Eternal GU125T User manual

Service Information Center:
Callusfirst ifyou haveanyquestionswiththis product.Wecanhelpyouwithquestionsaboutassembly
andWaterHeateroperationorifthereareanydamagedormissingpartswhenyouunpackthisunitfromthe
shipping box. Please callbeforereturningto the store.
1-866-946-1096
8:00am-4:30pmCST, MondaythroughFriday
157320069 Date 2014/11/20
Installation Operation Manual
NaturalGas (NG)-FactoryDefault
Liquid PropaneGas (LPG)-Optional Ori ce
RESIDENTIALWATERHEATERS
POWER VENTORDIRECTVENTCONVERTIBLE
ELECTRONIC IGNITION
ModelGU125T/ 518(11,12)1125
GU160T/ 518(11,12)1160
Donotstoreorusegasolineorother ammablevaporsandliquidsinthevicinityof thisoranyotherappliance.
Read this Operator'sManualcarefully andbesureyourWaterHeateris properly assembled, installed and
maintained.Failureto follow theseinstructionsexactlycouldresultin re,explosion,seriousbodily injuryand/or
propertydamage.
WARNING
! !
IMPORTANT:
Only speciallytrained andauthorizedpersonnel arepermittedtoservicethiswaterheater.
NOTETOASSEMBLER/ INSTALLER:
Leavethismanualwith the consumer.
NOTETOCONSUMER:
Keep thismanualforfuture reference.
RECORD YOUR SERIAL #_________________
(see clear CSAlabelonGasWaterHeater)
Onlyalicensedprofessionalcan install Eternalunitsforsafetyand code compliance.Ventingand plumbing
codescan varybylocation. Installation instructionsand all applicablecodesmustbe followed orproperty
damage,severeinjury,ordeathmayresult. Failureto usealicensedplumberorcontractor,followventing,
plumbing,and building codes,orfollowinstallation instructionsmaybeunlawfulandwillvoidthe product
warranty.GrandHallisnot responsibleforanycostsincurredforrepairinganyproblemsresultingfrom failureto
follow installation instructionsorapplicable codes.
WARNING
! !
1
CaliforniaProposition 65 listschemicalsubstancesknownto thestate tocausecancer,birth defects,death,
seriousillnessorotherreproductiveharm. Thisproductmaycontainsuchsubstances,be theiroriginfromfuel
combustion (gas,oil)orcomponentsof the product itself.
WARNING
! !
C

2
TableofContents
Included &OptionalAccessories P3
EternalHybrid WaterHeaterTechnicalSpecification P4
Dimensions P5
Parts&Service PartsList P6~8
InstructionsforYourSafety P9
TypicalInstallation P10
Installation Preparation P11
Exhaust / WaterHeaterStand / CondensateTrap Installation P12
Piping Installation P13
CondensateDisposal P14
CondensatePiping P15
IndoorInstallation / High Elevation P16
FloorMounting P17
VentingIntake &Exhaust Material P18
VentingSpecification P19
Vertical&HorizontalTermination P20~21
Clearance Requirementsfrom VentTerminationsto Building Openings P22
MultipleUnitsTermination P23
Vent Pipe Installation&TerminatorPosition P24
GasSupplyPiping P25
LPConversion P26
WaterSupplyConnection P27
Temperature andPressure Relief Valve &ElectricalConnection P28
RecirculationSystem with an EternalWaterHeater&Recirculationwith2 UnitsManifold P29
Operating Instructions&Temperature SettingProcedure P30
How To UseTheFront ControlInterface P31
Maintenance and Service P32
"D"Button DiagnosticFunction P33
Diagnostics P34
Wiringand Connection Diagram P35
Grand HallLimited Warranty P36~37
The stand assembly/ installationmanual P38~39

