Everbilt 1007122486 User manual

SKU#: 1007122486 / 1007122493/ 1007122499
73.5 in. Double Long Hang with Six Shelf Stack

•Quick Start Guide
•73.5 in Long Hang with Shelf Stack –Base Kit
•24 in. White / Gray / Birch Décor Shelf Cover
INSTRUCTION TABLE OF CONTENTS:

Quick Start Guide
Look for packet in this ‘BASE KIT’ box labeled “Modular
Configuration Guide”, find your layout in the packet, and
make sure you received the correct number of boxes and
contents to build your specific layout.
1. First, find the “Assembly and Installation” instructions
for building your ‘BASE KIT’ in this base kit box.
a) Measure your space to make sure the complete
closet design will fit.
b) Be sure to install the ‘Base Kit’ at the furthest left
side of your closet space.
c) Note: At this time, only install the hang track and
vertical rails. Save the brackets, shelves, closet
rods and decorative covers for later installation
steps.
2. Next, install the hang track and vertical rails from the
‘Extension’ box(s) if your layout includes extensions.
Save the brackets, shelves, closet rods and decorative
covers for later installation steps.
3. Now install the brackets, shelves, and closet rods from
the base kit and extension boxes, at the desired
locations.
4. Next, install components from the ‘Add-On’ box(s) if
your layout includes add-ons.
5. Last, finish the closet by installing the decorative hang
track covers, vertical rail covers, and shelf covers.

THANK YOU
We appreciate the trust and condence you have placed in Everbilt through the purchase of this closet organizer. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Everbilt!
Item # 1006-844-947
Model # 90441
73.5 IN. LONG HANG WITH SHELF STACK - BASE KIT
Questions, problems, missing parts? Before returning to the store,
call Everbilt Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-305-1726
HOMEDEPOT.COM
ASSEMBLY AND INSTALLATION GUIDE

2
Table of Contents
Table of Contents..........................................................2
Safety Information.........................................................2
Product Specications.................................................2
Warranty.........................................................................2
Pre-installation...............................................................3
Planning Installation...............................................................3
Tools Required........................................................................3
Hardware Package Contents...................................................3
Choose Your Hardware............................................................3
Component Package Contents................................................4
Installation ......................................................................6
Plan Your Closet Layout................................................5 Care and Cleaning..........................................................10
Install Hang Tracks...................................................................6
Install Upper Vertical Rails.......................................................6
Install Vertical Rail Joiners and Lower Vertical Rails................7
Install Brackets........................................................................8
Install Shelves..........................................................................9
Install closet rod brackets and closet rods...............................9
Install Closet Rod End Caps....................................................10
Install Hang Track Covers......................................................10
Install Vertical Rail Covers......................................................10
Warranty
LOAD CAPACITY
This product is guaranteed to be free of defects in materials and workmanship for 2 years from the date of purchase. If this product is
defective, call 1-800-305-1726 or return the product to the store from which it was purchased for a replacement. Guarantee does not
include normal wear and tear.
Product Specications
Safety Information
DANGER: The metal may have sharp edges or corners.
The use of protective gloves is strongly recommended.
WARNING: Do not overload the shelving units. This
may cause collapse of the system and cause personal
injury or property damage.
IMPORTANT: Please read and strictly follow the
assembly instructions for proper installation.
□Please read and strictly follow the assembly instructions for proper
installation. Failure to do so may cause objects to accidentally fall,
which may result in personal injury or property damage.
□Make sure to distribute the weight evenly on each shelf and use the
correct hardware for system mounting.
□Do not overload, which may cause collapse of the system and cause
personal injury or property damage.
□Do not climb, stand or step on the product, which may cause
collapse of the system and cause personal injury or property
damage.
□Be sure to wear appropriate safety equipment when using power
tools and hand tools.
□The metal may have sharp edges or corners. The use of protective
gloves is strongly recommended.
□Recommend to protect the work surface during assembly.
□This product is not a toy and contains small parts which may cause
choking hazard for small children. Close supervision is necessary
near children.
□Drywall installation requires mounting into at least 1 stud.
□Drywall requirement for claimed load : ASTM C1396 Compliant, Minimum thickness 1/2 in.
□Maximum spacing between two vertical rails: 24 in. center-to-center spacing, as shown in “Plan Your Layout” section.
□Closet rod support bracket a maximum of 18 in. spacing.
□Installed per manufacturer's requirements.
Maximum 45 lb per linear foot (closet shelf and rod) / Maximum 20 lb per linear foot for rod loading (when installed per manufacturer’s
instructions below):

3
Pre-installation
CHOOSE YOUR HARDWARE
PLANNING INSTALLATION
TOOLS REQUIRED
HARDWARE PACKAGE CONTENTS
NOTE: Hardware not shown to
actual size.
AA
BB
CC
DD
Panhead Screw (#12 x 2 in.)
Anchor (1/4 in.)
Bolt (3 in.)
Toggle (3/16 in.)
46
46
46
46
Part QuantityDescription
1. Measure the closet width and plan the layout. See the “Plan Your Closet Layout” section for illustration examples.
2. Select the correct hardware for assembly. See "choose your hardware" section below.
3. Use stud nder to locate the studs and mark. It is recommended to mount hang tracks onto studs.
4. For creating larger layouts that include multiple hang tracks, install this kit hang track rst then install additional hang track
extensions ensuring additional hang track is level and in line with previously mounted hang track(s).
Screwdriver Drill Pencil Tape Measure Level HacksawStud Finder
AA BB CC DD
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
Secure to the wall with panhead
screws (AA) at stud locations.
Drill 1/4 in. holes, insert wall
anchors (BB) and secure to the
wall with panhead screws (AA).
WARNING: Thisproduct can expose you to chemicals, including lead, which is known to the
State of California to cause cancer and birth defects or other reproductiveharm. For more
information go to www.P65Wamings.ca.gov
STUDS CONCRETE
AA
BB AA

