Erica Synths pico Series User manual

FEATURESTECHNICAL SPECS
Thank you for purchasing Erica Synths Pico Series module!
With Pico Series we challenged ourselves – can we make ANY
superior functionality synth module 3HP wide and affordable?
Erica Pico VCF1 is a younger brother of Erica Black Polivoks
VCF, designed on the similar topology using rare Russian opamps.
As result you get a filter for great acid basslines, screaming
resonance sweeps and deep wobbles.
Lowpass and bandpass modes
Self oscillation
Rare russian opamps used
Input protection against overvoltage
Power consumption +12mA, -11mA
Module width 3HP
Module depth 35mm
PICO
VCF1

PICO
VCF1
Use this knob to adjust VCF cutoff
manually
Choose between LP and BP modes
Use this knob to adjust VCF Resonance
manually
This knob adjusts cutoff CV level
Patch audio signal here
This is VCF output
Patch cutoff CV signal here
PICO
OUT
RESO
C-OFF
LP BP
CV IN
IN
CV IN
VCF1

Water is lethal for most of the electric devices, unless they are made
waterproof. This Erica Synths module is NOT intended for use in a humid or
wet environment. No liquids or other conducting substances must get
into the module. Should this happen, the module should be disconnected
from mains power immediately, dried, examined and cleaned by
a qualified technician.
Do not expose the module to temperatures above +50° C or below -20° C.
If you have transported module in extreme low temperatures, leave it in
room temperature for an hour before plugging it in.
Transport the instrument carefully, never let it drop or fall over.
Warranty does not apply to modules with visual damages.
The module has to be shipped in the original packaging only. Any module
shipped to us for return, exchange and/or warranty repair has to be in
its original packaging. All other deliveries will be rejected
and returned to you. Make sure you keep the original packaging and
technical documentation.
This device complies to the EU guidelines and is manufactured ROHS
conforming without use of led, mercury, cadmium and chrome.
Nevertheless, this device is special waste and disposal in household
waste is not recommended.
Safety Instructions
You will find Erica Synths terms of warranty at www.ericasynths.lv.
Items for return, exchange and/or warranty repair have to be sent to:
Erica Synths
Andrejostas Str. 12
Riga
Latvia
LV-1045
User manual by Girts Ozolins@Erica Synths
Design by Ineta Briede@Carre Branding
Copying, distribution or any commercial use in any way is prohibited and needs the written
permission by Erica Synths. Specifications are subject to change without notice.
In case of any questions, feel free to contact us through www.ericasynths.lv or via e-mail
[email protected]
Please follow the instructions for use of the Erica Synths module
below, ‘cause only this will guarantee proper operation of the module
and ensure warranty from Erica Synths.
