Eurofred daitsu RHR-SCO2 User manual

USER MANUAL
REMOTE CONTROL
RHR-SCO2
Serie
HEAT RECOVERY FRESHOME RHR
Edition
03/21
Models
RHR 150
RHR 200

Children over the age of 8, people with reduced physical or mental abilities and those with lit-
tle knowledge or experience may use this system provided they are supervised or have re-
ceived instructions on how to use the system safely and are aware of the associated dangers.
Children below the age of 3 must be kept away from the system, unless they are always supervised.
Children between the ages of 3 and 8 can only turn the system on and off, but always under supervision or if they
have received clear instructions on how to use the system safely and are aware of the potential dangers, and
provided the system has been placed and installed in the normal position of use. Children between the ages of 3
and 8 must not insert the plug into the socket, clean the system, make changes to its configuration or carry out
any of the maintenance tasks that the user normally performs. Children must not play with the system
If you need a new power cable, always request the spare part from Daitsu to prevent dangerous situations from
occurring. Only qualified experts can replace damaged mains connections.
Keep the manual in a safe place close to the unit.
DAITSU
RHR-S WIRELESS CO2PROBE
Country: EN

CONTENT
1 ABOUT THIS MANUAL............................................................................................ 4
1.1 About the device .................................................................................................. 4
1.2 How to use this manual ........................................................................................ 4
1.3 Original Instructions .............................................................................................. 4
1.4 Warnings .............................................................................................................. 4
2 SAFETY................................................................................................................... 5
2.1 Directives.............................................................................................................. 5
2.2 Signs on the unit................................................................................................... 5
2.3 General safety instructions.................................................................................... 5
3 DESCRIPTION......................................................................................................... 5
3.1 Intended use ........................................................................................................ 5
3.2 Operating principle ............................................................................................... 5
3.2.1 Ventilation speeds and modes. .......................................................................... 6
3.2.2 CO2setpoint...................................................................................................... 6
3.3 Visual signals........................................................................................................ 7
4 OPERATION ............................................................................................................ 7
4.1 Show status ......................................................................................................... 7
4.2 Setting mode........................................................................................................ 7
5 INSTALLATION ........................................................................................................ 8
5.1 Preparation........................................................................................................... 8
5.2 Installation procedure ........................................................................................... 8
5.3 Start-up................................................................................................................ 9
6 CONFIGURATION.................................................................................................... 9
6.1 Configuring settings.............................................................................................. 9
7 TECHNICAL DATA................................................................................................... 10

I 4
DAITSU WIRELESS CO2PROBE / INSTALLATION AND OPERATION MANUAL
1 ABOUT THIS MANUAL
1.1 ABOUT THE DEVICE
The wireless CO2probe is a user control and a CO2sensor for the ventilation system. The device communicates information
on the ventilation speed request and the system status via wireless communications with the central control device.
ALED status
BLED mode
CTouch button
1.2 HOW TO USE THIS MANUAL
1.3 ORIGINAL INSTRUCTIONS
1.4 WARNINGS
This manual is designed as a reference book for qualified installers to be able to install the wireless CO2probe (hereinafter
“device”) and for users to be able to use the device for its intended purpose. Make sure you have read and understood the
manual before installing and/or using the device.
The original instructions for this manual were written in Spanish. Versions of this manual in other languages are a translation
of the original instructions.
NOTE
It is used to highlight additional information.
DANGER
It identifies a danger that could cause personal injury, including death.

