Radio Description
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

1 Introduction
This document describes Radio 2203.
1.1 Warranty Seal
The product is equipped with a warranty seal sticker.
Note: Seals that have been implemented by Ericsson must not be broken or
removed, as it otherwise voids warranty.
Introduction
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 1

2 Product Overview
The radio expands coverage and performance in denser urban areas, where
the use of small handheld devices demand high capacity on the operators
networks. It is designed to be located in cities and in demanding radio
environments.
The radio is part of a modular radio building concept that enables a variety of
installation alternatives that is also easy to expand. Flexible mounting
solutions are provided using rails and pole clamps. The small size of the radio
together with the flexible mounting solutions reduces the site volume. The
lower weight also improves the handling of the radio.
The radio can be connected in a star or cascade configuration using optical
cable links. An optic cable connects the radio to the main unit, or to an
expanded Radio System.
Radio Description
2180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

Legends
Main unit
Ge7612B
Radio
Optical cable
Figure 1 Radio Installations
2.1 Main Features
The following are the main features of the radio:
•Wideband Code Division Multiple Access (WCDMA)
•Long Term Evolution Frequency Division Duplex (LTE FDD)
•Duplex transmitter/receiver (2TX/2RX) branches with 5 W per branch
•Up to 9.8 Gbps CPRI (optical)
•4x4 MIMO by installing two Radio 2203 with external or integrated
directional antenna
Product Overview
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 3

•Complies with 3GPP base station classes Medium Range (MR); relevant
standards are listed in Radio Standards Compliance on page 44.
2.2 Optional Equipment
The optional equipment for the radio is the following:
•External antenna equipment
•Integrated directional antenna
•Omnidirectional antennas
•Rail installation equipment
Radio Description
4180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

3 Technical Data
Note: Table 1 lists regulatory approved configurations. The listed standards
on a specific frequency band may not be generally available on all
markets. Contact the local Ericsson responsible for details.
Table 1 Radio 2203 Technical Data
Description Value
Maximum nominal
output power(1)
2 x 5 W
Number of carriers(1) WCDMA: One to four carriers
LTE: One to three carriers
Mixed mode: Two to five carriers
Frequency(2) 1920–1980 MHz uplink
2110–2170 MHz downlink
B1 for WCDMA and LTE
1850–1910 MHz uplink
1930–1990 MHz downlink
B2(3) for WCDMA and LTE
1710–1785 MHz uplink
1805–1880 MHz downlink
B3 for LTE
1744–1784 MHz uplink
1839–1879 MHz downlink
B3C for WCDMA and LTE
824–849 MHz uplink
869–894 MHz downlink
B5 for WCDMA and LTE
2500–2570 MHz uplink
2620–2690 MHz downlink
B7 for LTE
880–915 MHz uplink
925–960 MHz downlink
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 5

Description Value
B8 for WCDMA and LTE
1850–1915 MHz uplink
1930–1995 MHz downlink
B25(3) for WCDMA and LTE
1710–1780 MHz uplink
2110–2180 MHz downlink
B66A for WCDMA and LTE
Dimensions with Cover, Single Radio
Height 200 mm
Width 200 mm
Depth 100 mm
Dimensions with Cover, Dual Radio
Height 435 mm
Width 200 mm
Depth 105 mm
Dimensions with Antenna, Single Radio
Height 200 mm
Width 200 mm
Depth of Radio 2203 119 mm
Depth of Radio 2203 B5 129 mm
Depth of Radio 2203 B8 129 mm
Dimensions with Antenna, Dual Radio
Height 435 mm
Width 200 mm
Depth of Radio 2203 124 mm
Depth of Radio 2203 B8 134 mm
Weight with Cover, Single Radio
Radio 2203 4.5 kg
Weight with Cover, Dual Radio
Radio 2203 9.4 kg
Weight with Antenna, Single Radio
Radio 2203 4.9 kg
Weight with Antenna, Dual Radio
Radio 2203 9.8 kg
Radio Description
6180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

