Event Lighting M1H300W User manual

M1H300W
Hybrid Moving Head with CMY, CTO and Zoom
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to
change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting
for any clarification or information regarding this item.
www.event-lighting.com.au
V1.0

2
www.event-lighting.com.au
Safety Instructions
WARNING
• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
• CAUTION: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.
Product Installation
This device can be mounted in many orientations provided each
individual device is secured by the use of correct mounting bracket.
Use a safety chain when mounting this device overhead.

3
www.event-lighting.com.au
Product appearance, LUX chart, Dimensions
1. Project lens
2. Head
3. Arm
4. Base
5. Display
6. Foot stand
7. Operation button
8. Handle
9. Wireless indicator
10. Mic
11. Left button
12. Battery indicator
13. Up button
14. Down button
15. Enter button
16. Right button
17. 3-pin DMX in
18. 5-pin DMX in
19. 3-pin DMX out
20. 5-pin DMX out
21. Powercon in
22. Fuse
23. Power switch

4
www.event-lighting.com.au

5
www.event-lighting.com.au
Colour wheel
1 Open
2
Magenta
3
Orange
4
Sky blue
5
Pink
6
Yellow
7
Green
8
Blue
9
Red
Gobo wheel
Static gobo wheel Rotating gobo wheel (slot-in-out gobos)

6
www.event-lighting.com.au
Rotating gobo wheel
Position 1
Position 2
Position 3
Position 4
Position 5
Position 6
Position 7
Position 8

7
www.event-lighting.com.au
Static gobo wheel
Position 1
Position 2
Position 3
Position 4
Position 5
Position 6
Position 7
Position 8

8
www.event-lighting.com.au
Menu operation
Description of icons in the menu
CONNECT LIGHT INFOMATION SET PROGRAM
Menu
Default setting shadowed. Mark with ①can be basic reloaded, ② be program reloaded, ③can be private reloaded.
Connect
DMX Address① XXX DMX address setting
Wireless① Wireless Enabled
Light
Max
Temperature①
80~139℃80℃ /176~282℉176℉ Lamp off if temperature
continuously over for 5
minutes
Lamp Adjust① PAN…… Adjust value of channel
Information
Time Info. Current XXXX(Hours)
Fixture Life XXXX(Hours)
Fixture boot time
Fixture total run time
Temperature Near Lamp Temp (depends on fixture) Temperature Sensors
Fans Speed Near Lamp Fan (depends on fixture) Fan speed Sensors
Channel Value PAN…… Display value of channel
Error Message Pan,Tilt…… Error channels
Fixture Model xxxxxxxxxxxx Display model brand and
model
Software Ver 1U01 V1.0.00……… Version of each IC
Set
Reset All
Pan&Tilt
Colors
Gobos
Others
Reset all
Reset Pan & Tilt
Reset Colors
Reset Gobos
Reset Others
Movement Pan Reverse①
Tilt Reverse①
Pan Degree①
Encoders①
Pan/Tilt Mode①
ON/OFF
ON/OFF
630/540
ON/OFF
Stand/Smooth
Pan Reverse
Tilt Reverse
Choose Pan Degree
Encoder wheel on/off
Choose pan/tilt mode
UI Set Mic Sens. ③
No Signal①
Temperature. C/F①
Fans Mode①
Hibernation①
Backlight①
Flip Display①
0~99%,60%
Close/Hold/Auto/Music
Fahrenheit /Celsius
Auto Speed /High Speed
OFF, 01M~99M，15M
02~60m 02m
ON/OFF
Sensitivity of Mic
Mode when no signal
Temperature at ℃/℉
Fans mode
Sleeping mode
Show backlight time
Display 180°reverse

