EUFY RoboVac 30 User manual

T2116 51005001413 V02
Bedienungsanleitung l Manual del propietario
Manuel d'utilisation l Guida di Utilizzo l Handleiding
Owner’s Manual
RoboVac 30 (T2116)

01
English
Thank you for purchasing RoboVac 30. Read all instructions before using
this product, and keep it properly for future reference.
Table of Contents
02 Important Safety Instructions
05 About Your RoboVac
What's in the Box
RoboVac Anatomy
LED Indication
10 Using Your RoboVac
Important Tips Before Use
Preparation
Charge Your RoboVac
Start / Stop Cleaning
Select a Cleaning Mode
Use the Boundary Strip
Set Time and Scheduled Cleaning
19 Cleaning and Maintenance
Clean the Dust Collector and Filters
Clean the Rolling Brush
Clean the Side Brushes
Replace the Side Brushes
Clean the Sensors and Charging Pins
Clean the Swivel Wheel
24 Troubleshooting
26 Specifications
26 Customer Service
English 01
Deutsch 27
Español 53
Français 79
Italiano 105
Nederlands 131

02 03
English
English
Important Safety Instructions
To reduce the risk of injury or damage, read these safety
instructions carefully and keep them at hand when setting up,
using, and maintaining this device.
WARNING SYMBOLS USED
This is the safety alert symbol. This symbol alerts
you to potential hazards that could result in property
damage and/or serious bodily harm or death.
• This device can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of this
device in a safe way and understand the hazards involved.
• Children should be supervised to ensure they do not play
with this device.
• Cleaning and maintenance shall not be performed by
children without adult supervision.
• This device is only to be used with the power supply unit
provided.
• For the purposes of recharging the battery, only use the
detachable power supply unit provided with this device.
• The battery must be removed from this device before
this device is disposed of. To remove the battery from
this device, first remove the screws on the bottom, then
remove the main PCB and unscrew the battery cover using a
screwdriver. Remove the battery by disconnecting the quick
connector.
• The used battery should be placed in a sealed plastic bag
and disposed of safely according to local environmental
regulations.
• The external flexible cable or cord of the power supply unit
cannot be replaced; if the cord is damaged, the power supply
unit shall be disposed of.
• This device is for indoor use only.
• This device is not a toy. Do not sit or stand on this device.
Small children and pets should be supervised when this
device is operating.
• Store and operate this device in room temperature
environments only.
• Clean with a cloth dampened with water only.
• Do not use this device to pick up anything that is burning or
smoking.
• Do not use this device to pick up spills of bleach, paint,
chemicals, or anything wet.
• Before using this device, pick up objects like clothing and
loose paper. Lift up cords for blinds or curtains, and move
power cords and fragile objects out of the way. If this device
passes over a power cord and drags it, an object could be
pulled off a table or shelf.
• If the room to be cleaned has a balcony, a physical barrier
should be used to prevent access to the balcony and to
ensure safe operation.
• Do not place anything on top of this device.
• Be aware that this device moves around on its own. Take
care when walking in the area where this device is operating
to avoid stepping on it.
• Do not operate this device in areas with exposed electrical
outlets on the floor.
• Do not expose the electronics of this device, its battery, or
the integrated Charging Base. There are no user-serviceable
parts inside.

04 05
English English
• Do not use this device on an unfinished, unsealed, waxed
or rough floor. It may result in damage to the floor and this
device. Use only on hard floor surfaces or low-pile carpet.
• This device has been designed to be used on floors without
scratching them. We still recommend that you test this
device on a small area of the room to be cleaned to ensure
no scratches are made before cleaning the whole room.
Notice
This symbol on the device or its packaging indicates:
Do not dispose of electrical appliances as unsorted
municipal waste; use separate collection facilities.
Contact your local authority for information regarding
the collection systems available. If electrical appliances
are disposed of in landfills or dumps, hazardous
substances can leak into the groundwater and get into
the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the
retailer is legally obliged to take back your old appliance
for disposal at least free of charge.
Declaration of Conformity
Hereby, Anker Innovations Limited declares that the product type T2116 is in compliance
with Directives 2014/35/EU & 2014/30/EU.
The full text of the EU declaration of conformity is available at the following internet
address: https://www.eufylife.com/
Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong
About Your RoboVac
What's in the Box
RoboVac 30
Power Adapter Cleaning Tool Side Brushes (x4)
Charging Base Remote Control
(AAA Battery x2)
Additional
High-Performance
Filter
Boundary Strips
6.6 ft/2 m Length
(x2)
Adhesive Tapes (x4) Owner’s Manual &
Other Documents
Additional
Foam Filter
Cable Ties (x5)