Description Value
Color
Body NCS S 1002-B
(1) Detailed information about licenses and hardware activations codes (HWAC) can be found
in:
WCDMA: Licenses and Hardware Activation Codes in the WCDMA RAN CPI library.
LTE: Manage Licenses in the Radio Nodes libraries.
(2) Information about Instantaneous Bandwidth (IBW) can be found in RBS Configurations.
(3) B2 and B25 is combined in the same Radio Unit
Ge7602C
200
119
Unit of measurement: mm
200
Figure 2 Radio 2203 Dimensions with Antenna, Single Radio
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 7

Ge7602D
200
129
Unit of measurement: mm
200
Figure 3 Radio 2203 B5 and Radio 2203 B8 Dimensions with Antenna,
Single Radio
Ge7614B
200
100
Unit of measurement: mm
200
Figure 4 Radio 2203 Dimensions with Cover, Single Radio
Radio Description
8180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

Ge11822A
Unit of measurement: mm
435
124
200
Figure 5 Radio 2203 Dimensions with Antenna, Dual Radio
Ge11823A
Unit of measurement: mm
435
134
200
Figure 6 Radio 2203 B8 Dimensions with Antenna, Dual Radio
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 9

Ge11824A
Unit of measurement: mm
435
105
200
Figure 7 Radio 2203 Dimensions with Cover, Dual Radio
Table 2 Antenna Data
Antenna Frequency Band Frequency (MHz)
6502
Directional
B5, B8 791–960
6503
Directional
B1, B2/B25, B3, B3C, B66A 1710–2200
6504
Directional
B7 2300–2690
6507
Omnidirectional
B5, B8
B1, B2/B25, B3, B3C, B7, B66A
791–960
1710–2700
6509 Dual
Omnidirectional
B5, B8
B1, B2/B25, B3, B3C, B7, B66A
791–960
1710–2700
3.1 Installation Recommendations
To ensure reliable operation and maximum performance, an appropriate
installation location must be chosen.
When using the optional integrated directional antenna make sure the radio is
not pointing at any elements that can disturb the radio signals.
Radio Description
10 180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

3.1.1 Indoor Locations to Avoid
Although the unit is designed for outdoor use, it can be used indoors. For
indoor locations Ericsson recommends to operate according to ETSI EN 300
19-1-3 class 3.1, 3.2, 3.3, and 3.6. This does not cover installation with heat
traps or installation in lofts, where air ventilation does not exist. To ensure
smooth performance, avoid installing the unit in a potential microclimate
location, for example, places with unventilated lofts, with heat traps, or where
the product is exposed to direct sunlight through windows. Avoid installing the
equipment under glass covers or skylight windows without proper ventilation.
3.1.2 Outdoor Locations to Avoid
Although Ericsson declares this product suitable for outdoor environments,
avoid installing the unit in a potential microclimate location. Typical examples
of microclimate locations are sites where the product is not only exposed to
the actual surrounding temperature, but additional temperature as heat
coming from dark colored planes, for example, reflections from the floor or
walls. The additional temperature can generate heat traps with temperatures
up to 10°C higher than expected.
Avoid installing equipment in the following locations:
•Near the exhaust of building ventilation systems
•Near the exhaust of chimneys
•Opposite large surfaces made of glass or new concrete
If the unit is to be placed in an environment subjected to lightning strike, an
external Surge Protection Device (SPD) is needed.
3.1.3 Other Considerations
Installing the radio close to other electronic equipment can cause
interferences.
For sites with risk of ground fire, the recommended minimum installation
height is 3 m.
3.1.4 Painting Limitations
Ericsson does not recommend painting the radio as it may affect radio
performance of the unit.
Ericsson will apply limitations to the warranty and service contract if the radio
is painted.
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 11

