EDGE2: Disassembly Instructions
DISASSEMBLY
EDGE2 Assembled
min
10
APPLIES TO: EDGE2-MS, EDEG2-MAX, EDGE-MAX-DUAL

EDGE2: Disassembly Instructions
DISASSEMBLY
min
EDGE Series Components for breakdown
B
D
C
A: Vesa Plate
- Steel
B: Motion Arm
- Steel
C: Fixed Arm
- Steel
D: Wire Management Channel
- Plastic
E: Adhesive Pad
- Rubber
F: Desk Clamp
- Steel
G: Handle
- Plastic
Material Identification
A
F
G
10
E
Recommended Tools
Gloves Goggles 4mm Allen Wrench
2mm Allen Wrench Phillips Screwdriver
