Event Lighting PRO PAR19x15 User manual

PRO PAR
Model No. PAR19x15, PAR19x15O
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
www.event-lighting.com.au
Ver 3.0

www.event-lighting.com.au
1
CONTENTS
Safety Instructions
- Power input & power Linking
Product Installation
- Fuse replacement
Diagrams
- Lux chart
- Dimensions
- Fade Mode Chart
Control Board Operation
- DMX address setting
- DMX modes setting
- Dimmer Speed Setting
- Static colour setting
- Manual colour setting
- Auto run and sound active setting
- Master/slave setting
DMX chart
Technical specifications
Warranty

www.event-lighting.com.au
2
Safety Instructions
WARNING
• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
• CAUTION: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this number.
The maximum number of units that can be power linked is 4 units at 110V and 8 units at 240V.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by the use of correct
mounting bracket.
Use a safety chain when mounting this device overhead.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.

www.event-lighting.com.au
3
Lux Chart
Dimensions

www.event-lighting.com.au
4
CONTROL BOARD OPERATION
Display Options / Values Function
DMX Add <001> - <512> To set DMX address
DMX Cha <03>, <04>, <06>,<07>, <10>, <12>,<14>,
<24>
To set DMX channel modes
DimMode Standard, Stage, TV, Architec, Theater To set fade time.
Standard, Stage, TV, Architecture, Theater
StaticC R, G, B, W, GB, RB, RG, RGB, RW, GW,
BW, RGW, RBW, GBW, RGBW
To select static colours
ManualC
R<000~100>, G<000~100>, B<000~100>,
W<000~100>,
To select intensity of each colour separately for color
mixing
I<000~100> To select master dimmer for colour mixing
S<000~025> To select strobe rate
ManualW WT<01~11>
Dim<000~100>
To select 11 preset warm white or cool white WT
To select intensity Dim
Auto Pro <Pr01~Pr21> To select built-in automatic programs
<Sp000~Sp100> To set speed of auto run
Sound Sen<000~100> To set sound active mode and set sound sensitivity level
Mas/Sla <M>, <S> To set Master/Slave modes
UpDate <N>/ <Y> Select to update firmware
<START> Use this fixture to update another fixture's software
ReSet <N> / <Y> To reset factory default setting
DMX Addressing:
After selecting the "DMX Add" press “Enter”, use “Up” and “Down” buttons to select the desired DMX address, press
“Enter" to save new setting
DMX Modes
After selecting the "DMX Cha" press “Enter”, use “Up” and
“Down” buttons to select the desired DMX mode, press “Enter"
to save new setting
Fade Mode
Select "DimMode" in main menu and press “ENTER”, use the
“UP” and “DOWN” buttons to select the desired fade time.

www.event-lighting.com.au
5
Set Static Colour
Select "Static C" in main menu and press “ENTER”, use the “UP” and “DOWN” buttons to select the desired solid
colour.
Value: Function:
R Red
G Green
B Blue
W White
GB Green + Blue
RB Red + Blue
RG Red + Green
RGB Red + Green + Blue
RW Red + White
GW Green + White
BW Blue + White
RGW Red + Green + White
RBW Red + Blue + White
GBW Green + Blue + White
RGBW Red + Green + Blue + White
Manual Colour Mode
Set intensity of each colour separately, also you can set master dimmer and strobe function.
Select "ManualC" in main menu and press “ENTER”, use the “UP” and “DOWN” buttons to set the specific R, G, B or W
values (000-255), as well as the master dimmer values I<000~100> and strobe speed values S<000~025>. Press
“ENTER” to save new setting.
Manual Warm White / Cool White Mode
This fixture has 11 preset warm white / cool white. Select "Manual W" in main menu and press “ENTER”, use the “UP”
and “DOWN” buttons to set the desired preset mode. Press “ENTER” to confirm, then set the intensity using the “UP
and “DOWN” buttons and press “ENTER” to save new setting.
Automatic Mode
This fixture has 21 built-in programs. Only Pr21 is multi fixture chases.
Select "Auto Pro" in main menu and press “ENTER”, uses the “UP” and “DOWN” buttons to select the desired built-in
program and press “ENTER” to confirm. Set the program speed (SP00-SP100) using the “UP and “DOWN” buttons and
press “ENTER” to save new setting.
To setup multi fixture chases Pr 21. Before starting, go to each fixture and reset the menu to fixture defaults.
1. On the master unit, setup the DMX address to the total number of fixtures in the string. For example, you may have
a total of 20 par cans including the master, so the DMX address should be set to “20”.
2. On the master unit, go to master/slave menu setting and set the unit to master
3. On the master unit, set the unit to “Auto Pro” “Pr 21” which supports multi fixture chases.
4. On each slave unit, setup the DMX address to the fixture position in the string. For example, if this unit is the 2nd
unit in the string including the master, then set the DMX address to 2. If this the last unit of 20, then the DMX address