06 07
English English
RoboVac Anatomy
Top & Side
Auto cleaning Start/Stop button
Bumper
Dust collector
Dust collector release button
Infrared sensor
Bottom
Drop sensors
Charging contact pins
Battery compartment
Brush guard
Rolling brush
Main power switch (On/O)
Hall sensors
Swivel wheel
Side brushes
Wheels
Dust collector
Dust Collector
Pre-filter
Foam filter
High-performance filter
Suction Inlet
Dust collector
Suction inlet
Charging Base
Charging contact pins
Status light
Power cord storage
compartment
Power socket

08 09
English English
Remote Control
1
2
3
5
4
6
7
8
9
10
Start Auto cleaning
Start Auto cleaning
Stop cleaning
Start Spot cleaning
Start Edge cleaning
Adjust time
Adjust suction power level in Auto/Single Room
Cleaning mode
Control cleaning direction manually
Adjust the hour and minute
Start Single Room cleaning
Return RoboVac to Charging Base
Schedule Auto cleaning start time
Remote Control Display
6
1
2
3
4
5
7
8
9
10
Returning to Charging Base
Auto cleaning mode selected
Spot cleaning mode selected
Edge cleaning mode selected
Single Room cleaning mode selected
Clock
Standard suction power enabled
BoostIQ™ dynamic suction power enabled
Max suction power enabled
Scheduled cleaning time
Install 2 AAA batteries before using the remote control for the first time. Make sure
the positive and negative ends are facing the correct polarity direction as marked in
the battery compartment.
LED Indication
You can see the status of RoboVac from the LED indicator.
(Status Light) Status
Breathing orange Charging
Solid blue Standby / Cleaning / Fully charged
Solid orange Low power and returning to Charging Base
O
• RoboVac is off.
• To conserve power, the light automatically turns off
when RoboVac is not docked to the Charging Base
and has been inactive for 1 minute.
Flashing / Solid red + Beeping
RoboVac has an error.
Refer to the “Troubleshooting>Error Tone” section in this
manual for solutions.

10 11
English English
Using Your RoboVac
Important Tips Before Use
abc
d
e
f
a
Remove power cords and small objects from the floor that may entangle RoboVac. You
can use the supplied cable ties to organize your wires and power cords.
b
Fold tasseled edges of area rugs underneath to prevent tangling RoboVac. Avoid
cleaning very dark-colored high-pile rugs or rugs thicker than 1.02 in/26 mm as they
may cause RoboVac to malfunction.
c
Keep RoboVac away from spaces lower than 2.87 in/73 mm to prevent RoboVac from
getting stuck. If necessary, place a physical barrier to block off the problem areas.
d
Keep RoboVac away from wet areas.
e
RoboVac may climb on top of objects less than 0.63 in/16 mm in height. Remove these
objects if possible.
f
Anti-drop sensors prevent RoboVac from tumbling down stairs and steep drops. They
may work less effectively if dirty or used on reflective/very dark-colored floors. It is
recommended to apply the Boundary Strip(s) to block off areas where RoboVac may fall.
Place physical barriers or Boundary Strips in front of fireplaces and areas that
may cause damage to RoboVac if entered.
Preparation
Install the side brushes before use.
Turn on the main power switch on the bottom of RoboVac.
Remove the sticker next to the power switch, and the foam blocks beside the
bumper before use.
Place the Charging Base on a hard, level surface and against a wall.

