EVBox Dual Socket Test Box User manual

User manual
Dual
Socket
Test Box

User manual
Dual
Socket
Test Box

Contents 1
Safety precautions 1
Description 2
Features 2
Operation 3
Test charging station 3
Test kWh meter 4
Maintenance 5
Cleaning 5
Servicing 5
Technical specications 5
Acronyms 6
Contents
Safety precautions
Warnings
• The EVBox Dual Socket Test Box must be used exclusively for the purpose
intended, as described in “description”.
• Ensure that the EVBox Dual Socket Test Box is used under the correct
operating conditions.
• The EVBox Dual Socket Test Box contains no user-serviceable parts.
Consult EVBox or your distributor for more information in case of
observing unexpected behavior. Do not attempt to service or repair the
EVBox Dual Socket Test Box yourself!
• Do not modify the product in any way. This will result in a loss of product
warranty and liability and may lead to dangerous circumstances!
Standards and regulations
The product is manufactured and tested according to the following regulations:
• EN/IEC60884-1:2002+AMD1:2006+AMD2:2013
• EN/IEC 62196-2:2016
EN
1

2
Description
Schuko socket with
protective cover
Type 1 (SAE J1772) socket
with protective cover
Type 2 (EN/IEC 62196-2)
socket with protective cover
Socket light indicators
State Switch for EV
charging simulation
The EVBox Dual Socket Test Box has been designed for carrying out
comprehensive and accurate tests of an EVBox charging station.
This unit simulates the connection of an EVBox charging station to
an electric vehicle, allowing the installer to verify multiple safety and
operational requirements during commissioning or eld service.
This model with article number 462323 is designed to carry out a full
range of tests on all 16 A and 32 A Mode 3 charging stations with either a
Type 1 (SAE J1772) or Type 2 (EN/IEC 62196-2) plug. Load simulations
can be performed on phase 1 of the installation by applying a load on the
Schuko socket.
Features
• Simulates an electric vehicle
• Tests charging stations equipped with charge cable with Type 1 plug
(SAE J1772)
• Tests charging stations equipped with charge cable with Type 2 plug
(EN/IEC 62196-2)
• Allows for testing of contactor functionality of EV charging stations
• Includes indicator lights to show charging session status on
the selected socket
EN
Denition of state options
Position B Electric vehicle connected, not charging
Position C Electric vehicle connected, charging
A
B
C
D
E
A
B
C
E
E
D

How to test EVBox charging station
1. Plug the charging cable into the EVBox Dual Socket Test Box
in its designated socket (Type 1 or Type 2).
2. Set the switch button to “Position C” for the appropriate
socket type (Type 1 or Type 2).
3. Start the charging session by holding an RFID card in front of
the charging station’s RFID reader. Alternatively, you can use
any other available authorization method to start a charging
transaction.
4. The green LED ring (HMI) will begin ashing; you will hear
one beep sound.
5. At this point, the LED ring will turn yellow and then
immediately to blue, indicating that the simulated charging
session has started. You will see the green socket indicator
light for the chosen socket type (Type 1 or Type 2) lighting up,
indicating that its corresponding socket is energized.
6. Stop the charging session by holding the same RFID card in
front of the charging station’s RFID reader, or by using the
same alternate authorization mode from step 3 to stop the
charging transaction.
7. The LED ring will turn green or switch off completely
(depending on the settings).
Operation / charging station
Warnings
• The Schuko socket is intended for test purposes only.
• Do not use it as an extension for local power supply.
• The Type 1 or Type 2 socket is energized when its
corresponding light indicator is lit.
• Do not use both Type 1 and Type 2 sockets simultaneously.
3
EN

4
Operation / kWh meter
How to test the kWh meter on EVBox charging station
1. Plug the charging cable into the EVBox Dual Socket Test Box
in its designated socket (Type 1 or Type 2).
2. Plug any device into the Schuko socket (e.g. an electric
heater) and turn it on. Note: The maximum current rating of
the device must not exceed 10 A.
3. Set the switch button to “Position C” for the appropriate
socket type (Type 1 or Type 2).
4. Start the charging session by holding an RFID card in front of
the charging station’s RFID reader. Alternatively, you can use
any other available authorization method to start a charging
transaction.
5. The green LED ring (HMI) will begin ashing; you will hear
one beep sound.
6. At this point, the LED ring will turn yellow and then
immediately to blue, indicating that the charging session has
started. You will see the green socket indicator light for the
chosen socket type (Type 1 or Type 2) light up, indicating that
its corresponding socket is energized.
7. Some charging stations allow you to monitor the kWh meter
readings during a charging session. This will enable you to
monitor the actual energy consumption.
8. After a while, stop the charging session by holding the same
RFID card in front of the charging station’s RFID reader, or by
using the same alternate authorization mode from step 4 to
stop the charging transaction.
9. The LED ring will turn green again or switch off completely
(depending on the settings).
10. Check that the charging session is recorded in the online
portal and that the energy consumption is shown.
EN

Maintenance
This product contains no user-serviceable parts. Consult EVBox or
your distributor for more information. Do not attempt to service or
repair the product yourself!
Cleaning
No special maintenance is required for the housing. To clean the
surface of the EVBox Dual Socket Test Box, use a soft cloth slightly
moistened with soapy water.
Warnings
• Do not use petrol- or hydrocarbon-based liquids.
• Do not spill cleaning liquid over the EVBox Dual Socket
Test Box.
Service
For any repairs under warranty, please contact your distributor.
Technical specications
400 V (3-phase)
50/60 Hz
13 A intermittent operation
IP 44
+2000 m (6560 ft) above sea level
230 x 150 x 85 mm (9 x 6 x 3 in)
1,36 kg (3 lbs)
state B (EV connected, not charging), state C (EV connected, charging)
-25°C to +60°C (-13°F to +140°F)
Max. 95 % non-condensing
-25°C to +60°C (-13°F to +140°F)
Max. 95 % non-condensing
General properties
Input voltage
Frequency
Maximum test current
Protection degree
Altitude
Dimensions (L x W x H)
Weight
Functions
CP simulation
Operation conditions
Operating temperature range
Operating humidity
Storage conditions
Storage temperature range
Maximum relative humidity
5
EN

The present document is drawn up by way of information only and does not constitute an offer binding
upon EVBox. EVBox has compiled the contents of this document to the best of its knowledge.
No express or implied warranty is given for the completeness, accuracy, reliability or tness for particular
purpose of its content and the products and services presented therein. Specications and performance
data contain average values within existing specication tolerances and are subject to change without
prior notice. Prior to ordering, always contact EVBox for the latest information and specication. EVBox
explicitly rejects any liability for any direct or indirect damage, in the broadest sense, arising from or
related to the use and/or interpretation of this document. EVBUM_062019 © EVBox B.V.
EVBox strives to produce products of the highest quality. EVBox products are fully CE certied and
compliant with the essential requirements of Low Voltage Directive 2014/35/EU. More details can be
found at evbox.com or in this User Manual. EVBox products are sold with a limited warranty described at
evbox.com/general-terms-conditions.
© 2019 EVBox B.V. All rights reserved. Elvi®, EVBox® and the EVBox logo
are trademarks or registered trademarks of EVBox B.V. in the EU and
in other countries.
EVBox B.V.
Fred. Roeskestraat 115,
1076 EE Amsterdam
The Netherlands
[email protected]
evbox.com
Acronyms
EV:
HMI:
kWh:
LED:
RFID:
Electric vehicle
Human-machine interface
kilowatt-hour
Light-emitting diode
Radio frequency identication
6
EN

Article number: 999500.2
EVBUM_062019 © EVBox B.V.
