eSSL ThermoAccess-9 User manual
User Manual
ThermoAccess-9
Basic specifications:
Sensor
WTTS001
Display
Infrared LED
Accurate
±0.2℃
Measuring time
<0.5s
Working voltage
5V ~ 12V input
Working ambient temperature:
5℃~44℃
Measuring distance:
5~10cm
Temp measurement range:
35℃~42.9℃
Internal relay
Yes
Wiegand input/output
Yes
Alarm
Yes(external available)
Certificates
CE/FCC
Size
130*90*53mm
Weight
240g
Package
Neutral packaging
Installation
Wall mounted
Settings:
You are suggested to set to a new password before using the this device with administrator
function
Administrator function: Long pressing key “M” for 6 seconds, displaying default password “0000”,
Press Key “M” again to set the new passwords. Key “+/-“ is for Increasing and decreasing
the value, key “M” is for positioning (notes: please make sure to remember the new
passwords)
Infrared Thermometer Access Control
ThermoAccess-9
1. Alarm temperature setting: Press key “M” one time, the display will show 1. 37.5, meaning
the default high temperature value is 37.5℃, press key “+/-“ to adjust the target high
temperature
2. Te mp era ture c ompens at i on va lu e setting: Press key “M” twice, the display will show 2. 0.0,
press key “+/-“ to adjust the value (adjust value unit is 0.1℃)
3. Alarm switch off setting: Press key “M” three time, the display will show 3. ON, press key
“+/-“ to switch off or switch on the alarm
4. Interval time setting: Press key “M” the fourth time, the display will show 4. 5, key “+/-“ to
adjust value of interval time (interval time available between 3s ~ 90s)
5. Passwords change setting: Press key “M” the fifth time, the display will show 5 PC, key
“+/-“ to adjust value of passwords, Key “+/-“ is for Increasing and decreasing the value, key
“M” is for positioning (notes: please make sure to remember the new passwords)
6. Exit setting: Press key “M” the sixth time to exit the setting
IM3 Access control connection Sketch Map
IM3 connection diagram
Connection descriptions:
Connection A:
1. GND: GND input
2. D2 OUT：wiegand output
3. D2 IN：wiegand input
4. GND：GND input
5. DI OUT：wiegand output
6. D1 IN: wiegand input
Connection B:
1. NO IN：Relay input
2. NO OUT：Relay output
3. GND：GND input
4. +12V：12V power input
Connection C:
1. BELL+: Alarm + 12V output
2. BELL-: Alarm - GND output
