Euphonix System 5 User manual

Installation Guide
Document Revision: 2.5
Part Number: 840-07591-05
Release Date: March, 2007
Euphonix, Inc.
220 Portage Ave.
Palo Alto, California 94306
Phone: [phone]
Fax: [phone]
Web: http://www.euphonix.com
e-mail: [e-mail]
Euphonix System
5

In the interest of continued product development, Euphonix reserves the right to make
improvements in this manual and the products it describes at any time, without notice or
obligation.
System 5, S-5, PatchNet, eMix, EuCon, R-1, Audio Deck, Studio Hub are trademarks of
Euphonix, Inc.
©2002 Euphonix, Inc. All rights reserved worldwide. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form by any means without written permission of Euphonix, Inc.

Euphonix System 5 Installation Guide
iii
Table of Contents
List of Figures .........................................................................................................................v
List of Tables ........................................................................................................................ vii
Chapter 1: System 5 Overview ....................................................................................9
Introduction to System 5.......................................................................................9
Digital Signal Processing (DSP)...............................................................9
The System 5 Console ..............................................................................9
Analog and Digital I/O............................................................................10
Mic inputs ...............................................................................................11
Monitoring ..............................................................................................11
Power ......................................................................................................11
Digital Sync ............................................................................................11
System Control Connections...............................................................................12
Estimating System Requirements .......................................................................14
Number of CM408T Eight-channel Sections............................................14
I/O Specification .....................................................................................15
Chapter 2: Interconnecting System Components..........................................17
Component Specifications ..................................................................................17
Typical Room and Equipment Layout for System 5 ..........................................20
Typical Console Layout......................................................................................20
Console Dimensions ...........................................................................................21
Suggested Rack Elevations .................................................................................23
Audio Hookup.....................................................................................................25
Synchronization Hookup ....................................................................................26
MADI Hookup ....................................................................................................27
Control Hookup ..................................................................................................31
Number of DF66 DSP Line Cards...........................................................14

Euphonix System 5 Installation Guide
iv
Chapter 3: System 5 Components ..........................................................................33
DF66 SuperCore..................................................................................................33
Sync Card.................................................................................................35
DSP Line Card.........................................................................................35
SP661 Signal Processor ..........................................................................35
System 5 Console................................................................................................36
SC263 System Computer....................................................................................38
PC254i Interface Computer ................................................................................39
MC524 Monitor Interface ...................................................................................40
Input/Output Connections.......................................................................41
ML530 Mic/Line Interface .................................................................................46
Failover Switch ...................................................................................................48
AM713 Analog to MADI Converter...................................................................49
Front Panel ..............................................................................................49
Rear Panel ...............................................................................................50
MA703 MADI to Analog Converter...................................................................52
Front Panel ..............................................................................................52
Rear Panel ...............................................................................................53
DM714 AES/EBU to MADI Converter..............................................................55
Front Panel ..............................................................................................55
Rear Panel ...............................................................................................56
MD704 MADI to AES/EBU Converter..............................................................58
Front Panel ..............................................................................................58
Rear Panel ...............................................................................................59
FC726 Format Converter ....................................................................................61
GP132 .................................................................................................................68
Input and Output Connections ................................................................68
Connector Pinouts (DB-25 RT1–RT4) ...................................................69
TT007..................................................................................................................70

