Riedel CCP1116 User manual

CCP1116
Quick Guide
Commentary Panel
Document Reference 1.2
S.Franke
01/2013

© 2013 Riedel Communications GmbH & Co KG. Alle Rechte vorbehalten.
Dieses Handbuch ist urheberrechtlich geschützt. Das Kopieren, Vervielfältigen, Übersetzen oder Umsetzen in irgendein elektronisches Medium oder maschinell lesbare Form im
Ganzen oder in Teilen ohne vorherige schriftliche Genehmigung von Riedel ist nicht gestattet. Riedel übernimmt keine Gewähr für die Richtigkeit des Inhalts dieses Handbuchs.
Die Rechte an anderen in diesem Handbuch erwähnten Marken- und Produktnamen liegen bei ihren Inhabern und werden hiermit anerkannt.
© 2013 Riedel Communications GmbH & Co KG. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Riedel. Every effort has been made to ensure that the information in
this manual is accurate. Riedel is not responsible for printing or clerical errors. All trademarks are the property of their respective owners.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
TABLE OF CONTENT
1CONTROL ELEMENTS - DESCRIPTION..........................................................................................................................4
2CONNECTORS ..................................................................................................................................................................5
2.1 Connectors front side ..............................................................................................................................................................5
2.2 Connectors rear side................................................................................................................................................................6
3REAR SIDE - DIP SWITCHES ..........................................................................................................................................7
4AUDIO BLOCK DIAGRAM................................................................................................................................................8
5DIRECTOR CONFIGURATION OF A CCP-1116 .............................................................................................................9
5.1 Key assignment Commentator A/B................................................................................................................................... 10
5.2 GPIO functions....................................................................................................................................................................... 12
5.3 Commentary Audiopatch settings...................................................................................................................................... 13
6PANEL TEST / CONFIG MODE..................................................................................................................................... 15
6.1 Info .......................................................................................................................................................................................... 15
6.2 Key Test .................................................................................................................................................................................. 15
6.3 Config...................................................................................................................................................................................... 16
6.3.1 Config: Text Color............................................................................................................................................................... 16
6.3.2 Pan Type ............................................................................................................................................................................. 17
6.4 Demo Mode............................................................................................................................................................................ 17
7SPECIFICATIONS .......................................................................................................................................................... 18
8SERVICE......................................................................................................................................................................... 19
9NOTES ............................................................................................................................................................................ 20

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 4
1CONTROL ELEMENTS - DESCRIPTION
Nr.
Function
Description
1
AUX 1 ON
Activating the button: Mixes analog input „AUX 1“ from the rear side to the
Headphones (depending of the dip-settings on the rear side to the left-, right- or
both ears). The button will light up in yellow. With the Levelmeter you can adjust
the listen level.
2
AUX 2 ON
Activating the button: Mixes analog input „AUX 2“ from the rear side to the
Headphones (depending of the dip-settings on the rear side to the left-, right- or
both ears). The button will light up in yellow. With the Levelmeter you can adjust
the listen level.
3
MIC B ON
Activating the button: Mixes the MIC B from 2nd commentator to the Headphones
(depending of the dip-settings on the rear side to the left-, right- or both ears). The
button will light up in yellow. With the Levelmeter you can adjust the listen level.
4a
MIC A
Sidetone: Mixes the “MIC A” signal to the Headphones A (depending of the dip-
settings on the rear side to the left-, right- or both ears). With the Dip switch
“Always” you can choose to activate the Sidetone always or only when ON AIR is
pressed
4b
MIC A Signal
LED
Indicates green, as soon a signal from MIC A is coming into the CCP-1116. LED-
color changes to orange, when the signal is clipping
5
PHONES A
Adjust the outgoing volume to Phones A
6
ON AIR A
(Latching)
Activates the “ON AIR” function. When activated, the Button light up red. The “MIC
A” is sent to the analog outputs “AIR A OUT” and “AIR A+B OUT”. Also GPI IN 1 is
internally activated and can be used within the Artist configuration. The Level
meter is showing the ON AIR Mic level with green and orange LEDs
7
MIC A MUTE
(Momentary)
Mute the “MIC A” input. When activated the button light up yellow. If “ON AIR” is
activated, also this button changes color to yellow. The “MIC MUTE” buttons can
also be activated via GPO 1 (A) and 2 (B) within the Artist configuration

