Eton ZoneGuard+ User manual

Owner’s manual
The Flashing, Dashing Wireless Weather Alert,
Alarm Clock Radio System

3
ZONEGUARD OWNER’S MANUAL
+
NEED HELP? CONTACT US.
Etón Corporation, 1015 Corporation Way, Palo Alto, CA
94303, USA. 1-800-872-2228 (U.S.); 1-800-637-1648
(Canada); 650-903-3866 (worldwide); M-F, 8:00-4:30,
Pacic Standard Time; www.etoncorp.com.
WARNING
Do not expose this appliance to rain or moisture.•
Do not submerge or expose for extended period to water.•
Protect from high humidity and rain.•
Only operate within specied temperature range •
(0 °C to 40 °C).
Unplug immediately if liquid has been spilled or any•
object has fallen into the apparatus.
Clean only with a dry cloth. Do not use detergents or•
chemical solvents as this might damage the nish.
Unplug and disconnect external antennas during•
lightning storms.
Do not remove cover [or back].•
Refer servicing to qualied service personnel.•
ENVIRONMENT
Disposal
According to the European Directive 2002/96/EC all
electrical and electronic products must be collected
separately by a local collection system.
Please act according to your local rules and do not dispose
of your old products with your normal household waste.
Please dispose of all types of batteries per your
Government, State or Local rules and/or regulations.
If you are unsure, please call the appropriate local authority
to nd out how to dispose of them safely and help protect
the environment.

4
ZONEGUARD OWNER’S MANUAL
+
ZONEGUARD
Thank you for purchasing the Etón ZoneGuard . We want
you to thoroughly enjoy the use of this product. To take
advantage of its many excellent and unique features,
we urge you to carefully read the Owner’s Manual.
1WEATHER BAND ALERT
Button
2WEATHER BAND Button
3AM/FM
4TEST Button
5Display
6Select Button
7Power Button
8Alert Off
9Speaker
5
12
14
10
13
7
8
9
611
FRONT
+
+

5
ZONEGUARD OWNER’S MANUAL
+
LEFT SIDE RIGHT SIDE
10 Warning Light
11 Menu Button
12 Alarm On/Off
13 SNOOZE Button
14 Memory Location 1-6
15 Antenna
16 Battery Compartment
17 V+
18 V-
19 Backstand
20 DC in
20
19
15
16
17
18
1
2
3
4

6
ZONEGUARD OWNER’S MANUAL
+
POWER SUPPLY
Battery Power
(3 AA Batteries)
Install 3 AA batteries with
correct polarity shown in
the compartment(on the
back of the radio).
DC-IN 5V AC Adapter
Plug in the AC adapter
(5V, 150mA) to the DC IN
socket.
TURNING THE UNIT ON/OFF
The unit is powered with 3 AA batteries and AC adapter.
Press the < > button to turn ON/OFF the unit.
VOLUME CONTROL
Press the <V+> or <V-> button (located on the right side of
the unit) to adjust volume.
AA Battery Compartment

7
ZONEGUARD OWNER’S MANUAL
+
LISTEN TO AM/FM
Select Band
Press the <AM/FM> button to listen to AM/FM band,
repeatedly press it to shift between AM and FM.
Tuning in Stations
1. Manual Tuning: Press the < > or < > button
repeatedly to tune into your desired
station.
2. Auto Scan Tuning: Press and hold the < > or < >
button until frequency starts
scanning to auto tune into the next
available station. If the signal is
not strong enough, you can tune
manually to get a better reception.
Storing Stations
When listening to AM/FM band, tune into your desired
station, press the <MENU> button, the LCD will display
<STORE-->. then press either of the 6 <Memory Location>
button, (located on the front of the unit, beyond the
speakers. You can directly press the corresponding memory
location to listen to the station next time.
When listen to FM, adjust the length of the antenna and go
near a window to get better reception,
When listen to AM, rotate the unit to have better reception
of AM.

8
ZONEGUARD OWNER’S MANUAL
+
SETTING THE CLOCK
1. In the unit off mode, press <MENU> button shortly to
enter “SET UP-TIME” mode.
2. Press the < > or < > button. When the hour ashes,
press the < > or < > button to adjust the hour.
3. After adjusting the hour, press < > or < >.
When the minute ashes, press < > or < >
to adjust the minute.
4. Press the <MENU> button to conrm.
NOTE: The clock mode is 12 hours; <AM> displays in
the morning and <PM> displays in the afternoon.

9
ZONEGUARD OWNER’S MANUAL
+
SETTING THE ALARM
Setting The Alarm Time
1. In radio OFF mode, press the <MENU> button, then press
the < > or < > button to enter <SETUP ALARM>
mode.
2. In the <SETUP ALARM> mode, press the < > or < >
button. When the hour ashes, press the < > or < >
button the adjust the hour.
3. After adjusting the hour, press the < > or < > button,
when the minute ashes, press < > or < > to adjust
the minute.
4. Press the <MENU> button to conrm.
Activating and deactivating the alarm
Press the < > button to activate or deactivate
the alarm. If the alarm function is activated, the symbol <
> will show on the display. When the alarm time is reached,
the unit will beep. If the alarm function is deactivated, the
alarm symbol < > will disappear.

