ETIC IPL-E User manual

DOC_DEV_IPL-E_User guide_A
IPL-E
Router Firewall
_________________
USER GUIDE

The IPL-E router is manufactured by
ETIC TELECOM
13 Chemin du vieux chêne
38240 MEYLAN
FRANCE
TEL : + 33 4-76-04-20-00
Hotline : + 33 4-76-04-20-05
FAX : + 33 4-76-04-20-01
E-mail : [e-mail]
web : www.etictelecom.com

Router Firewall IPL-E DOC_DEV_IPL-E_User guide_A Page 5
CONTENT
OVERVIEW .......................................................................................................................7
1 Certificate of conformity..................................................................................7
2 Products identification ....................................................................................8
3 Data-sheet.....................................................................................................10
4 Product Overview ..........................................................................................12
4.1 Applications .............................................................................................. 12
4.2 Functions .................................................................................................. 13
4.3 Router interfaces & organisation................................................................ 14
INSTALLATION ..............................................................................................................15
1 Product description .......................................................................................15
1.1 Dimensions ............................................................................................... 15
1.2 Push-buttons ............................................................................................ 15
1.3 Connectors................................................................................................ 15
1.4 IPL-E-400 or IPL-EW-400 (WiFi option) ..................................................... 19
1.5 IPL-E-220 or IPL-EW-220 (WiFi option)...................................................... 20
1.6 IPL-E-230 or IPL-EW-230 (WiFi option)...................................................... 21
1.7 IPL-E-260 or IPL-EW-260 (WiFi option)...................................................... 22
1.8 IPL-E-261 or IPL-EW-261 (WiFi option)...................................................... 23
2 Mounting the product on a Din rail .................................................................24
3 Cooling..........................................................................................................24
4 Supply voltage...............................................................................................24
5 Digital input and output .................................................................................25
6 RS232 ...........................................................................................................25
7 RS485 connection (IPL-E-220 or IPL-EW-220)...............................................25
8 RS422 isolated interface (IPL-E-260 or IPL-EW-260) ....................................27
9 RS485 isolated interface (IPL-E-261 or IPL-EW-261).....................................28

CONTENT
Page 6 DOC_DEV_IPL-E_User guide_A Router Firewall IPL-E
PREPARING THE SETUP ................................................................................................29
1 First setup .....................................................................................................29
2 Protecting the access to the administration web server .................................29
3 HTTPS set-up modifications through the WAN interface................................30
4 Recovering the factory LAN IP address..........................................................30
5 Restoring the factory set-up ..........................................................................30
6 Saving or restoring a set of parameters .........................................................31
7 Configuration steps .......................................................................................32
DIAGNOSTIC ..................................................................................................................34
1 Diagnostic .....................................................................................................34
1.1 Logs.......................................................................................................... 34
1.2 Network status.......................................................................................... 35
1.3 Serial gateways status............................................................................... 36
1.4 « Ping » tool .............................................................................................. 36
1.5 « WiFi » scanner tool.................................................................................. 36
2 Firmware update............................................................................................37

Router Firewall IPL-E DOC_DEV_IPL-E_User guide_A Page 7
OVERVIEW
Certificate of conformity
The manufacturer, ETIC Telecom –13 chemin du vieux chêne –38240 Meylan –France, Hereby declares
that the listed products
Type of device : Ethernet interfaces IP router
Reference : IPL-E
conforms to the Council Directive 1999/5/EC related to radio and telecommunication terminal equipment.
The harmonized standards to which the equipment complies are :
Standard
Title
EN301489-1
Electromagnetic compatibility and Radio spectrum Matters :
Part 1 : General requirements
EN61000-6-2
Ed. 2001
Immunity :
EN60100-4-2 Electrostatic Discharge
EN60100-4-3 Radiated Immunity
EN60100-4-4 EFT/Burst Immunity
EN60100-4-5 Surge Immunity
EN60100-4-6 Conducted Immunity
EN61000-6-4
Ed 2001
Emission :
EN55022 radiated and conducted emission
EN60950
Security
EN50385
Human exposure to radio frequency fields exposure
Philippe DUCHESNE
Quality manager
5th January 2015