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 5
8
Intercom Mic
Connector for standard Artist microphones. Normally not used for commentary
mode, only when the CCP-1116 is used as ordinary Intercom panel.
9
Function keys
Standard Artist panel function keys (Shift, HS, OPT, F1, F2) + Master Volume.
ATTENTION: The Master Volume is not influencing the volume of Phones A or B
10
Speaker
Panel speaker. Normally not used for commentary mode, only when the CCP-
1116 is used as ordinary Intercom panel.
11
Intercom OLED
keys
Standard keys, to be configured within the Artist configuration
1-7 is identically also for Commentator B
2CONNECTORS
2.1 Connectors front side
1 2 3 4 5 6
Nr.
Function
Connector
Type
Artist Director
Pin out
1
PHONES A
6,35mm
Stereo Jack
Audio Patch:
Audio OUT A
Tip: Left
Ring : Right
Sleeve: GND
2
MIC A
1
2
3
XLR3 female
Audio Patch:
Audio IN A
Pin 1 : Shield
Pin 2 : Signal + (hot)
Pin 3 : Signal –(cold)
3
HEADSET A
INTERCOM
(only for pure
Intercom use)
1
2 3
4
XLR4 male
Audio Patch:
Headset A
Pin 1: Shield (Mic -)
Pin 2: MIC + (+4V - switchable within
Director)
Pin 3: Phones –
Pin 4: Phones +
4
HEADSET B
INTERCOM
(only for pure
Intercom use)
1
2 3
4
XLR4 male
Audio Patch:
Headset B
Pin 1: Shield (Mic -)
Pin 2: MIC + (+4V - switchable within
Director)
Pin 3: Phones –
Pin 4: Phones +
5
MIC B
1
2
3
XLR3 female
Audio Patch:
Audio IN B
Pin 1 : Shield
Pin 2 : Signal + (hot)
Pin 3 : Signal –(cold)
6
PHONES B
6,35mm
Stereo Jack
Audio Patch:
Audio OUT B
Tip: Left
Ring : Right
Sleeve: GND

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 6
2.2 Connectors rear side
1
2
3
4
5
12345 6 78910 11 12 13 14
Nr.
Function
Connector Type
Artist
Pin out
1
Main Input
90-265V, 47-63Hz
2
DC EXT. 12V
1
2 3
4
XLR4 male
Pin 1: GND
Pin 2: n.c.
Pin 3: n.c.
Pin 4: +10 …+14VDC (3A)
3
GPIO
1
2
3
4
5
XLR5 female
Panel GPI IN 3
Panel GPI Out 3
Pin 1: OUT - ( > Director: GPI Out 3)
Pin 2: OUT + ( > Director: GPI Out 3)
Pin 3: IN - ( > Director: GPI IN 3)
Pin 4: IN + ( > Director: GPI IN 3)
Pin 5: +5V (250mA)
Shield: Ground
4
MATRIX (BNC)
BNC
Pin: Tx/RX Data +
Shield: Tx/Rx Data -
5
MATRIX (CAT5)
CAT5
Pin 1: TxD +
Pin 2: TxD –
Pin 3: RxD +
Pin 6: RxD -
6
Ext. Speaker
1 2
3
XLR3 male
Audio Patch:
Ext. OUT
Tip: Left
Ring : Right
Sleeve: GND
7
LINE IN
1
2
3
XLR3 female
Audio Patch:
External MIC
(only available in
Speaker Mode)
Pin 1 : Shield
Pin 2 : Signal + (hot)
Pin 3 : Signal –(cold)
8
AUX 1 IN
XLR3 female
n.a.
See 7
9
AUX 2 IN
XLR3 female
n.a.
See 7
10
DIRECT B OUT
(permanent)
XLR3 male
n.a.
See 6
11
AIR B OUT
XLR3 male
n.a.
See 6
12
AIR A+B OUT
XLR3 male
n.a.
See 6
13
DIRECT A OUT
(permanent)
XLR3 male
n.a.
See 6
14
AIR A OUT
XLR3 male
n.a.
See 6

