EUCHNER CES-I-AS2A-C04 User manual

EN
Operating Instructions
Non-Contact Safety Switch
CES-I-AS2A-C04 (Unicode/Multicode)

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
2(Translation of the original operating instructions) 2120544-07-07/20
Contents
1. About this document............................................................................................. 4
1.1. Scope............................................................................................................................................4
1.2. Target group ..................................................................................................................................4
1.3. Key to symbols...............................................................................................................................4
1.4. Supplementary documents ..............................................................................................................4
2. Correct use .......................................................................................................... 5
3. Description of the safety function .......................................................................... 6
4. Exclusion of liability and warranty ......................................................................... 6
5. General safety precautions ................................................................................... 6
6. Function............................................................................................................... 7
6.1. Limit-range monitoring ....................................................................................................................7
6.2. Switching states .............................................................................................................................7
7. Mounting.............................................................................................................. 8
8. Electrical connection ............................................................................................ 9
8.1. Notes about ...........................................................................................................................9
8.2. Setting the AS-Interface address ....................................................................................................10
8.3. Conguration in the AS-Interface safety monitor ..............................................................................10
8.3.1. Dual-channel dependent....................................................................................................10
8.3.2. Dual-channel positively driven............................................................................................10
8.4. AS-Interface status messages........................................................................................................10
9. Setup ................................................................................................................. 11
9.1. LED displays ................................................................................................................................11
9.2. Teach-in function for actuator (only for unicode evaluation) ...............................................................11
9.2.1. Preparing device for the teach-in operation and teaching-in actuator ....................................11
9.3. Functional check...........................................................................................................................12
9.3.1. Electrical function test......................................................................................................12
10. System status table ............................................................................................ 13
11. Technical data .................................................................................................... 14
11.1. Technical data for safety switch CES-I-AS2A-C04 .............................................................................14
11.1.1. Dimension drawing of safety switch CES-I-AS2A-C04...........................................................15
11.2. Typical system times.....................................................................................................................15
11.3. Technical data for actuator CES-A-BBN-C04 ....................................................................................16
11.3.1. Dimension drawing...........................................................................................................16
11.3.2. Operating distances .........................................................................................................16
11.3.3. Typical actuating range in approach direction A ..................................................................17

3
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
11.4. Technical data for actuator CES-A-BDN-06 ......................................................................................18
11.4.1. Dimension drawing...........................................................................................................18
11.4.2. Operating distances .........................................................................................................18
12. Ordering information and accessories................................................................. 19
13. Inspection and service ........................................................................................ 19
14. Service .............................................................................................................. 19
15. Declaration of conformity ................................................................................... 20

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
4(Translation of the original operating instructions) 2120544-07-07/20
1. About this document
1.1. Scope
These operating instructions are valid for all CES-I-AS2A-C04. These operating instructions, the document Safety information
and any enclosed data sheet form the complete user information for your device.
1.2. Target group
Design engineers and installation planners for safety devices on machines, as well as setup and servicing staff possessing
special expertise in handling safety components.
1.3. Key to symbols
Symbol/depiction Meaning
Printed document
Internet
www Document is available for download at www.euchner.com
DANGER
WARNING
CAUTION
Safety precautions
Danger of death or severe injuries
Warning about possible injuries
Caution slight injuries possible
NOTICE
Important!
Notice about possible device damage
Important information
Tip Useful information
1.4. Supplementary documents
The overall documentation for this device consists of the following documents:
Document title
(document number) Contents
Safety information
(2525460) Basic safety information
Operating instructions
(2120544) (this document)
Internet
www
Possibly enclosed data
sheet Item-specic information about deviations or additions
Important!
Always read all documents to gain a complete overview of safe installation, setup and use of the
device. The documents can be downloaded from www.euchner.com. For this purpose enter the doc.
no. in the search box.