3
IncludedAccessories
OptionalAccessories

4
*Maximum manifoldpressureisindicated ontherating labelon rightsideof the unit.
*AHRICerti ed.
*IndependentDOEtested.
EternalHybridWaterHeaterTechnicalSpecications
ModelName GU125T GU160T
Energy Factor (*) / ThermalEf ciency(*) 0.82EnergyFactor/ 96%
Installation Indoor/ Floor Standing
Vent Run 3"PVC Upto100ft, 6ElbowsMax, 5ftDeductionPerElbow
CondensatepH Level 4 pH
Gas Type Pre-set For NG / LPConversionKit Included
UnitConnections Water 3/4"maleNPT
Gas 1/2", 3/4"FemaleNPT
Electricity Dedicated 120VAC, 60Hzw/3ProngedPower Cord
Gas Input Rate Max 75,000BTU/Hr 100,000BTU/Hr
Gas SupplyPressure NG / LP 3.5"WC to10.5"WC / 8"WC to14"WC
Ignition System Direct ElectronicIgnition w/AutomaticFlameSensing
Burner System Sealed Combustion withMetal Fiber PremixBurner
Gas ValveSystem DualStageNegativePressureModulation
ReserveTank 20Gallons 20Gallons
First Hour Rating 120Gallons 160Gallons
ActivationSensing TankTemperature
TemperatureControl ThermistorStartswithHeatingCycle
OutputTemperatureSettingRange Mechanical TemperingValvefrom70°Fto145°F(FactoryPreset120°F)
UnitDimensions(Round xHeight) 20.9" x46.9"
UnitWeight 120
SafetyDevices T&PValve,FlameRod,Remaining FlameDetection,FanRPMCheck,
VentBlockageDetection,ThermostatSwitches(194°F), 1x5AFuse,Intake
Blockage Detection.

5
Dimensions-GU125T /518(11,12)1125
GU160T /518(11,12)1160

6
Dimensions-GU125T /518(11,12)1125
GU160T /518(11,12)1160

7
Dimensions-GU125T /518(11,12)1125
GU160T /518(11,12)1160

8
KEY DESCRIPTIONPARTSNo.
1PourFoam(PU) 332120087
2Top Service Panel 332040047
3Top Cover 332040046
4AirIntake 152320178
5 Mesh Screen 151320057
6 Chassis 332010013
7 Main Controller 193320041(GU125T) / 193320101(GU160T)
8ControllerCover 152320048
9T&PRelief Valve 194140151
10 Drain Valve 150050273
11 Pipe Foot 155140027
12 Main PowerCord 192320148
13 Handle 195320059
14 Pipe Support 151320061
15 WaterHeaterStand 332070080
16 Outlet WaterPipe 332060040
17 Two WayValve 150320023
18 TemperingValve 194320110
19 ExhaustAdaptor 152320028
20 TrapClamp 151010032
21 CondensateTrap 332070125
22 IntakeAirPressure Switch 192320116(GU125T)/ 192290098(GU160T)
23 ExhaustAirPressure Switch 192320117(GU125T)/ 192290098(GU160T)
24 GasAdaptor 150320054
25 GasTube 150320038
26 GasValve 194140204
27 RadialBlowerAssembly 192320037(GU125T) / 192320100(GU160T)
28 Ignitor 193320094
29 IgnitorBox 332010036
30 GasValve Support 332010037
31 Pipe Clamp 190180003
32 Exhaust Chamber 152320027
33 BurnerAssembly 332010014
34 WaterTank 332020005
35 H/EThermistor 193320113
36 Outlet Thermistor 193320091
37 RadialBlowerAdaptor 152320065
38 APSAdaptor 152140233
39 GVPowerPlug 152140205
Dimensions-GU125T /518(11,12)1125
GU160T /518(11,12)1160