Euphonix System 5 Installation Guide
v
List of Figures
2-1 Typical Room and Equipment Layout for System 5 ........................................................20
2-2 System 5 Console ..............................................................................................................20
2-3 Console Dimensions - Top ...............................................................................................21
2-4 Console Dimensions - Side ...............................................................................................21
2-7 CM40xT Module Dimensions............................................................................................23
2-8 Single and Redundant-core Systems..................................................................................24
2-9 Audio Hookup ...................................................................................................................25
2-10 Synchronization Hookup ..................................................................................................26
2-12 MADI hookup: one DF66 core and multiple DF66 cores................................................. 29
2-13 MADI hookup for two DF66 cores and Failover Switch...................................................30
2-14 Control Hookup ................................................................................................................32
3-1 DF66 SuperCore Front and Rear Panels.............................................................................33
3-2 SP662, 6x6 Bridge, and Sync Cards ..................................................................................34
3-3 MADI I/O DSP Line Card Cable .....................................................................................35
3-4 16-port BNC Bulkhead Panel............................................................................................36
3-7 SC263 Front and Rear Panels ...........................................................................................38
3-8 PC254i Front and Rear Panels ..........................................................................................39
3-9 MC524 Front and Rear Panels ..........................................................................................40
3-10 Elco 38 Connector ............................................................................................................41
3-11 Elco 90 Connector ............................................................................................................42
3-12 Elco 90 Connector ............................................................................................................43
3-13 Elco 90 Connector ............................................................................................................44
3-14 DB-25 Connector ..............................................................................................................45
3-15 ML530 Front and Rear Panels ..........................................................................................46
3-5 CM401T Expansion Port: DB-25 Female pinout................................................................37
3-6 Typical Talkback Wiring ..................................................................................................37
2-5 Console Dimensions - Top........................................................................................22
2-6 22
S5MC
Console Dimensions - Side......................................................................................
S5MC
2-11 Recommended Sync Distribution Method ........................................................................27
3-17 ML530 Out 1/Out 2 Pinout: Elco 38 Socket .....................................................................47
3-16 ML530 In 1/In 2 Pinout: Elco 38 Socket ..........................................................................47

Euphonix System 5 Installation Guide
vi
3-21 MA703 Front Panel ..........................................................................................................52
3-22 MA703 Rear Panel ............................................................................................................53
3-23 DM714 Front Panel ..........................................................................................................55
3-24 DM714 Rear Panel ............................................................................................................56
3-25 DM714 Parallel AES/EBU Digital Inputs: Female DB-25 ..............................................57
3-26 MD704 Front Panel ..........................................................................................................58
3-27 MD704 Rear Panel ............................................................................................................59
3-28 DM704 Parallel AES/EBU Digital Outputs: Female DB-25 ............................................60
3-29 FC726 Front and Rear Panels ............................................................................................61
3-30 GP132 Front and Rear Panels ...........................................................................................68
3-31 GP132 Input and Output Connections ..............................................................................68
3-32 TT007 front and rear panels ..............................................................................................70
3-19 AM713 Front Panel ..........................................................................................................49
3-20 AM713 Rear Panel ............................................................................................................50
3-18 Failover Switch..................................................................................................................48

Euphonix System 5 Installation Guide
vii
List of Tables
1-1 DF66 Requirements ...................................................................................................... 14
1-2 Summary of System 5 Components ............................................................................... 16
2-1 System 5 Components: Dimensions, Power Consumption, Heat Dissipation ............... 17
2-2 Fuse Ratings for System 5 Components ........................................................................ 19
3-1 Switch Functions ...........................................................................................................37
3-2 In 1 Elco 38 Pinout ........................................................................................................ 41
3-3 In 2 Elco 90 Pinout ........................................................................................................ 42
3-4 Out 1 Elco 90 Pinout ...................................................................................................... 43
3-5 Out 2 Elco 90 Pinout ...................................................................................................... 44
3-6 Out 3 DB-25 Pinout ....................................................................................................... 45
3-7 AES/EBU DB-25 Pinout ............................................................................................... 63
3-8 Common DD-50 Connector Pinout and Usage With Third-party Devices ................... 64
3-9 FC726 TDIF Cable Wiring Specification ...................................................................... 65
3-10 FC727 Pro Tools Cable Wiring Specification .............................................................. 66
3-11 FC726 SDIF Cable Wiring Specification ...................................................................... 67
3-12 GP132 Outputs ............................................................................................................... 69
3-13 GP132 Inputs ................................................................................................................. 69

Euphonix System 5 Installation Guide
viii
This page is intentionally blank.

