ERNITEC DS-2XM6726G0-IS/ND User manual

Dome Network Camera
Quick Start Guide
COPYRIGHT © 2018 Hikvision. ALL RIGHTS RESERVED

Quick Start Guide
ALL RIGHTS RESERVED
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or whol-
ly, by any means, without the prior written permission of Hikvision.
Unless otherwise stipulated, Hikvision does not make any warran-
ties, guarantees or representations, express or implied, regarding to
the Manual.
About this Manual
This Manual is applicable to Dome Network Camera.
The Manual includes instructions for using and managing the prod-
uct. Pictures, charts, images and all other information hereinafter
are for description and explanation only. The information contained
in the Manual is subject to change, without notice, due to rmware
updates or other reasons. Please nd the latest version in the com-
pany website (http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are
the properties of Hikvision in various jurisdictions. Other trademarks
and logos mentioned below are the properties of their respective
owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL
FAULTS AND ERRORS, AND HIKVISION MAKES NO WARRAN-
TIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITA-
TION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS
FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF
THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS,
OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR
ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT

DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR
LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH
THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE
USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR AB-
NORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAM-
AGES RESULTING FROM CYBER ATTACK, HACKER ATTACK,
VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL
SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE
CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE
USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR
USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL
NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED
WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL
AND THE APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly ap-
proved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC compliance: This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC conditions
This device complies with part 15 of the FCC Rules. Operation is sub-
ject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interfer-
ence that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories
too are marked with "CE" and comply therefore withthe
applicable harmonized European standards listed under
the the EMC Directive 2014/30/EU, the RoHS Directive
2011/65/EU.
2012/19/EU (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted municipal
waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated
collection points. For more information see: www.
recyclethis.info
2006/66/EC and its amendment 2013/56/EU (battery
directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European
Union. See the product documentation for specic battery
information. The battery is marked with this symbol, which
may include lettering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the battery to
your supplier or to a designated collection point. For more
information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards require-
ments.

Safety Instruction
These instructions are intended to ensure that the user can
use the product correctly to avoid danger or property loss.
Laws and Regulations
The device should be used in compliance with local laws,
electrical safety regulations, and re prevention regulations.
Transportation
Keep the device in original or similar packaging while
transporting it.
Power Supply
The input voltage should conform to IEC60950-1 standard:
SELV (Safety Extra Low Voltage) and the Limited Power
Source. Refer to the appropriate documentation for detailed
information.
DO NOT connect multiple devices to one power adapter, to
avoid over-heating or re hazards caused by overload.
Make sure the plug is properly connected to the power
socket.
System Security
The installer and user are responsible for password and
security conguration and its settings.
Battery
Improper use or replacement of the battery may result in
explosion hazard. Replace with the same or equivalent
type only. Dispose of used batteries in conformance with
the local codes.
Maintenance
If the product does not work properly, please contact your
dealer or the nearest service center. We shall not assume
any responsibility for problems caused by unauthorized
repair or maintenance.

A few device components (e.g., electrolytic capacitor)
require regular replacement. The average lifespan varies,
so periodic checking is recommended. Contact your dealer
for details.
Cleaning
Please use a soft and dry cloth when clean inside and
outside surfaces of the product cover. Do not use alkaline
detergents.
Using Environment
When any laser equipment is in use, make sure that the
device lens is not exposed to the laser beam, or it may burn
out.
Do not expose the device to high electromagnetic radiation
or dusty environments.
For indoor-only device, place it in a dry and well-ventilated
environment.
Do not aim the lens at the sun or any other bright light.
Make sure the running environment meets the requirement
of the device. The operating temperature shall be -30 °C to
60 °C (-22 °F to 140 °F), and the operating humidity shall
be 95% or less (no condensing).
Do not place the camera in extremely hot, cold,
dusty or damp locations, and do not expose it to high
electromagnetic radiation.
Emergency
If smoke, odor, or noise arises from the device, immediately
turn off the power, unplug the power cable, and contact the
service center.
Time Synchronization

Set up camera time manually for the rst time access if the
local time is not synchronized with that of the network. Visit
the camera via Web browse/client software and go to time
settings interface.
Installation
Make sure the device is rmly secured to any wall or ceiling
mountings.
Be sure that there is enough space to install the camera
and accessories.
Make sure that the device in the package is in good
condition and all the assembly parts are included.
Make sure that the wall is strong enough to withstand at
least 4 times the weight of the camera and the mount.
The standard power supply is 12 VDC, please make sure
your power supply matches with your camera.
Make sure that the power has been disconnected before
you wire, install, or disassemble the device.
Make sure that no reective surface is too close to the
camera lens. The IR light from the camera may reect back
into the lens causing reection.
For device with this sticker, this device is
intended for installation in a restricted access
location, access can only be gained by service
persons or by users who have been instructed about the
reasons for the restrictions applied to the location and
about any precautions that shall be taken.
Symbols and Marks
Notice

Warning
Forbidden
Correct
Incorrect
Turn to page A and continue.
i. Not necessarily included accessory.
ii. Variable accessory amount.
iii. Skip this step if not required.
MicroSD card
Grounding
Disposal
Purchase separately
Other situations
Other situations omitted

Waterproof
Skip this step if not necessary