5
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
2. Correct use
The series CES-I-AS Coded Electronic Safety switches from EUCHNER are operated as slaves on the safety bus AS-Interface
Safety at Work and function as interlocking devices without guard locking (type4). The device meets the requirements ac-
cording to ENIEC60947-5-3. Devices with unicode evaluation possess a high coding level, devices with multicode evaluation
possess a low coding level.
In combination with a movable guard and the machine control, this safety component prevents dangerous machine functions
from occurring while the guard is open. A stop command is triggered if the guard is opened during the dangerous machine
function.
This means:
ÌStarting commands that cause a dangerous machine function must become active only when the guard is closed.
ÌOpening the guard triggers a stop command.
ÌClosing a guard must not cause automatic starting of a dangerous machine function. A separate start command must
be issued. For exceptions, refer to ENISO12100 or relevant C-standards.
Before safety switches are used, a risk assessment must be performed on the machine, e.g., in accordance with:
ÌENISO13849-1
ÌENISO12100
ÌIEC62061
Correct use includes observing the relevant requirements for installation and operation, e.g.
ÌENISO13849-1
ÌENISO14119
ÌEN60204-1
The safety switch must be used only in conjunction with the designated CES actuators from EUCHNER. On the use of different
actuators, EUCHNER provides no warranty for safe function.
Important!
ÌThe user is responsible for the proper integration of the device into a safe overall system. For this
purpose, the overall system must be validated, e.g. in accordance with ENISO13849-2.
ÌCorrect use requires observing the permissible operating parameters (see technical data).
ÌIf a data sheet is included with the product, the information on the data sheet applies.
ÌIt is only allowed to use components that are permissible in accordance with the table below.
Table 1: Possible combinations for CES components
Safety switch
Actuator
CES-A-BBN-C04-115271 CES-A-BDN-06-104730
CES-I-AS2A-C04-…
(Unicode/Multicode)
Key to symbols Combination possible

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
6(Translation of the original operating instructions) 2120544-07-07/20
3. Description of the safety function
Devices from this series feature the following safety functions:
Monitoring of the guard position
(interlocking device according to ENISO14119)
ÌSafety function:
When the guard is open, no valid code sequence is sent (see chapter 6.2. Switching states on page 7).
ÌSafety characteristics: category, Performance Level, PFHD(see chapter 11. Technical data on page 14).
4. Exclusion of liability and warranty
In case of failure to comply with the conditions for correct use stated above, or if the safety regulations are not followed,
or if any servicing is not performed as required, liability will be excluded and the warranty void.
5. General safety precautions
Safety switches fulll personnel protection functions. Incorrect installation or tampering can lead to fatal injuries to personnel.
Check the safe function of the safeguard particularly
Ìafter any setup work
Ìafter the replacement of a system component
Ìafter an extended period without use
Ìafter every fault
Independent of these checks, the safe function of the safeguard should be checked at suitable intervals as part of the
maintenance schedule.
WARNING
Danger to life due to improper installation or due to bypassing (tampering). Safety components fulll
a personnel protection function.
ÌSafety components must not be bypassed, turned away, removed or otherwise rendered ineffec-
tive. On this topic pay attention in particular to the measures for reducing the possibility of bypass-
ing according to ENISO14119:2013, section 7.
ÌThe switching operation must be triggered only by actuators designated for this purpose.
ÌMounting, electrical connection and setup only by authorized personnel possessing the following
knowledge:
- specialist knowledge in handling safety components
- knowledge about the applicable EMC regulations
- knowledge about the applicable regulations on operational safety and accident prevention
Important!
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating
instructions are always available during mounting, setup and servicing. For this reason you should
archive a printed copy of the operating instructions. You can download the operating instructions from
www.euchner.com.

7
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
6. Function
The safety switch monitors the position of movable guards. When the actuator is moved to/removed from the actuating
range, a corresponding bit sequence is sent via the AS-Interface bus.
The system consists of the following components: coded actuator (transponder) and switch.
Whether the device learns the complete actuator code (unicode) or not (multicode) depends on the respective version.
Devices with unicode evaluation: The actuator must be assigned to the safety switch by a teach-in operation so that it
is detected by the system. This unambiguous assignment ensures a particularly high level of protection against tampering.
The system thus possesses a high coding level.
Devices with multicode evaluation: Unlike systems with unicode evaluation, on multicode devices a specic code is not
requested but instead it is only checked whether the actuator is of a type that can be detected by the system (multicode
detection). There is no exact comparison of the actuator code with the taught-in code in the safety switch (unicode evalua-
tion). The system possesses a low coding level.
When the guard is closed, the actuator is moved towards the safety switch. When the operating distance is reached, power
is supplied to the actuator by the switch and data are transferred.
When the guard is closed and the code is permissible, each CES-I-AS transmits a switch-specic, unique safety code sequence
with 8 x 4 bits via the AS-Interface bus.
The zero sequence is transmitted via the AS-Interface bus when the guard is opened.
In the event of a fault in the safety switch, the zero sequence is sent and the DIA LED illuminates red. The occurrence of
faults is detected at the latest on the next demand to close the safety outputs (e.g.on starting).
6.1. Limit-range monitoring
If the safety door with the actuator should settle over time, the actuator can drift out of the read head actuating range. The
device recognizes this situation and indicates that the actuator is in the limit range by ashing the STATE LED. This allows
the safety door to be readjusted in time. Also see chapter 10. System status table on page 13.
6.2. Switching states
The detailed switching states for your switch can be found in the system status table. All safety outputs, monitoring outputs
and display LEDs are described there.
Guard closed
(actuator in the actuating range and permissible
code detected)
Guard open
(actuator not in the actuating range)
Programming State D0, D1 D2, D3 Monitor diagnostics
Dual-channel
dependent
Synchronization time ≥
100ms /
Dual channel
positively driven
Guard closed Code sequence
Green
If start-up test selected:
yellow ashing on start-up
Intermediate state during opening or closing of the
guard.
Switch S1 (internal) open
Half-se-
quence 00 On opening: yellow ashing
On closing: red
After expiration of the synchronization time:
yellow ashing
Intermediate state during opening or closing of the
guard.
Switch S2 (internal) open
00 Half-se-
quence
Guard open 00 00 Red
Address 0 or communication disrupted – Gray