9
InstructionsforYour Safety
WARNING
If youdo not follow theseinstructionsexactly,a reorexplosion couldresultcausingpropertydamage,personal
injuryorloss of life.
InstallationCodes
BeforeInstallation
Theinstallationmustconformwith localcodesor,inthe absenceoflocalcodes,with NationalFuelGasCode,
ANSIZ223.1/NFPA54.
Properlyground the unitinaccordancewith alllocalcodesor,inthe absenceoflocalcodes,withthe National
ElectricalCodes,ANSI/NFPA70.
Thiswaterheaterdoesnot haveapilot. Itisequippedwith anignitiondevicethat automaticallylightstheburner.
Donottryto light the burnerbyhand.
Smellallaround the waterheaterarea forevidence ofleaking gas.Besureto smellnextto the oorbecauseLP
gasisheavierthanairand willsettleonthe oor.
Useonlyyourhandtoturnthe manualgasvalveknob. Neverusetools. Ifthe knob willnot turnbyhand, don't try
to repairit. Calla quali ed servicetechnician. Forcedorattemptedrepaircould result in a reorexplosion.
Donotusethiswaterheaterifanyparthasbeenunderwater.Immediatelycallaquali ed servicetechnician to
inspect the waterheaterandto replaceanydamaged parts.
Farawayfromwaterheater
In approved containers
Tightlyclosed
Out of children'sreach
Cannot beseen
Vapors areheavierthan air
Go along wayonthe oor
Can becarriedfrom otherroomstothemainburnerbyaircurrents
Turn offallelectricalpowertothewaterheaterif service isto be performed.
Turn the manualgasvalve locatedontheoutsideof the unit clockwiseto the off position.
Vapors fromflammableliquidswillexplodeandcatchfirecausing deathorsevereburns.Donotuseorstore
ammableproductssuchasgasoline, solventsoradhesivesinthesameroomorarea nearthewaterheater.
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
Keep ammableproducts
Vapors
TOTURN OFFGASTOWATER HEATER
□
□
WHATTO DOIFYOU SMELLGAS
Do not try to light anyappliance.
Do not touch anyelectricalswitch; do not useanyphone in yourbuilding.
Immediately callyourgassupplierfrom a neighbor'sphone. Follow the gassupplier'sinstructions.
If you cannotreach yourgassupplier,callthe redepartment.
WARNING
□
□
! !
! !
Usethis waterheateratyourownrisk.The setoutlet watertemperaturecancausesevereburnsinstantly or
death fromscalds.Testthe waterbeforebathing orshowering. Donot leavechildren orthe disabed without
supervision.
WARNING
! !
WARNING

TypicalInstallation
10
Thermal Expansion
Determine ifacheck valveexistsintheinletwaterline.Checkwith yourlocalwaterutilitycompany.It mayhave
beeninstalled inthe coldwaterlineasaseparatebackowpreventer,oritmaybepartofapressurereducing
valve,watermeterorwatersoftener.Acheck valve located in the cold waterinletlinecan causewhat isreferredto
asa “closedwatersystem.”Acoldwaterinlet line with nocheck valveorbackow prevention deviceis referredto
asan “open”watersystem.
As wateris heated,itexpandsinvolume and createsanincreaseinthepressurewithinthe watersystem.This
action isreferred to as “thermalexpansion.”Inan “open”watersystem,expanding waterwhichexceedsthe
capacityof the waterheater owsbackinto the citymainwherethe pressureiseasilydissipated.
A “closedwater system,”however,preventsthe expanding waterfrom flowing backintothe mainsupplyline,
andtheresultof “thermal expansion”can createarapidand dangerouspressureincreaseinthe waterheater
andsystem piping. Thisrapidpressureincreasecanquickly reachthesafetysettingof therelief valve,causing
ittooperate duringeachheatingcycle.Thermalexpansion,andtheresultingrapidandrepeatedexpansionand
contractionof componentsinthewaterheaterand pipingsystemcancauseprematurefailureoftherelief valve,
and possiblythe heateritself. Replacing the relief valvewillnot correct the "problem!"
The suggested method of controlling thermalexpansion isto install an expansion tankinthe coldwaterline
betweenthewaterheaterand thecheckvalve(seeillustrationabove).Theexpansiontankisdesigned withan air
cushion builtinthatcompressesasthesystempressureincreases,therebyrelievingthe overpressurecondition
andeliminatingtherepeatedoperationofthereliefvalve. Othermethodsofcontrollingthermalexpansionare
alsoavailable. Contactyourinstalling contractor,watersupplierorplumbing inspectorforadditionalinformation
regarding thissubject.

