ErgoVerse CASSIOPEIA DSS-27 User manual

CASSIOPEIA
Desktop Sit-Stand Retrofit
Models: DSS-27 and DSS-36
Tools Required
Technical Data
Assembly Step 1
Carefully open carton and remove the CASSIOPEIA from
the packing materials.
Carefully place the sit-stand unit on the desk or table
surface.
Assembly Step 2
a. Snap decorative safety cover onto the
lifting arms.
b. Attach the keyboard tray brackets to the
keyboard tray using the 8 screws provided.
c. Suspend the keyboard brackets from the
knob assembly below the front of the work
surface.
d. Tighten keyboard bracket knobs to secure
the keyboard tray in place.
CAUTION
B
A
A: 3~15kg
B:<=2kg
A+B=3~15kg
CAUTION
CAUTION
Please read all instructions before using this product.
Retain this manual for future reference.
The specifications of the product may vary slightly from the illustrations.
CAUTION
Use appropriate safe lifting techniques to ensure safety when removing the CASSIOPEIA from the packaging materials.
DO NOT overtighten screws.
For best results the heads of the screws should be just flush with the counterbored hole in the bracket.
Please do not exceed the maximum recommended weight loads
DSS-27 DSS-36
x1
x8 x4
x1 x1
x2
x1
Package Contents

Assembly Step 3
To Raise or Lower the CASSIOPEIA simultaneously squeeze the
release paddles on both sides. With the paddles sqeezed, raise or
lower the work surface to the desired height and then release
the paddles to engage the locking mechanism. The unit will then
lock into place at the next highest position
NOTE: Both release paddles must be fully engaged at the same
time to avoid catching or uneven adjustment.
Assembly Step 4
Raise the CASSIOPEIA to the maximum height before placing
equipment on the work surface.
If a monitor arm (optional) is to be used to provide greater
elevation it should be attached at this point and the monitor(s)
secured in place.
Position keyboard, mouse, and monitor(s) so that they are fully
supported by the workstation surfaces.
Use the included Cable Clips or optional cable routing guides to
safely route cabling in order to avoid potential damage. Ensure
that cables have sufficient length to permit full and easy
adjustment throughout the entire height range.
CAUTION
CAUTION
For safety please ensure that no hands or
equipment are near the scissor lift mechanism
when the height of the unit is being adjusted.
Please ensure that all devices are fully supported on the
appropriate surfaces.
Do not exceed the recommended weight bearing loads.
WARRANTY
CASSIOPEIA Desktop Sit-Stand Retrofit units come with a 2 year limited warranty against defects in material and
workmanship under normal use and service.
CAUTION
Prior to removing equipment from the CASSIOPEIA the work surface should be raised to the maximum elevation.
Imported by ErgoVerse Ergonomics Ltd. PO Box 9022 Saskatoon SK S7K 7E7
Web: www.ergoverse.com Email: i[email protected]
When moving the CASSIOPEIA ensure that the unit is fully locked before removing from the desk. Appropriate safety precautions and
lifting protocols should be adhered to.
CAUTION
