ETC VORA User manual

LifeWorkEtc.com
800-634-9514
STEP 01
VORA A S S E M B LY
PLACE SEAT ASSEMBLY UPSIDE DOWN ON AN
ELEVATED FLAT SURFACE. POSITION SWIVEL TILT
CONTROL MECHANISM ON BOTTOM SIDE OF
SEAT ASSEMBLY TO MATCH THE INSIDE 4-HOLE
CONFIGURATION.
NOTE: THE SWIVEL TILT CONTROL ADJUSTMENT
KNOB IS TO BE POSITIONED TOWARD THE FRONT OF
THE SEAT. THE FRONT OF THE SEAT IS IDENTIFIED
BY THE FRONT ASSET LABEL. USING THE 5MM HEX
KEY WRENCH, SECURE THE SWIVEL TILT CONTROL
MECHANISM TO THE SEAT ASSEMBLY USING FOUR
5/16-18 X 1" HEX HEAD BOLTS.
FRONT
OF SE AT
STEP 02
POSITION THE RIGHT AND LEFT ARM ASSEMBLIES
ON THE BOTTOM OF THE SEAT AS SHOWN.
NOTE: TO ASSURE PROPER ASSEMBLY OF THE
RIGHT AND LEFT ARMS, EACH ARM SHOULD ANGLE
TOWARD THE FRONT OF THE SEAT, NOT REARWARD.
USING THE 5MM HEX KEY WRENCH, SECURE EACH
ARM WITH THREE 5/16-18 X 1 1/4" TRUSS HEAD BOLTS.
FRONT
OF SE AT

LifeWorkEtc.com
800-634-9514
VORA A S S E M B LY
POSITION THE BACK ASSEMBLY TO THE
CORRESPONDING HOLE CONFIGURATION
ON THE BACK BOTTOM OF THE SEAT
ASSEMBLY. USING THE 5MM HEX KEY
WRENCH, SECURE THE BACK ASSEMBLY
WITH FOUR 5/16-18 X 1 1/4" HEX HEAD BOLTS.
STEP 04
INSERT 5 CASTERS INTO THE PLASTIC BASE.
STEP 03

LifeWorkEtc.com
800-634-9514
VORA A S S E M B LY
ORIENT THE GAS LIFT CYLINDER AS
SHOWN AND INSERT THE LARGER END
OF THE CYLINDER INTO THE HOLE IN
THE CENTER OF THE BASE.
STEP 06
CAREFULLY POSITION THE SEAT ASSEMBLY
OVER THE GAS LIFT CYLINDER, ALIGNING THE
HOLE IN THE SEAT CONTROL WITH THE TOP,
SMALLER END OF THE CYLINDER. PRESS THE
SEAT ASSEMBLY ONTO THE CYLINDER THEN
SIT ON THE SEAT TO COMPLETELY MATE THE
COMPONENTS TOGETHER. WHILE SEATED,
ACTUATE HEIGHT CONTROL LEVER AND
REMOVE WEIGHT FROM CHAIR TO ADJUST
CHAIR UP TO COMFORTABLE SITTING HEIGHT.
STEP 05
