Eskon EPA 200 User manual

KK-EPA.004 Rev No:0 28.09.18
1
EPA 200
USER
MANUAL
PROCESS CONTROL DEVICE

KK-EPA.004 Rev No:0 28.09.18
2
INDEX
INDEX ................................................................................................................................................................................2
1.TECHNICAL SPECIFICATIONS ..........................................................................................................................................4
2. MECHANICAL DIMENSIONS ..........................................................................................................................................4
3. CONNECTIONS...............................................................................................................................................................5
4. FRONT PANEL IDENTIFICATIONS...................................................................................................................................6
5. MENU TREE...................................................................................................................................................................7
6. SETUP ............................................................................................................................................................................8
6.1 Connecting the Sensor to the Device......................................................................................................................8
6.2.1. Setting the Scale Value..................................................................................................................................9
6.2.2 Setting Factor Value.........................................................................................................................................9
6.2.3 Setting Calibration Method............................................................................................................................10
6.2.4 Start Calibration (START)................................................................................................................................11
6.3. ADJUSTING THE RELAY SET VALUES.....................................................................................................................11
6.3.1. Relay Output Settings ...................................................................................................................................11
6.3.2 Changing Quick Set Values.............................................................................................................................12
6.4. RELAY PROGRAMMING MODE ............................................................................................................................12
6.4.1. Relay Function Selection...............................................................................................................................12
6.4.2 Delay ..............................................................................................................................................................14
6.4.3. Hysteresis......................................................................................................................................................14
6.4.4. Offset Value...................................................................................................................................................15
6.4.5. Default Status Of The Relay (Cond)...............................................................................................................15
6.4.6. Sensor Selection (Snsor)................................................................................................................................16
6.5. ANALOGUE OUTPUT SETTINGS............................................................................................................................16
6.5.1. Analogue Output Type Selection ..................................................................................................................16
6.5.2. Analogue Output ON/OFF.............................................................................................................................17
6.5.3. Inverse Setting ..............................................................................................................................................17
6.5.4. Analogue Output Scale Setting .....................................................................................................................18
6.5.5. Wave Function ..............................................................................................................................................18
6.6. DIGITAL OUTPUT SETTINGS..................................................................................................................................19
6.6.1. UART Settings................................................................................................................................................19
6.6.2. CAN-Open Settings........................................................................................................................................21
6.7. KEY TONE (SOUND) SETTING................................................................................................................................25
6.8. SECURITY (SECURE) MENU...................................................................................................................................25
6.8.1. Hide the Menu (HIDE)...................................................................................................................................25
6.8.2. Lock the Menu (LOCK)...................................................................................................................................26

KK-EPA.004 Rev No:0 28.09.18
3
6.8.3. Password Determination (PASS)...................................................................................................................26
6.8.4. Return to Factory Settings (FTRY) .................................................................................................................26
6.8.5. Restart the Device (RESET)............................................................................................................................27
7. OTHER SETTINGS.........................................................................................................................................................27
7.1. Display Menu .......................................................................................................................................................27
7.1.1. Decimal Point (POINT)...................................................................................................................................27
7.1.2. Tare Function (TARE).....................................................................................................................................28
7.1.2.1. Event ..........................................................................................................................................................28
7.1.2.2. Input...........................................................................................................................................................28
7.1.3. Screen Refresh Rate (REFRS).........................................................................................................................29
7.1.4. Prevention for Screen Flicker (FILTR)...........................................................................................................30
7.1.4.1. AVRGE (Average Calculation):....................................................................................................................30
8. OPERATION MODE FUNCTIONS..................................................................................................................................34
8.1. Tare (Reset ) Fonction......................................................................................................................................34
8.2. Viewing Maximum and Minimum Values which are read...............................................................................34
9. PRODUCT CODING ......................................................................................................................................................35
10. WARRANTY CERTIFICATE ..........................................................................................................................................36