9
www.event-lighting.com.au
Display Bright③
Brand Show①
Key Lock①
Language③
00~31 10
ON/OFF
ON/OFF
En/简/繁/Fr/Sp
Display Brightness
Show brand or not
Key lock on/off
Language Select
Users User Mode① Standard
Extended
Basic-8bit
Basic-16bit
User
Standard mode
Extended mode
Basic-8bit mode
Basic-16bit mode
User program mode
Edit User③ Max Channel = XX
PAN = CH01
:
Edit users mode
Calibration③ -Password-
Color
:
=XXX
=XXX
:
Password: 050
Calibrate channel value
Fixture ID③ Name
-Password-
PID Code
Name
Password: 050
Set PID of RDM
Wireless Set① DMX On Cable
Reset Connect
ON/OFF
ON/OFF
DMX Send Out
Reset Connect
Reload Default Basic Reload(①)
Program Reload(②)
---Password---
Private Reload(③)
All Reload
ON/OFF
ON/OFF
XXX
ON/OFF
ON/OFF
Basic Reload
Program Reload
Password: 050
Private Reload
All Reload
Program
Play① DMX Receive
Slave Receive
Sequence
Music
Slave Receive 1,2,3
Master / Alone
Master / Alone
DMX Receive
Choose slave position
Run Sequence
Music mode
Select Chase② Chase Part 1
Chase Part 2
Chase Part 3
Chase 1 ~ 8 Chase 1
Chase 1 ~ 8 Chase 2
Chase 1 ~ 8 Chase 3
Select and run auto program
Edit Chase② Chase 1
:
Chase 8
Chase Test
Step 01
Step 64
=SCxxx
=SCxxx
Test
Beginning scene
Ending scene
Edit Scenes② Edit Scene 001
~ Edit Scene 250
Pan,Tilt,……
--Fade Time--
--Secne Time--
DMX Input
=xxx
=xxx
=xxx
Input manual scene
Modify manually fading time
Modify manually scene time
Input scene from exterior
controller
Scenes Record ScXX=>ScXX Auto Input scenes

10
www.event-lighting.com.au
DMX Chart
Channel name function Min
DMX
Max
DMX
St Ex Ba1 Ba2
1 1 1 1 Pan Pan Coarse 0 255
2 2 Pan fine Pan Fine 0 255
2 3 2 3 Tilt Tilt Coarse 0 255
4 4 Tilt fine Tilt Fine 0 255
3 5 3 5 Movement
Speed fastest to Slowest 0 255
6
Movement
Function
Normal 0 15
Movement With Blackout 16 31
TBD 32 255
4 7
Shutter
Function
Normal Shutter Functions 0 15
Pulse-effect Forward 16 31
Pulse-effect Reverse 32 47
Random Strobe 48 63
TBD 64 255
5 8 Shutter
Normal Shutter Functions
Close 0 31
Strobe Rate (slow to fast) 32 223
Open 224 255
Pulse-effect Forward
Close 0 31
Strobe Rate (slow to fast) 32 223
Open 224 255
Pulse-effect Reverse
Close 0 31
Strobe Rate (slow to fast) 32 223
Open 224 255
Random Strobe
Close 0 31
Strobe Rate (slow to fast) 32 223
Open 224 255
4 6 Shutter
Shutter closed 0 31
No function (shutter open) 32 63
Strobe effect slow to fast 64 95
No function (shutter open) 96 127
Pulse-effect in sequences 128 159
No function (shutter open) 160 191
Random strobe effect slow to fast 192 223
No function (shutter open) 224 255
6 9 5 7 Dimmer Dimmer(Close to Open) 0 255

11
www.event-lighting.com.au
7 10
Colour
Function
Indexed 0 15
Indexed With Blackout 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Colour Bounce 80 111
TBD 112 255
8 11 Colour
Indexed & Indexed With Blackout & Colour Bounce
Position 1 (Open) 0 13
Position 2 ~ Position 18 14 255
Forward Spin
Stop to fastest 0 255
Reverse Spin
Stop to fastest 0 255
Continuous
Positioning from 0-360 degrees 0 255
6 8 Colour
Indexed
Position 1 (Open) 0 2
Position 2 ~ Position 18 3 53
Indexed With Blackout
Position 1 (Open) 54 56
Position 2 ~ Position 18 57 106
Indexed With Bounce
Position 1 107 119
Position 2 ~ Position 9 120 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
9 12 7 9 Cyan Cyan 0->100% 0 255
10 13 8 10 Magenta Magenta 0->100% 0 255
11 14 9 11 Yellow Yellow 0->100% 0 255
12 15 10 12 CTO CTO 0->100% 0 255
13 16
Rot Gobo
Function
Indexed 0 15
Indexed With Blackout 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Shake 80 95
TBD 96 255
14 17 Rot Gobo
Indexed & Indexed With Blackout & Shake
Position 1 (Open) 0 31
Position 2 ~ Position 8 32 255
Forward Wheel Spin