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
8(Translation of the original operating instructions) 2120544-07-07/20
7. Mounting
CAUTION
Safety switches must not be bypassed (bridging of contacts), turned away, removed or otherwise
rendered ineffective.
ÌObserve ENISO14119:2013, section 7, for information about reducing the possibilities for by-
passing an interlocking device.
NOTICE
Risk of damage to equipment and malfunctions as a result of incorrect installation.
ÌSafety switches and actuators must not be used as an end stop.
ÌObserve ENISO14119:2013, sections 5.2 and 5.3, for information about mounting the safety
switch and the actuator.
ÌFrom the assured release distance Sar, the safety outputs are safely shut down.
ÌWhen mounting several safety switches, observe the stipulated minimum distance to avoid mutual
interference.
.
min. 80 mm
ÌIf the actuator is installed ush, the operating distances change as a function of the installation
depth and the guard material.
ÌObserve direction of arrow on the device (see gure below).
Permissible approach directions
A B
C D
Note the following points:
ÌActuator and safety switch must be easily accessible for inspection and replacement.
ÌActuator and safety switch must be tted so that
- the front faces are at the minimum operating distance 0.8xSao or closer when the guard is closed. To avoid entering
the area of possible side lobes, a minimum distance is to be maintained in case of a side approach direction. See
chapter 11. Technical data, section Typical actuating range for the related actuator.
- when the guard is open up to the distance Sar (assured release distance), a hazard is excluded.
- the actuator is positively mounted on the guard, e.g. by using the safety screws included.
- they cannot be removed or tampered with using simple means.
ÌPay attention to the maximum tightening torque for the read head or safety switch and actuator fastenings of 0.8Nm.

9
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
8. Electrical connection
1 AS-Interface +
3 AS-Interface -
4 Not used
View of plug connector
Safety switch
1
4
3
Figure 1: Terminal assignment, AS-Interface M8 plug connector
CAUTION
Risk of damage to equipment or malfunctions as a result of incorrect connection.
ÌPower devices which are a powerful source of interference must be installed in a separate location
away from the input and output circuits for signal processing. The cable routing for safety circuits
should be as far away as possible from the cables of the power circuits.
ÌTo avoid EMC interference, the physical environmental and operating conditions at the in-
stallation site of the device must comply with the requirements according to the standard
EN60204-1:2006, section 4.4.2 (EMC).
ÌPay attention to any interference elds from devices such as frequency converters or induction
heating systems. Observe the EMC instructions in the manuals from the respective manufacturer.
ÌTo ensure the degree of protection IP67 is achieved, the mating connector must be tightened with
0.3Nm. This value must not be exceeded, however.
Important!
If the device does not appear to function when operating voltage is applied (e.g. green STATE LED
does not ash), the safety switch must be returned unopened to the manufacturer.
8.1. Notes about
Important!
ÌThis device is intended to be used with a Class 2 power source in accordance with UL1310.
As an alternative an LV/C (Limited Voltage/Current) power source with the following properties can
be used:
- This device shall be used with a suitable isolating source in conjunction with a fuse in accordance
with UL248. The fuse shall be rated max. 3.3A and be installed in the max. 30VDC power supply
to the device in order to limit the available current to comply with the requirements. Please note
possibly lower connection ratings for your device (refer to the technical data).
ÌFor use and applications as per the requirements of 1), a connecting cable listed under the UL
category code CYJV2 or CYJV must be used.
1) Notice on the scope of the UL approval: only for applications as per NFPA 79 (Industrial Machinery). The devices have been tested as per the requirements of
UL508 and CSA/ C22.2 no. 14 (protection against electric shock and re).