I 5
DAITSU WIRELESS CO2PROBE RHR-SCO2
The device complies with the following EC directives:
 EMC Directive: 2004/108/EC
 Low Voltage Directive: 2006/95/EC
 RTTE Directive: 1999/5/EC
 RoHS Directive: 2002/95/EC
 WEEE Directive: 2002/96/EC
2 SAFETY
2.1 DIRECTIVES
2.2 SIGNS ON THE UNIT
Warning: Check the instructions for use as a precaution.
Danger: Risk of electric shock.
IEC 61140 Protection Class II (double insulation).
CE mark compliance.
Use of the device may not be legal in all member states.
Dispose of in accordance with European Community Directive 2002/96/EC (WEEE).
2.3 GENERAL SAFETY INSTRUCTIONS
 This product was designed and manufactured to ensure maximum safety during installation, operation and service.
 Always read the safety instructions before installing, maintaining or repairing the product and strictly observe these
instructions.
 Parts of the device carry mains power, which is a potentially lethal voltage.
 Disconnect the power supply to the supply line, circuit breaker or fuse before installing, repairing or removing the device.
 The device is designed for indoor use only. Do not expose the device to rain or moisture in order to prevent short circuits.
 A short circuit can cause fire or electric shock.
 Operate the device between 0°C and 40°C.
 Only use a soft, damp cloth to clean the unit.
 Never use abrasive or chemical products. Do not paint the device.
3 DESCRIPTION
3.1 INTENDED USE
The device is designed for the following purposes:
1. To set the ventilation level via the fan speed, according to the user input or the measured level of CO2.
2. Configure the parameters for controlling the ventilation. Any other use or additional use is not in compliance with the
intended use.
3.2 OPERATING PRINCIPLE
The device communicates with the control device via wireless communications for controlling the ventilation. Via the button
and the LEDs, you can read and configure the control mode that the ventilation system is currently in. When it is in Eco mode
or Comfort mode, the device requests the ventilation level according to the amount of CO2in the air.

I 6
DAITSU WIRELESS CO2PROBE / INSTALLATION AND OPERATION MANUAL
3.2.1 VENTILATION SPEEDS AND MODES.
3.2.2 CO2SETPOINT
The ventilation system operates in one of the following modes. In each of these modes, the control device adjusts the
ventilation system to a configured ventilation level.
The device measures the level of CO2in the air continuously and compares the measured value to a configured setpoint.
The device controls the ventilation accordingly to keep the measured level of CO2below the requested level. When it is in
Comfort mode, the requested level is the same as the configured value. In Eco mode, the requested level is 250 ppm above
the configured value.
The control device drives the fan according to the highest values sent by the linked wireless sensors. When you start the timer
mode from this device, the ventilation will be active for 30 minutes.
ABSENCE MODE:
It represents periods of non-occupancy, when the heat recovery unit will operate at the lowest capacity.
MAXIMUM TIMER:
High fan speed, for a limited time. When the button is pressed, the heat recovery unit will reach maxi-
mum speed for 30 minutes.
ECO MODE:
Sensor-based automatic ventilation. In ECO, the system will begin at a higher CO2level to ventilate like
in COMFORT mode.
COMFORT MODE:
Sensor-based automatic ventilation. The system will accelerate the CO2-based ventilation after a certain
default activation value is exceeded.
AT HOME MODE:
It represents occupancy of the home or a room. By selecting this button, the heat recovery system
knows that there is one person (or more) in the room or home. It will set the speed to the default level.
NOTE
The device stores the fan speed values configured on the control device and requests them from there. The device
stores the CO2setpoint itself and does not communicate it to any other device.

I 7
DAITSU WIRELESS CO2PROBE RHR-SCO2
LED STATUS LED MODES
Start-up
STEADY WHITE ON ON ON ON ON
System status
STEADY GREEN <800 PPM
STEADY YELLOW 800-1900 ppm
STEADY
RED >1900 ppm
1 flash Communication error
2 flashes Dirty filter
3 flashes Fan error
4 flashes CO2sensor error
5 flashes Low battery
Selection
ABSENCE MODE
OFF
·
AT HOME MODE ·
MAXIMUM TIMER ·
ECO MODE ·
COMFORT MODE ·
3.3 VISUAL SIGNALS
4.2 SETTING MODE
From the status screen:
1. Tap the button. The mode LEDs show the following selection.
2. If necessary, tap the button within 2 seconds, repeat until the selection shows the required mode.
3. Wait 2 seconds. The device applies the requested mode.
The LED status and the LED modes show the system status.
4 OPERATION
4.1 SHOW STATUS
1. Tap the button.
The LED status and the LED modes show the system status.