3.1.4.1 Technical Limitations
If the radio is painted, be aware of the technical limitations below:
•Sunlight on dark paint may increase the temperature of the radio causing
it to shut down.
•The plastic surfaces and the plastic covers are suited for painting with
normal, commercially available one- or two-component paints.
•Never use metallic paint or paint containing metallic particles.
•Ensure that ventilation and drainage holes are free from paint.
•Ensure proper adhesion of the paint.
3.1.4.2 Commercial Limitations
If the radio is painted, the commercial limitations below apply:
•Failure modes directly related to overheating due to painting are not valid
for repair within the scope of the warranty or standard service contract.
•Product failures related to paint contamination of components of the unit
are not valid for repair within the scope of warranty or standard service
contract.
•When a painted unit is repaired, it will be restored to the standard color
before being returned to the market. It is not possible to guarantee the
same unit being sent back to the same place. This is also valid for units
repaired under a service contract.
•For repairs within the warranty period or a standard service contract, the
customer will be charged the additional costs for replacing all painted
parts of the unit or the complete unit.
3.2 Space Requirements
The radio can be installed in one of the following ways:
•Single Radio or Dual Radio on a wall (A)
•Single Radio or Dual Radio on a wall (B) using a tilt installation kit
•Single Radio or Dual Radio on a pole (C)
•Single Radio or Dual Radio on a pole (D) using a tilt installation kit
•Rail installation on a wall (E), Single Radio only
Radio Description
12 180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

•Single Radio or Dual Radio on a ceiling (F), see note below for outdoor
installation
•Single Radio or Dual Radio lying horizontally (G), see note below for
outdoor installation
The installation alternatives described in this section are the primary
installation scenarios for the radio. Flexible installation alternatives are
available for radios installed indoors.
The installation alternatives are shown in Figure 8.
Note: Figure 8 shows a Single Radio, however the installation alternatives
A, B, C, D, F, and G are similar for Dual Radio.
Ge7376I
ED
C
A
FG
B
Figure 8 Installation Method Alternatives
Note: For mounting direction F or G in an outdoor environment the radio
needs to be protected from direct rain.
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 13

3.2.1 Generic Requirements
The radios can be placed directly against each other side by side. To ensure
sufficient working space, allow adequate free space in front of the radio.
3.2.2 Wall Installation
Ge11796A
0
A
50
50
Unit of measurement: mm
Figure 9 Wall Installation, Single Radio
Table 3 Dimension A, when using the Integrated Antenna
Band Combination Dimension A (mm)
B2 + B8 150
B3 + B5 100
B5 + B66A 100
Other 50
If external antenna is used, A = 50 mm for any band combination.
Radio Description
14 180/1551-LZA 701 6001/1 Uen AC | 2017-11-08

Ge11798B
Unit of measurement: mm
200 200
200
Figure 10 Wall Installation, Dual Radio
Ge11821A
50
50
Unit of measurement: mm
0
Figure 11 Wall Installation, Dual Radio (Further Options)
3.2.2.1 Site Layout
To ensure adequate airflow between the units, allow a minimum of 50 mm free
space between the radio and the roof. Depending on band combination and
Technical Data
180/1551-LZA 701 6001/1 Uen AC | 2017-11-08 15

Single Radio or Dual Radio, allow a minimum of 50–200 mm between radios
installed on a wall, on top of one another. Refer to Wall Installation on page
14.
3.2.3 Wall or Pole Installation Using a Tilt Installation Kit
Ge12444A
1 2
A
B
30 °
30 °
Figure 12 Tilt Installation Kit, Single Radio (1) and Dual Radio (2)
Table 4 Tilt Installation Kit, Single Radio (1) and Dual Radio (2)
Description Value A (mm) Value B (mm)
Distance with cover 198 322
Distance with HB
antenna
216 338
Distance with LB
antenna
224 347
Radio Description
16 180/1551-LZA 701 6001/1 Uen AC | 2017-11-08
