Introduction
The Source 4WRD Color is a replacement for a standard Source Four
burner assembly. It converts the HPL source to an RGBA (red, green, blue,
and amber) LED and provides a significant reduction in power
consumption. The Source 4WRD Color uses DMX dimming and requires
power from a non-dimmable source. When not using DMX, you can use
any of the 12presets or 5sequences on the Source 4WRD Color.
The Source 4WRD Color can also be used with the Source 4WRD PAR or
PARNel Fixture Body to create a Source 4WRD Color PAR or PARNel
fixture. For best results, we recommend that you use the included
diffusion on the Source 4WRD PAR or PARNel Fixture Body when paired
with the Source 4WRD Color. For more information, see the Source 4WRD
Color PAR and PARNel datasheet at etcconnect.com.
Retrofit kit,
shown installed
on a Source Four
fixture body
Note: The Source 4WRD Color retrofit kit is not compatible with
Source Four LED, Fresnel, PAR, PARNel, or jr fixtures.

2 Source 4WRD Color Installation and User Manual
Help from ETC Technical Services
If you are having difficulties and your problem is not addressed by this
document, try the ETC support website at support.etcconnect.com or the
main ETC website at etcconnect.com. If none of these resources are
sufficient, contact ETC Technical Services directly at one of the offices
identified below. Emergency service is available from all ETC offices
outside of normal business hours.
When calling for help, take these steps first:
•
Prepare a detailed description of the problem
•
Go near the equipment for troubleshooting
•
Find your notification number if you have called in previously
Americas United Kingdom
ETC, Inc. ETC Ltd
Technical Services Department Technical Services Department
3031 Pleasant View Road 26-28 Victoria Industrial Estate
Middleton, WI 53562 Victoria Road,
800-775-4382 (USA, toll-free) London W3 6UU England
[phone] [phone]
[e-mail] [e-mail]
Asia Germany
ETCAsia ETC GmbH
Technical Services Department Technical Services Department
Room 1801, 18/F Ohmstrasse 3
Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany
9 Sheung Yuet Road [phone]
Kowloon Bay, Kowloon, Hong Kong [e-mail]
[phone]
[e-mail]
France
ETC France
Zone Urbaparc -
Bâtiment E
6 Boulevard de la Libération
Saint-Denis, 93200
[phone]
[e-mail]

Source 4WRD Color Installation and User Manual 3
Safety
The Source 4WRD Color fixture is intended for professional use only.
Read the entire manual before using this equipment.
WARNING: Note the following safety warnings before use:
•
Do not mount the fixture on or near a flammable
surface.
•
Do not use this fixture with a damaged power lead. If
the power lead (cord set) is damaged, it must be
replaced.
•
Mount and support the fixture only by the primary
suspension holes in the yoke.
•
Suspend the fixture from a suitable structure using only
hardware rated for the weight of the fixture.
•
In addition to primary suspension, attach a safety cable
to the fixture housing. An appropriate attachment point
(hole) is provided in the protruding tab on the fixture
housing.
•
Disconnect the unit from power and DMX and allow the
fixture to cool before removing or installing accessories,
and before all cleaning and maintenance.

4 Source 4WRD Color Installation and User Manual
AVERTISSEMENT : Prendre connaissance des avertissements
de sécurité suivants avant toute utilisation :
•
Ne pas installer le projecteur sur ou à côté d’une surface
inflammable.
•
Ne pas utiliser ce projecteur avec un cordon
d’alimentation endommagé. Si le cordon d’alimentation
(câble) est abîmé, il doit être remplacé.
•
Installer et accrocher le projecteur uniquement par les
trous de fixation principaux de la lyre.
•
Accrocher le projecteur à une structure convenable en
utilisant seulement du matériel adapté au poids du
projecteur.
•
En plus de l'accroche principale, fixer une élingue de
sécurité (modèle ETC400SC ou autre câble/dispositif de
sécurité certifié) au corps du projecteur. Un point
d’accroche (trou) approprié est prévu dans la patte qui
ressort du boîtier du projecteur.
•
Déconnecter l’alimentation et le DMX et laisser le
projecteur refroidir avant d’enlever ou installer
l'optique découpe ou les autres adaptateurs, et avant
tout nettoyage et entretien.
WARNING: Note the following safety warnings before use:
•
The Source 4WRD Color is not user serviceable. Field
modification of the Source 4WRD Color will void your
ETC warranty.
•
Do not use the fixture below 5°C (41°F).
•
Minimum storage temperature is 5°C (41°F). When the
fixture has been stored or transported in cold
temperatures, allow it to warm to room temperature
for a minimum of 1hour before applying power.
Applying power to a cold fixture will cause damage to
the fixture and void the ETCwarranty.
•
Do not use this fixture if a glass lens is deeply scratched
or cracked. Damaged lenses must be replaced.
•
To prevent wiring damage, or abrasion, do not expose
wiring to edges of sheet metal or other sharp objects.
•
Use the fixture in dry locations only, where humidity
does not exceed 90 percent (non-condensing). These
fixtures are not intended for outdoor use.

