Crosley CF1121 User manual

Leg
Partition Panel
Fixed Shelf
Panel

3
Please do not use tools to assemble this unit unless specifically indicated.
Step 1. Attach legs (part I) to bottom panel (part D) using spring washers (part #4),
flat washers (part #3), bolts (part #2) and allen wrench (part #7).

4
Step 2. Insert partition panels (part E) to fixed shelf panel (part F).
Step 3. Attach panels (parts B & C) to fixed shelf panel (part F) pull down to lock.

5
Step 4. Attach assembled unit (parts B, C & E) to bottom panel (part D) pull down to
lock.
Step 5. Carefully turn unit upright. Insert back panels (parts G & H) into grooves of
assembled unit (parts B, C, D & E).

6
Step 6. Attach top panel (part A) to assembled unit (parts B, C & E) using wood
dowels (part #5) and lock the hardware.
Step 7. Secure back brackets (part #6) at the corner of center back panel (part H)
using screws (part #1) and phillips head screwdriver.
Note: It is important to adjust levelers once fully assembled and upright. Extend
adjustable leveler until it's firmly in contact with the floor. If relocating, adjust
leveler as needed until it's firmly in contact with the floor in new Iocation.
Important: Safety strap kit (part #8) must be installed to preventing tipping, damage
and /or injury.

#8
Wall Anchor Short ScrewWasher D8*3/4" Safety Wall Strap
Long Screw
D8*1-1/2"
7
