR Button
Test all remote functions. If the remote buttons do not impact the
adjustable base movements, please repeat the process again or call
Dawn House customer service: 1-888-DAWNHSE (1-888-329-6473)
STEP 1 STEP 2
STEP 3

15
THE PUCK VOICE ACTIVATED SYSTEM OVERVIEW
ATTENTION: Your adjustable base can pose an entrapment hazard which
is increased in households with small children and or pets. Using voice
controls further increases this entrapment hazard due to the potential of
unintentionally triggering a command vocally. The voice controls could
be unintentionally triggered by yourself, a small child, the television, a
radio program, etc. and by using this product you agree that you have
read and reviewed the commands, including the Emergency Commands,
and acknowledge the increased entrapment risk associated with using
voice commands.
If you agree with this statement, please read the instructions on the
following pages to learn how to setup the Puck, however if you have any
questions in regard to the use of voice controls please contact customer
service prior to activating the Puck.
WIRELESS CHARGER
• Intro: This item has a wireless charging function. The maximum
charging power is 10W. Place the device to be charged in the center
of the wireless charger. During normal operation, the green light will
indicate that it is charging.
• Overheat Protection: In a high temperature environment, when the
internal temperature of the product rises to 158 degrees (F), the
wireless charger will enter a protection mode and the product will
turn off the wireless charging function. When the internal temperature
lowers to below 122 degrees (F), the charging function will resume.
• Incompatible Device Detection: If an incompatible device is placed
on the charger, the red light will indicate that the device should be
removed.
OVERVIEW
PLEASE FAMILIARIZE YOURSELF WITH ALL SAFETY INFORMATION BEFORE SETTING UP THE PUCK VOICE
ACTIVATED SYSTEM.
SAFETY INFORMATION
If you wish to stop using voice commands, you can turn the device
off by switching the slider on the puck to the middle “OFF” position.
Your adjustable base can pose an entrapment hazard and there is an
increased risk for households with small children and or pets. Using voice
controls increases this entrapment hazard due to the potential of accidentally
triggering a command vocally. The voice controls could be unintentionally
triggered by a small child, television, radio program, etc., please read
the “Emergency Commands” section so that you are familiar with these
commands in the event of an emergency.
ENTRAPMENT HAZARD: This bed can crush and kill when it moves. Using
voice controls may increase this risk. Review emergency commands before
activating voice controls.
Puck Cable
Puck Voice Control

16
THE PUCK VOICE ACTIVATED SYSTEM INSTALLATION
Remove the Puck from the box.
Please take a minute to familiarize yourself with the voice commands
listed on the page 17.
Use the remote control to lift the
HEAD to the maximum angle.
When the HEAD is raised to the
maximum angle, locate the Puck
connector and then connect it with
the plug as shown in the picture.
The Puck Voice Control will arrive in the
Off position and you will need to activate
the Puck by selecting an invocation
command of your preference.
Use the slider switch on the back side of
the Puck to select the invocation phrase
you wish to use, either “HELLO DAWN”
or “HELLO BED”.
Note: If you have a split base, each side
must have a different invocation phrase
in order to work independently.
STEP 2
STEP 1
STEP 3
STEP 4
STEP 5
FOLLOW THE INSTALLATION STEPS BELOW TO SET UP THE PUCK VOICE ACTIVATED SYSTEM.
WAKE UP DEVICE
To use the Puck Voice Activated System, simply say the invocation
command you chose during setup, either “HELLO DAWN” or “HELLO
BED”, and wait 1-2 seconds for the microphone to activate. Once the
microphone is activated, indicated by the blue light, it will be active
for 8 seconds. While the microphone is active you can now use any
of the voice commands listed below to control your adjustable base.
If no command is heard within 8 seconds, the Puck will enter “sleep
mode” and the microphone will be deactivated.
Proceed to the next page for list of voice commands.

17
THE PUCK VOICE COMMANDS
ONCE THE INVOCATION PHRASE HAS BEEN UTTERED, THE MICROPHONE WILL BE ACTIVE FOR 8 SECONDS
WHICH IS INDICATED BY THE BLUE LIGHT. WHILE THE MICROPHONE IS ACTIVE YOU CAN NOW USE ANY OF THE
COMMAND PHRASES LISTED BELOW TO CONTROL YOUR ADJUSTABLE BASE.
VOICE COMMAND EXPLANATION
Common
Controls
GOOD-NIGHT Flat bed
RISE-AND-SHINE Adjust the bed to preset position for Zero-G®
Actuator
Controls
RAISE-HEAD Head up 3s
LOWER-HEAD Head down 3s
RAISE-FOOT Foot up 3s
LOWER-FOOT Foot down 3s
LIFT-BASE Bed height rises 3s
LOWER-BASE Bed height lowers 3s
Presets
FLAT-PRESET Flat bed
ZERO-G®/ZERO-GRAVITY Adjust the bed to preset position for Zero-G®
SIT-UP Adjust the bed to preset position for READ
GETTING-IN Adjust the bed to preset position for IN
GETTING-OUT Adjust the bed to preset position for OUT
Underbed
Lights
TURN-ON-LIGHT Turn on the bed lights
TURN-OFF-LIGHT Turn off the bed lights
Massage
TURN-ON-MASSAGE Turn on the bed massage
TURN-OFF-MASSAGE Turn off the bed massage
MASSAGE-UP Increase massage intensity
MASSAGE-DOWN Reduce massage intensity
VOICE COMMAND EXPLANATION
EMERGENCY
COMMANDS
STOP Stop all movement
ALL-UP Raise both the head &
Foot 6 seconds

18
SYNCING TWO TWIN LONG BASES (OPTIONAL)
Sync Cord
Control Box 1
Control Box 2
A SYNC CORD IS INCLUDED WITH THE BASE. NOT AVAILABLE ON QUEEN OR FULL SIZE BASES.
THE SYNC CORD CONNECTS THE TWO CONTROL BOXES TO SYNCHRONIZE THE MOVEMENT OF THE TWO
BASES. USE THIS FOR A KING SIZE MATTRESS ON TWO ADJACENT TWIN LONG BASES.
If bases become mismatched, returning the bases to the at
positions will re-sync the mechanical positions.
The system is now linked. Pressing buttons on either remote
will control both bases simultaneously.
Raise the head of both bases, then unplug them from power source.
Connect the Sync Cord to the extension cord under the head
section.
Plug bases back into the power source. Ensure that all cords are
securely attached.
STEP 1
STEP 2
STEP 3
PERFORMANCE NOTES