Source 4WRD Color Installation and User Manual 5
Retrofit the Fixture
WARNING: RISK OF FIRE OR ELECTRIC SHOCK! Installing the
Source 4WRD Color retrofit kit requires knowledge of
luminaire electrical systems. If you are not qualified, do not
attempt installation. Contact a qualified electrician.
AVERTISSEMENT : RISQUE D'INCENDIE OU DE DÉCHARGE
ÉLECTRIQUE! Installer le nécessaire de conversion Source
4WRD Color nécessite une connaissance des systèmes
électriques de projecteurs. Si vous n’êtes pas qualifié, ne
tentez pas l’installation. Faire appel à un électricien qualifié.
Note: THE RETROFIT KIT IS ACCEPTABLE AS A COMPONENT OF A
LUMINAIRE WHERE THE SUITABILITY OF THE COMBINATION SHALL
BE DETERMINED BY AUTHORITIES HAVING JURISDICTION.
Retrofit kit
LEDs
RJ45 data in
and data thru
User interface and
navigation buttons
Wire the Power Connector(If Needed)
If you ordered a Source 4WRD Color retrofit without a power connector,
wire the connector in accordance with all national and local electrical
codes:
•
Brown = Live
•
White (heat shrink on blue wire) = Neutral
•
Green/Yellow = Protective earth

6 Source 4WRD Color Installation and User Manual
Remove Incandescent Lamp Housing
1. Unplug the Source Four incandescent fixture and place it on a flat,
stable surface.
2. Loosen the brass thumb screw located above the beam adjustment
knob. The lamp housing is now loose.
3. Remove the lamp housing from the fixture body.
Note: The burner assembly is no longer needed. If you would like
ETC to recycle the burner assembly, contact ETC Technical Services
for more information. See Help from ETC Technical Services on
page2.
Install the Source 4WRD Color Retrofit
WARNING: RISK OF FIRE OR ELECTRIC SHOCK! Install this kit
only onto luminaires that have the construction features and
dimensions shown in the images in this document and where
the input rating of the retrofit kit does not exceed the input
rating of the luminaire.
AVERTISSEMENT : RISQUE D'INCENDIE OU DE DÉCHARGE
ÉLECTRIQUE! N’installer ce kit que sur les projecteurs qui ont
les caractéristiques de construction et les dimensions
indiquées sur les images de ce document et où la puissance
électrique nécessaire à la conversion n’excède pas la puissance
maximale du projecteur.
WARNING: Do not make or alter any open holes in an
enclosure of wiring or electrical components during kit
installation.

Source 4WRD Color Installation and User Manual 7
CAUTION: Do not touch or clean LED emitters with anything
other than oil-free canned air.
Tools required:
•
Adjustable wrench
•
#2 Phillips screwdriver
1. Use oil-free canned air to clean the LED emitters before you install
the retrofit. Do not touch the LEDemitters.
2. With the fixture resting securely on a flat surface, attach the
supplied threaded post to the back end of the fixture body. Use an
adjustable wrench to tighten the threaded post one-quarter turn
past finger tight.
3. Gently slide the Source 4WRD Color onto the fixture body and
threaded post while guiding the LED tower into the lamp housing
hole, as shown in the following image. Take care to prevent contact
between the LEDs and the reflector.
Insert threaded
post here
Tighten
screw
Z-adjustment
knob
Source Four
fixture body
Lamp
housing
hole
4. Use a #2 Phillips screwdriver to tighten the screw located on the
back end of the Source 4WRD Color, directly above the
Z-adjustment knob.
5. Pull gently to verify secure attachment.
6. Set the Z-adjustment using the Z-adjustment knob. See Set the Z-
adjustment on page15 .