11
Installation Preparation
Unpack theunit carefully andmakesure that the included accessoriesareputaside so theywillnotbe lost.
●Operator'smanual●WarrantyRegistration Card●Included Parts
Inspect thewaterheaterforpossible shipping damages.
Checkthemarkingsoftheratingplateonthewaterheatertobecertainthetypeofgasbeingfurnished
correspondsto what the waterheaterisequipped for.
Donotconnectthiswaterheaterto a fueltype not in accordance with the rating plate.
Carefullychoosethe locationforthenew heater,asplacementisavery importantconsiderationforthesafetyof
theoccupantsin the building andforthe mosteconomicaluseof the appliance.
Whetherreplacing anold waterheaterorputting the waterheaterin anew location, considerthe following critical
points:
Read the Safetyguidelinesin the beginningof thismanual.
The internalcomputercontrolledregulatoris presetbythemanufacturerand shouldnotbeadjusted bythe
user.
Maintainproperspacearound theunitforservicing.Installthe unitsothat itcanbeconnectedorremoved
easily.
Theelectricalconnectionrequiresameansforswitching offthe powersupply.
Avoidinstallingtheunitinan area withhigh levelsof dust, sand, ordebris.Theseparticlesmayclogtheair
ventorimpairthefunctionof the fan,leadingto impropercombustion.Regularmaintenance isneeded.
Do not installthe unit wheretheexhaustventis pointing into anyopening inabuilding orwherethe noisemay
disturb neighbors.
The locationselectedshouldbe ascloseto the ventterminationpointaspossible,andcentered withinthe
waterpiping system forbesthot waterdelivery.
If ventedthroughanoutsidewallorthrough theroofusing 3"vent piping, thetotalvent runcannotexceed95
feetwithone 90°elbow.If moreelbowsarerequired, the ventingdistancemustbereduced 5feetforevery
90°elbow.
Condensation maybecreated at timesasthe combustion gasesexit the vent cap. Discoloration of surfacesin
proximityto the vent cap mayoccur.
□
□
□
□
□
□
UnpackingYourEternal WaterHeater
Additional SafetyInstructions
WaterHeaterPlacement
●
●
●
●
●
●
●
●
●
WARNING
Allwaterheaterseventuallycanleak.The applianceshouldbelocated inanarea whereleakage ofthe
tankorconnectionswillnot resultindamageto the area adjacent to theapplianceorto lowersfloors
ofthestructure. Itis required that asuitabledrainpan beinstalledunderthe appliancedrainpansare
availableat yourlocalhardwarestore. Suchdrainpan musthaveaclearanceofat least1.0”(2.5cm)
greaterthananypointonthewaterheater’souterjacketandmustbepipedtoanadequatedrain.
Theminimum inlet gaspressuremustbewithinthe value speci edbythe manufacturerand the minimumvalue
listedisonlyforthe purposeof input adjustment.
If awaterheaterisinstalledinaclosed watersupplysystem, suchasonehaving abackow preventerinthe
coldwatersupplyline,thenathermalexpansiontankisrequired,contactthewatersupplierorlocalplumbing
inspectoron how tocontrolthissituation.
The TemperatureandPressure(T&P)reliefvalvemustbecerti ed asmeetingtherequirement of the Standard
forRelief ValvesandAutomatic GasShut-offDevicesforHot WaterSupply SystemsANSIZ21.22/CAN1-
4.4.The valvemustbemarkedwithamaximum setpressurenot toexceedthemarkedhydrostatic working
pressureofthewaterheater(150 psi) andadischargecapacitynotless than the waterheaterinputrateas
marked ontherating plate.
□
□
□
□
WARNING
! !
BeforeCommencingTheInstallation
Check thatitis inaccordancewithrelevantbuilding
and mechanicalcodes,aswell asanylocal,state or
federalregulations.
!!
CAUTION
!!
CAUTION
Thedrainvalvemust betightenedby
HandONLY, notbytoolsofanykind.

Exhaust /WaterHearterStand /CondensateTrapInstallation
InstallationProcedure:
12
Assemble the included waterheaterstandasper installation procedure.
Insertcondensate trap intotheexhaust adaptor, and installtrap clamp.
Placeexhaustpipe inside exhaust adaptorsocket bottom.Then, holdthe exhaustpipe in place,byattaching the
pipeclamp tothepipe supportusing2 (M5)screws.
Factory supplied waterheaterstand&condensatetrap must be installed.
□
WARNING
WARNING
! !
1.
2.
3.