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 7
3REAR SIDE - DIP SWITCHES
Example for Commentator A. Identical functionality for Commentator B
Nr.
Function Group
Function
Description
1
PHONES MODE
MIC A
Routes MIC A signal (Sidetone) to left-(L), right- (R), or both ears (M)
2
PHONES MODE
MIC B
Routes MIC B signal to left-(L), right- (R), or both ears (M)
3
PHONES MODE
I/COM
Routes Intercom signal to left-(L), right- (R), or both ears (M)
4
PHONES MODE
AUX 1
Routes AUX 1 signal to left-(L), right- (R), or both ears (M)
5
PHONES MODE
AUX 2
Routes AUX 2 signal to left-(L), right- (R), or both ears (M)
6
ALWAYS
MIC A
Sidetone MIC A: Always routed to the phones A, or only when “ON AIR
A” is pressed
7
ALWAYS
MIC B
MIC B signal always routed to the phones or only when “ON AIR B” is
pressed. Only works when “MIC B ON” is activated.
8
MIC Settings
GAIN
Adjust Mic Input gain
9
MIC Settings
-20dB
Switch between Dynamic- (OFF) and Electret Microphone (-20dB ON)
10
MIC Settings
48V
Switch 48V Phantom power ON/OFF

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 8
4AUDIO BLOCK DIAGRAM

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 9
5DIRECTOR CONFIGURATION OF A CCP-1116
When you want to use the CCP-1116 Commentary panel with its full functionality for 2
commentators, you have to adapt some configuration settings in the Director.
First you have to create a new CCP-1116 on an odd digital port (for 2channel operation) and
activate „enable 2nd Audio channel“ in the properties of the port.
Open the Panel view with a double click on the port.
Hint: Up from Director 6.60 the CCP will be created automatically as a 2-channel port, when you
add it to an odd port and the following port is unused.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 10
5.1 Key assignment Commentator A/B
Attention: The commentator Function buttons, like „ON AIR, MIC Mute, AUX1, AUX2, etc“ cannot be
configured and monitored in Remote control in the Director. They are just showing the Design of
the CCP-1116.
Now you can add all needed functions and calls to the keys of the CCP-1116 with drag and drop.
When you want to use the panel with 2 commentators you can virtually split the keys for example
in the middle and configure functions for Commentator A on the left and for commentator B on
the right keys.
Please keep in mind that on all functions for the Commentator B the 2nd audio channel as source
has to be enabled. You can find this option in the properties of the audio functions.
So open the properties of the keys with audio functionality for Commentator B one after the other
and enable the 2nd audio channel as source for “Call to…” functions, and also as source for “Listen
to…” functions.
When commentator Aneeds to talk directly with commentator Band reverse, just drag and drop
this CCP-1116 panel to both sides of the panel to create “Call to port” functionality. Afterwards it is
recommended to edit the key label of both keys manually.
ATTENTION: The other possibility is to activate the keys „MIC B ON“, resp. „MIC A ON“ direct on the
CCP-1116 to route the Mic signal of the other commentator permanently to the own Phone-mix.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 11
Commentator A -> B
Commentator B -> A
Please keep in mind, that on audio functions on other ports to call/listen to the Commentator B
also the 2nd audio channel of the CCP-1116 have to be used. Therefore you have to activate the
flag “to 2nd channel”in the properties of the function. It is useful to manually label the key in “Com
B” or similar.
ATTENTION: For the Commentator B there are some limitations at the moment:
-Reply is not working correctly for the Commentator B (for the 2nd audio channel)
-It is not possible, to use an IFB from the IFB-Tabelle for the 2nd Commentator. Here you have to
configure an IFB in the „manual“ way for the 2nd audio channel.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 12
5.2 GPIO functions
Open the „Properties“ of the CCP-1116 to define the GPIOs.
GPIO IN 1 and 2can be used within the Artist system to signalize activated „ON AIR“ buttons on
the CCP-1116 somewhere and somehow in the system.
GPIO Out 1 and 2are used internally in the CCP-1116 to activate the “MIC Mute” buttons, for
example when the Commentator is talking to an Intercom destination while he is on air.
Both GPIOs will be labeled automatically with the panel name and functionality.
GPIO IN 3and GPIO OUT 3 are the only ones, which can be used individually.
The GPIO 3 is available on a XLR5 pin connector on the rear side of the CCP-1116.
Now you can drag and drop GPO 1 and 2 to all the intercom buttons, that are able to activate the
microphone of the panel (Call to Port, Call to Group, Call to Conference), to automatically activate
the On Air “MIC MUTE” button of the corresponding Commentator-side.
For only listen functions (Listen to) an assigned GPO is not necessary.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 13
5.3 Commentary Audiopatch settings
Finally you have to adjust the internal audio routing of the Audio patches in the CCP-1116.
Up to Director Version 6.50 the audio in-and outputs of the Audio patches are used inside the CCP-
1116 as follows:
Audiopatch INPUT
CCP-1116 connector
Panel MIC
Standard panel gooseneck microphone
(only when the CCP-1116 is used as a pure intercom panel)
Headset A
Headset A Intercom (XLR 5pol. front side)
(only when the CCP-1116 is used as a pure intercom panel)
External MIC
LINE IN Input (XLR 3pol. rear side) only available in Speaker-Mode
Headset B
Headset B Intercom (XLR 5pol. front side)
(only when the CCP-1116 is used as a pure intercom panel)
AUDIO IN A
MIC A (XLR 3pol. front side)
The key “MIC MUTE A” take effect always on this input signal. Exclusive this signal
is routed hard wired to the XLR “AIR A OUT” and “AIR A+B OUT” analog outputs
and can be affected by the “ON AIR A” key.
AUDIO IN B
MIC B (XLR 3pol. front side)
The key “MIC MUTE B” takes effect always on this input signal. Exclusive this
signal is routed hard wired to the XLR “AIR B OUT” and “AIR A+B OUT” analog
outputs and can be affected by the “ON AIR B” key.
Matrix CH. 1
Audio channel 1 (Commentator A), Intercom coming from the matrix to the CCP-
1116
Matrix Ch. 2
Audio channel 2 (Commentator B), Intercom coming from the matrix to the CCP-
1116
Audiopatch OUTPUT
CCP-1116 connector
Speaker
Standard panel loudspeaker
Headset A
Headset A Intercom (XLR 5pol. front side)
External Out
Ext. Speaker (XLR 3pol. rear side)
Headset B
Headset B Intercom (XLR 5pol. front side)
AUDIO OUT A
PHONES A (Stereo-jack, front side)
AUDIO OUT B
PHONES B (Stereo-jack front side)
Matrix CH. 1
Audio channel 1 (Commentator A), Intercom going from the CCP-1116 to the
matrix
Matrix Ch. 2
Audio channel 2 (Commentator B), Intercom going from the CCP-1116 to the
matrix