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
10 (Translation of the original operating instructions) 2120544-07-07/20
8.2. Setting the AS-Interface address
The address can be set prior to or after mounting.
The AS-Interface address of the safety switch is set using an AS-Interface programming device. Addresses 1 to 31 are valid.
The unit is programmed by connecting the programming device to the M8 plug connector of the safety switch with a pro-
gramming cable.
The AS-Interface address can also be set directly on the AS-Interface bus with a master.
Default setting on delivery is address 0 (the AS-Interface LED illuminates red).
8.3. Conguration in the AS-Interface safety monitor
(see operating instructions for the AS-Interface safety monitor)
8.3.1. Dual-channel dependent
The safety switch is congured in the AS-Interface safety monitor with the AS-Interface address set as follows,
for example:
ÌDual-channel dependent
ÌWith or without start-up test
ÌSynchronization time ≥100 ms
8.3.2. Dual-channel positively driven
The safety switch is congured in the AS-Interface safety monitor with the AS-Interface address set as follows,
for example:
ÌDual-channel positively driven
ÌWith or without start-up test
8.4. AS-Interface status messages
A dual LED on the M8 plug connector (red/green) depicts the colors red and green. The following table provides assistance
with troubleshooting.
State
ASI LED Explanation
green Normal operation
red
No data exchange between master and slave
Cause:
- Master in STOP mode
- Slave not in LPS
- Slave with wrong IO/ID
red No data exchange between master and slave
Cause: slave address=0
red/green Device fault in the slave.
Contact the manufacturer.
Cat.
4
Cat.
4

11
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
9. Setup
9.1. LED displays
You will nd a detailed description of the signal functions in chapter 10. System status table on page 13.
LED Color
STATE green
DIA red
9.2. Teach-in function for actuator (only for unicode evaluation)
The actuator must be allocated to the safety switch using a teach-in function before the system forms a functional unit.
During a teach-in operation, the bit sequence 0000 is transmitted, i.e. the system is in the safe state.
Important!
ÌThe teach-in operation may be performed only if the device functions awlessly. The red DIA LED
must not be illuminated.
ÌThe safety switch disables the code of the preceding device if teach-in is carried out for a new
actuator. Teach-in is not possible again immediately for this device if a new teach-in operation is
carried out. The disabled code is released again in the safety switch only after a third code has
been taught-in.
ÌThe safety switch can be operated only with the last actuator taught-in.
ÌIf the switch detects the actuator that was most recently taught-in when in the teach-in standby
state, this state is ended immediately and the switch changes to normal operation.
ÌIf the actuator to be taught-in is within the actuating range for less than 60s, it will not be activat-
ed and the most recently taught-in actuator will remain saved.
9.2.1. Preparing device for the teach-in operation and teaching-in actuator
1. Connect AS-Interface bus to the safety switch.
¨A self-test is performed for approx. 0.5s. After this, the LED ashes cyclically three times and signals that it is in
standby state for teach-in.
Standby state for teach-in remains active for approx. 3minutes.
2. Move new actuator to the read head (observe distance < Sao).
¨Teach-in operation starts, green LED ashes (approx. 1 Hz). During the teach-in operation, the safety switch checks
whether the actuator is a disabled actuator. Provided this is not the case, the teach-in operation is completed after
approx. 60 seconds, and the green LED goes out. The new code has now been stored, and the old code is disabled.
3. To activate the new actuator code from the teach-in operation in the safety switch, the safety switch must then be dis-
connected from the AS-Interface bus for min. 3seconds.
LEDs

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
12 (Translation of the original operating instructions) 2120544-07-07/20
9.3. Functional check
WARNING
Danger of fatal injury as a result of faults in installation and functional check.
ÌBefore carrying out the functional check, make sure that there are no persons in the danger zone.
ÌObserve the valid accident prevention regulations.
9.3.1. Electrical function test
After installation and any fault, the safety function must be fully checked. Proceed as follows:
1. Switch on operating voltage.
¨The machine must not start automatically.
¨The safety switch carries out a self-test. The green STATE LED then ashes at regular intervals.
2. Close all guards.
¨The machine must not start automatically.
¨The green STATE LED illuminates continuously.
3. Enable operation in the control system.
4. Open the guard.
¨The machine must switch off and it must not be possible to start it as long as the guard is open.
¨The green STATE LED ashes at regular intervals.
Repeat steps 2 - 4 for each guard.