12 13
English English
Remove objects within 3 ft/1 m of the left and right side and within 6 ft/2 m of the
front of the Charging Base.
Connect the round connector of the adapter into the power socket on the Charging
Base and the other end into a wall outlet.
• When the Charging Base connects to AC power, the LED indicator on the
Charging Base is SOLID WHITE.
- Install the Charging Base in a location that RoboVac
can easily access. It is recommended to place the
Charging Base against a wall, and on a hard-level
surface rather than on rugs or carpets.
- Always keep the Charging Base plugged in, otherwise
RoboVac will not automatically return to it.
T
- Install the Charging Base in a location that RoboVac
can easily access. It is recommended to place the
Charging Base against a wall, and on a hard-level
surface rather than on rugs or carpets.
- Always keep the Charging Base plugged in, otherwise
RoboVac will not automatically return to it.
Charge Your RoboVac
• RoboVac has a pre-installed rechargeable battery that has to be fully charged before
use.
• RoboVac returns to the Charging Base at the end of a cleaning cycle or when its
battery is running low.
Method 1: Attach RoboVac to the Charging Base by aligning its charging pins with the
charging pins on the base.
Method 2: Press on the remote control to return RoboVac to the Charging Base.
Turn off the main power switch if RoboVac will not be used for a long period of
time. To preserve the battery’s lifespan, recharge at least once every 6 months.
Start / Stop Cleaning
Make sure the main power switch on the bottom of RoboVac is turned on before use.
1. Press on RoboVac or / on the remote control to start cleaning in Auto Mode.
2. Press on RoboVac or on the remote control to stop cleaning.

14 15
English English
Select a Cleaning Mode
You can also select a cleaning mode via the EufyHome app.
1. Auto cleaning
RoboVac optimizes its cleaning path by selecting different cleaning modes automatically
until cleaning is complete. This is the most commonly used cleaning mode.
Press on RoboVac or / on the remote control to start cleaning in Auto Mode.
- RoboVac will return to the Charging Base automatically when the battery level becomes
low or when RoboVac finishes cleaning.
- By default, RoboVac starts in Auto cleaning mode when it is turned on.
BoostIQ™ Feature
When the BoostIQ™ feature is enabled, RoboVac will automatically increase the suction
power if it detects stronger power is needed to ensure the best clean. BoostIQ™ is ideal for
cleaning thicker carpets and hard-to-sweep messes, which will reduce the total cleaning
time, but increase the noise level. If the vacuuming noise caused by BoostIQ™ disturbs you,
you can disable this feature. This feature only works in Auto and Quick cleaning modes.
In Auto or Quick cleaning mode, press on the remote control repeatedly to adjust the
suction power level.
• The corresponding icon is displayed on the remote control.
Icon Suction Power Level
Standard
Standard power
BoostIQ
Automatically switches between Standard and Enhanced power (default)
Max
Maximum power
When RoboVac starts cleaning in Auto or Quick mode the next time, it will clean
according to the suction power level you previously selected.
2. Spot cleaning
RoboVac intensively cleans a specific area in a spiral pattern, useful if there is a
concentrated area of dust or debris. In Spot mode, RoboVac will stop cleaning after 2
minutes.
Press on the remote control to start cleaning in Spot Mode.
3. Edge cleaning
RoboVac reduces its speed when it detects a wall and then follows the wall to ensure the
edge is cleaned thoroughly. In Edge mode, RoboVac will clean for 20 minutes and return to
the Charging Base.
Press on the remote control to start cleaning in Edge Mode.

16 17
English English
4. Single Room cleaning
RoboVac intensively cleans one single room and stops after 30 minutes. Select this mode
only when one specific room needs to be cleaned. Make sure to confine RoboVac to the
room by closing the door.
Press on the remote control to start cleaning in Single Room Mode.
.
5. Manual cleaning
You can direct RoboVac to clean a particular area by using the directional buttons on the
remote control.
Turn left
Move backward
Turn right
Move forward
Use the Boundary Strip
With the Boundary Strip, you can keep RoboVac away from any area or item you do not
want RoboVac to clean. RoboVac will recognize the Boundary Strip and will not cross into
the blocked-off area.
1. Identify the area or item you do not want RoboVac to get close to.
2. If necessary, use scissors to cut the Boundary Strip to a shorter length. Be sure to
correctly measure the length before cutting.
3. Apply the supplied strips of adhesive tape to lay the Boundary Strip flat on the floor.
Make sure the strip is placed FLAT on the floor or under an area rug.
- If the Boundary Strip is rolled up, remove and then re-apply on the floor with
adhesive tape. Otherwise the Boundary Strip may not work well.
- Make sure the Boundary Strip is placed on the same surface plane RoboVac is
used on.
- Be careful not to damage the floor when using adhesive tape. It is not
recommended for use on carpets.
- Keep the Boundary Strip away from objects that emit excessive heat.