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 14
Up to Director Version 6.50:
For the basic commentator functionality you have to adjust the Audiopatch for Speaker AND
Headset mode minimum as follows:
Up from Director 6.60 the labels of the audio IOs are showing the correct names of a CCP and the
basic crosspoints within the Audiopatch are already set as default.
Hint: It is recommended to also add an additional Audiopatch with standard panel settings
(Gooseneck Microphone + Speaker) to the Panel.
This preset can be activated by a “Select Audiopatch” function (for example on the Shift page of
the Commentary Panel) to activate a standard Intercom audio routing during rehearsals or when
the commentary headset is not yet available. For details please refer the Director User Manual.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 15
6PANEL TEST / CONFIG MODE
The CCP-1116 panel also has an internal Setup-Menu available, to edit basic settings of the panel
or for testing.
Therefore you have to press “Shift”+”F1”+”F2”simultaneous to reboot the panel.
Immediately press the “F1”- button and keep it pressed until the panel has started the Service
menu.
6.1 Info
Press the “Info”- button, to show the current installed firmware versions for the front board.
Press any button to go back to the main menu.
6.2 Key Test
Press “Test” to get into the test mode. Press “Key Test” to start the Key Test mode. Please do not
use the “FlashTst”, it is just for internal service. It will delete all Icons from the flash memory.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 16
In the “Key Test” mode you can test all key-contacts, rotary encoders, encoder switches and LEDs.
Every time you press a button or turn an encoder, the half side color on the responsible OLED-
display will change.
By turning and pressing the Master volume encoder, the 8 Volume LEDs will change the color.
To stop the “Key Test” mode, you have to reset the panel by pressing “Shift”+”F1”+”F2”.
6.3 Config
In the “Config” menu, you can adjust the default display color and if the panel should be detected
by the Director as a “DCP-1116” or “CCP-1116”.
6.3.1 Config: Text Color
In this menu you can set the default text color. This default color is shown, as long the panel is in
the “Wait for” mode when it is not connected to the matrix.
Press “Config” in the main menu
Select the color by pressing the desired color button.
or
With “<back>”you can go back to the config menu. After resetting the panel, it will show the
selected color in the “Wait for” mode.
As soon the panel is connected to an Artist system, the Artist configuration assigns the colors to
the buttons.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 17
6.3.2 Pan Type
For some reasons it is necessary, to change the panel type information that is sent to the Director.
For example if you want to use the CCP panel with an Artist version older 6.40 where the CCP is
not directly supported. Therefore you have to adjust the mode to “DCP-1116”.
Also if you get an Alarm message within the Director, that a wrong panel type is connected (DCP
instead of a CCP) you have to change the mode to CCP.
Press the button “Pan Type”
Then press the button with the panel type you want to use.
After resetting the panel it will log on in the Artist as the assigned type.
6.4 Demo Mode
By pressing “Demo” you can start a demo mode, where all buttons are labeled with different
caracter sets.
To stop the “Key Test” mode, you have to reset the panel by pressing “Shift”+”F1”+”F2”.