13
Piping Installation
Usespannertofixthe waterpipe holderandthen tighten
waterpipe withpipewrench.
UseSpannertofix gasadaptorandthentighten gas
pipewith pipewrench.
Usespannertofixvalveandthen tightenT&Pvalve
with pipe wrench.
□
□
□
WaterPipeInstallation
GasPipeInstallation
T&PReliefValveInstallation (FactoryInstalled)

14
Condensate Disposal
Overtime, blockageofthetrap bydebrismayoccur;whenthecondensatecannot bereleased, theunitwillgo
into errorandwill shut down. Whenthisoccurs, the trap mustbe cleaned.
Cleaning Out TheCondensate Trap
Thecondensatetrap must be lledwith waterpriorto usingthewaterheater.
Pourwaterdownthe exhaustadaptoruntilwatervisiblyflowsout of the
condensate drainbefore rst use.
□
ToRemove Trap
1. Remove clip securing trap tothenipple.
2. Gentlypulltrap bodydownwardsto remove.
Thecondensate trap mustbe lledandunobstructed toallowunrestricted ow ofcondensate.Thecondensate
shouldnot be subjectto conditionswherefreezing couldoccur.If the condensateissubjected to freezing or
obstruction, itwillresultinpotentialwaterdamage tothewaterheaterand surrounding area.
CAUTION
! !
The condensatedrain linematerialmustbeanapprovedmaterialbythe authorityhaving jurisdiction. Inabsence
of suchauthority,PVCand CPVCpiping mustcomplywith ASTM D1785 orD2846. Thispipe mustbeconnected
to the condensatetrap. Theend ofthepipe should drainto alaundrytub orto a oordrain.
NOTICE
! !
1/2"PVC(SCH40,ASTM-D1785)
or
1/2" CPVC(SDR11,ASTM-D2846)
Eternalwaterheaterwill typicallyproduceacondensatethatis considered slightlyacidic withaPhcontentof
approximately3-4.Installa neutralizing lterifrequired byauthorityhaving jurisdiction (See gureabove).
Directto drainfromtheunit.
Drain through neutralizerfrom the unit.
Drain tolaundrytub from the unit. In thiscase,theunit must behigherthenthelaundrytub.
Wheninstalling acondensatepump, ensurethe pump isapproved foruse with acondensing appliance.
Thepump shouldbeequipped withanoverow switchtopreventpropertydamage from potentialcondensate
spillage.
1.
2.
3.
4.
NOTICE
! !
WaystoDisposeCondensate:
□
□

Condensate Piping
Thiswaterheaterisahighef ciency,fully condensingappliancewhichproducescondensateduring operation.
Thewaterheaterincorporatesacollectionand removalsystemofcondensatewhichmustbeproperlydrained in
orderto ensure properoperationof thisappliance.
PleaseusePVCorCPVCforthedrainline. Donotusesteel,blackiron, oranyothermaterialwhichcan
corrodewhen contacting with condensate water.
Keep the length of the drainpipe asshortaspossible. Long runs,orapplicationswherethe nearestdrainis
abovethewaterheater,will requirethe useofacondensatepump.Sizethepumptoallowforamaximum
condensate discharge of 2GPH from the waterheater.
Horizontalrunsmust be sloped1/4"perfoot towardsthe drainorcondensatepump.
Besureto checkthat condensate isfreelyflowing fromthe drainpiping afterthe system hasbeeninstalled.
Condensate willbegin owing out ofthewaterheaterwithin 15 minutesafteroperation hasstarted.
□
□
□
□
CondensatePipingtoFloorDrain CondensatePipingtoCondensatePump
EternalCondensateNeutralizer
CondensatePump
EternalCondensateNeutralizer
□
CAUTION
!
Theend ofthe drainpipe mustnotbe submerged inwateror blocked inanyway.
Takingmeasurestopreventthecondensatedrainlinesfrom freezingisrecommended (insulation,heattape,electric
heater, etc.)
!
15
1/2"CPVC
1/2"CPVC