12
www.event-lighting.com.au
Stop to fastest 0 255
Reverse Wheel Spin
Stop to fastest 0 255
Continuous
Positioning from 0-360 degrees 0 255
11 13 Rot Gobo
Indexed
Position 1 (Open) 0 5
Position 2 ~ Position 8 6 47
Indexed With Blackout
Position 1 (Open) 48 53
Position 2 ~ Position 8 54 97
Indexed With Shake
Position 2 98 115
Position 3 ~ Position 8 116 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
15 18
Gobo Rot
Function
Continuous 0 15
Forward Spin 16 31
Reverse Spin 32 47
Forward Animate Rotate 48 63
Forward Animate Rotate With Blackout 64 79
Reverse Animate Rotate 80 95
Reverse Animate Rotate With Blackout 96 111
TBD 112 255
16 19 Gobo Rot
Continuous
Positioning from 0-360 degrees 0 255
Forward Spin
Stop to fastest 0 255
Reverse Spin
Stop to fastest 0 255
Forward Animate Rotate & Forward Animate Rotate
With Blackout
Stop to fastest 0 255
Reverse Animate Rotate & Reverse Animate Rotate
With Blackout
Stop to fastest 0 255
12 14 Gobo Rot
Continuous
Positioning from 0-360 degrees 0 191
Forward Animate Rotate
Stop to fastest 192 207
Reverse Animate Rotate
Stop to fastest 208 223

13
www.event-lighting.com.au
Forward Spin
Stop to fastest 224 239
Reverse Spin
Stop to fastest 240 255
17 20
Gobo
Function
Indexed 0 15
Indexed With Blackout 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Shake 80 95
TBD 96 255
18 21
Fixed
Gobo
Indexed & Indexed With Blackout & Shake
Position 1 (Open) 0 31
Position 2 ~ Position 8 32 255
Forward Wheel Spin
Stop to fastest 0 255
Reverse Wheel Spin
Stop to fastest 0 255
Continuous
Positioning from 0-360 degrees 0 255
13 15 Fixed
Gobo
Indexed
Position 1 (Open) 0 5
Position 2 ~ Position 8 6 47
Indexed With Blackout
Position 1 (Open) 48 53
Position 2 ~ Position 8 54 97
Indexed With Shake
Position 2 98 115
Position 3 ~ Position 8 116 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
19 22 14 16 Prism
Indexed & Indexed With Blackout
Position 1 (Open) 0 84
Position 2 85 169
Frost 0->100% 170 255
20 23 15 17 Prism Rot
Forward Spin
Stop to fastest 0 127
Reverse Spin
Stop to fastest 128 255
21 24
Focus
Function
Continuous 0 15
5m Auto Focus 16 31
7.5m Auto Focus 32 47

14
www.event-lighting.com.au
10m Auto Focus 48 63
15m Auto Focus 64 79
>20m Auto Focus 80 95
TBD 96 255
22 25 16 18 Focus
Continuous
Focus In to Focus Out 0 255
Auto Focus
Focus In to Focus Out Fine 0 255
23 26 17 19 Zoom Continuous
Zoom Small to Big 0 255
24 27
Iris
Function
Indexed 0 15
Pulse opening With Forward Blackout 16 31
Pulse opening With Reverse Blackout 32 47
Pulse closing With Forward Blackout 48 63
Pulse closing With Reverse Blackout 64 79
TBD 80 255
25 28 Iris
Indexed
Max. diameter to Min. diameter 0 255
Pulse opening & Pulse closing
Pulse Slow to Fast 0 255
18 20 Iris
Indexed 0 191
Pulse opening With Forward Blackout 192 207
Pulse opening With Reverse Blackout 208 223
Pulse closing With Forward Blackout 224 239
Pulse closing With Reverse Blackout 240 255
26 29 19 21 Control
Normal 0 7
Reset All 8 15
Pan & Tilt Reset 16 23
Color Reset 24 31
Gobo Reset 32 39
TBD 40 47
Other Reset 48 55
Display Off 56 63
Display On 64 71
TBD 72 79
TBD 80 87
Hibernation 88 95
TBD 96 255
- The device is controlled by universal DMX 512 protocol, DMX address is the start channel used to receive
instructions from the external controller. For independent control, each fixture must be assigned its unique address
control channels. For example, this device has four channel modes: 26/29/19/21, if we set the mode at standard 26
channels mode, and there are several models need to be independently controlled, we just simply address first
fixture at 1, and second fixture at 27, third one at 53, etc.