KK-EPA.004 Rev No:0 28.09.18
4
1.TECHNICAL SPECIFICATIONS
2. MECHANICAL DIMENSIONS
Supply Voltage
24 VAC/DC 50/60 Hz
85-265 VAC 50/60 Hz
Power Consumption
9 VA / 2,7 Watt Maximum
Sensor Supply Voltage
Pot:
5 VDC
mV/V:
10 VDC
0-10V:
24 VDC
0-5V:
5 VDC
0,5-4,5V:
5 VDC
4-20 mA:
24 VDC
CANopen:
24 VDC
Max Sensor Supply Current
100 mA
Sampling Rate
3.5 kHz
Input Resolution
16 bit
Thermocouple Resolution
19 bit
RTD Resolution
15 bit
Analogue Inputs
Potentiometer, 0-10 V, 4-20 mA, 0-20 mA, 3,33 mV/V, 2mV/V, 2,5mV/V Ratiometric,
Thermocouple (K, J, N, R, S, T, E and B type), RTD
Relay Outputs
3 pcs 250 VAC 3A (For Resistive Load) Relay
Serial Communication (Optional)
RS-232, RS-485, USB, CANopen
Analogue Outputs (Optional)
0-10 V, 0-5 V, 0.5- 4.5 V, 4-20 mA, 0-20 mA
Analogue Output Resolution
12 bit
Connection
Terminals with 2,5 mm2sockets
Operating Temperature
0 °C … 50 °C
Storage Temperature
-10 °C … 60 °C
Protection Class
IP60 Front Panel, IP20 Back Panel
Dimensions
67 x 67 x 74 mm
Weight
~190 gr
Mounting
It is fixed to the panel with the feet at the top and bottom.
SECTION A-A

KK-EPA.004 Rev No:0 28.09.18
5
1. Relay Output
OUT-1
2. Relay Output
OUT-2
3. Relay Output
OUT-3
Supply Voltage
24 VAC/DC or
85/265 VAC
The following table
shows the pin
numbers.
Digital
Communication
Analogue Outputs
and Tare Input
Sensor Inputs
3. CONNECTIONS
Digital Conn.
12
13
14
RS485
A
B
GND
RS232
Rx
Tx
GND
USB HID
USB B TYPE CONNECTOR
USB VIRTUAL
USB B TYPE CONNECTOR
CANopen
CAN HIGH
CAN LOW
GND
Analogue
Outputs
15
16
17
4-20 mA
Output
GND
4-20 mA
Output
0-10 V
Output
GND
0-10 V
Output
Tare Input
Tare
Input
GND
1
2
3
4
5
6
7
8
9
10
11
24
23
22
21
20
19
18
17
16
15
14
13
12
SENSOR
24
23
22
21
20
19
18
Potentiometer
3. terminal
2. terminal
1. terminal
X
X
4-20 mA Input
GND
Sensor Signal
Sensor Supply
X
X
0-20 mA Input
GND
Sensor Signal
Sensor Supply
X
X
0-10 V Input
GND
Sensor Signal
Sensor Supply
X
X
3,33 mV/V Input
2 mV/V Input
2.5 mV/V Input
GND
X
Sensor Supply
Signal(-)
Signal(+)
Thermocouple
T-
T+
RTD
R-
R+

KK-EPA.004 Rev No:0 28.09.18
6
4. FRONT PANEL IDENTIFICATIONS
SAFETY WARNINGS
1. Always follow the instructions and instructions in the operating instructions before making
the connections and during use.
2. Please check the power supply type before you connect energy to your device.
3. During the operation, be sure to mount it firmly on the panel to be used against falling,
sliding, shaking and shaking.
4. Make sure the sensor connections are not energized in your device, and do not disconnect or
connect the devices while the device is running.
5. Make sure that the cables between the sensor and your device are shielded and free from
high-current energy cables.
6. Do not expose your device directly to a heat source (solar, heater, etc.) in its operating
environment.
7. The EPA200 is an industrial control device which is not suitable for outdoor use; please use
only in room conditions.
8. Wipe with a damp cloth to clean your device, do not use water, alcohol, thinner and
similiar chemicals.
9. Comply with the limit values specified in the technical specifications for relay outputs.
10. The device cannot be changed by the user in the event of a fault, Please contact our
technical service in case of failure.
1) Top Display Line: It has 5 digits and shows the
measured process value.
2) Bottom Display Line: It has 6 digits and shows the relay
setpoint, the temperature measured by the thermocouple
or the ambient temperature.
3)Min Status LED: It lights up when the lowest
(minimum) value has been read since the moment the
device is started.
4) Max Status LED: It lights up when the maximum value
has been read since the moment the device is started.
5) Tare Status LED: It lights up when the Tare function is
active.
1
2
3
5
4
6
7
8
9
6) Set Status LEDs: The LED associated with the active relay lights up.
7) PRG Button: Programming and Enter key. It is used to enter menus or to confirm entered values.
8) ESC Button: Escape, exit and back key. It is used to return to the upper menu or to exit the menu.
9)UP and DOWN Buttons: Navigating through the menus; is used to increase and decrease the value while entering
values, or to move to a lower and higher digit.