18 19
English English
Set Time and Scheduled Cleaning
Set Time
Make sure the time is set correctly to your local time before setting a scheduled cleaning.
Make sure the main power switch on the bottom of RoboVac is turned on.
Press on the remote control. The time will blink on the display.
Press to set the “hour” and “minute”.
Note: Make sure AM/PM is set correctly.
Press or to save the setting. RoboVac will BEEP ONCE to indicate the time has
been set.
ON
To ensure the time is set successfully, make sure RoboVac is turned on. You will hear
a beep when the time has been set.
Set a Scheduled Cleaning
You can schedule RoboVac to start cleaning at a specified time. To cancel a previously
scheduled cleaning, press and hold for 3 seconds until RoboVac beeps twice and
disappears.
Note: Before setting a scheduled cleaning, make sure the time has been set correctly to
your local time; refer to the previous section “Set Time” for how to set the time.
Make sure the main power switch on the bottom of RoboVac is turned on.
Press on the remote control. will blink on the display.
Press to set the “hour” and “minute”.
Note: Make sure AM/PM is set correctly.
Press or to save the setting. RoboVac will BEEP ONCE to indicate the
schedule has been set.
1
4
ON
To ensure the schedule is set successfully, make sure RoboVac is turned on. You
will hear a beep when the schedule has been set.
Cleaning and Maintenance
For optimal performance, follow the instructions below to clean and maintain RoboVac
regularly. The cleaning/replacement frequency will depend on your usage habits of
RoboVac.
Recommended cleaning/replacement frequency
RoboVac Part Cleaning Frequency Replacement Frequency
Dust Collector After each use -
Filters Once every week Every 2 months
Rolling Brush Once every week Every 6-12 months
Side Brushes Once every month Every 3-6 months (or when visibly worn)
Brush Guard Once every month Every 3-6 months (or when the silicone
rubber strip on the brush guard becomes
visibly worn)
Sensors Once every month -
Charging Pins Once every month -
Swivel Wheel Once every month -

20 21
English English
Clean the Dust Collector and Filters
Press the dust collector release button to pull the dust collector out.
Open and empty the dust collector.
2
1
Remove the pre-filter by pulling the hooks as shown.
Take out the foam filter and high-performance filter.
Clean the dust collector and filters with a vacuum cleaner or a cleaning brush.
Put the filters and pre-filter back together in the dust collector.
Push the dust collector back into the main unit.
You can wash the dust collector, pre-filter and foam filter with water. Be sure to
air-dry them thoroughly before reassembling. Do not wash the high-performance
filter with water, as it may damage the filter and reduce the suction power.
Clean the Rolling Brush
Pull on the release tabs to unlock the brush guard as shown.
Lift the rolling brush to remove.
Clean the rolling brush with the provided cleaning tool or a vacuum cleaner.
Reinstall the rolling brush by inserting the fixed protruding end first and then clicking
into place.
Press down to snap the brush guard into place.
1
4
2
5
3
Clean the Side Brushes
Foreign substances, such as hair, can easily get tangled in the side brushes, and dirt may
adhere to them. Be sure to clean them regularly.
Remove the side brushes.

22 23
English English
Carefully unwind and pull off any hair or string that is wrapped between the main unit
and the side brushes.
Use a cloth dampened with warm water to remove dust from the brushes or to gently
reshape them.
Only use the side brushes when they are completely dry.
Replace the Side Brushes
The side brushes may become bent or damaged after being used for a period of time.
Follow the instructions below to replace them.
Pull off the old side brushes and snap the new ones into place.
Clean the Sensors and Charging Pins
To maintain the best performance, clean the drop sensors and charging pins regularly.
• Dust off the drop sensors and charging contact pins using a cloth or cleaning brush.
Clean the Swivel Wheel
Hair or dust particles can easily get entangled in the swivel wheel. Be sure to clean the
swivel wheel periodically and as needed.
Wheel
Axle
Pull out the swivel wheel.
Clean any hair or debris wrapped around the wheel or entangled inside the wheel
cavity.
Reinstall the wheel and push in until it clicks into place.
- You can clean the swivel wheel with water.
- Use the swivel wheel only when it is completely dry.