13
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
10. System status table
Operating mode
Actuator/door po- sition
CES LED indicator
Output
State
STATE (green) DIA (red)
Normal operation
closed Normal operation, door closed
closed
Flash burst
inverse
5 x
Normal operation, door closed, actuator in the limit range ¨Re-adjust door
open 1 x Normal operation, door open, no actuator taught
open 2 x No actuator taught, teach-in operation not completed successfully
Teach-in operation
(only unicode)
open 3 x
- Door open, device is ready for teach-in for another actuator (only short time after power
UP)
- Switches that have not been taught-in remain in teach-in standby until the teach-in opera-
tion starts
closed 1 Hz Teach-in operation
X Positive acknowledgment after completion of teach-in operation
Fault display
closed 3 x Defective actuator (e.g. fault in code or code not readable)
X Internal fault (e.g. component faulty, data error)
Key to symbols
LED not illuminated
LED illuminated
10 Hz (8 s) LED ashes for 8 seconds at 10 Hz
3 x LED ashes three times, and this is then repeated
X Any state
After the cause has been remedied, faults can generally be reset by opening and closing the guard. If the fault is still dis-
played afterward, briey interrupt the power supply. Contact the manufacturer if the fault could not be reset after restarting.
Important!
If you do not nd the displayed device status in the system status table, this indicates an internal device
fault. In this case, you should contact the manufacturer.

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
14 (Translation of the original operating instructions) 2120544-07-07/20
11. Technical data
NOTICE
If a data sheet is included with the product, the information on the data sheet applies.
11.1. Technical data for safety switch CES-I-AS2A-C04
Parameter Value Unit
min. typ. max.
Housing material PBT plastic
Rubber-support material NBR 80 ±5 Shore
Fixing screw tightening torque - - 0.8 Nm
Dimensions 42 x 25 x 18 mm
Weight (without connection cable) 0.04 kg
Ambient temperature at UB= DC 30 V -25 - +65 °C
Storage temperature -25 - +70
Degree of protection IP67
Safety class III
Degree of contamination 3
Installation orientation Any
Mounting method Non-ush
Connection M8 plug connector, 3-pin
Tightening torque for mating connector max. 0.3Nm
For the approval acc. to UL the following applies Operation with UL-class 2 power supply only
Rated insulation voltage Ui- - 300 V
Rated impulse withstand voltage Uimp - - 1.5 kV
Resilience to vibration Acc. to ENIEC60947-5-2
Switching frequency - - 1 Hz
Ready delay - 0.5 - s
Risk time - - 260 ms
Turn-on time 300 ms
AS-Interface data EA code: 0 ID code: B
AS-i operating voltage 19 - 31.6 DC V
Total current consumption - - 50 mA
Valid AS-Interface addresses 1 - 31
AS-Interface inputs Acc. to AS-Interface Safety at Work
Door monitoring contact D0 - D3
Reliability values acc. to ENISO13849-1
Category 4
Performance Level PL e
PFHD4.5 x 10 -9 / h
Mission time 20 years

15
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
11.1.1. Dimension drawing of safety switch CES-I-AS2A-C04
Active face
Rubber support
(included)
With rubber support
8
25
42
4,8
14,5
15,5
10,6
4,1
32
13
M8
ASi green/red
LED status indication
LED status indication
Active face
11.2. Typical system times
Refer to the technical data for the exact values.
Ready delay: After switch-on, the device carries out a self-test. The system is ready for operation only after this time.
Turn-on time: The max. reaction time ton is the time from the moment when the actuator is in the actuating range to the
moment when the code sequence is sent.
Risk time according to EN60947-5-3: If an actuator moves outside the actuating range, the zero sequence is sent via
the AS-Interface bus.

