EUTECH INSTRUMENTS CyberScan PCD 650 User manual

•Use keypad buttons to access
the functions displayed above it.
•The first function group appears when you enter
“Measurement” mode. Use and to access
the 2nd and 3rd function groups.
•Use or to toggle selection and increase
or decrease values in Setup & Calibration modes.
•Use to confirm value selections and
calibrations during Setup and Calibration
procedures.
■System Set Up Mode
• Select “System” to customise your parameters and system settings, including password configuration.
Quick Guide
Waterproof CyberScan PCD 650
pH/mV/Ion/Conductivity/TDS/Resistivity/Salinity/
Dissolved Oxygen/ºC/ºF
■Keys & Functions
“Measurement” mode. Use and to access
“Measurement” mode. Use and to access
the 2nd and 3rd function groups.
Use or to toggle selection and increase
or decrease values in Setup & Calibration modes.
Use or to toggle selection and increase
or decrease values in Setup & Calibration modes.
Use to confirm value selections and
calibrations during Setup and Calibration
Use or to toggle selection and increase
Use or to toggle selection and increase
Use or to toggle selection and increase
Use or to toggle selection and increase
Keys Functions
Activates/Deactivates freezing
of measurement
Activates calibration mode
Selects parameter
Shuts off meter (hold for 3 seconds)
Switches between different
function groups
Activates setup mode
Recalls stored data from memory
Stores data into memory
Escapes to 1st function group
Shows calibration report
Sends data to PC or printer
Activates temperature calibration mode
1st Function Group
2nd Function Group
3rd Function Group
Use or to toggle selection and increase
or decrease values in Setup & Calibration modes.
Use or to toggle selection and increase
Please turn overleaf >>
System - Page 1
• ‘Stable’ Indicator: ENABLE
• Stability Criteria: FAST
• Auto Hold: DISABLE
• Tem. Display From: pH/Cond
• Display Setting:
- 1st Row: pH
- 2nd Row: Conductivity
- 3rd Row: DO (%)
System - Page 2
• Year: 2006
• Month: Jan
• Day: 01
• Hour: 00
• Minute: 00
• Second: 00
System - Page 2
• Year: 2006
• Month: Jan
• Day: 01
• Hour: 00
• Minute: 00
• Second: 00
System - Page 3
• Auto-Off : ENABLE
• On Time: 10 Mins
• Back Light Settings:
- Permanently On: DISABLE
- On With Key Press: DISABLE
- On Time With Key: 1 Min
System - Page 3
• Auto-Off : ENABLE
• On Time: 10 Mins
• Back Light Settings:
- Permanently On: DISABLE
- On With Key Press: DISABLE
- On Time With Key: 1 Min
System - Page 4
• Print Mode: IrDA
• Data Format: CyberComm
• Current Data Set: TIMED
• Interval: 9 Secs
• Fixed Setting: 2400 8-N-1
System - Page 4
• Print Mode: IrDA
• Data Format: CyberComm
• Current Data Set: TIMED
• Interval: 9 Secs
• Fixed Setting: 2400 8-N-1
System - Page 5
• Password
Protection: DISABLE
• Set Password: 00000
• Confi rm Password: NO
System - Page 5
• Password
Protection: DISABLE
• Set Password: 00000
• Confi rm Password: NO
System - Page 6
• Clear Logged Data
Memory: NO
• Factory Reset: NO
System - Page 6
• Clear Logged Data
Memory: NO
• Factory Reset: NO
Part of Thermo Fisher Scientific

68X068067 07/08 Rev 1
■pH, Ion & Temperature Set Up Mode
• Access“pH” to configure pH calibration-related settings, alarm set points and pH resolution.
• Access“Ion”to select measurement units.
• Access“Temperature” to select measurement units and temperature compensation mode.
pH - Page 1
• Buff er: USA
• Cal Points: 3
• pH Alarm:
DISABLE
• Set Points:
- Hi pH: 20.00 pH
- Lo pH: 0.00 pH
pH - Page 1
• Buff er: USA
• Cal Points: 3
• pH Alarm:
• Set Points:
- Hi pH: 20.00 pH
- Lo pH: 0.00 pH
- Lo pH: 0.00 pH
pH - Page 2
• pH Calibration
Due: 5 DAYS
• pH Resolution:
0.00
Ion - Page 1
• Ion Unit: ppm
Ion - Page 1
Ion - Page 1
• Ion Unit: ppm
• Ion Unit: ppm
Temp - Page 1
• Unit: ºC
• Mode: ATC
■Conductivity, TDS, Salinity, Resistivity Set Up Mode
• Access “Conductivity”, “TDS”, “Salinity” and “Resistivity” to configure pure/linear temperature
coefficients, normalisation temperature, cell constant, calibration-related settings as well as alarm set
points limits.
Conductivity - Page 1
• Pure Water Coeffi cient: ENABLE
• Linear Temp Coeffi cient: 2.100
• Normalisation Temp: 25.0
• Cell Constant: 1.000
• Calibration Due: DISABLE
• Calibration Points: SINGLE
• Calibration Std: AUTO
TDS - Page 1
• Pure Water Coeffi cient: ENABLE
• Linear Temp Coeffi cient: 2.100
• Normalisation Temp: 25.0
• Cell Constant: 1.000
• Calibration Due: DISABLE
• Calibration Points: SINGLE
• TDS Factor: 0.500
Salinity - Page 1
• Pure Water Coeffi cient: ENABLE
• Linear Temp Coeffi cient: 2.100
• Normalisation Temp: 25.0
• Cell Constant: 1.000
• Calibration Due: DISABLE
• Calibration Points: SINGLE
Resistivity - Page 1
• Pure Water Coeffi cient: ENABLE
• Linear Temp Coeffi cient: 2.100
• Normalisation Temp: 25.0
• Cell Constant: 1.000
• Calibration Due: DISABLE
• Calibration Points: SINGLE
Resistivity -
Page 2
• Resistivity
Alarm: DISABLE
• Set Points:
- Hi: 2.00 Ω
- Lo: 1.00 Ω
Salinity -
Page 2
• Salinity Alarm:
DISABLE
• Set Points:
- Hi: 2.000 ppm
- Lo: 1.000 ppm
Cond - Page 2
• Conductivity
Alarm:
DISABLE
• Set Points:
- Hi: 2.000 µS
- Lo: 1.000 µS
TDS - Page 2
• TDS Alarm:
DISABLE
• Set Points:
- Hi: 2.00 ppm
- Lo: 1.00 ppt
■Dissolved Oxygen % Saturation & Concentration Set Up Mode
• Access“Setup”to configure calibration-related settings, unit of measure, pressure and salinity settings
as well as alarm set points limits.
DO (%) - Page 1
• Off set Cal: 0.0 %
• Calibration Due (%): 5 DAYS
• Select Pressure Unit: mmHg
• Measured Pressure: 760.0
• Adjusted Pressure: 760.0
• Pressure Comp: ENABLE
DO (mg/L) - Page 1
• Select DO Unit:
mg/L
• Auto Salinity Comp:
DISABLE
• Set Salinity:
0.0 ppt
DO (%) - Page 2
• DO Alarm: DISABLE
• Set Points:
- Hi DO: 200.0 %
- Lo DO: 10.0 %
DO (mg/L) - Page 2
• DO Alarm: DISABLE
• Set Points:
- Hi DO: 20.00 mg/L
- Lo DO: 1.00 mg/L