24 25
English English
Troubleshooting
Problems Solutions
RoboVac cannot be
activated.
• Make sure the main power switch is in the ON position.
• Make sure the battery is fully charged.
• Replace the batteries (2 AAA) in the remote control.
• Make sure the remote control is within range (16 ft/5 m) of
RoboVac.
• If you still have trouble, turn o the main power switch and
then turn it back on.
The remote control
does not work.
• Replace the batteries in the remote control.
• Make sure RoboVac is turned on and fully charged.
RoboVac stops
working suddenly.
• Check if RoboVac is trapped or stuck on an obstacle.
• Check if the battery level is too low.
• If you still have trouble, turn o the main power switch, wait
for 2 seconds, and then turn it back on.
You cannot schedule
cleanings.
• Make sure the main power switch on the bottom of RoboVac
is turned on.
• Make sure the time, time of day (AM/PM), and the scheduled
time have been set correctly.
• Check if RoboVac’s power is too low to start cleaning.
Suction power is
weak.
• Check if any obstructions are blocking the suction inlet.
• Empty the dust collector.
• Clean the filters with a vacuum cleaner or a cleaning brush.
• Check if the filters are wet due to water or other liquid on the
floor. Air-dry the filters completely before use.
RoboVac cannot be
charged.
• Check if the indicator on the Charging Base lights up. If
not, contact the eufy service center to repair or replace the
Charging Base.
• Dust o the charging contact pins with a dry cloth.
• Check if you can hear a beep when RoboVac is docked onto
the Charging Base. If not, contact the eufy service center to
repair or replace the Charging Base.
RoboVac cannot
return to the
Charging Base .
• Remove objects within 3 ft/1 m to the left and right side and
within 6 ft/2 m of the front of the Charging Base.
• When RoboVac is in the vicinity of the Charging Base, it will
return more quickly. However, if the Charging Base is located
far away, RoboVac will need more time to return. Please be
patient as it works its way back.
• Clean the charging contact pins.
Problems Solutions
The rolling brush
does not rotate.
• Clean the rolling brush.
• Check if the rolling brush and brush guard have been installed
properly.
RoboVac’s
movements or travel
path are abnormal.
• Clean the sensors carefully with a dry cloth.
• Restart RoboVac by turning the power switch o and on.
Error Tones
When RoboVac is in trouble, it will emit a series of short or long beeps and the red indicator
on RoboVac will be solid or flashing.
Flashing red indicator light
Error Tone Cause Solution
One beep
• RoboVac is stuck and one of the
wheels is not making contact with
the floor (hanging in mid-air).
• RoboVac may be in an extremely
large room and the bumper is not
registering obstacles.
Restart cleaning in a new location.
Two beeps RoboVac’s bumper is stuck. Tap RoboVac’s bumper several times to dislodge any debris that may be
trapped underneath.
Three beeps
• RoboVac’s drop sensors are dirty.
• RoboVac is stuck on the ledge of a
staircase and cannot reverse.
• Clean the drop sensors gently
with a dry cloth.
• Place RoboVac in a new location.
• Use a physical barrier to block o
the problem area.
Four beeps RoboVac’s power level is too low. Manually charge RoboVac for at least
5 hours.
Solid red indicator light
Error Tone Cause Solution
One beep RoboVac’s left/right wheel is
stuck. Turn o RoboVac and remove any hair or debris from the left/right wheel.
Two beeps RoboVac’s side brush is stuck. Turn o RoboVac and remove any hair or
debris from the side brush.
Three beeps RoboVac’s suction fan is stuck.
• Turn o RoboVac, then remove and
empty the dust collector.
• Make sure the suction inlet is not
blocked by any hair or debris.
Four beeps RoboVac’s rolling brush is stuck. Turn o RoboVac and remove any hair or
debris from the rolling brush.