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
16 (Translation of the original operating instructions) 2120544-07-07/20
11.3. Technical data for actuator CES-A-BBN-C04
Parameter Value Unit
min. typ. max.
Housing material PBT plastic
Rubber-support material NBR 80 ±5 Shore
Dimensions 42 x 25 x 18 mm
Weight 0.03 kg
Ambient temperature - 40 - + 65 °C
Degree of protection IP67/IP69K
Installation orientation Active face opposite read head
Power supply Inductive via read head
11.3.1. Dimension drawing
Active face
4,5
32
14
25
42
6
14,5
18
15,5 With rubber support
Rubber support
NOTICE
Ì2 safety screws M4x20 included.
ÌRubber support included.
11.3.2. Operating distances
Actuating range for center offset m = 0
Approach direction Parameter Value Unit
A B min. typ. max.
Operating distance - 15 -
mm
Assured operating distance sao 1) 10 - -
Switching hysteresis 1) 1 2 -
Assured release distance sar
- in x/z direction
- in y direction
-
-
-
-
40
60
1) On approach in z direction
Approach direction Parameter Value Unit
C D min. typ. max.
Operating distance - 11 -
mm
Assured operating distance sao 1) 6 - -
Switching hysteresis 1) 1 2 -
Assured release distance sar
- in x/z direction
- in y direction
-
-
-
-
40
60
1) On approach in x direction.

17
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
11.3.3. Typical actuating range in approach direction A
(only in combination with actuator CES-A-BBN-C04)
-25
-30
X
10
5
15
20
-20
-25
-30
-40
-35
-15
-10
-5
-10
20
25
30
15
10
40
35
5
Y
-5
-15
-20
Z
10 15 20 25
530
For a side approach direction (y direction) for the actuator and safety switch, a
minimum distance of s = 6 mm must be maintained so that the actuating range
of the side lobes is not entered.
Figure 2: Typical actuating range

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
18 (Translation of the original operating instructions) 2120544-07-07/20
11.4. Technical data for actuator CES-A-BDN-06
Parameter Value Unit
min. typ. max.
Housing material Macromelt PA-based plastic
Dimensions 26 x ∅6 mm
Weight 0.005 kg
Ambient temperature - 40 - + 70 °C
Degree of protection IP67 / IP69K 1)
Installation orientation Active face opposite read head
Power supply Inductive via read head
1) With ush installation.
11.4.1. Dimension drawing
Installation options
26
0
+ 0,5
Ø
30
* min.
30 * 30 *
6,1
0
+ 0,1
6
* Metal-free zone
Operating distance
C
A
Approach
direction
CAUTION
ÌDo not mount at temperatures below 0 °C.
ÌThe actuator can be damaged during mounting.
11.4.2. Operating distances
Actuating range for center offset m = 0
Approach direction Parameter Value Unit
Amin. typ. max.
Operating distance - 19 -
mm
Assured operating distance sao 1) 14 - -
Switching hysteresis 1) - 2 -
Assured release distance sar
- in x/z direction
- in y direction
-
-
-
-
40
60
1) The values apply to surface mounting of the actuator.
Approach direction Parameter Value Unit
Cmin. typ. max.
Operating distance - 15 -
mm
Assured operating distance sao 1) 10 - -
Switching hysteresis 1) - 2 -
Assured release distance sar
- in x/z direction
- in y direction
-
-
-
-
40
60
1) The values apply to surface mounting of the actuator.

19
2120544-07-07/20 (Translation of the original operating instructions)
Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
EN
12. Ordering information and accessories
Tip!
Suitable accessories, e.g. cables or assembly material, can be found at www.euchner.com. To order,
enter the order number of your item in the search box and open the item view. Accessories that can
be combined with the item are listed in Accessories.
13. Inspection and service
WARNING
Loss of the safety function because of damage to the device.
ÌIn case of damage, the entire device must be replaced.
ÌOnly accessories or spare parts that can be ordered from EUCHNER may be replaced.
Regular inspection of the following is necessary to ensure trouble-free long-term operation:
ÌCheck the switching function (see chapter 9.3. Functional check on page 12)
ÌCheck the secure mounting of the devices and the connections
ÌCheck for soiling
No servicing is required. Repairs to the device are only allowed to be made by the manufacturer.
NOTICE
The year of manufacture can be seen in the lower right corner of the rating plate. The current version
number in the format (VX.X.X) can also be found on the device.
14. Service
If servicing is required, please contact:
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16
70771 Leinfelden-Echterdingen
Germany
Service telephone:
[phone]
E-mail:
[e-mail]
Internet:
www.euchner.com

Operating Instructions
Non-Contact Safety Switch CES-I-AS2A-C04
20 (Translation of the original operating instructions) 2120544-07-07/20
15. Declaration of conformity
