Installation, use and maintenance manual
In the kit:
A- Loop nut
B- Ozone duct for HZ canopy
C- Ceiling panel for modular
connection
D- Grease collection container
E- Blind plate for grease filter rail
F- HFK Grease lter
G- Bolts and cap nuts
H- Screws
ABCD
EFGM5/10 HM4/16
H
GM5/10
1- Supply air adjustment plate
2- Supply air connection
3- Ozonator
4- Front panel
5- Suspension points
6- Lighting
7- Exhaust air connection
8- Adjustment plate for exhaust air
9- Front panel
10- Front panel lock
11- "AirGrip" air nozzle system
12- Airflow measuring nozzles
13- HFK grease lter
14- Grease collection container
15- Blind plate for grease lter rail
Safety �������������������������������������������������������������������������������������������������������������������������������������������������������������� 3
1� Removing the ceiling panel ���������������������������������������������������������������������������������������������������������������������� 3
2� Hanging the kitchen canopy and ozone ducts installation ������������������������������������������������������������������������ 4
3� Leveling the canopy ���������������������������������������������������������������������������������������������������������������������������������� 4
4� Opening the front panel ���������������������������������������������������������������������������������������������������������������������������� 4
5� Fastening kitchen canopy modules together �������������������������������������������������������������������������������������������� 5
6� Installing the grease collection container and blind panel for grease lter������������������������������������������������ 6
7� Installing HFK grease lters ���������������������������������������������������������������������������������������������������������������������� 6
8� Installing the ozonator������������������������������������������������������������������������������������������������������������������������������� 7
9� Lighting connection ����������������������������������������������������������������������������������������������������������������������������������� 7
10� Measuring and adjusting airflow ��������������������������������������������������������������������������������������������������������������� 8
11� Accessories����������������������������������������������������������������������������������������������������������������������������������������������� 9
12� Replacing the luminaires������������������������������������������������������������������������������������������������������������������������� 10
13� Kitchen canopy maintenance������������������������������������������������������������������������������������������������������������������ 11
M8