KK-EPA.004 Rev No:0 28.09.18
7
5. MENU TREE
Top Menu
Sub Menu
Out - 3
SCALE
LABEL
UNIT
POINT
POINT
TARE
REFRS
Out - 2

KK-EPA.004 Rev No:0 28.09.18
8
6. SETUP
6.1 Connecting the Sensor to the Device
Potentiometer Connection
4…20mA / 0…20mA Connection
*2 wire connection:
Sensor supply terminal must be connected to terminal 22
Sensor signal terminal must be connected to terminal 23
mV/Volt Connection
0…10 Volt Connection
Thermocouple Connection
RTD Connection
Potentiometer Connection
*0-5 V and 0.5-4.5 V connections are made as above.
*K, J, N, R, S, T, E and B type thermocouples can be connected

KK-EPA.004 Rev No:0 28.09.18
9
6.2 Device Calibration
Press and hold to the PRG key to switch to the programming menu.
6.2.1. Setting the Scale Value
Your device is automatically calibrated to the factory settings and operates in the 0-100 range. That is, the
smallest value read on the sensor is 0, and the maximum value is 100 on the display. You can change this
scale on calibration menu. Use the S-LO for the minimum value displayed on the screen and the S-HI option
for the maximum value.
* After you have set the S-LO value, you can do the same for the S-HI value.
6.2.2 Setting Factor Value
You can use the Fctor menu to expand your scale by multiplying it with a fixed factor.The number of this
factor, which is the default value of 1, is multiplied by the values of S-LO and S-HI to determine the scale
value.
For example; When you set the S-LO value to 1, the S-HI value to 20 and make the factor 4, your device will
operate in the range of 4-80 value range.
WARNING: Changing the scale and factor value does not change the calibration of your device, it only
indicates the displayed value range on the screen.
25
25.
2.5
The decimal point
starts flashing. Use
the UP and DOWN
buttons to select the
decimal digits point.
Press and hold the UP button to
move to the next step. To enter a
negative (-) value, move to one of
the non-digit digits and press the
DOWN button.
When you press and hold
to the PRG key, the value
in the second line starts
blinking. Enter the
desired value using the
UP and DOWN buttons.
2.5
The new S-LO value you confirmed with the PRG key has been
set. Press UP button to move to S-HI.
OUT
S-LO.
0
Cal I b
SCALE
Press and hold the PRG button.

KK-EPA.004 Rev No:0 28.09.18
10
6.2.3 Setting Calibration Method
Your device has been calibrated during production. If you want, you can do this calibration according to
your sensor. To do that you should select the calibration method on this menu.
6.2.3.1 Factory calibration (default)
The default calibration on your device. The multipoint calibration or the two pointed calibration that you
have made to your device does not disturb the factory calibration.
6.2.3.2 Two-point calibration
By two-point calibration option, only the maximum and minimum points are selected. For example; While
you are calibrating a 10 cm linear potentiometer, the minimum point is identified when the potentiometer
is in the fully closed position and the maximum point is identified when the potentiometer is in the fully
open position.
* After you set the CAL-L value, you can do the same for the CAL-H value.
6.2.3.3 Multiple (segmented) Calibration
With the multiple calibration option, you can calibrate your device at up to 10 different points. This
method increases the linearity of the sensor.
For example; If the length of the sensor is 40 cm and you want to calibrate at 5 different points, these
points are; There may be 0. cm, 10. cm, 20 cm, 30 cm when sensor starts and 40 cm points where the
sensor ends. These points can be set anywhere in the scale range. We recommend you to choose by equal
intervals for a more suitable linearity.
6.2.3.4. Determining the Number of Calibrations (CL.CNT)
If you select the multi-segmented calibration option, in this menu that appears, you can specify the
number of points you want to calibrate the device. It's a maximum of 10.
FCAL
2_Pnt.
SEGnt.
Factory calibration (Default)
CL.Cnt.
3
3
When the PRG button is pressed and entered into the menu, the second line starts blinking. Enter the desired value using
the UP and DOWN buttons and confirm by pressing the PRG button again.
START
CAL-L
XXX
.donE.
Multiple (Segmented )
Calibration
2 pointed calibration
CL.Cnt.
10
10

