EUROSEC CP7 User manual

CC
CCPP PP77 77 // // CC CCPP PP88 88
UU
UUSS SSEE EERR RR
MM
MMAA AANN NNUU UUAA AALL LL
TM
TM
USER.qxd 26/07/01 08:39 Page 1
Intelligent Security & Fire Ltd

Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Full Setting the System . . . . . . . . . . . . . . . . . . . . 1
Part Setting the System (using Part 1) . . . . . . . . 2
Part Setting the System (using Part 2 or 3) . . . . . 2
Unsetting the System . . . . . . . . . . . . . . . . . . . . . 3
Display After Alarm . . . . . . . . . . . . . . . . . . . . . . . 3
Resetting After Alarm . . . . . . . . . . . . . . . . . . . . . 3
Programmable User Options . . . . . . . . . . . . . . . . 4
Zone Remove Option . . . . . . . . . . . . . . . . . . . . . 4
System Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
Turning Chime On/Off . . . . . . . . . . . . . . . . . . . . . 6
Programming User Codes . . . . . . . . . . . . . . . . . . 7 - 8
Keypad Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Tamper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Details . . . . . . . . . . . . . . . . . . . . . . . . . . 9
USER.qxd 26/07/01 08:39 Page 2
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 11 11
Introduction
Welcome to the eurosec control panel. Your installation company will
have programmed your system to protect your premises to the highest
possible standards. Several user programmable options are available
that will be covered later in this manual. Throughout this manual refer-
ence will be made to the User Code, the factory set default is 5678.
This code is programmable along with eight other User Codes.
Full Setting the System
Two methods are available for Full Set. After checking the premises are
secure.
1) Press Quick followed by Full
OR
Enter a valid User Code followed by Full.
2) The exit tone will now sound.
3) Exit the premises via an authorised exit route .
Note: Pressing the Quick key during exit will shorten the exit time
to 3 seconds.
Note: To abort the exit enter a valid User Code.
USER.qxd 26/07/01 08:39 Page 1
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 22 22
Part Setting the System (using Part 1)
Up to three Part Sets may be available for your system. Please refer to
the customer details at the rear of this manual for information about
Part Set zones. Part Set zones will be omitted from the system when
that particular Part Set is used. To set the system using Part 1.
1) Press Quick followed by Part
OR
Enter a valid User Code followed by Part
2) Retire to an unprotected area.
Part Setting the System (using Part2 or 3)
Two other Part Sets may be available for your system. Part 2 is a sec-
ond set of zones that may be omitted and Part 3 will combine Part 1
and Part 2. To use Part 2 or 3.
1) Press Quick followed by 2 or 3.
OR
Enter a valid User Code followed by 2 or 3.
2) Retire to an unprotected area.
Note: Pressing the Quick key during exit will shorten the exit time
to 3 seconds.
Note: To abort the exit enter a valid User Code.
USER.qxd 26/07/01 08:39 Page 2
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 33 33
Unsetting the System
1) Enter the premises via an authorised Entry Point.
2) The Entry Tone will sound.
3) Proceed to the keypad and enter a valid User Code.
Display After an Alarm
After an alarm has occurred the system should be unset as above.The
display will show the zone that caused the alarm via a flashing LED.
Resetting After an Alarm
After an alarm the system needs to be reset. To reset the system.
If Any Code Reset has been programmed.
1) Press Reset
Or
If Master Code Reset has been programmed.
1) Enter a valid User Code
2) Press Reset
Note: The terms of your insurance may prohibit User reset.
Contact your installation company if none of the above
procedures are effective.
USER.qxd 26/07/01 08:39 Page 3
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 44 44
Programmable User Options
Throughout this section reference will be made to the LEDs on the dis-
play. Three modes are possible for each LED ON, OFF or FLASHING.
Programmable User Option may only be accessed via a Master Code.
Fig. 1 LED Modes Key
Zone Remove Option
This option allows individual zones to be removed (omitted) when the
system is being set. It is only applicable to the one Set state and will
need to be repeated for subsequent Sets. If you are removing particu-
lar zones on a regular basis ask your installation company to include
them in a Part Set.
1) Enter a valid User Code followed by No
the display will show
(this is user programming mode)
2) Press 4
the display will show
3) Press the key(s) corresponding to
the zone(s) you wish to remove (omit) from the next
Set.
OFF
ON
FLASHING
USER.qxd 26/07/01 08:39 Page 4
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 55 55
4) Press 0 twice
the display will show
5) Press Full for Full Set
or
Press Part for Part 1 Set
or
Press 2 for Part 2 Set
or
Press 3 for Part 3 Set
6) The system will now start the relevant Set with the zones
you selected removed (omitted).
Note: This will be for the one Set state only.
System Test
This option allows the User to test zones, bells and strobes on the
system.
1) Enter a valid User Code followed by No
the display will show
(this is user programming mode)
2) Press 5
the display will show
USER.qxd 26/07/01 08:39 Page 5
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 66 66
3) Violate each zone on the system (as you do so the
corresponding LED will extinguish) to verify its integrity
4) To test the bells (external sounders) and strobe press 9.
To stop the bell test press 9 again.
5) To escape back to Unset press 0 three times.
Turning Chime On/Off
Your installation company may have programmed a group of zones or
a single zone as Chime. This Chime function may be turned on or off
by the User.
1) Enter a valid User Code followed by No
the display will show
2) Press 7
the display may show
or
3) If LEDs 1 to 7 are On then Chime is On
If LEDs 1 to 7 are Off then Chime is Off
Press No to change the Chime Status
4) To escape back to Unset press 0 three times.
USER.qxd 26/07/01 08:39 Page 6
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 77 77
Programming User Codes
Up to nine user codes may be programmed on predetermined levels
these are.
User Numbers 1 to 3 Master Level
Allows Set, Part Set, Unset and User Programming Mode.
User Numbers 4 to 7 User Level
Allows Set, Part Set and Unset.
User Numbers 8 to 9 Set Only Level
Allows Set Only
User Number 1 is factory default 5678. This code may only be
changed. There is no facility for deleting this code.
All other codes may be changed or deleted as required.
To program User Codes.
1) Enter a valid User Code followed by No
the display will show.
2) Press 9
the display will show.
3) Enter a single digit for the User No. you wish to program.
the display will show.
USER.qxd 26/07/01 08:39 Page 7
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 88 88
4) Enter the four digit code you require
the display will show
provided your code
has been accepted
or
If your code has not
been accepted
If your code has not been accepted it may already be in use
please return to step 1 and use a different code.
5) Provided the code has been accepted in 4 you may escape
to Unset by pressing 0 twice.
Keypad Alert
If programmed by your installation company keys 1 & 3 when pressed
together will act as alert keys. The exact function will depend on what
they have been programmed for but for example if they are pro-
grammed as panic pressing them will activate the alarm when the sys-
tem is set or unset. Keypad activation is indicated by LEDs 1 & 3
Flashing.
Tamper
Tampers and other system problems will be indicated via the Tamp
LED. Please contact your installation company.
USER.qxd 26/07/01 08:39 Page 8
Intelligent Security & Fire Ltd

PP
PPaa aagg ggee ee 99 99
System Details
Installation Company Name Installation Company Address
Tel:
Fax:
Zone No. Location Type Chime Pt1 Pt2
1
2
3
4
5
6
7
8
Installation Date Service Timer On Off
Serviced Next Due Serviced Next Due
Notes
USER.qxd 26/07/01 08:39 Page 9
Intelligent Security & Fire Ltd

Installed By:-
PR4966 Rev2.0