Euphonix System 5 Installation Guide
9
Chapter 1: System 5 Overview
This chapter explains the basic elements of any digital audio mixing system and introduces
the components of System 5. It concludes with a section explaining how to estimate your
system’s requirements.
Chapter 2: Interconnecting System Components illustrates how to connect the components,
where to locate them, and lists technical information about the components.
Chapter 3: System 5 Components presents relevant details about each component’s
connectors and cables.
Introduction to System 5
Digital Signal Processing (DSP)
The DF66 SuperCore is a rack-mounted unit that performs all audio processing in a System
5: dynamics and EQ, mix buses, record buses, aux sends, and monitor buses.
The DF66
DSP can be allocated, using factory-supplied Mixer Model files, to provide different num-
bers of buses and channels for each project. The number of DF66 DSP cards required in a
system depends on the number of logical
channels desired: a mono input uses one logical
channel, a stereo input uses two, and a 7.1 input uses eight.
The System 5 Console
The System 5 console must contain the CM401T center section module and a variable num-
ber of CM408T Eight-channel Modules, each providing eight physical faders. Several op-
tional sections can be included:
• CM403: Houses the dual joystick panner and film monitor panel;
• CM409F: Blank section the size of a CM408;
Facilities often install a larger console frame than is initially filled with modules
and panels. This can be due to plans for future expansion or to fulfill physical
requirements for console access. The blank sections merely fill in the space to
avoid having a hole across part of the console width;
• CM409H: Half-width blank section;
• CM409HTP: Half-width section that contains a trackball panner
The following sections discuss important concepts necessary to specify a console layout.
• CM402T: Central channel control with eight assignable faders.
• CM411: VGA input module that can be configured with joysticks.

Euphonix System 5 Installation Guide System 5 Overview
10
Inputs
System 5 inputs may be mono, stereo, or any format up to 7.1, which means that a single
input may use one to eight logical channels.
Physical Faders
Each CM408T Eight-channel Module contains eight physical faders. Each fader can control
two inputs using a Swap button that switches the fader between the Swap and Main inputs.
Layouts
Inputs are assigned to physical faders by using Layouts. Numerous Layouts can be easily
stored and recalled to remap the console surface. To understand Layouts, consider the fol-
lowing examples:
• A console fitted with one CM408T has eight physical faders that can control up
to 16 inputs (Swap and Main per input). One Layout can assign 16 stereo inputs
to the faders for a total of 32 logical channels.
• Another Layout for the same system with eight faders can assign 7.1 inputs to
the Main and Swap layers. This yields 16 inputs each with eight channels for a
total of 128 logical channels.
• To make the situation even more interesting, these two examples can be combined!
Assuming the DSP processing is available in the DF66, the first 32-channel
Layout can be assigned and left connected to the mix buses while the second
Layout is recalled. If none of the channels between the Layouts are the same,
there are now 160 logical channels feeding the mix buses at the same time, al-
though they cannot be controlled simultaneously from the console surface.
Layouts may also be used to place the inputs most often used on the top fader layer, or in-
puts that should be grouped together (i.e., drums).
Analog and Digital I/O
All audio signals are converted to and from the MADI format through analog and digital
converters. All MADI devices are connected to the DF66 SuperCore. If a Failover System
Analog I/O
All analog I/O is converted between analog and MADI formats via the AM713 Analog to
MADI Converter, and the MA703 MADI to Analog Converter. Each unit’s main I/O handles
24 signals and also contains an auxiliary stereo analog input or output, and an auxiliary stereo
digital input or output (AES/EBU and S/PDIF).
is employed, all MADI devices and DF66 cores are connected to the SH612 Studio Hub.