10
ZONEGUARD OWNER’S MANUAL
+
SNOOZE FUNCTION
When the alarm activates, press the <SNOOZE> button to
snooze for 5 minutes (the symbol < > will appear in the
display). After 5 minutes, the unit will start to beep again.
Press the < > button to turn off the Snooze function.
LISTEN TO WEATHER BAND
1. Turn on the radio, press <WB> button shortly to receive
the weather band. You can also press the <WB ALERT>
button (the rst button on the left side of the unit)
shortly to enter standby mode to receive weather band.
The symbol <ALERT.WB> appears in the display if the
unit is in standby mode.
2. Press the button < > or < > to select the weather
station(CH1-CH7 is available).
WB ALERT: Receiving alert in silent, no sound when not
receiving any messages.

11
ZONEGUARD OWNER’S MANUAL
+
3. Once receiving the weather information, the
<Warning Light> will be on and you can receive the
weather message in the display. You press <ALERT
ON/OFF> button shortly. The alarm beep will be off,
but you can still receive the message in the display.
4. Press < > or < >, you can read the received 4
messages. If there are not any weather information,
the LCD will display <NO MESSAGE>.
SETTING ALERT
1. In radio off mode, press <MENU> button shortly and
then press < > or < > to enter <ALERT – SIREN/
VOICE/DISPL> mode.
2. Press < > or < > button, when the <SIREN/VOICE/
DISPL> ashes, then press < > or < > to select
<SIREN>, <VOICE> or <DISPL>.
3. Press the <MENU> button to conrm.
[VOICE]: The alarm beep will play about a few seconds
and the LCD will display the message.
[SIREN]: The alarm beep will play about 5 minutes and
the LCD will display the message.
[DISPL]: No alarm beep, just display the message in
the LCD when received a weather information.

12
ZONEGUARD OWNER’S MANUAL
+
SELECT THE COUNTY
1. In the radio off mode, press <MENU> button and then
press < > or < > to enter to <COUNTY – ALL/SINGL/
MULTI> mode.
2. Press < > or < > button with <ALL>, <SINGL> or
<MULTI> ashes, then press < > or < > button
repeatedly to select from the three.
Select <SINGL> if you want to enter a code for a single area.
Select <MULTI> if you want to enter mutiple codes for
different areas.
Select <ALL> if you do not know the local code.
3. Press the < > or < > button to start inputting
county code.
4. Press the < > or < > button to set rst code digit.
5. Repeat step 3 and 4 until all other digits are set.
6. Press the <MENU> button to conrm and exit the menu.

13
ZONEGUARD OWNER’S MANUAL
+
SETTING DEFEAT
1. In radio off mode, press the <MENU> button, then
press the < > or < > button shortly to enter
<DEFEAT-SIREN> mode.
2. Press the < > or < > button to make the alert
mode scroll in the display.
3. Press the < > or < > button to switch from one
alert mode to another, carefully reading each other.
4. Press the < > or < > button to select enable
or disable.
5. Press the <MENU> button to conrm and exit.
ENABLE: Alert when receiving a message.
DISABLE: Displays the message on the LCD
when receiving a message.

14
ZONEGUARD OWNER’S MANUAL
+
MODULE
Power
Indicator
POWER SUPPLY
Battery Power
(3 AA Batteries)
Install 3 AA batteries with correct polarity shown in the
compartment(on the back of the radio). The <POWER
INDICATOR> will be on.
NOTE: The power indicator starts to blink, representing
the battery power is too low.

15
ZONEGUARD OWNER’S MANUAL
+
Battery
Compartment
RECEPTION TEST
After powering the module, press the <TEST> button
(located on the right side of the unit). If the module set off
an alarm beep, the module is receiving normal signals.
NOTE: 1. The test alarm beep will last only for 3 seconds.
2. When receiving a message, the alarm beep will
last for 5 minutes. You can turn off the beep
by pressing the <Alert On/Off> button of the unit
after 10 seconds.
3. Only in <VOICE> and <SIREN> mode, the module
will set off the alarm beep when the unit is
receiving a message.

16
ZONEGUARD OWNER’S MANUAL
+
WARRANTY REGISTRATION
To ensure full warranty coverage or product updates,
registration of your product should be completed as soon
as possible after purchase or receipt.
Please go to http://www.etoncorp.com/productregistration
to register your product.
LIMITED WARRANTY
Retain the warranty information from your warranty
card with your proof of purchase or the Limited Warranty
information can also be viewed at www.etoncorp.com.
SERVICE FOR YOUR PRODUCT
To obtain service for your product, we recommend
rst contacting an Etón service representative at
800-872-2228 US, 800-637-1648 Canada or
[phone] for problem determination and trouble-
shooting. If further service is required, the technical staff
will instruct how to proceed based on whether the radio is
still under warranty or needs non-warranty service.
PRODUCT WARRANTY
Visit http://www.etoncorp.com/productregistration to
register your product and get warranty information.
WARRANTY
If your product is still in warranty and the Etón service
representative determines that warranty service is needed,
a return authorization will be issued and instructions for
shipment to an authorized warranty repair facility.
Do not ship your radio back without obtaining the return
authorization number.
NON-WARRANTY
If your product is no longer under warranty and requires
service our technical staff will refer you to the nearest
repair facility that will be able to best handle the repair.
For service outside of North America, please refer
to the distributor information included at time of
purchase/receipt.

Etón Corporation
Corporate Headquarters
1015 Corporation Way
Palo Alto, California 94303 USA
tel [phone]
tel [phone]
fax [phone]
Etón Canada
5580 Explorer Drive, Suite 503
Mississauga, Ontario L4W 4Y1 Canada
tel [phone]
www.etoncorp.com
Designed by Etón Corporation and assembled in China.
© Copyright 2013 Etón Corporation. All rights reserved. v030713