16
IndoorInstallation
Clearances
From top of waterheater 12inches From back of unit 4 inch
From front of unit 4 inches(*)From left sideof unit (gaspipingside)6 inches
From side wall ueorventconnectorinanydirection 6 inches From right sideof unit 6 inches
GU125T/GU160Tcanbe usedeitherasaPower-VentorDirect-Vent appliance.WhenusedasaPower-Vent
appliance,thewaterheatershouldbe locatedinanareawhereenoughairis availableforpropercombustion
and ventilation.Followthelatest editionof ANSI Z223.1 and anyof yourlocalcodesthat are applicable.
GU125T/GU160Tis aCategoryIVvented applianceandmanufacturer'sventilation specificationsshouldbe
followed.
In general,theserequirementsspecifythatifthe unitisinstalledinaconfinedspace,theremustbe permanent
airsupply openingsif Eternalisn't installedasDirect-Vent.
Whencombustionairissupplieddirectly through an outsidewall,suchasintakelouveropeningsintothedwelling,
eachopening shouldgiveaminimumfreearea of onesquareinchper4,000 Btu/hourof the totalinput ratingsofall
appliancesinthe enclosed area.
Whencombustionairissuppliedfrominsidethe building,eachopeningshouldgiveaminimumfreeareaof one
squareinch per1,000 Btu/hourofthetotalinputratingsofall appliancesinthe enclosed area.Theseopenings
shouldneverbe lessthan40sq.in.
Theminimumrequiredtotalspacevolumewithout airventsis50 cuft. perevery1,000 Btu/hour.
□
□
□
CombustionAirSupply
Airsupplyfrom outsidebuilding:
Airsupplyfrom insidebuilding:
Minimum RecommendedAirSupplytoWaterHeateras Power-Vent
Model# WaterHeaterCapacity OutsideAirArea Inside AirArea
GU125T Max.75,000Btu/hour 20 sq.in. 75 sq.in.
GU160T Max.100,000 Btu/hour 25sq.in. 100 sq.in.
Model# WaterHeaterCapacity Minimum Required AirVolume
GU125T Max.75,000Btu/hour 3,750cu.ft
GU160T Max.100,000 Btu/hour 5,000cu.ft
Naturalgasathighaltitudemightcontainless heatingvalue than typical1,000 BTU/cuftand thereforecan
causeimproperair/gasmix leadingto impropercombustion. Fornaturalgas installations at highaltitude above
3000 ft, besure tocon gurethedipswitch settingcorrectly.Pleasecall886-946-1096.
WARNING - high elevation installations
! !
AirVents
Heater
AirVents
Heater
*Foraccessibilitywhen performingmaintenance, 24"clearance in front oftheunit it isrecommended.