Euphonix System 5 Installation Guide System 5 Overview
11
Digital I/O
All digital I/O is converted to and from MADI format via the DM714 AES/EBU to MADI
Converter, and the MD704 MADI to AES/EBU Converter. Each unit’s main I/O handles
24 signals (12 AES/EBU pairs) and also contains an auxiliary stereo analog input or output,
and an auxiliary stereo digital input or output (AES/EBU and S/PDIF). All digital inputs
have built in Sample Rate Converters.
Format Conversion
The FC726 is a bidirectional device with 56 channels of sample-rate-converted I/O. All inputs
and outputs are converted to and from MADI which are connected to the MADI I/O on the
DF66 DSP card or through the optional Failover Switch. In addition to AES/EBU I/O, the
FC726 allows direct connection to several third-party digital formats. Formats suppor-
ted by the unit are TDIF, ProDigi, SDIF-2, and ADAT Optical. AES/EBU outputs are al-
ways active even when using third-party formats.
Mic inputs
Mic inputs are handled by the ML530 Mic/Line Interfaces. Each unit contains 24 remote
control mic preamps. Each ML530 is connected to a dedicated AM713 Analog to MADI
Converter. Up to five ML530s may be deployed in a system.
Monitoring
Monitoring is handled by the MC524 Monitor Interface. This unit provides Main (7.1), Alt
1 (5.1), and Alt 2 (stereo) control room monitoring, SLS (7.1), and Cues 1–3 (each stereo)
studio monitoring, 2 talkback preamps, and 4 listen mic preamps. The MC524 is connected
to a dedicated MA703 MADI to Analog Converter.
Power
Some of the System 5 console components have dual power entry connectors for redundant
power supplies. We recommend deriving the two power supplies from different sources to
maximize the failsafe capabilities of the system. The best case is to connect one power sup-
ply to a UPS (Uninturuptable Power Supply) and the other to a clean technical power
source. If a UPS is not used, the power supplies should be connected to seperately protected
clean technical power circuits.
Digital Sync
A high quality digital sync source is required for the System 5 console. Some facilities may
already have a digital master clock or house reference in place but others may require one.
Euphonix has tested several digital sync generators and distribution amplifiers and can supply
these devices with the console. Contact a Euphonix sales representative for further information.

Euphonix System 5 Installation Guide System 5 Overview
12
We recommend following these guidelines:
• It is important to minimize the timing differences between signal paths to avoid
cumulative timing errors. It is good system engineering practice to send sync
signals to all system components from one source.
• Sync signals should not be looped and each distribution amplifier should be fed
directly from the master clock source.
• Drawings in this installation guide show the use of Word Clock. The user may
use either AES/EBU sync or Word Clock.
System Control Connections
Ethernet
Several intelligent system components are connected via RJ45 ethernet through a EuCon
ethernet hub. These devices include:
• SC263 System Computer
• PC254i Interface Computer
• CM408T Eight-channel Modules
• CM401T Master Fader Module (console center section)
• CM402T Expanded Channel Module (console center section)
• CM403 Film and Joystick Panels
Monitor, Trackball, and Keyboard
The SC263 System Computer provides master control for the entire system. A monitor,
trackball, and keyboard located in the control room connect to this computer and control
mixing, routing, and file management. A KVM Extender is typically used which routes
these signals from the machine room to the control room through a single multipair cable
built into the console ethernet harness.
TCC Control
The PC254i Interface computer also requires no user interaction. It connects to the MC524
Monitor Interface and up to five ML530 Mic/Line Interfaces via TCC connection.
•DF66 SuperCore
•Failover switch (optional)
Machine Control
The TT007 provides machine control of three serial 9-pin devices, MTC, and LTC. The
TT007 connects via MIDI in and out to a MOTU MIDI I/F. This interface is connected to
the SC263 System Computer, MMC, LYNX Net, and ESBus via the USB port.

Euphonix System 5 Installation Guide System 5 Overview
13
GPIO Control
The GP132 provides GPIO control for the system. The GP132 connects via MIDI in and
out to a MIDI Interface (supplied). This interface is connected to the SC263 System Com-
puter via the USB port.

Euphonix System 5 Installation Guide System 5 Overview
14
Estimating System Requirements
This section helps estimate the system requirements for a particular installation. Contact a
Euphonix representative for an exact specification. Use following categories to determine
the System 5 components necessary for your studio. Most of the studio details considered
here are relevant to any digital mixing system.
Number of DF66 DSP Line Cards
Some examples of Mixer Models and their relationship to the number of DF66 cards are
shown below.
Table 1-1 DF66 Requirements
NOTE: Table 1-1 refers to logical audio channels not inputs. See Inputs on page 10
to see how to count logical channels based on the number and type of inputs.
Number of CM408T Eight-channel Sections
One application may require a small, powerful console to control many inputs from a small
number of faders. Other applications may trade console size for the power of accessing
each input quickly without having to swap the fader or recall a Layout. Specify enough
physical faders to conveniently control the required number of inputs.
Number
of cards
Sample
Rate
Logical
Channels
Record
Buses
Mix
Buses
Aux
Sends
1 48 kHz 35 8
1 48 kHz 12
2 48 kHz 8
2 48 kHz 8
3 48 kHz 84 24 24 16
3 48 kHz 16
4 48 kHz 130 24 16
4 48 kHz 154 8 32 16
5 48 kHz
5 48 kHz 24
6 48 kHz 180 24 32
6 48 kHz 200 24 48 24
8 4
40 4 4
70 16 16
80 8 24
102 8 32
24
148 24 32 24
158 8 48
24