27
Deutsch
26
English
Vielen Dank, dass Sie den RoboVac 30 gekauft haben. Lesen Sie alle
Anweisungen, bevor Sie dieses Produkt verwenden, und bewahren Sie sie gut auf.
Inhaltsverzeichnis
28 Wichtige Sicherheitsinformationen
31 Über Ihren RoboVac
Im Lieferumfang
Aufbau des RoboVac
LED-Anzeige
36 Verwendung Ihres RoboVac
Wichtige Tipps vor der Verwendung
Vorbereitung
Aufladen Ihres RoboVac
Reinigung starten / stoppen
Auswählen eines Reinigungsmodus
Verwenden des Begrenzungsstreifens
Reinigungszeitplan einstellen
45 Reinigung und Wartung
Reinigen von Staubbehältern und Filtern
Reinigen der rotierenden Bürste
Reinigen der seitlichen Bürsten
Auswechseln der seitlichen Bürsten
Reinigen der Sensoren und Ladekontaktstifte
Reinigen des Schwenkrads
50 Fehlerbehebung
52 Technische Daten
52 Kundenservice
Specifications
Product Model T2116
Input 19 V 0.6 A
Battery Voltage DC 14.4 V
Power Consumption 40 W
Battery Type DC 14.4 V
Li-ion 2600 mAh
Dust Collector Capacity 0.6 L
Cleaning Time Max. 100 mins
Charging Time 300 - 360 mins
Input 19 V 0.6 A
Output 19 V 0.6 A
Customer Service
For FAQs and more information, please visit www.eufylife.com.
@EufyOcial
@EufyOcial
@EufyOcial @EufyOcial
Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong

28 29
Deutsch Deutsch
Wichtige Sicherheitsinformationen
Um das Risiko von Verletzungen oder Schäden zu verringern,
lesen Sie diese Sicherheitsinformationen sorgfältig durch und
halten Sie sie beim Einrichten, Verwenden und Warten des
Geräts griffbereit.
VERWENDETE WARNSYMBOLE
Dies ist das Sicherheitswarnsymbol. Dieses
Symbol weist Sie auf mögliche Gefahren hin, die
zu Sachschäden und/oder schweren Verletzungen
oder Todesfällen führen können.
• Dieses Gerät kann von Kindern ab 8 Jahren sowie von
Personen mit physischen, sensorischen, psychischen oder
geistigen Beeinträchtigungen verwendet werden, sofern
sie angemessene Überwachung oder Einweisung in die
sichere Verwendung des Geräts erhalten und die damit
einhergehenden Risiken richtig einordnen können.
• Kinder sollten beaufsichtigt werden, um sicherzustellen,
dass sie nicht mit diesem Gerät spielen.
• Reinigung und Wartung dürfen nicht von Kindern ohne
Aufsicht von Erwachsenen durchgeführt werden.
• Dieses Gerät darf nur mit dem im Lieferumfang enthaltenen
Netzteil verwendet werden.
• Verwenden Sie zum Aufladen des Akkus nur das
abnehmbare Netzteil, das im Lieferumfang des Geräts
enthalten ist.
• Der Akku muss aus diesem Gerät entfernt werden, bevor
das Gerät entsorgt wird. Zum Entfernen des Akkus aus
diesem Gerät entfernen Sie die Schrauben an der Unterseite,
entfernen Sie dann die Hauptplatine, und öffnen Sie die
Akkuabdeckung mit einem Schraubendreher. Entfernen Sie
den Akku, indem Sie die Schnellkupplung trennen.
• Der gebrauchte Akku muss in einem versiegelten
Plastikbeutel aufbewahrt und gemäß den örtlichen
Umweltvorschriften entsorgt werden.
• Das externe flexible Kabel oder Netzkabel des Netzteils kann
nicht ausgetauscht werden. Wenn das Kabel beschädigt ist,
muss das Netzteil entsorgt werden.
• Der Adapter darf ausschließlich in Innenbereichen
verwendet werden.
• Dieses Gerät ist kein Spielzeug. Setzen oder stellen Sie sich
nicht auf das Gerät. Kleine Kinder und Haustiere sollten
beaufsichtigt werden, wenn das Gerät in Betrieb ist.
• Lagern und betreiben Sie dieses Gerät nur in Umgebungen
mit Raumtemperatur.
• Verwenden Sie zur Reinigung nur ein mit ein wenig Wasser
angefeuchtetes Tuch.
• Saugen Sie mit diesem Gerät keine brennenden oder
rauchenden Objekte auf.
• Verwenden Sie dieses Gerät nicht zum Aufsaugen von
verschütteten Bleichmitteln, Farben, Chemikalien oder
Flüssigkeiten.
• Heben Sie vor Verwendung dieses Geräts Objekte wie
Kleidung und loses Papier vom Boden auf. Binden Sie
Jalousien- oder Vorhangkordeln hoch, und entfernen Sie
Netzkabel und zerbrechliche Gegenstände vom Boden.
Wenn das Gerät über ein Netzkabel rollt und es mitzieht,
können die entsprechenden Elektroartikel von Tischen oder
Regalen gerissen werden.
• In Räumen mit Balkon sollte eine physische Barriere
verwendet werden, um den Zugang zum Balkon zu
verhindern und einen sicheren Betrieb zu gewährleisten.
• Stellen Sie keine Gegenstände auf das Gerät.
• Beachten Sie, dass dieses Gerät sich eigenständig bewegt.
Gehen Sie beim Betreten des Bereichs, in dem das Gerät