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 18
7SPECIFICATIONS
POWER
Internal Power Supply
90 –253V AC (47-63Hz) max 35VA
Power supply redundancy via external power supply
10 –16V DC via XLR4
MICROPHONE INPUT (MIC A IN, MIC B IN)
Coupling
Transformer
Phantom Power
48V
Gain Range
10 –70dB
Gain Switch
-20dB
Maximum Input Level
+6dBu
High-Pass Filter
100Hz
Limiter
@ +6dBu
Input Noise Voltage
-126dBu @200Ω Source
CMRR
>60dB @ 1kHz
AUDIO LINE INPUT (AUX 1 IN, AUX 2 IN)
Coupling
Transformer
Impedance
≥10kΩ
Maximum Input Level
+18dBu
Nominal Input Level
+6dBu
Input Noise Voltage
-73dBu (20Hz-22kHz)
THD+N
<0,1% (+18dBu, 1kHz)
CMRR
>60dB @ 1kHz
AUDIO LINE INPUT (LINE IN)
Coupling
Transformer
Impedance
≥10kΩ
Input Level
10 –+18dBu
Nominal Input Level
-+6dBu
Input Noise Voltage
-73dBu (20Hz-22kHz)
THD+N
<0,2% (<0,05% @ 1kHz)
SNR
>91dB
AUDIO LINE OUTPUT (DIRECT OUT A, DIRECT OUT B, AIR A OUT, AIR B OUT, AIR A+B OUT)
Coupling
Transformer
Impedance
≤50Ω
Maximum Output Level
+18dBu
Nominal Ouput Level
-+6dBu
Output Noise Voltage
-100dBu (20Hz-22kHz)
THD+N
<0,02% (+6dBu @ 1kHz)
<0,2% (+6dBu @ 40Hz)
HEADPHONE (PHONE A, PHONE B)
Load
>25Ω
Maximum Output Level
+25dBu
Output Noise Voltage
-75dBu
THD+N
<0,05% (+18dBu @ 1kHz)

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 19
8SERVICE
We offer comprehensive customer service options for this product, if you have further questions or
suggestions. Service includes:
Telephone service
E-mail service
Skype service
Fax service
Configuration support
Trainings
Repairs
Your first contact should always be your local distributor / dealer.
In addition, Riedel Customerservice in Wuppertal, Germany is always available to help you.
Telephone: [phone]
(Monday - Friday, 8:00 –17:00 Central European Time)
Fax: [phone]
Skype: riedel.communications.service
Or use the contact form on our website:
www.riedel.net
For repairs, please contact your local distributor. Your distributor will help you with the repair
process and with securing replacement parts.
The address for sending repairs directly to Riedel Communications GmbH & Co. KG is:
Riedel Communications GmbH & Co. KG
- Repairs -
Uellendahler Str. 353
D-42109 Wuppertal
Germany

CCP-1116 Commentary Control Panel –Quick Guide 1.2
Page 20
9NOTES
