ETC®Setup Guide
Congo™Radio Remote Focus Unit (cRRFU)
cRRFU Setup Guide Page 1 of 5 Electronic Theatre Controls, Inc.
Corporate Headquarters  3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel [phone]  Fax [phone]
London, UK  Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel [phone]  Fax [phone]
Rome, IT  Via Ennio Quirino Visconti, 11, 00193 Rome, Italy  Tel [phone]  Fax [phone]
Holzkirchen, DE  Ohmstrasse 3, 83607 Holzkirchen, Germany  Tel [phone]  Fax [phone]
Hong Kong  Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel [phone]  Fax [phone]
Service: (Americas) [e-mail]  (UK) [e-mail]  (DE) [e-mail]  (Asia) [e-mail]
Web: www.etcconnect.com  Copyright © 2007 ETC. All Rights Reserved.  Product information and specifications subject to change.
7310M2200  Rev D  Released 01/2009
Overview
The Congo Radio Remote Focus Unit (cRRFU) provides a simple, wireless solution for remote control.
Compatible with the ETC Congo and Congo jr consoles, this small hand-held transmitter unit provides
access to frequently used commands for dimmer and channel checks as well as update and record
functions. The small receiver unit plugs directly into and is powered by a USB port on the console or
through a powered USB hub.
Installation Instructions
The receiver unit is provided with a chassis USB connector and connects via a supplied 1.8m USB
cable to the console. The maximum distance is 5m between receiver and console (hub).
If you need to deploy the receiver further away from the console,
please look for our RFR Advanced Radio Remote Unit that is
based on Ethernet.
The transmitter unit requires a single 9V alkaline battery (provided)
for power. This battery should provide approximately one year of
normal usage before requiring replacement. To replace the battery,
remove the two M3x4mm screws at the bottom of the unit to
access the battery compartment and replace with a 9V alkaline
battery. Replace the lid and secure it with the same two screws.
Dispose of the old battery as is appropriate in your local area.
Transmitter Setup
The transmitter unit has a slide switch (on/off) and 16 keys for
console commands. The unit has a “sleep” feature that helps to
conserve battery life when the switch is left in the “on” position. Set
the switch to the “off” position to guard against accidental key
presses.
The keys of the transmitter unit are illuminated. The keys are
brightly lit while keys are pressed and the unit is transmitting. After
the key is released, the keys remain dimly lit for a period of time
before the unit sleeps. The sleep delay can be programmed at the
transmitter unit as described below.
Note:
If multiple units are to be used separately within range of each other’s receiver
units, please refer to Page 4 for modification of the communication encoding.
C
0 %
Update
1
Preset
4
7
2
5
8
100%
3
6
9
0
Record
Go / Goto
.
Thru
Func
@ Level
Group
Check+Check-
Ch
Go Back
- % + %
+
-
All

ETC Setup Guide
Congo™Radio Remote Focus Unit (cRRFU)
cRRFU Setup Guide Page 2 of 5 Electronic Theatre Controls, Inc.
Set the transmitter unit sleep delay:
• Turn the power switch to “off.”
• Hold down the key for the timeout that you require.
• While pressing the appropriate key, slide the power switch to the “on” position.
• Wait about 5 seconds.
• All keys will flash and then come on solid. This indicates that programming is complete.
Operation Instructions
The transmitter has two available commands for each key on the unit. Direct commands are displayed
above each key. To access the commands that are displayed vertically to the left of each key, press the
[FUNC] key first (do not press and hold [FUNC]). An example of mixing direct and [FUNC] commands
to record channels 1-5 at 75% into Preset 5 follows:
Specifications
Desired Timeout Congo RRFU key Expression/Express RRFU
key
5 seconds FUNC FUNC
12 seconds THRU THRU
25 seconds CH REL
Never turn off @LEVEL ENTER
[1] [CHAN] [5] [THRU] [7][5] [@ LEVEL] [5] [FUNC] [RECORD]
Transmitter Unit Receiver Unit
• Output: US: UHF 914.5MHz, 1mW maximum
EU: UHF 433,92MHZ, 10mW maximum
• Output: RS485 serial communications
• Antenna: Helical, fixed • Connections: Integral USB connector to console or
powered USB hub
• Working range: 75m indoor, 200m in free field • Max. Cable Length: 5m (16.5') Max from power source.
• Power: 9 Volt 6F22 battery • Power: 7-12Vdc, 25-30mA
• Size/Weight: 115mm (4.5”) x 65mm (2.6”) x 20mm (.8”)
(excl. antenna)
280g (10oz) (incl. antenna)
• Size/Weight: 112mm (4.4”) x 71mm (2.8”) x 45mm (.7”)
(excl. antenna)
465g (1lb) (incl. cable and antenna)