30 31
Deutsch Deutsch
betrieben wird, vorsichtig vor, damit Sie nicht versehentlich
auf das Gerät treten.
• Betreiben Sie dieses Gerät nicht in Bereichen mit frei
liegenden Bodensteckdosen.
• Legen Sie die Elektronik dieses Geräts, des Akkus oder der
integrierten Ladestation nicht frei. Keine Teile im Inneren des
Geräts können durch den Benutzer gewartet werden.
• Verwenden Sie dieses Gerät nicht auf Rohbeton oder auf
unversiegeltem, gewachstem oder rauem Bodenbelag.
Andernfalls kann es zu Schäden am Boden und am Gerät
kommen. Verwenden Sie das Gerät nur auf Hartbelägen
oder Kurzflorteppichen.
• Dieses Gerät wurde für die kratzerfreie Verwendung auf
Böden entwickelt. Dennoch empfehlen wir, dieses Gerät in
einem kleinen Bereich des zu reinigenden Raums zu testen,
um vor dem Reinigen des ganzen Raums sicherzustellen,
dass keine Kratzer entstehen.
Hinweis
Dieses Symbol auf dem Gerät oder der Verpackung hat
die folgende Bedeutung:
Entsorgen Sie elektrische Geräte nicht im
Haushaltsabfall; geben Sie sie bei separaten
Sammelstellen ab. Wenden Sie sich an die örtliche
Kommunalverwaltung, um Informationen über
die verfügbaren Sammelstellen einzuholen. Wenn
Elektrogeräte in Mülldeponien entsorgt werden,
können Gefahrstoffe in das Grundwasser und somit
in die Nahrungskette gelangen und Ihre Gesundheit
und Ihr Wohlbefinden beeinträchtigen. Wenn Sie neue
Elektrogeräte kaufen, sind die Einzelhändler gesetzlich
verpflichtet, Ihre Altgeräte kostenlos zur Entsorgung
anzunehmen.
Über Ihren RoboVac
Im Lieferumfang
RoboVac 30
Netzteil Reinigungsdüse Seitenbürsten
(× 4)
Ladestation Fernbedienung
(Zwei AAA-Batterien)
Zusätzlicher
Hochleistungsfilter
Begrenzungsstreifen
2 m Länge (x 2)
Gebrauchsanweisung
und andere Unterlagen
Zusätzlicher
Schaumstofilter
Kabelbinder (x 5)
Klebeband (x 4)

32 33
Deutsch Deutsch
Aufbau des RoboVac
Oberseite und Seite
Start/Stopp-Taste für automatische Reinigung
Stoßfänger
Staubbehälter
Entriegelungstaste für Staubbehälter
Infrarotsensor
Unterseite
Sturzsensoren
Ladekontaktstifte
Batteriefach
Bürstenschutz
Rollbürste
Netzschalter (Ein/Aus)
Flursensoren
Schwenkrad
Seitliche Bürsten
Räder
Staubbehälter
Staubbehälter
Vorfilter
Schaumstofilter
Hochleistungsfilter
Ansaugöffnung
Staubbehälter
Ansaugeinlass
Ladestation
Ladekontaktstifte
Statusleuchte
Aufbewahrungsfach
für Netzkabel
Steckdose