KK-EPA.004 Rev No:0 28.09.18
11
6.2.4 Start Calibration (START)
After selecting the number of calibration, press the button to access the start menu.
Error Message:
6.3. ADJUSTING THE RELAY SET VALUES
Your device has tree relays in total with two contacts, normally open and normally closed. You can use the
relay contacts in five different functions according to your needs. These functions are described by 6.4.1
6.3.1. Relay Output Settings
Set the SET values in which the relay outputs of your device will be activated.
For SET 1 value;
This error message can only be seen on devices with 4-20mA and 0.5-4.5V inputs.
Meaning; The sensor is not connected to the device or the sensor is defective.
OUT
25
30
30.
0.30
The decimal point
starts blinking. Use the
UP and DOWN buttons
to select the decimal
digit point.
Press and hold the UP button to move to the next
step.To enter a negative (-) value, move to one of
the non-digit digits and press the DOWN button.
When you press and
hold to the PRG key ,
the value in the
second line starts
blinking. Enter the
desired value using
the UP and DOWN
buttons.
The new SET-1 value you confirmed with the PRG button has
been set. You can return to run mode with the ESC button.
* You can also set other relay outputs in the same way.
START
SEG. 1
XXX
. . .
This process is
repeated for
each segment.
.DONE.
Press and hold the PRG button.
SET - 1
0.30
OUT - 1
SET - 1
25
Sn. err

KK-EPA.004 Rev No:0 28.09.18
12
6.3.2 Changing Quick Set Values
You can quickly change the adjustable relay set values when the device is in operation mode.
6.4. RELAY PROGRAMMING MODE
6.4.1. Relay Function Selection
This function selection determines when the relay output will switch on and switch off according to the set
values.
Relay Function Options:
* You can set the functions for other relay outputs in the same way.
SET - 1
0.25
25
Press and hold
the ESC button.
When you press and hold to the PRG key , the
value in the second line starts blinking. Enter
the desired value using the UP and DOWN
Press and hold the UP button
to move to the next step.To
enter a negative (-) value,
move to one of the non-digit
digits and press the DOWN
button.
The decimal digit point starts
blinking. Use the UP and
DOWN buttons to select the
decimal digit point.
25.
0.25
The new SET-1 value you confirmed with
the PRG button has been set. You can
return to run mode with the ESC button.
* You can set the quick set values for other relay outputs in the same way.
SET - 1
20
OFF
The relay does not switch off in any way.
20
Stand.
off
The new function you confirmed with the
PRG button has been set. You can return to
run mode with the ESC button.
Press and hold the PRG button.
.
Funct.
off
OUT - 1
OUT
Other function options can be changed by pressing
UP or DOWN buttons. Function options and
descriptions are shown below.
Funct.
Stand.

KK-EPA.004 Rev No:0 28.09.18
13
STAND.
When the value read in the device reaches or exceeds Set-1,
the relay pulls.
BAND
When the value read on the device is between Set-1A and
Set-1B value, relay pulls.
CATCH
The value read on the device remains set to the value of Set-1
by increasing or decreasing the value of the relay each time it
is released for the time which is entered.
DUAL
When the value read in the instrument is increased or
decreased with the value of Set-1A or Set-1B, the relay remains
drawn up for the time entered.
PER DC.
When the value read in the device is increased or decreases
with the value of Set-1 or the value of Set-1 in every floor
such as 2,3,4,5 ..., the relay remains drawn for the time
entered.

KK-EPA.004 Rev No:0 28.09.18
14
6.4.2 Delay
The relay specifies in seconds how long it will active and inactive after it is switched off. If '0' is entered as a
zero value in the Stand function, the relay will remain drawn unless the relay output condition changes.
6.4.3. Hysteresis
Due to the unstability in decimal value read on the connected sensor, you can enter the hysteresis value to
prevent the relay from being turned on and off at any time, so that the set value you set for the relay will
be activated and inactivated as low as Hysdn and above Hysup.
0
20
The new delay value you confirmed with the
PRG button has been set. You can return to
run mode with the ESC button.
Press and hold the PRG button.
delay
20
OUT - 1
OUT
delay
0
When you press and hold
to the PRG key , the value
in the second line starts
blinking. Enter the desired
value using the UP and
DOWN
OUT
0
30
30.
30
The decimal point starts
blinking. Use the UP and DOWN
buttons to select the decimal
digit point.
Press and hold the UP button to move to the
next step.To enter a negative (-) value, move
to one of the non-digit digits and press the
DOWN button.
When you press
and hold to the PRG
key , the value in
the second line
starts blinking.
Enter the desired
value using the UP
and DOWN
.
Press and hold the PRG button.
OUT - 1
Hysup/hysdn
0
hysup
30
The new hysteresis value you confirmed with the PRG button
has been set. You can return to run mode with the ESC button.
* You can also set other relay outputs in the same way.
* You can also set other relay outputs in the same way.
bağlantıları:

KK-EPA.004 Rev No:0 28.09.18
15
6.4.4. Offset Value
If you want to add offset to the entered set value, this menu is used. All set values are, as much as ofset
value is shifted forward and if it is selected negative then it is shifted backwards .
6.4.5. Default Status Of The Relay (Cond)
Depending on the factory settings of your device, the relay is normally off, so you can change it as normally
open. Use the Cond option to do this. The factory setting NC (Normally Closed) indicates that the relay is
normally closed, NO. (Normally Open) indicates that the relay is normally open.
OUT
0
30
30.
30
The decimal point starts
flashing. Use the UP and DOWN
buttons to select the decimal
digit point.
Press and hold the UP button to move to the
next step.To enter a negative (-) value, move
to one of the non-digit digits and press the
DOWN button.
When you press and
hold to the PRG key ,
the value in the
second line starts
blinking. Enter the
desired value using
the UP and DOWN
* You can also set other relay outputs in the same way.
bağlantıları:
Press and hold the PRG button.
OUT - 1
OFSET
30
The new offset value you confirmed with the PRG button has
been set. You can return to run mode with the ESC button.
ofset
0
OUT
nc
no
When you press and hold
to the PRG key , the
value in the second line
starts blinking. Enter the
desired value using the
UP and DOWN
Press and hold the PRG button.
OUT - 1
cond
no
The new relay condition you confirmed with the PRG button has
been set. You can return to run mode with the ESC button.
cond
nc
* You can also set other relay outputs in the same way.
bağlantıları:

KK-EPA.004 Rev No:0 28.09.18
16
6.4.6. Sensor Selection (Snsor)
Assignment can be done to the selected relay for the sensor types shown below.
Sensor Type:
6.5. ANALOGUE OUTPUT SETTINGS
If your EPA 200, which is specially manufactured according to your order, has analogue output module, you
can make the necessary settings on this menu.
6.5.1. Analogue Output Type Selection
Under the Type menu, any of the following analogue output types can be selected.
DEFAULT
When the relay output is wanted to be activated for sensor input, the
"DEFAULT" should be selected.
TEMP.
When the relay output is wanted to be activated for Thermocouple or RTD
input, the "TEMP" should be selected.
CAN.dt 1
When the relay output is wanted to be activated for CAN-Open
communucation connection through data-1, the "CAN.dt1" should be
selected.
CAN.dt 2
When the relay output is wanted to be activated for CAN_Open
communucation connection through data-2, the "CAN.dt2" should be
selected.
OUT
dfault
temp
When you press
and hold to the
PRG key , the value
in the second line
starts blinking.
Enter the desired
value using the UP
and DOWN
buttons. Sensor
types that can be
selected and
descriptions are
shown below.
Press and hold the PRG button.
OUT - 1
snsor
temp
The new sensor type you confirmed with the
PRG button has been set. You can return to
run mode with the ESC button.
snsor
dfault
* You can also set other relay outputs in the same way.
bağlantıları:
OUT
0-10V
4-20ma
When you press and
hold to the PRG key ,
the value in the
second line starts
blinking. Enter the
desired value using
the UP and DOWN
buttons. Output
types that can be
selected are shown
below.
Press and hold the PRG button.
anlog
type
4-20ma
The new output type you confirmed with the PRG button has
been set. You can return to run mode with the ESC button.
type
0-10V