ETC Setup Guide
Congo™Radio Remote Focus Unit (cRRFU)
cRRFU Setup Guide Page 3 of 5 Electronic Theatre Controls, Inc.
FCC Notes (914.5MHz US version):
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communication. Operation of this equipment in a residential are is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
In order to maintain compliance with FCC regulation shielded cables must be used with this equipment. Operation
with non-approved equipment or unshielded cables is likely to result in interference to radio and television reception.
EU Notes (433,92MHz EU version):
CE - Product
The RRFU system conforms to the CE requirements set up by the European Community. This can be recognized
by this label on the outside of the product.
R&TTE Regulations (433,92MHz EU version):
The HF modules used are designed and manufactured by Radiometrix (UK) and approved to ETS 300-220-1.
The transmitter is approved according to R&TTE guideline 1999/5/EC and carries the declaration CE0889.
The unit is approved for use in the following countries in Europe:
A, B, DK, FIN, F, D, EL, IRL, I, L, NL, P, E, S, UK, IS, NO, CH

ETC Setup Guide
Congo™Radio Remote Focus Unit (cRRFU)
cRRFU Setup Guide Page 4 of 5 Electronic Theatre Controls, Inc.
ETC RRFU Transmitter settings
The RRFU has three possible encoding settings to allow multiple units to be used in the same area.
Changing the setting is done via a special key sequence on the transmitter and, depending on the
version of receiver you own, a hardware jumper or a software application.
• The encodings are designated ‘+’, ‘0’ and ‘-’.
• Express/ion RRFUs ship from ETC set to ‘+’.
• Congo RRFUs ship from ETC set to ‘-’.
To change the transmitter encoding
• Turn the power switch to ‘Off.’
• Hold down the key for the frequency that you require based on the type of console you are using
the RRFU to control.
• Power up the transmitter while holding down the key.
• Keep pressing key for about 10 seconds.
• All keys will flash and then come on solid. This indicates that programming is complete.
To change the receiver encoding
There are two versions of receiver hardware currently in use. One version has one 6-pin XLR connector
and the other version has one USB connector.
On a receiver with XLR connector only
• Unplug the receiver from the console.
• Open the cover.
• Identify the jumper block and the +, 0, - symbols that correspond to each jumper.
• Move jumper to selected encoding.
• Closer cover.
• Reconnect console.
Desired Encoding Congo RRFU Transmitter Expression/Express RRFU
Transmitter
00 AT
+C 0
- . (period) FULL
Jumper
Block

ETC Setup Guide
Congo™Radio Remote Focus Unit (cRRFU)
cRRFU Setup Guide Page 5 of 5 Electronic Theatre Controls, Inc.
On a receiver with USB connector only
USB receiver encoding is performed by downloading a software utility, connecting the receiver to your
PC using a USB cable, and running the utility on your PC.
To download and install the Channel Setup utility:
Step 1: Using your web browser, navigate to the ETC web site www.etcconnect.com.
Step 2: Click “Downloads” at the top of the home page.
Step 3: Fill in the search fields as follows:
•Product Line: Accessories
•Product: Radio Remote Focus Units (RRFU and cRRFU)
•Download Type: Software
Step 4: Click “Search”
Step 5: In the search results, double-click on
the appropriate file (named in step 3).
Windows will display the prompt at
right.
Step 6: Click “Run” to allow windows to install
the software.
Step 7: Follow the prompts in the setup wizard
to complete the install process.
To run the Channel Setup utility:
Step 1: Connect your receiver unit to one of your PC’s USB ports using a USB cable.
Step 2: Run the utility by clicking Start Menu>Programs>Channel Setup.
Step 3: If successful, the utility will open a small window with the
three encoding settings (0, +, -) displayed (shown at right).
Step 4: Click the setting that matches your transmitter unit (see To
change the transmitter encoding on page 4).
Step 5: Your receiver encoding will be updated. You may
disconnect the unit from your PC and close the Channel
Setup utility.
If you receive the error prompts shown below, instead of the Channel Setup Window, the
receiver may not be fully connected. Check the USB connection between the receiver and your
computer. Then try to re-run the utility. If you still have difficulty, contact ETC Technical Services
at the appropriate number listed at the bottom of page 1.