I 8
DAITSU WIRELESS CO2PROBE / INSTALLATION AND OPERATION MANUAL
5 INSTALLATION
5.1 PREPARATION
5.2 INSTALLATION PROCEDURE
DANGER
Disconnect the power supply to the supply line,
circuit breaker or fuse before installing the de-
vice.
DANGER
Make sure that the power supply is turned off.
1. Press the clip and pull the
upper section of the lower
section.
When the device is not placed in a recessed wall box:
1. Prepare the wall, if necessary. Use the mounting plate as a template.
2. Remove the detachable plastic from the cable entry on the housing.
2. Position the lower section
of the device.
3. Secure the lower section
with the bolts.
5. Position the upper section
of the device on the lower
section.
a. Position the clips.
b. Close and press until
it clicks.
2. Open the safety cover.
Use a small flat-head
screwdriver to loosen
the clip.
1. Pass the power cable
through the rear hole (A)
or the cable entry (B).
4. Connect the power cable
to the bolt terminals.
NOTE
Do not place the device in a metal housing.

I 9
DAITSU WIRELESS CO2PROBE RHR-SCO2
6 CONFIGURATION
NOTE
When configuring the fan speeds, make sure that the average fan speed is between the low fan speed and the
high fan speed.
5.3 START-UP
6.1 CONFIGURING SETTINGS
1. Enable the 230 V power supply.
All of the LEDs will light up for 3 seconds.
2. Wait until the status LED displays link mode.
If the device shows another indication, the device is already linked. See 6.2 on how to link the device again.
3. Make sure that the fan box is in link mode.
4. Tap the button. The device tries to link to the control device.
It displays the result in the LED status.
When the communication fails, make sure that the control device is in link mode and try again.
From the status screen (see 4.1):
1. Tap the button. The mode LEDs show the following selection.
2. If necessary, tap the button within 2 seconds, until the selection shows the element to be configured.
3. Keep the button pressed until the status LED starts flashing white.
4. Release the button. The status LED shows the selected element, and the LED flashing modes show its current value.
5. If necessary, tap the button within 10 seconds, until the mode LEDs show the value to be set.
6. Wait 10 seconds and the device will apply the configured value. The LED status and the LED modes show the system
status.
LED STATUS LED MODES
Configuration
LOW SPEED
OFF
·
MEDIUM SPEED ·
HIGH SPEED ·
CO2SETPOINT ·
LINKING ·
VALUE
Blue/red Low speed Off 10% 20% 30% 40%
Blue/green Medium speed 30% 40% 50% 60% 70%
Red/green/blue High speed 60% 70% 80% 90% 100%
Blue (flashing) CO2setpoint 700 ppm 800 ppm 900 ppm 1000 ppm 1100 ppm
Red/green Linking

I 10
DAITSU WIRELESS CO2PROBE / INSTALLATION AND OPERATION MANUAL
7 TECHNICAL DATA
DAITSU WIRELESS CO2 PROBE
TOTAL DIMENSIONS 100 x 100 x 25 mm (height x width x depth)
WEIGHT ± 125g
ENVIRONMENTAL
CONDITIONS
Temperature
Operating 0 to 40°C
Transport
and storage -20 to 55°
Relative humidity 0 - 90%, without condensation
Electrical protection (IEC60529) IP30
ELECTRICAL
SPECIFICATIONS
Main power supply 195 - 253 VAC, 50 Hz.
Maximum energy consumption 4 VA
Cable diameter 0.25 to 2.5 mm2
CO2MEASUREMENT
SPECIFICATIONS
Optimal measuring range
Measurement accuracy (within the optimal
range, >10 min after start-up):
400 to 2000 PPM.
Stabilization period after start-up 40 PPM + 2% of reading at 20°C 2 minutes
VERSION 1
Eurofred S.A.
Marqués de Sentmenat 97
08029 Barcelona
www.eurofred.es

I 11