17
FloorMounting
ForinstallationinCaliforniathiswatermustbebraced oranchoredtoavoidfallingormovingduring anearthquake. See
instructionsforcorrectinstallationprocedures.InstructionsmaybeobtainedformCaliforniaOfficeofthe State Architect.
1102 QStreet, Suite 5100,Sacramento, CA95811.
FOR INSTALLATIONSIN THESTATEOFCALIFORNIA
INSTALLATION REQUIREMENTSFORTHECOMMONWEALTH OFMASSACHUSETTS
MassachusettsCode requiresthis waterheatertobe inatalledinaccordancewith Massachusetts248-CMR2.00:State
Plumbing Codeand 248-CMR 5. SeeCommonwealth ofMassachusettsbelow.
Forall sidewall terminated,horizontally ventedpowervent,directvent,andpowerdirectventgasfueled waterheaters
installedinevery dwelling,bulidingorstructureusedinwholeorinpartforresidentialpurposes,includingthoseowned
oroperated bytheCommonwealthandwherethesidewall exhaustventterminationsis less thanseven (7)feetabove
finished gradeinthearea of theventing, including but not limited todecks andporches,thefollowingrequirementsshould
besatisfied:
InstallationofCarbonMonoxideDetectors
Atthetimeofinstallationoftheside wallhorizontalventedgasfueledequipment,theinstallingplumberorgasfittershould
observethatahardwiredcarbonmonoxide detectorwithanalarmand batteryback-upisinstalledonthefloorlevelwhere
thegasequipment isto beinstalled. In addition, the installing plumberorgasfittershould observe that abatteryoperatedor
hardwired carbonmonoxidedetectorwithan alarmis installedon eachadditionallevelof thedwelling, buildingorstructure
served bythesidewall horizontalvented gasfueled equipment. It shouldbe the responsibilityof the propertyownerto
secure the servicesofqualified licensed professionalsfortheinstallation of hard wired carbon momoxide detectors.
In the event that thesidewallhorizontallyventedgasfueled equipment is installed inacrawlspaceoranattic,thehard
wired carbon monoxidedetectorwith alarmand battery back-up maybe installedonthenext adjacent floorlevel.
Intheeventthattherequirementsofthissubdivisioncannotbemetatthetimeofcompletionofinstallation,theowner
shouldhaveaperiodthirty(30)daystocomply with theaboverequirementsprovided that during saidthirty(30)dayperiod,
a batteryoperated carbon monoxidedetectorwith an alarmshouldbe installed.
ApprovedCarbonMonoxidedetectors
Eachcarbonmonoxide detectorasrequired inaccordancewith theaboveprovisionsshould complywith NFPA720and be
ANSI/UL2034listed andCSAcertified.
Signage
Ametalorplasticidentificationplate shouldbepermanentlymountedto theexteriorof thebuildingataminimum height
ofeight(8)feetabovegradedirectly inlinewiththeexhaustventterminalforthehorizontally ventedgasfueledheating
applianceorequipment. Thesignshouldread, inprint sizenoless than one-half(1/2)inchinsize.GASVENTDIRECTLY
BELOW.KEEP CLEAROFALLOBSTRUCTIONS.
Inspection
Thestate orlocalgasinspectorof thesidewallhorizontallyventedgasfueled equipment shouldnotspprovetheinstalltion
unless,uponinspection, theinspectorobservescarbonmonoxide detectors andsignageinstalledinaccordancewiththe
provisionsof 248 CMR 5.08(2)(a)1 through 4.
Exemptions:
Thefollowing equipment is exempt from248 CMR 5.05(2)(a)1through 4:
Theequipment listedinChapter10entitledEquipment Not RequiredToBeVentedinthemostcurrent edition of NFPA
54asadopted bythe Board; and
1.
ProductApproved sidewallhorizontallyvented gasfueledequipment installed inaroomorstructureseparatefromthe
dwelling, building, orstructureused in whole orinpart forresidentialpurposes.
2.
ManufacturerRequirements-Gas Equipment Venting System Provided
Whenthemanufacturerof ProductApprovedsidewallhorizontally vented gasequipment providesa ventingsystemdesign
orventing system componentswith the equipment, theinstructionsprovided bythe manufacturerforinstallation of the
equipment and the venting system should include:
Detailedinstructionsfortheinstallationof the venting system design orthe venting system components;and1.
Acomplete partslist forthe venting system designorventing system.2.
ManufacturerRequirements-Gas Equipment Venting System NotProvided
Whenthe manufacturerofaProductApprovedsidewallhorizontallyventedgasfueled equipment dosenotprovidethe
partsforventing thefluegases,but identifiesspecialventingsystems,thefollowing requirementshouldbesatisfied bythe
manufacturer:
Thereferenced specialventing system instructiosshouldbe included with the applianceorequipment installation
instructions;and
1.
The specialventing systemsshouldbeProductApprovedbythe Board, and the instructionsforthat system should
include apartslist and detailed installation instructions.
2.
Acopyof allinstallation instructionsforallProductApproved sidewallhorizontallyvented gasfueledequipment, allventing
instructions,allpartslistsforventing instructions,and/orallventingdesign instructionsshouldremainwiththeapplianceor
equipment at thecompletion oftheinstallation.

EternalHybridWaterHeaterisagasburning appliancewithfan-assisted exhaust.Theappliancemustbevented
with 3" CategoryIVspecialventing, which isairtight to prevent leakageof exhaust gases.
Theappliancemust be vented separatelyfromallotherappliances.
Thefollowing typeof non-metallicvent can beused:
VentPipeMaterial
Allprimers,cleanersand cementsmustmeetalllocalcodesandapplicablestandardsof the AmericanSocietyfor
Testing Materials(ASTM).
CementingPVC, ABSorCPVC PIPE and FITTING
Thiswaterheatermustbe properly vented forremovalof exhaustgasesto the outside of the home. Correct
installationof thevent pipesystemismandatoryforthesafeand ef cient operation of this waterheaterand isan
important factorin the lifeof the unit.
WARNING
! !
If Eternalcombustionairinletislocatedinanarealikely to causeorcontaincontamination, the combustionair
mustberepipedandterminatedatanotherlocation. Contaminated combustionairwilldamagetheunitandits
burnersystem, resulting in possible severepersonalinjury,death orsubstantialpropertydamage.
WARNING
! !
ForinstallationsinCanada, eldsuppliedplasticvent piping mustcomplywith CAN/CGA-B149.1(latestedition)
andbe certi edtothe StandardForTypeBHGasVenting Systems,ULCS636Componentsof thislistedsystem
shallnotbeinterchanged withothervent systemsorunlisted pipe/ ttings. Allplasticcomponentsand speci ed
primers andgluesofthecerti edventsystemmustbefromasinglesystemmanufacturerandnotintermixed
with othersystem manfacturer'svent system parts.The supplied ventconnectorsarecertified aspartofthe
waterheater.
WARNING
! !
18
Venting Intake &Exhaust Material
PVC (schedule40,ASTM-D1785)CPVC (schedule40,ASTM-D2846)
PVC-DWV (ANSI/ASTM-D2665)ABS(schedule40, ASTM-D2661)
Polypropylene Pipe Single wall&Components(ULC-S636, UL-1738)
Note : Do not usecellularfoam core pipe.
●
●
●
●
*
●
Thefollowingguidelines shouldbefollowedwheninstalling theexhaustoutletpiping:
Venting shouldbeasdirect aspossiblewith aminimumnumberof pipe ttings.
Venting diametermust not be reduced unlessspeciallynotedintheinstallationinstructions.
Support allhorizontalpiperunsevery 3½feet according to localcodes.
Ventsrunningthroughunconditionedspaceswherebelowfreezingtemperaturesareexpectedshouldbe
properlyinsulatedto preventfreezing.Forhorizontalruns,wrapthe vent pipewith self-regulating 3or5watt
heat tape.The heat tapemustbe U.L. listed and installed permanufacturer'sinstructions.
Donotconnectthisventing system withanexisting vent orchimney.
Donotconnectcommon vent with the vent pipeof anyotherwaterheaterorappliance.
Donotuse bushing asreducer.
□
□
□
□
□
□
NOTICE-VENTING GUIDELINES
! !
□

