Ernitec Mercury W301-S7 IP Demo Camera Quick Guide
This guide is for quick installing and connecting the Mercury W301-S7 IP Dome Camera. For more details, please
refer to the User’s Manual of the camera in the supplied CD.
Camera’s Connectors (
No.
Connector
Pin
Definition
Remarks
1
RJ-45
-
For network and PoE connections
2
Power (DC 12V / AC 24V)
1
AC 24V 1
Power connection
2
AC 24V 2
3
GND
4
DC 12V +
3
BNC
-
For analog video output
4
Alarm & Audio I/O
1
Alarm In –
Alarm connection
2
Alarm In +
3
Alarm Out –
4
Alarm Out +
5
Audio Out R
Audio line out
6
Audio Out L
7
Audio GND
8
Audio In R
Audio line in
9
Audio In L
5
microSD Card Slot
-
Insert the microSD card into the card slot to store videos and
snapshots. Do not remove the microSD card when the camera is
powered on.
6
Default Button
-
Press the button with one finger for at least 20 seconds to restore the
system.
NOTE: It is not recommended to record with the microSD card for 24/7 continuously, as it may not be able to
support long term continuous data read/write. Please contact the manufacturer of the microSD card for
information regarding the reliability and the life expectancy.
Camera Cabling
Please follow the instructions below for cable connections.
Power Connection
Please use a DC 12V / AC 24V power adaptor and plug it to the camera and the power outlet.Alternatively, users can
use an Ethernet cable and connect it to the RJ-45 connector of the camera and a Power Sourcing Equipment (PSE)
switch.
NOTE: If PoE is used, make sure PSE is in used in the network.
Ethernet Cable Connection
Connect one end of the Ethernet cable to the RJ-45 connector of the camera, and plug the other end of the cable to
the network switch or PC.
NOTE: In some cases, Ethernet crossover cable might be needed when connecting the camera directly to the
PC.
NOTE: Check the status of the link indicator and activity indicator LEDs. If the LEDs are unlit, please check
the LAN connection.
Green Link Light indicates good network connection.
OrangeActivity Light flashes for network activity indication.
No.
Connector
Pin
Definition
Remarks
1
Audio I/O
Pink
Audio In
Two-way audio transmission
Green
Audio Out
2
Alarm
(4-Pin Terminal Block)
1
Alarm In –
Blue
2
Alarm In +
Green
3
Alarm Out –
Yellow
4
Alarm Out +
Orange
3
Power (AC 24V)
White
AC 24 1
Power connection
Gray
AC 24 2
4
Power Jack (DC 12V)
-
Power connection
5
BNC
-
For analog video output
6
RJ-45
-
For network and PoE connections
-
Default Button
-
Please refer to Default Button in the table under Camera’s Connectors
Before Login to the Camera
A client program will be automatically installed to the PC when connecting to the camera. Before logging in to the
camera, please ensure downloading the ActiveX control is allowed by either changing the ActiveX controls and
plug-ins or setting Internet’s security level to default. For further details, please refer to the User’s Manual in the
supplied CD.
ActiveX Controls and Plug-ins Settings
Internet Security Level
Step 1: Start the Internet Explorer (IE).
Step 2: Select <Tools> from the main menu of the
browser. Then click on <Internet Options>.
Step 3: Click on the <Security> tab and select
<Internet>, and click on <Custom level> to
change ActiveX settings.
Step 4: Set “ActiveX controls and plug-ins”items to
<Prompt> or <Enable>.
Step 1: Start the Internet Explorer (IE).
Step 2: Select <Tools> from the main menu of the
browser. Then click on <Internet Options>.
Step 3: Click on the <Security> tab and select
<Internet>.
Step 4: Down the page, click <Default Level> and click
on <OK> to confirm the setting. Close the
browser window, and open a new one later for
accessing the IP camera.
Camera Login
The default IP address of the camera is: 192.168.0.250. Therefore, to access the camera for the first time, please set
the IP address of the PC as: 192.168.0.XXX; for example:
IP Address: 192.168.0.100
Subnet Mask: 255.255.255.0
Login ID and Password
Key in the camera’s IP address in the URL bar of the web browser window and hit on “Enter”.
Enter the default username (Admin) and password (1234) in the prompt request dialogue. Note that username is
case sensitive.
Install the ActiveX Control
After connecting to the camera, the request for installing theActiveX control will appear just below the URL bar.
Right click on the information bar, and then click on <Install ActiveX Control…> to permit ActiveX control
installation.

In the pop-up security warning window, click on <Install> to start downloading DC Viewer software on the PC.
Click on <Finish> after DC Viewer installation is completed.
Browser-based Viewer
The main page of the IP camera user interface is shown as the figure below. Please note that function buttons will
vary depending on the camera model.
Ernitec Mercury W301-S7
Quick Guide
Ver. 1.01.042014