8 Source 4WRD Color Installation and User Manual
Install Diffusion on Reflector
When you use the Source 4WRD Color with a Source Four fixture body,
you must install the diffusion provided with the Source 4WRD Color on
the output end of the reflector.
WARNING: Do not use the diffusion with a Source Four HPL
lamp. Using the diffusion with a Source Four HPL lamp can
result in damage to the diffusion and the fixture body.
1.
Fold corners x4
Shiny side
facing up
With the shiny side of the diffusion
facing up, fold the four tabbed
corners of the diffusion along the
perforated lines.
2. Remove the lens tube and shutter
barrel from the fixture in order to
access the reflector housing.
a. Remove the beam focus knob at the bottom of the shutter
barrel and remove the retaining bolt on the opposite side of
the shutter barrel. Slide the lens tube out of the shutter barrel.
b. Loosen the barrel rotation knob at the bottom of the reflector
housing and loosen the retaining bolt on the opposite side of
the reflector housing. Rotate the shutter barrel and remove it
from the reflector housing.
Beam
focus
knob
Barrel
rotation
knob
Retaining
bolts Reflector
housing

Source 4WRD Color Installation and User Manual 9
Insert
diffusion
Shiny side
facing out
3. Insert the diffusion into the
reflector housing with the dull
side of the diffusion facing the
lamp and the shiny side facing
out.
4. Ensure that the tabbed corners
are snug under the reflector
bracket wings.
Tabbed corner fits
under reflector
bracket wings
5. Replace and secure the shutter barrel and lens tube.

10 Source 4WRD Color Installation and User Manual
Install the Fixture
Retrofit
Source Four lens tube
(not included)
Adjustable yoke
Shutters (x4) Attached power lead
Cat5 cable
strain relief
Yoke locking knob
Attach C-clamp and Safety Cable
The C-clamp attaches the fixture to the mounting pipe and allows you to
adjust the position of the mounted fixture. ETC recommends using 1.5in
schedule 40 pipe.
1. Tightly fasten the C-clamp to the yoke with the provided yoke bolt
and lock washer.
2. Place the C-clamp on mounting pipe, and then tighten the pipe
bolt to secure it.
3. Loosen the C-clamp pan screw and rotate the yoke to the desired
position.
4. Tighten the pan screw to lock the fixture.
5. Connect the safety cable.
6. Tighten the C-clamp pipe bolt to 15–20 ft-lb (20–27 Nm),
approximately finger tight plus up to one-quarter turn.
CAUTION: Do not exceed 25 ft-lb (33 Nm) while tightening
the C-clamp pipe bolt. Do not use excessive force.
7. Tighten the yoke pivot bolt to 5–10 ft-lb (6–7 Nm), approximately
finger tight plus up to one-eighth turn.
CAUTION: Do not exceed 15 ft-lb (20 Nm) while tightening
the yoke pivot bolt. Do not use excessive force.

Source 4WRD Color Installation and User Manual 11
Connect Cables
WARNING: Do not use or store the Source 4WRD Color
fixture below 5°C (41°F). When the fixture has been stored or
transported in cold temperatures, allow it to warm to room
temperature for a minimum of 1 hour before applying power.
Applying power to a cold fixture will cause damage to the
fixture and void ETC warranty.
1. Connect one RJ45 data cable for data-in and one for data-thru, as
needed. Use the strain relief at the bottom of the fixture to support
the data cables.
•
To order an RJ45-to-female XLR adapter, use ETC part number
W6538.
•
To order an RJ45-to-male XLR adapter, use ETC part number
W6539.
2. If this is the last fixture in the line, terminate the fixture with a
120Ohm resistor. Please contact your ETC customer service
representative to purchase ETC part number N4086. See Help from
ETC Technical Services on page2 .
3. Connect the fixture to a non-dimmable power source.
DMXDimming
•
When using DMX over Cat5, use Cat5e or better.
•
Cable distance for full DMX daisy chain must not exceed 300m
(1000ft).
•
Up to 32 fixtures can be connected together into a daisy chain.
•
The fixture cannot be controlled via Ethernet protocols and should
not be directly connected to an Ethernet system.

12 Source 4WRD Color Installation and User Manual
DMX channels
Channel Description Value
1 Intensity
2 Red
3 Green
4 Blue
5 Amber
6 Strobe 0 = No strobe
1–254 = Linear increase from 1 per second (DMX = 1) to
33 per second (DMX = 254)
255 = No strobe
DMXpinout
Pin Description
1 DMX +
2 DMX -
3 DMX2 + (Pass Thru)
4 Not connected
Pin Description
5 Not connected
6 DMX2 - (Pass Thru)
7 Common (shield)
8 Common (shield)
Configure the Fixture
Up and down
navigation buttons
User interface
Use the up and down navigation
buttons to configure the fixture.
Set the DMXAddress
1. Press any button to wake the
display. The display shows the
DMX address.
2. Use the Up and Down buttons to
select the DMX address for the
fixture.
You can also use RDM for DMX
addressing.

