Lightolier HX Series User manual

HX Series
Hazardous Location Combination LED Exit Sign
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: Illumination
of the exit stencil face is
accomplished with long lasting,
high output LEDs, producing
an average illumination level
in excess of 25 fl (85.7 cd/m2)
at the end of the 90 minute
emergency run time. A variety
of optional lamp heads provide
design flexibility for egress
lighting.
Housing: Constructed of
impact-resistant, fiberglass-
reinforced polyester. Housing
color is gray with corrosion-
resistant hardware and clear
polycarbonate cover. The HX
Series is UL listed for Class I,
Division 2, Groups A, B, C &
D; Class I, Zone 2, Groups IIA,
IIB (+ H2) & IIC; and Class II,
Division 2, Groups F & G. The
housing includes a one-piece
formed gasket and corrosion-
resistant hardware. Standard
internal or external mounting
feet provides installation
flexibility.
Operating Temperature
Range: Standard location
65°F (19°C) to 85°F (30°C)
Diagnostic Electronics
(standard): 120/277 VAC
dual voltage input with surge
protection is standard on all
models. Charging system is
microprocessor driven with
software embedded diagnostic
routine and temperature
compensation. 120/277 VAC
input, surge protection,
brownout, AC lockout and low
voltage disconnect features are
standard.
Self-Testing Diagnostics
(optional): The diagnostic/
charging platform with self-
testing mode automatically
runs a one-minute self-test
every 30 days and a 30-minute
test on the sixth and twelfth
month. A one-minute or
90-minute test may be initiated
via the push to test switch on
the unit or by activating the
appropriate test command on
the optional IR test device.
Electrical Specifications:
6 V 18 W Red or Green:
120 VAC, 0.133 A, PF 0.80
277 VAC, 0.058 A, PF 0.80
6 V 36 W Red or Green:
120 VAC, 0.122 A, PF 0.70
277 VAC, 0.053 A, PF 0.70
6 V 72 W Red or Green:
120 VAC, 0.129 A, PF 0.80
277 VAC, 00.56 A, PF 0.80
Code Compliance
UL 924 and 844 listed. NFPA
101, NEC, BOCA, OSHA and
IBC illumination standards.
Temperature Rating (T-Rating)
160° (T3C). Class I, Zone 2
T-Rating 200° (T3). IEC
61951-1 Life Testing (batteries).
Warranty
Five year full electronics
warranty. One year full plus
four year prorated battery
warranty.
13.2"
(33.5 cm)
11.2"
(28.4 cm)
HX636R2HT18SD2
6.6"
(16.8 cm)
17.5"
(44.5 cm)

HX Series
Hazardous Location Combination LED Exit Sign
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
HX Series - Combo May 22, 2012
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2012.All rights reserved.
Job Information Type:
Ordering Information
Series
HX =
Hazardous
Location
Combination
Exit
Lead Calcium
18 = 18 Watt Unit
36 = 36 Watt Unit
72 = 72 Watt Unit
Battery/Wattage3Letter Color
R= Red
G= Green
SD2 = Diagnostic
Electronics
Model Designator1
Note
1) For self-testing models refer to options.
2) Some option combinations may impact UL listing.
Consult factory for specifics.
3) Battery capacity to support local/remote load.
SD2
BF = Buzzer/Flasher
BZ = Buzzer
EX = Special Input Transformer
(specify voltage & frequency)
FL = Flasher (self-powered models
only)
S= Shatterproof Lamp Head Lens
T= Self-Testing Diagnostics
(non-audible)
TA = Audible Self-Testing Diagnostics
TD = Time Delay
Factory Installed Options2
Accessories (order as a separate item)
SDREMOTE = Infrared Remote Test Device
WG5 = Wire Guard
HX
Optics
Wall mounted 7.5' AFF, ‘IH’ 6 Volt 12 Watt Halogen Lamps Represented
1 FC Average
7.5 ft.
24 ft. 10 ft.
Average initial footcandles at floor = 1.05
Maximum initial footcandles at floor = 3.3
Minimum initial footcandles at floor = 0.1
Maximum to minimum ratio = 33.00
* The optics layout shown is intended to be used as reference only. Standard reflectances used were 80/50/20. Lightolier is not responsible for site specific conditions that
may alter the results.
6= 6 VDC
System Voltage
6
# of Heads
Blank = No
Lamp Heads
1= One Lamp
Head
2= Two Lamp
Heads
Lamp Heads
Tungsten
HT8 = 8 Watts
HT18 = 18 Watts
HT25 = 25 Watts
Halogen
HH6 = 6 Watts
HH8 = 8 Watts
HH12 = 12 Watts