Euphonix System 5 Installation Guide System 5 Overview
15
I/O Specification
When considering I/O requirements, count the number of analog and AES/EBU inputs and
outputs required to hook up all equipment and auxiliary panels for extra equipment. Do not
specify I/O from the console perspective. For example, it is not efficient to specify one an-
alog input and one analog output to be used as an insert point for each channel input. For
microphone preamps, count the maximum number of preamps required including extras
rather than one preamp for every channel.
Number of ML530 Mic-Line Interfaces
Each ML530 contains 24 remote-controlled microphone preamps. Note that each ML530
requires one dedicated AM713 Analog to MADI Converter.
Total = (Microphone Preamps required / 24)
Number of AM713 Analog to MADI Converters
Each AM713 contains 24 analog to MADI converters (equipment outputs).
Total = (Analog inputs required / 24) + (1 per ML530)
Number of MA703 MADI to Analog Converters
Each MA703 contains 24 MADI to analog converters (equipment inputs).
Total = (Analog outputs required / 24) + (1 for MC524)
Number of DM714 AES/EBU to MADI Converters
Each DM714 contains 24 (12 pairs) AES/EBU to MADI converters (equipment outputs).
Total = (AES/EBU inputs required / 24)
Number of MD704 MADI to AES/EBU Converters
Each MD704 contains 24 MADI to AES/EBU converters (equipment inputs).
Total = (AES/EBU outputs required / 24)
Number of FC726 Format Converters
Each FC726 is a bidirectional device that contains 56 AES/EBU inputs and outputs (112
signals) that can be simultaneously sample-rate-converted in blocks of eight channels.
format conversion of 56 third-party format digital channels.
Total = (Format-converted Inputs or Outputs / 56)
The following chart summarizes this section:
It also enables

Euphonix System 5 Installation Guide System 5 Overview
16
Table 1-2 Summary of System 5 Components
Component Function Number Notes
CM401T
Master Module These two modules make up the center section
of the S5 console.
Ethernet devices. CM401T includes
TB Mic and expansion port for TB
external switches wiring.
CM402T Expanded
Channel Module
CM403 Powered
Console Module
Allows installation of joystick panner panel and
film monitor panel. optional Ethernet device
CM408T
8-channel Module
Contains 8 physical faders that control two lay-
ers of 8 inputs. 1 required Ethernet device
CM409HTP Track
Panner Module Half-width console section with trackball panner
.
optional Serial device
PC254i
Interface Computer Computer for MC524 and ML530 1 required Ethernet device. Connects to MC524
and up to 7 ML530s via TCC.
TT007 Machine control Interface; Synchronizer 1 required
GP132
Input/Output and
Relay System
Provides up to 32 input/output relay closures Optional
(4 max)
MIDI device connects to MIDI
Express.
MIDI Express XT MIDI communication between console and
GP132/TT007 1 required
MC524
Monitor Interface Analog monitor output controller 1 required TCC connection to Inteface Pilot.
1 MA703 is required (standard).
ML530
Mic/Line Interface 24 remote-control mic preamps 7 max 1 AM713 is required per ML530
SC263
System Computer Master system computer 1 required
Ethernet device. Connects to control
room display monitor, keyboard, and
trackball.
DF66 Performs all system DSP 1 required
Failover Switch
MADI routing hub for Failover System.
AM713
Analog to MADI
Converter
Provides 24 Analog to MADI Converters, a
Aux Digital Input (AES/EBU or
1 required for
each ML530
specified.
Requires digital sync reference.
MA703
MADI to Analog
Converter
Provides 24 MADI to Analog Converters, a
Aux Digital Output (AES/EBU or
, and 2 Aux Ana log Outputs.
1 required for
the MC524. Requires digital sync reference.
DM714
AES/EBU to MADI
Converter
Provides 24 AES/EBU to MADI Converters, a
dual-channel Aux Digital Input (AES/EBU or
, and 2 Aux Anal og Inputs.
Optional
Requires digital sync reference.
MD704
MADI to AES/EBU
Converter
Provides 24 MADI to AES/EBU Converters, a
dual-channel Aux Digital Output (AES/EBU or
S/PDIF), and 2 Aux Analog Outputs.
Optional
Requires digital sync reference.
Optional Requires digital sync reference.
FC726
Digital Format
Converter
Provides 56 channels of format converted inputs
and outputs (112 channels total). Supports
MADI, AES/EBU, T-DIF, ADAT Optical, S-DIF2,
ProDigi.
a
USB device connects to SC263.
SuperCore
Ethernet device. Requires digital
sync reference.
Optional Ethernet device.
S/PDIF)
dual-channel
S/PDIF)
dual-channel
S/PDIF), and 2 Aux Analog Inputs.
CM411
VGA Input Module
VGA flat display inside module; can be
configured with joysticks. optional VGA display device with serial port
option for joysticks.
CM401T is
required.
Video sync recommended for 9-pin
operation. MIDI connection to MIDI
express.
Optional 75-ohm BNC AES/EBU
connectors.
Optional 75-ohm BNC AES/EBU
connectors.

