Europa components ECSS-101 Instruction manual

EDS1304-001
Page 1 of 2
It is the responsibility of the person installing the electrical equipment to ensure that the installation meets the
requirements of the IET wiring regulations and is therefore ‘t for purpose’. Factors such as correct selection
of components, cable sizing, protective devices and Earth bonding are all critical and should be checked prior
to full testing and power-up. Any other regulations applicable to the equipment being installed such as the
Machinery Directive and current health and safety legislation must also be adhered to.
All connections (including factory made) must be checked for the correct tightness prior to commissioning of
the electrical installation.
All connections should be checked periodically to ensure correct tightness.
Important Safety Notice
DO NOT USE POWER TOOLS ON THESE PRODUCTS
!
SPD Specication
Technical Data: Safe Surge Unit | ECSS-101
TY6 30N
According the IEC61643-11 Type 2
Earthing System TT/TN
System Voltage Un 230/400V
Max. continous operation AC voltage Uc 275V
Norminal discharge current (8/20µs) In 15kA
Maximum discharge current (8/20µs) Imax 30kA
Voltage protection level Up 1.5kV
Maximum backup fuse 63A gL
Response time tA 25ns
Enviroment temperature Tu -40 C ~ 80 C
Status indicator non/red
Mounting 35mm Din Rail
Cross section of wire (min.) 4mm
Cross section of wire (max.) 16mm
Casing material Thermal plastic
UL94 - V0
Degree of protection IP20
Enclosure Dimensions
Isolator Specication
Product Ranges ISO100-2
Standard (s) IEC 60947-3, EN 60947-3
Certication CE, SEMKO
Rated Current (In) 100A
Rated Uninterupted Current (Iu) 100A
Rated Operational Voltage (Ue) AC 230 (240) / 400 (415)V
Rated Frequency 50/60Hz
Rated impulse withstand voltage (Uimp) 6kV
Number of poles 2
Rated Insulation Voltage (Ui) 500V
Utilization Category AC-22B
Operating Temperature -5 to 40 C*
Altitude Not exceeding at 2000 metres
Humidity Not exceeding 50% at 40 C and 90% at 20 C
Pollution Degree 3
Terminal Protection IP20
Mounting 35mm DIN Rail
Terminal Type Tunnel
Terminal Capacity 2.5-35mm²
Recommended Terminal Torque 2.0Nm
* average not exceeding 35 C over 24 hour period
238
105
78
102
32 DIA.
181
55
6 DIA.

EDS1304-001
Page 2 of 2
Technical Data: Safe Surge Unit | ECSS-101
Europa House, Airport Way, Luton, Beds, LU2 9NH Tel: [phone] / Fax: [phone]
Email: [email protected] Website: http://wwweuropacomponents.com
ECSS-101 Installation
The ECSS-101 surge protection device is designed to be installed directly from from a spare way in the consumer unit using 6mm cable.
Short circuit protection should be provided by a 32A ‘C’ curve MCB.
The combined length of the connecting conductors in relation to the current path should ideally be less than 0.5 Metres and in no
circumstances exceed 1 Metre.
Live + CPC = <0.5M (Maximum 1M)
Neutral + CPC = <0.5M (Maximum 1M)
100A
Main Switch
L N E
ECSS-101
CONSUMER UNIT
Main Earth Terminal
Customer wiring
32A MCB
ISO100-2
TY6-30N
L
N
PE
Connect CPC to Main Earth Terminal or
Consumer unit earth terminal
