OWNER’S MANUAL
KENDALL DINING CHAIRS
Caution: Read owner's manual completely before assembly and use.
Product code: 0-08612933-5
UPC code: 729437125109
Date of purchase: / /

1
1. Use the long end of the Allen wrench to fasten Allen bolts loosely and quickly.
2. Use the short end of the Allen wrench for final tightening.
1. Chair-maximum load weight per chair is 300 pounds.
1. Please read the assembly instructions prior to assembling this product.
2. To avoid damage, assemble this product on a non-abrasive surface such as carpet.
3. Make sure all bolts, nuts, and screws are tightly fastened before the product is used.
4. Not for commercial use.
5. Care: Wipe with a damp cloth. Use furniture polish or lemon oil on the wood as needed.
Avoid prolonged exposure to moisture.
12
! WARNING: After a few days of initial assembly and chairs have acclimated
to their new environment, retighten all hardware. Periodically
check and retighten the screws every few months.
Please make sure you have all parts before beginning assembly. Please wait until all steps are
completed before tightening bolts, nuts, and screws. We recommend using two people for
assembly.
G E N E R A L I N F O R M AT I O N & T I P S
M A X I M U M R E C O M M E N D E D W E I G H T C A P A C I T Y
C U S T O M E R S E R V I C E I N F O R M AT I O N
Ying Fu Enterprise Co., Ltd..
EMAIL: [email protected]
FAX: [phone]
8:30 am to 5:00 pm CST, Mon. thru Fri.

2
A. Chair Back B. Seat Frame C. Chair Seat
QTY: 2 pcs QTY: 2 pcs QTY: 2 pcs
D. Chair Leg
QTY: 4 pcs
PA R T S L I S T

3
1. Flat Washer 2. Spring Washer 3. Wood Screw
QTY: 20 pcs QTY: 20 pcs QTY: 8 pcs
4. Long Bolt 5. Medium Bolt 6. Short Bolt
Dia 1/4 x 3 inch L Dia 1/4 x 2-1/2 inch L Dia 1/4 x 1-1/2 inch L
QTY: 8 pcs QTY: 8 pc QTY: 4 pc
7. Allen Wrench
QTY: 1 pc
H A R D W A R E L I S T

4
Diagram #1
A S S E M B LY I N S T R U C T I O N S
Step 1
1. Attach Seat Frame (B) to Chair Back (A) using Short Bolt (6), Spring Washer (2) and
Flat Washer (1) as shown in inset (a); using Long Bolt (4), Spring Washer (2) and Flat
Washer (1) as shown in inset (b). Do not tighten the bolts at this step.
A
A
A
B
B
B
7
6
2
1
74
2
1
a
b

5
Diagram #2
A S S E M B LY I N S T R U C T I O N S
Step 2
2. Attach Front Legs (D) to the assembled unit from Step 1, using Medium bolt (5),
Spring Washer (2) and Flat Washer (1) as shown in inset (a). Do not tighten the bolts
at this step.
3. Turn the chair upright. Make sure the assembled chair is level and square. Tightly
fasten all bolts with the Allen Wrench (7).
a
D
D
B
B
A
1
2
5

6
Diagram #3
A S S E M B LY I N S T R U C T I O N S
a
3
C
C
Step 3
4. Place Chair Seat (C) upside down on a non-abrasive table surface. The rear (tapered
end) on the Seat Frame (B) should be near the table edge.
Hint: Protect the non-abrasive table surface and Chair Seat (C) by laying a
towel in-between the chair seat and table.
5. Place the assembled Chair Frame on the Chair Seat (C) as shown. Attach with Wood
Screw (3) as shown in inset (a) with Phillips head screwdriver (not provided).
6. Turn the chair upright. The chair is ready for use.
7. Repeat all the steps to assemble another chair.

7
Please refer to part numbers when reordering
For questions or comments about product:
Email: [email protected]
Made in / Hecho en VIETNAM. Distributed by Kmart Corporation, Hoffman Estates, IL 60179