19
Venting Specication
GU125T/GU160Tis factory configuredasasealed combustion unitwithdedicated intakeand exhaust
connections.
Wheninstalledasa Direct Vent appliance, allcombustion airisdrawn directlyfrom outside ofthehome.
DirectVentconfiguration isforindooronly.
Recommended forfacilitieswith difficultyaccessingcombustion air.
Isforindooronly.
Isnot sealedcombustionif intake is notused to bring airdirectlyfrom outside.
DirectVent
PowerVent
Insuf cient airsupplyusedwith PowerVentappliancemaycausethebuilding to experiencenegativepressure
inside.Negativepressureis notallowablebymostbuildingcodesand can causeback draftingofcoldairfrom
outsidethroughtheunit, potentially freezing the heatexchanger/ tank.
WARNING
! !
To configure the unitforpowervent, leave intakeopen.
HowToCongureUnitForPower-Vent
MaximumAllowableVentandCombustion AirPiping Length
3 inch Piping
Feet Max# of90°elbows
100 6
●Reducethemaximum allowablelengthforeach elbow usedasfollows:
-45 degreeelbow : Deduct 3feet
-90 degreeelbow : Deduct 5feet
● The intakeand exhaustventlengthscanbeof equal lengthor less;thereis no balancing requirementbetween intake
and exhaust.
●
Someterminationsare considered typesofelbows,and correct deduction should be applied.Suchas,aturn down
90˚or an open T termination isconsidered 1x90˚elbow,andacandycane terminationis consideredas2x90ºelbows.
●
Toavoid accumulationofcondensatewaterintheexhaust ventrun,itisrecommendedtopositionthestartof
the horizontal section lower,then slope upwardswithno lessthan1/4"riseperfootofpipe towardstheventing
termination toallowcondensation flow backintothe unit.
●
Horizontal runsrequire adequatesupportat31/2footintervalsand vertical runssuppartat5footintervals.

20
VerticalTermination
Below diagramsareexamplesof verticalterminations.
Through roof (DirectVent) Through roof (ConcentricVent)
□ □
The Grand Hallapprovedconcentrickitisaunique
pipe-in-pipe ventingsystemdesignedfortermination.
Donottryto replicate ormakeyourown. Formore
information, pleasereferto ConcentricVent Kit
section in the Operation manual.
WARNING
! !
Through roof (PowerVent)
Minimum twelve(12)inchesaboveanticipated
snowlevel.
Theterminationcannot beconnectedtoan existing
ventpiping orchimney.
The totalverticaland horizontalrunscannot exceed
the maximum lengthwitha maximumnumberof 90
degree elbowsasspeci ed in the table of page 19.
Eternalcan be ventedstraightupandahorizontal
section isnot required forverticalterminations.
□
□
□
□
NOTICE
! !
Anopenteeisrecommended to useasa
terminationtoalleviate and preventback
pressure in the venting system.