KK-EPA.004 Rev No:0 28.09.18
17
Analogue Output Types:
6.5.2. Analogue Output ON/OFF
6.5.3. Inverse Setting
0-10V
4-20mA
0-5V
0.5-4.5V
0-20mA
“ON”is used to turn on the analogue output and “OFF”is used to turn it off.
You can choose in which direction the value to be read on the analogue output increases or decreases
according to the sensor. This option, which is OFF according to the factory default settings, provides an
analogue output that increases or decreases in proportion to the value which is read at the sensor. If you
turn this ON, while the value which is read out at the sensor is increasing, the value at the analogue
output will decrease, ie an inversely proportional output will be provided.
OUT
on
off
When you press and
hold to the PRG key ,
the value in the
second line starts
blinking. Enter the
desired value using
the UP and DOWN
buttons.
Press and hold the PRG button.
anlog
cond
off
The new output condition you confirmed
with the PRG button has been set. You can
return to run mode with the ESC button.
cond
on
OUT
off
ON
When you press and
hold to the PRG key
the value in the
second line starts
blinking. You can
turn ON or OFF
using the DOWN
and UP buttons.
Press and hold the PRG button.
anlog
Invrs
oN
The new inverse condition you confirmed
with the PRG button has been set. You can
return to run mode with the ESC button.
Invrs
off

KK-EPA.004 Rev No:0 28.09.18
18
6.5.4. Analogue Output Scale Setting
On the device with the analogue output feature, to set the output signal to the desired scale range, SCALE
mode on this menu must be ON. Then S-LO. and S-HI. values can be entered.
6.5.5. Wave Function
On this menu, you can find the linear standard waveform which is in the factory setting ; you can set as
the sine, cosine or triangular format.
Press the PRG button after selecting
ON with the direction buttons
When you press
and hold to the PRG
key the value in the
second line starts
blinking. Enter the
desired value using
the UP and DOWN
buttons.
Press and hold the UP button to move
to the next step.To enter a negative (-)
value, move to one of the non-digit
digits and press the DOWN button.
The decimal point starts flashing. Use the UP
and DOWN buttons to select the decimal digit
point.
S-LO.
0.20
The new S-LO
value you
confirmed with
the PRG button
has been set. You
can return to run
mode with the
ESC button.
* After you have set the S-LO value, you can do the same for the S-HI value.
SCALE
ON
SCALE
ON/OFF
S- LO.
0
20
20.
0.20
OUT
LINER
SIN.
When you press and
hold to the PRG key
the value in the
second line starts
blinking. Select the
desired wave form
using the UP and
DOWN buttons.
Press and hold the PRG button.
anlog
Vave.f.
SIN.
The new wave form you confirmed with
the PRG button has been set. You can
return to run mode with the ESC button.
Vave.f.
LINER
0

KK-EPA.004 Rev No:0 28.09.18
19
6.6. DIGITAL OUTPUT SETTINGS
WARNING: After changing the UART or CANopen settings, you should restart the device to make the
changes to take effect.
If your device has a USB port, use MyPanelMeter, which you can download from our website to check your
device. Check the user manual of the program.
6.6.1. UART Settings
If you are communicating with your device via RS-485 or RS-232; You can make the necessary settings
here. You can select the communication protocol, baudrate, parity, address and period information. For
the MODBUS Protocol address information, see the relevant booklet.
6.6.1.1. Protocol Settings
6.6.1.2. Baudrate Setting
OUT
ascII
When you press and hold to the PRG key the value in the second
line starts blinking. You can select one of ASCII, Modbus RTU
veya Modbus ASCII protocols using the UP and DOWN buttons.
Press and hold the PRG button.
dgtal
prtcl
MB.RTU
.
The new communucation protocol you confirmed with the PRG
button has been set. You can return to run mode with the ESC
button.
uart
prtcl
ascII
Mb.rtu
OUT
9600
When you press and hold to the PRG key the value in
the second line starts blinking. Select the desired
baudrate using the UP and DOWN buttons.
Press and hold the PRG button.
dgtal
baud
19200
The new baudrate you confirmed with the PRG button has
been set. You can return to run mode with the ESC button.
uart
baud
9600
19200

KK-EPA.004 Rev No:0 28.09.18
20
6.6.1.3. Parity Setting
6.6.1.4. Address Setting
OUT
none
When you press and hold to the PRG key the value in the second
line starts blinking. You can select NONE, ODD or EVEN parity
using the UP and DOWN buttons.
Press and hold the PRG button.
dgtal
prITY
even
The new parity type you confirmed with the PRG button has been
set. You can return to run mode with the ESC button.
uart
prITY
none
even
OUT
1
When you press and hold to the PRG key the value in the second
line starts blinking. Enter the desired address value using the UP
and DOWN buttons.
dgtal
adres
2
The new address value you confirmed with the PRG button has
been set. You can return to run mode with the ESC button.
uart
adres
1
2
Press and hold the PRG button.