Euphonix System 5 Installation Guide
17
Chapter 2: Interconnecting System
Components
This chapter summarizes technical information for System 5’s components, including size,
weight, power consumption, cooling, and fuse requirements and shows their interconnections.
To plan an installation, examine Figure 2-1 to learn about suggested equipment locations.
The Sync, MADI, and Control hookup diagrams (Figures 2-10, 2-12, and 2-14) all show
maximum cable distances.
Component Specifications
Table 2-1 System 5 Components: Dimensions, Power Consumption, Heat Dissipation
Component Height Width Depth Weight Power
Consumption
Heat
Dissipation
CM401T 13.25”
34 cm
12”
30 cm
33.5"
84 cm
35 lb
16 kg 120 W 410 BTU/hr
CM402T 13.25”
34 cm
12”
30 cm
33.5"
84 cm
35 lb
16 kg 120 W 410 BTU/hr
CM403 13.25”
34 cm
12”
30 cm
33.5"
84 cm
35 lb
16 kg 120 W 410 BTU/hr
CM408T 13.25”
34 cm
12”
30 cm
33.5"
84 cm
35 lb
16 kg 120 W 410 BTU/hr
CM409F 13.25”
34 cm
12”
30 cm
33.5"
84 cm
16 lb
7 kg NA NA
CM409H 13.25”
34 cm
6”
15 cm
33.5"
84 cm
9 lb
4 kg NA NA
CM409HTP 13.25”
34 cm
6”
15 cm
33.5"
84 cm
10 lb
4.5 kg NA NA
CM424
Producer’s Module
with Writing Surface
13.25”
34 cm
24”
60 cm
33.5"
84 cm
150 W with
display
512 BTU/hr
with display
Console Frame
6 ft
39.5”
1 m
6’10”
2.08 m
41”
1.04 m
245 lb
111 kg NA NA
Console Frame
9 ft
39.5”
1 m
9’10”
3 m
41”
1.04 m
300 lb
136 kg NA NA
Console Frame
12 ft
39.5”
1 m
12’10”
3.9 m
41”
1.04 m
380 lb
172 kg NA NA
CM411 13.25”
34 cm
12”
30 cm
33.5"
84 cm
18 lb
8.2kg
35 lb/16 kg
(50.5 lb
22.9 kg
with display)
35 W 119 BTU/hr
S5MC Frame
5 ft
38.4”
0.975 m
5 ’5”
1.64 m
41.5”
1.05 m
270 lb
122.5 kg NA NA
S5MC Frame
7 ft
38.4”
0.975 m
7’5”
2.25 m
41.5”
1.05 m
326 lb
147.9 kg NA NA
S5MC Frame
9 ft
38.4”
0.975 m
41.5”
1.05 m NA NA
9’5”
3 m
382 lb
173.3 kg