www.event-lighting.com.au
6
should be set to 20. It is possible to double up fixture positions as well as fixture 1.
5. On each slave, go to the master/slave menu setting and set it to slave.
Sound Mode
Select "Sound" in main menu and press “ENTER”, use the “UP” and “DOWN” buttons to set the sensitivity
(SEN000-SEN100), press “ENTER" to save new setting.
Master/Slave
Set the master fixture to one of the standalone operating modes.
Set the slave, enter "Mas/Sla" mode, set to “S”, press “Enter” to save the setting.
Firmware update
The fixture can be managed by the RDM controller. It also can be upgraded firmware from one to another by DMX
connector. The firmware on multiple fixtures can be upgraded simultaneously via DMX.
Use fixture A to update fixture B’s firmware
- Set fixture A to “Update” mode, select “Y” then select “START”
- Link fixture A and fixture B with DMX cable, then power up fixture B
- Press “Enter” on fixture A, fixture B’s firmware will be copied from fixture A.
*Ensure that fixture A and B are of the same type, otherwise damage may occur.
* Only fixture A and B should be in the DMX chain when updating firmware.
Restore Factory default setting
Select "RESET" in main menu and press “ENTER”, use the “UP” and “DOWN” buttons to select “Y”, then press
“ENTER” to restore the fixture to factory default settings.
DMX Chart
3 channels Mode
Channel Value Function
1 000-255 Red: 0% ~ 100%
2 000-255 Green: 0% ~ 100%
3 000-255 Blue: 0% ~ 100%
4 channels Mode
Channel Value Function
1 000-255 Red: 0% ~ 100%
2 000-255 Green: 0% ~ 100%
3 000-255 Blue: 0% ~ 100%
4 000-255 White: 0% ~ 100%

www.event-lighting.com.au
7
6 channels Mode
Channel Value Function
1 000-255 Red: 0% ~ 100%
2 000-255 Green: 0% ~ 100%
3 000-255 Blue: 0% ~ 100%
4 000-255 White: 0% ~ 100%
5 000-255 Master dimmer: 0% ~ 100%
6
000-007 Shutter closed ( No light)
008-015 Shutter on
016-119 Strobe slow to fast (1-25Hz)
120-127 Shutter on
128-183 Strobe random slow to fast
184-191 Shutter on
192-247 Strobe sound sensitivity from low to high
248-255 Shutter on
7 channels Mode
Channel Value Function
1 000-255 Red: 0% ~ 100%
2 000-255 Green: 0% ~ 100%
3 000-255 Blue: 0% ~ 100%
4 000-255 White: 0% ~ 100%
5 000-255 Master dimmer coarse: 0% ~ 100%
6 000-255 Master dimmer fine: 0% ~ 100%
7
000-007 Shutter closed ( No light)
008-015 Shutter on
016-119 Strobe slow to fast (1-25Hz)
120-127 Shutter on
128-183 Strobe random slow to fast
184-191 Shutter on
192-247 Strobe sound sensitivity from low to high
248-255 Shutter on
10 channels Mode
Channel Value Function
1 000-255 Red: 0% ~ 100%
2 000-255 Green: 0% ~ 100%
3 000-255 Blue: 0% ~ 100%
4 000-255 White: 0% ~ 100%
5 000-255 Master dimmer: 0% ~ 100%
6 000-009 Strobe OFF

www.event-lighting.com.au
8
010-255 Strobe (slow-fast 1-25Hz)
7
000-009 No Function
010-031 White 1
032-054 White 2
055-077 White 3
078-100 White 4
101-123 White 5
124-146 White 6
147-169 White 7
170-192 White 8
193-215 White 9
216-238 White 10
239-255 White 11
8
000-009 No Function
010-020 Auto run 1
021-032 Auto run 2
033-044 Auto run 3
045-056 Auto run 4
057-068 Auto run 5
069-080 Auto run 6
081-092 Auto run 7
093-104 Auto run 8
105-116 Auto run 9
117-128 Auto run 10
129-140 Auto run 11
141-152 Auto run 12
153-164 Auto run 13
165-176 Auto run 14
177-188 Auto run 15
189-200 Auto run 16
201-212 Auto run 17
213-224 Auto run 18
225-236 Auto run 19
237-255 Auto run 20 ( cycle run auto 1-19)
9 000-255 Speed of auto programs (slow ~ fast) or sound sensitivity
10
000-009 Dimmer mode as set from main menu
010-058 Standard (dimmer 1)
059-108 Stage (dimmer 2)
109-158 TV (dimmer 3)
159-208 Architecture (dimmer 4)
209-255 Theatre (dimmer 5)