15
www.event-lighting.com.au
- If the devices have the same address, they will behave synchronically.
- Display is flashing when no DMX signal is received.
More functions
- RDM. RDM stands for “Remote Device Management”, with this function, users can realize remote control of the
device, such as remotely changing DMX address, reverse pan/tilt setting, check a lot of useful information such as
temperature, power consumption, fan speed. Etc. Every single device has a unique RDM code programmed at
manufacture to distinguish from each other. It is not recommended for users to change this code.
- Software upgrade function via DMX cable. If there is any new firmware for this device, it can be upgraded simply via
a software upgrade box, no need to change any mechanical parts. The upgrade box is not included in the package,
if need any further assistance please just contact your authorized dealer.
- Hibernation. The device will enter sleeping mode if activated after a period of disconnecting DMX signal to save the
power consumption, and will return immediately as soon as the DMX signal is sent again.
- Display back-up communication IC. There is a back-up communication IC installed in the display PCB, so users
could replace at once if the original one is broken.
- Display flip. By press up and down button for more than 3 seconds, the display will flip automatically, this function is
useful to read menu conveniently when device is hanged.
Technical Specifications
Power
- Input Voltage: 100~240V AC, 50/60 Hz
- Power Consumption: 420W
- Connection: Neutrik® PowerCON – In
Photometric
- Light Source: Advanced 6500K 300W White LED Module
- Beam Angle: 6° to 48°
- Output: 18000 lumen, 89700 lux on @2.5M
- PWM: 1200Hz
- LED Lifespan: 60,000 hours
Effects
- Dimming: 0 ~ 100%
- Strobe: 0.5 ~26 Hz
- Focus: Linear via DMX
- Prism: 3 Facet & Frost
- Iris: Yes
- Zoom: Linear via DMX 6° to 48°
- Movement 8 / 16 bit Auto Reposition
- Pan: 630°( 4.0 sec) or 540°( 3.58 sec)
- Tilt: 265°(2.8 sec)
Colour
- Liner CMY & CTO
- 8 Colours + Open

16
www.event-lighting.com.au
Gobos
- Fixed: 1 x 7 + Open Fixed Gobo Wheel
- Rotating: 1 x 7 + Open Interchangeable Rotating Gobo Wheel (Outside Ø27mm, Inside Ø20mm).
Control
- Operational Modes: DMX, Auto Program, Sound Active, Master / Slave
- RDM: Change DMX Address, Display Flip, X/Y Reverse and so on
- Protocol: DMX512 (W-DMX™ Optional)
- DMX Channels: 26 / 29 / 19 / 21
- Interface: 3-Pin & 5-Pin XLR
- Display: 2.4″ Colour LCD Control Panel with Back-up Power.
- Software Upgrade via DMX: Yes
Housing
- Materials: ABS & Steel
- Finishing: Matte black
- Cooling: Multi Sensor Thermostat Controlled Variable Speed Fan
- IP rating: IP20
- Dimension: 369 x 437 x 658 mm
- Net Weight: 18 kg
- Rigging: 2pcs Omega Brackets with 1/4-turn Quick Locks
MISC
- Road case: MCASE1LS (fit 1 unit) MCASE2VLS (fit 2 units)
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au.