OVERVIEW
Page 8 DOC_DEV_IPL-E_User guide_A Router Firewall IPL-E
Products identification
The present user guide describes the products listed hereafter.
Router without WiFi
IPL-E-
400
220
230
260
261
IP routing
•
•
•
•
•
Firewall SPI
•
•
•
•
•
IPSEC & OpenVPN VPNs (16 tunnels max.)
•
•
•
•
•
25 remote users RAS
PPTP / L2TP/IPSec / OpenVPN / HTTPS
•
•
•
•
•
HTTPS portal
•
•
•
•
•
Serial gateway (Raw TCP & UDP, Telnet, Modbus,
Unitelway)
-
•
•
•
Ethernet 10 / 100 BT (LAN / WAN)
4 / 1
2 / 1
2 / 1
2 / 1
2 / 1
RS232
-
1
2
-
-
RS485
-
1
-
-
-
RS422 isolated
-
-
-
1
-
RS485 isolated
-
-
-
-
1
USB
1
1
1
1
1
NAT
•
•
•
•
•
Port forwarding
•
•
•
•
•
SNMP
•
•
•
•
•
DNS
•
•
•
•
•
DHCP server on the LAN inteface
•
•
•
•
•
Digital input for alarm email
1
1
1
1
1
HTTPS / HTML / SSH configuration
•
•
•
•
•

OVERVIEW
Router Firewall IPL-E User Guide 9021209-01 Page 9
Router with WiFi interface
IPL-EW-
400
220
230
260
261
IP routing
•
•
•
•
•
WiFi 2.4 & 5 GHz Client or Access point
•
•
•
•
•
Firewall SPI
•
•
•
•
•
IPSEC & OpenVPN VPNs (16 tunnels max.)
•
•
•
•
•
25 remote users RAS
PPTP / L2TP-IPSec / OpenVPN / HTTPS
•
•
•
•
•
HTTPS portal
•
•
•
•
•
Serial gateway (Raw TCP & UDP, Telnet, Modbus,
Unitelway)
_
•
•
•
•
Ethernet 10 / 100 BT (LAN / WAN)
4 / 1
2 / 1
2 / 1
2 / 1
2 / 1
RS232
_
1
2
_
_
RS485
_
1
_
_
_
RS422 isolated
_
_
_
1
_
RS485 isolated
_
_
_
_
1
USB
1
1
1
1
1
NAT
•
•
•
•
•
Port forwarding
•
•
•
•
•
SNMP
•
•
•
•
•
DNS
•
•
•
•
•
DHCP server on the LAN inteface
•
•
•
•
•
Digital input for alarm email
1
1
1
1
1
HTTPS / HTML / SSH configuration
•
•
•
•
•
Option
Référence
Service de connexion M2Me_Connect
M2Me pack initial

OVERVIEW
Page 10 DOC_DEV_IPL-E_User guide_A Router Firewall IPL-E
Data-sheet
General characteristics
Dimensions
137 x 48 x 116 mm (h, l, p)
Electrical safety
EN 60950- UL 1950
EMC
ESD : EN61000-4-2 : Discharge 6 KV
RF field : EN61000-4-3 : 10V/m < 2 GHz
Fast transient : EN61000-4-4
Surge voltage : EN61000-4-5 : 4KV line / earth
RoHS
2002/95/CE (RoHS)
Supply voltage
IPL-E-400, IPL-EW-400 10 to 60 VDC
IPL-E-230, IPL-EW-230 10 to 60 VDC
IPL-E-260, IPL-EW-260 10 to 60 VDC
IPL-E-261, IPL-EW-261 10 to 60 VDC
IPL-E-220, IPL-EW-220 10 to 30 VDC
Operating T°
-20°C / + 60°C Humidity 5 –95 %
WiFI
Type
2.4 & 5 GHz
RF connector
R-SMA female
WiFi transmission
802.11 a/b/g/n
VPN & firewall
VPN
Client or server IPSEC or OpenVPN
Encryption AES256 3DES
Certificate X509 or preshared key
16 VPNs maximum of the same type (OpenVPN or IPSec)
Firewall
Stateful packet inspection (50 rules)
Deny of service filter
Source & destination IP address & port number filter
Remote users filter
Logs
Date and time stamped logs
Remote access server (RAS)
User list
25 users
Connection
PPTP / L2TP-IPSec / Open VPN / HTTPS
Login & password
Certificate X509
M2Me
(option)
VPN Compliant with the M2Me_Secure VPN client
Compliant with the M2Me_Connect mediation service
Alarms
1 input : emails or SM (cellular models)