Source 4WRD Color Installation and User Manual 13
Play Presets and Sequences
The fixture has twelve factory-configured presets and five factory-
configured sequences. When you play a preset or sequence on a fixture:
•
The same preset number or sequence number plays on any
connected fixtures that are not receiving DMX.
•
If you power down the fixture, the preset or sequence resumes
when you power it on again.
1. Press the Up button and Down button simultaneously to activate
the Presets/Sequences menu. The last active preset or sequence
plays automatically. (If DMX data is present, the current preset or
sequence plays in the background and DMX data continues to take
priority.)
2. Press the Up button or Down button as needed to scroll through
the available presets and sequences.
3. To stop the selected preset or sequence, press the Up button and
Down button simultaneously. The display will revert to show the
DMX start address.
Pre-configuredPresets
You cannot re-record presets and sequences locally on the fixture, but
you can modify them via RDM.
Preset Name
1 3200 K White
2 5600 K White
3 Red
4 Green
5 Blue
6 Cyan
Preset Name
7 Magenta
8 Yellow
9 Orange
10 Light Yellow
11 Light Blue
12 Light Pink

14 Source 4WRD Color Installation and User Manual
Pre-configuredSequences
Sequence Name
1 Rainbow Fast
2 Rainbow Slow
3 Warm Colors Fast
4 Cool Colors Fast
5 Random
Data Loss Behavior
When DMX data is lost, the fixture does one of the following actions:
•
If you selected a preset or sequence, that preset or sequence
automatically plays.
•
If no preset or sequence is active in the background, the fixture
goes dark and the DMXstart address flashes on the user interface.
RDMValues
Parameter RDMPID Value
Manufacturer ID 0x6574 Electronic Theatre Controls
Model ID 0x0802 ETCSource 4WRD Color
DMX Start Address 0x00F0 Range = 1–507
Output Frequency 0x8123 0 = Standard (1.2 kHz)
1 = High (20 kHz)

Source 4WRD Color Installation and User Manual 15
Focus the Fixture
Set the Z-adjustment
Use the Z-adjustment knob located on the rear of the fixture to adjust the
field of the LED light for specific applications.
1. Turn on the fixture and aim it at a flat surface.
2. Slide the fixture barrel toward or away from the Source 4WRD
Color to create a hard-edged beam of light.
3. Turn the knob toward PEAK or FLAT until you achieve the desired
field.
Ideal beam of
uniform light
Adjust toward PEAK to
blend overlapped beams
Adjust toward FLAT to
improve sharp focus
Z-adjustment knob
Note: The Source 4WRD PAR or PARNel Fixture Body optics are
optimized for PEAKfocus. When using the Source 4WRD Color in a
Source 4WRD PAR or PARNel Fixture Body, turn the Z-adjustment
knob toward PEAK until the knob becomes loose, and then tighten
the Z-adjustment knob an additional quarter turn. This sets the
LED light source into the appropriate position within the fixture.
Adjust the Yoke Position
Change the Height Position
Low clearance
position
General use
position
1. Remove the yoke locking knobs,
washers, and hex bolts from either side
of the fixture.
2. Raise or lower the fixture to the desired
position within the yoke.
3. Reinstall the yoke’s hex bolts, washers,
and locking knobs.
4. Tighten the yoke knobs to secure the
yoke in position.

16 Source 4WRD Color Installation and User Manual
Set the Angle within the Yoke
Yoke locking
knob
1. Loosen the yoke locking knob. Do not
remove the knob.
2. Tilt the fixture to the desired position.
3. Tighten the yoke locking knob to secure
in position.
Shape the Beam
You can shape the beam by using the shutters, a pattern, an optional
drop-in iris, and by rotating the barrel.
Use the Accessory Holder
The accessory holder is equipped with a spring-loaded retaining clip that
prevents color frames and accessories from falling out.
WARNING: Make sure all color frame accessories are locked
in position with the retaining clip before hanging the fixture.
AVERTISSEMENT : S’assurer que tous les porte-filtres sont
verrouillés en place à l’aide du verrouillage de la cassette
avant de suspendre le projecteur.
Retaining
clip
1. Release the retaining clip by pushing it
sideways while gently pulling backwards.
2. Insert the color frame or accessory.
3. Lock the retaining clip by pushing
sideways while gently pushing forward.
Use a Pattern
The pattern holder slot is on the top side of the barrel and in front of the
shutters. It accommodates A-size, B-size, and glass pattern holders.
Because the Source 4WRD Color fixture aperture is 3 inches wide, ETC
recommends A-size patterns for maximum effectiveness.
7.93 cm
(3.12 in)
diameter
7 cm
(2.75 in)
diameter
9.4 cm
(3.7 in)
9.4 cm
(3.7 in)
A-size pattern holder:
Holds 7.6 cm (3 in)
diameter patterns
B-size pattern holder:
Holds 6.35 cm (2.5 in)
and 7 cm (2.75 in)
diameter patterns