Euphonix System 5 Installation Guide Interconnecting System Components
18
ML530
Mic/Line Interface
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
17 lb
7.7 kg 100 W 345 BTU/hr
SC263
System Computer
7”
177 mm
4RU
19"
483 mm
19”
483 mm
44 lb
20 kg 200 W 685 BTU/hr
PC254i
Interface Pilot
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
23 lb
10.5 kg 200 W 685 BTU/hr
DF66 7”
177 mm 19”
483 mm
19"
483 mm

44 lb
20 kg 500 W 1025 BTU/hr
Failover Switch
3.5”
89 mm
2RU
17”432 mm
(19”/483 mm
faceplate)
11.7”
mm kg 100 W 345 BT
U
/h
r
TT007
Machine Control
Interface
1.75”
44.5 mm
1RU
19”
483 mm
12”
305 mm
4 lb
1.8 kg 15 W NA
GP132
General Purpose
Input/Output and
Relay System
1.75”
44.5 mm
1RU
19”
483 mm
6.4”
163 mm
3.5 lb
1.6 kg 15 W NA
MIDI Express XT
MIDI Communication
1.75”
44.5 mm
1RU
19”
483 mm
5.5”
140 mm
3 lb
1.4 kg 10 W NA
AM713
Analog to MADI Con-
verter
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
17 lb
7.7 kg 50 W 175 BTU/hr
MA703
MADI to Analog Con-
verter
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
17 lb
7.7 kg 50 W 175 BTU/hr
DM714
AES/EBU to MADI
Converter
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
17 lb
7.7 kg 25 W 90 BTU/hr
MD704
MADI to AES/EBU
Converter
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
17 lb
7.7 kg 25 W 90 BTU/hr
FC726
Digital Format
Converter
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
13.5 lb
6 kg 50 W 175 BTU/hr
SuperCore 4RU
296
MC524
Monitor Interface
3.5”
89 mm
2RU
17”/432 mm
(19”/483 mm
faceplate)
18.5”
470 mm
17 lb
7.7 kg 70 W 240 BTU/hr
Note: Computers and computer-based equipment frequently require ac power sources
more than a 5% harmonic voltage distortion factor.
ratic behavior and unpredictable performance.
that have no
Higher levels of harmonics can result in er-

Euphonix System 5 Installation Guide Interconnecting System Components
19
Table 2-2 Fuse Ratings for System 5 Components
Component 100/115/120 VAC 220/230/240 VAC How to Change
Voltage Setting
CM401T T5 A T5 A autoranging
CM402T T5 A T5 A autoranging
CM403 T5 A T5 A autoranging
CM408T T5 A T5 A autoranging
MC524
Monitor Interface 6 A 3 A autoranging
ML530
Mic/line Interface 6 A 3 A autoranging
SC263
System Computer 6 A 3 A autoranging
PC254i
Interface Pilot 6 A 3 A autoranging
DF66 SuperCore 5 A breaker 5 A breaker autoranging
Failover Switch autoranging
TT007
Machine Control Interface 2 A 2 A autoranging
GP132
General Purpose Input/
Output and Relay System
2 A 2 A autoranging
MIDI Express XT
MIDI Communication
Interface
125 mA 125 mA side panel selector switch
AM713
Analog to MADI Converter 630 mA 315 mA rear panel selector switch
MA703
MADI to Analog Converter 630 mA 315 mA rear panel selector switch
DM714
AES/EBU to MADI Converter 630 mA 315 mA rear panel selector switch
MD704
MADI to AES/EBU Converter 630 mA 315 mA rear panel selector switch
FC726
Digital Format Converter T2.5 A T2.5 A autoranging
1A 500mA

Euphonix System 5 Installation Guide System 5 Components
Typical Room and Equipment Layout for System 5
20
Figure 2-1 Typical Room and Equipment Layout for System 5
Typical Console Layout
Figure 2-2 System 5 Console