www.event-lighting.com.au
9
12 Channels Mode
Channel Value Function
1 000-255 Centre Red: 0% ~ 100%
2 000-255 Centre Green: 0% ~ 100%
3 000-255 Centre Blue: 0% ~ 100%
4 000-255 Centre White: 0% ~ 100%
5 000-255 Inner ring Red: 0% ~ 100%
6 000-255 Inner ring Red: 0% ~ 100%
7 000-255 Inner ring Blue: 0% ~ 100%
8 000-255 Inner ring White: 0% ~ 100%
9 000-255 Outer ring Red: 0% ~ 100%
10 000-255 Outer ring Green: 0% ~ 100%
11 000-255 Outer ring Blue: 0% ~ 100%
12 000-255 Outer ring White: 0% ~ 100%
14 Channels Mode
Channel Value Function
1 000-255 Centre Red: 0% ~ 100%
2 000-255 Centre Green: 0% ~ 100%
3 000-255 Centre Blue: 0% ~ 100%
4 000-255 Centre White: 0% ~ 100%
5 000-255 Inner ring Red: 0% ~ 100%
6 000-255 Inner ring Red: 0% ~ 100%
7 000-255 Inner ring Blue: 0% ~ 100%
8 000-255 Inner ring White: 0% ~ 100%
9 000-255 Outer ring Red: 0% ~ 100%
10 000-255 Outer ring Green: 0% ~ 100%
11 000-255 Outer ring Blue: 0% ~ 100%
12 000-255 Outer ring White: 0% ~ 100%
13 000-255 Master dimmer
14
000-007 Shutter closed ( No light)
008-015 Shutter on
016-119 Strobe slow to fast (1-25Hz)
120-127 Shutter on
128-183 Strobe random slow to fast
184-191 Shutter on
192-247 Strobe sound sensitivity from low to high
248-255 Shutter on

www.event-lighting.com.au
10
24 Channels Mode
Channel Value Function Section
1 000-255 Red: 0% ~ 100%
Centre
2 000-255 Green: 0% ~ 100%
3 000-255 Blue: 0% ~ 100%
4 000-255 White: 0% ~ 100%
5 000-255 Master dimmer coarse: 0% ~ 100%
6 000-255 Master dimmer fine: 0% ~ 100%
7
000-007 Shutter closed ( No light)
008-015 Shutter on
016-119 Strobe slow to fast (1-25Hz)
120-127 Shutter on
128-183 Strobe random slow to fast
184-191 Shutter on
192-247 Strobe sound sensitivity from low to high
248-255 Shutter on
8
000-009 Dimmer mode as set from main menu
010-058 Standard (dimmer 1)
059-108 Stage (dimmer 2)
109-158 TV (dimmer 3)
159-208 Architecture (dimmer 4)
209-255 Theartre (dimmer 5)
9 000-255 Red: 0% ~ 100%
Inner ring
10 000-255 Green: 0% ~ 100%
11 000-255 Blue: 0% ~ 100%
12 000-255 White: 0% ~ 100%
13 000-255 Master dimmer coarse: 0% ~ 100%
14 000-255 Master dimmer fine: 0% ~ 100%
15
000-007 Shutter closed ( No light)
008-015 Shutter on
016-119 Strobe slow to fast (1-25Hz)
120-127 Shutter on
128-183 Strobe random slow to fast
184-191 Shutter on
192-247 Strobe sound sensitivity from low to high
248-255 Shutter on
16
000-009 Dimmer mode as set from main menu
010-058 Standard (dimmer 1)
059-108 Stage (dimmer 2)
109-158 TV (dimmer 3)
159-208 Architecture (dimmer 4)
209-255 Theatre (dimmer 5)

www.event-lighting.com.au
11
17 000-255 Red: 0% ~ 100%
Outer ring
18 000-255 Green: 0% ~ 100%
19 000-255 Blue: 0% ~ 100%
20 000-255 White: 0% ~ 100%
21 000-255 Master dimmer coarse: 0% ~ 100%
22 000-255 Master dimmer fine: 0% ~ 100%
23
000-007 Shutter closed ( No light)
008-015 Shutter on
016-119 Strobe slow to fast (1-25Hz)
120-127 Shutter on
128-183 Strobe random slow to fast
184-191 Shutter on
192-247 Strobe sound sensitivity from low to high
248-255 Shutter on
24
000-009 Dimmer mode as set from main menu
010-058 Standard (dimmer 1)
059-108 Stage (dimmer 2)
109-158 TV (dimmer 3)
159-208 Architecture (dimmer 4)
209-255 Theatre (dimmer 5)

www.event-lighting.com.au
12
TECHNICAL SPECIFICATIONS
Model PAR19x15O PAR19x15
Dimensions and Weight
Overall size LxWxH (mm) 370x380x165 370x380x160
Weight (kg) 9.5
Power
Power Supply 100~240V AC, 50/60 Hz
Power Consumption (w) 250
Fuse T 3.15 A, 250 V
LED 19pcs 15W RGBW 4 in 1 LED
Operation Modes DMX
Static macros
Manual dimming colour,
Auto programs
Preset colour temperature setting
Sound active,
Beam Angle 25°
Beam Angle Options 9°, 15°, 50°
Dimmer 16-bit 0-100% dimmer
Fade Modes Standard, Stage, TV, Architecture, Theater
Refresh Rate 1200Hz
DMX Channel mode 3, 4, 6, 7, 10, 12, 14, 24
Power Input Seetronic® Outdoor Powerkon Neutrik® Powercon
DMX Connector Seetronic® 3 Pin Outdoor DMX socket 3 / 5 Pin DMX socket
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au.