34 35
Deutsch Deutsch
Fernbedienung
1
2
3
5
4
6
7
8
9
10
Automatische Reinigung Starten oder Beenden
Automatische Reinigung Starten oder Beenden
Reinigungsvorgang beenden
Starten Sie eine Fleckenreinigung
Starten Sie eine Eckenreinigung
Zeiteinstellungen
Saugkraft im Automatischen / Raumreinigungs-
Modus einstellen
Manuelle Steuerung des RoboVac
Zeiteinstellung
Starten Sie eine Einzelzimmer Reinigung
Rufen Sie den RoboVac an die Ladestation zurück
Planen Sie die Reinigungsstartzeit
Fernbedienungsanzeige
6
1
2
3
4
5
7
8
9
10
Zurück zur Ladestation
Automatischer Reinigungsmodus aktiviert
Fleckenentfernungsmodus aktiviert
Eckenreinigungsmodus aktiviert
Ein-Zimmer-Reinigungsmodus aktiviert
Uhrzeit
Standard-Saugkraft aktiviert
Starke BoostIQ™ Saugkraft aktiviert
Maximale Saugkraft aktiviert
Voreingestellte Reinigungszeit
Geben Sie zwei AAA-Batterien in das Batteriefach, bevor Sie die Fernbedienung
benutzen. Achten Sie darauf, dass die Kontakte der Fernbedienung mit denen der
Batterien übereinstimmen.
LED-Anzeige
Sie können den RoboVac-Status mithilfe der LED-Anzeige ablesen.
(LED-Anzeige des
RoboVac) Status
Rot blinkend Lädt
Durchgehend blau Standby / Reinigung im Gange / Zurück zur Ladestation
Rot Energiesparmodus an und zurück zur Ladestation
Aus
• RoboVac ist ausgeschaltet.
• Um Energie zu sparen, schaltet die Anzeige nach
1 Minute Inaktivität automatisch aus, wenn sich
RoboVac nicht an der Ladestation befindet.
Blinkend / durchgehend rot
und Signalton erklingt
Fehlermeldung
Wenden Sie sich an das Kapitel "Fehlerbehebung" in dieser
Bedienungsanleitung, um das Problem zu lösen.

36 37
Deutsch Deutsch
Verwendung Ihres RoboVac
Wichtige Tipps vor der Verwendung
abc
de
f
a
Entfernen Sie Netzkabel und kleine Gegenstände, in denen der RoboVac sich verfangen
könnte, vom Fußboden. Sie können die im Lieferumfang enthaltenen Kabelbinder
verwenden, um Kabel und Stromkabel zu organisieren.
b
Falten Sie Teppichfransen unter den Teppichrand, damit der RoboVac sich nicht in ihnen
verfängt. Vermeiden Sie sehr dunkle Teppiche, hochflorige Teppiche oder Teppiche von
mehr als 26 mm Dicke, denn sie können zu Fehlfunktionen des RoboVac führen.
c
Sorgen Sie für ausreichenden Abstand des RoboVac von Bereichen mit weniger als
73 mm Höhe, damit RoboVac sich nicht einklemmt. Sperren Sie derartige potenzielle
Problembereiche ggf. mit einer physischen Barriere ab.
d
Halten Sie den RoboVac von feuchten Bereichen fern.
e
Der RoboVac kann auf Objekte bis zu einer Höhe von 16 mm klettern. Entfernen Sie
derartige Objekte, sofern möglich.
f
Sturzsensoren verhindern, dass der RoboVac Treppen und steile Stufen hinunter fällt. Ihre
Funktion kann durch Verschmutzung oder stark reflektierende/sehr dunkle Bodenbeläge
beeinträchtigt werden. Wir empfehlen daher, einen oder mehrere Begrenzungsstreifen
zum Absperren von Bereichen zu verwenden, in denen der RoboVac herunterfallen
könnte.
Legen Sie physische Barrieren oder Begrenzungsstreifen vor Kamine und
Bereiche, die zu Schäden am RoboVac führen könnten.
Vorbereitung
Montieren Sie vor dem Gebrauch des Geräts die seitlichen Bürsten.
Schalten Sie den Netzschalter an der Unterseite des RoboVac ein.
Entfernen Sie vor dem Gebrauch den Aufkleber neben dem Netzschalter und die
Schaumstoffblöcke neben dem Stoßfänger.
Stellen Sie die Ladestation auf einer festen, ebenen Fläche an eine Wand.