4
Pre-installation (continued)
COMPONENT PACKAGE CONTENTS
A
B
C
D
E
F
G
H
48 in. Vertical Rail
30 in. Vertical Rail
25.5 in. Hang Track
25.5 in. Hang Track Cover
30 in. Vertical Rail Cover
48 in. Vertical Rail Cover
24 in. x 16 in. Wire Shelf
Shelf Bracket
4
4
1
1
4
4
8
14
Part QuantityDescription
AB
E F
I
H
NL M
DC
K
J
G
I
J
K
L
M
N
O
P
Vertical Rail Joiner
24 in. Hang Track
24 in. Hang Track Cover
24 in. Chrome Closet Rod
Chrome Closet Rod Bracket
Chrome Closet Rod Endcap
Spacer
Drilling Template Box
4
2
2
2
4
4
1
1
Part QuantityDescription
P
CHOOSE YOUR HARDWARE
O
VERTICAL RAIL SPACER
*DO NOT DISCARD*
*DO NOT DISCARD*
*DO NOT DISCARD*
*DO NOT DISCARD*
DRYWALL
Drill a 1/2 in. hole in the drywall. If
you hit a stud during drilling, use
above stud hardware/instructions
for each stud location.
Insert bolt through hang track (or
vertical rail/vertical rail joiner) then
screw on toggle (DD).
Install toggles (DD) in each hole of
the component you are attaching
before attaching to the wall.
Compress and pass the toggle (DD)
through the hole you drilled.
Allow the toggle (DD) to spring
apart behind the drywall.
Screw the bolt (CC) until tight to
secure. Pull back on screw head
for tension if toggle (DD) is
spinning behind wall. Install
toggles (DD) in each hole of
components before attaching to
wall.
DD CC

HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
5
When planning your installation, measure the dimensions of your installation location. For specic designs refer to separate Modular Closet
System Conguration Guide.
NOTE: All vertical measurements are taken from the oor.
Plan Your Closet Layout
TIP: Shelf height can be adjusted
per your personal needs.

6
Installation
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
Install Upper Vertical Rails
□Attach the upper vertical rail (A) to the hang track (C) slots as
the diagram shows (see Fig. 1).
□Slide the rst vertical rail (A) to the left edge of the hang track
(C) , so make sure it is ush with the end of the hang track (C)
(see Fig. 2).
□Use a level to ensure upper vertical rail (A) assembly is
vertically straight (plumb) and secure it using screw holes in
vertical rail with appropriate hardware (see Fig. 3).
□Use provided spacer (O) to line up the next upper vertical rail
(A) (see Fig. 4). It is CRITICAL to install vertical rails at the
correct spacing using spacer (P) for the system to work.
□Repeat the above process to install remaining upper vertical
rails.
2
TIP: When creating larger closet layouts that include multiple hang tracks, install this kit hang track to the far-left of your planned closet design.
Additional shorter length hang tracks will be installed in continuous sequence to the right of this kit hang track.
If creating a larger kit (which ships in several boxes) install all hang tracks and vertical rails from boxes labeled 'EXTENSION' BEFORE installing
any brackets, shelves or decorative covers in following steps.
Install Hang Track
1
□Use a stud finder to locate and mark your studs if installing on drywall.
□Place the longest hang track (C) flush against the wall, the bottom of the track should be 84 in. off the ground. The thicker side
should be on top, closest to the ceiling.
□Make sure the track is level and mark each screw hole on the wall. Ensure at least one hole aligns with a stud.
□Use correct hardware to secure the hang track and tighten (see "Choose Your Hardware" in the Pre-installation section).
□Repeat steps above for adding remaining hang tracks (J). Be sure to install the next shorter hang tracks (J) level and ush with
previous installed hang track (C).
WARNING: Before cutting, drilling, or hammering into any wall, verify the location of electrical, plumbing, and gas lines. Cutting may cause serious
injury.
Thicker side up
WALL
Fig. 1
Fig. 4
Fig. 2
25.5 in. (64.8 cm) 24 in. (60.9 cm)
Keep level and ushC J
WARNING: Before cutting, drilling, or hammering into any wall, verify the location of electrical, plumbing, and gas lines. Cutting may cause serious
injury.
A
C
Fig. 3
A
VERTICAL RAIL SPACER
*DO NOT DISCARD*
*DO NOT DISCARD*
*DO NOT DISCARD*
*DO NOT DISCARD*
WALL WALL WALL

Installation (continued)
SCENARIO 1: STUD
□Push vertical rail joiner (I) up into upper
vertical rail (A) as shown, secure the vertical
rail joiner (I) on hole B with panhead screw
(#12 x 2 in.) (see Fig. 5).
□Put the lower vertical rail (B) as shown and
secure the lower vertical rail (B) on the hole C
and D with panhead screw (#12 x 2 in.) (see
Fig. 6).
□Use remaining screw holes in lower vertical
rail (B) to secure to wall with appropriate
hardware, just as you did for upper vertical rail
(A) installation (see Fig. 7).
□Use provided spacer (P) to line up the next
lower vertical rail. It is CRITICAL to install
vertical rails at the correct spacing using
spacer (P) for the system to work.
□Repeat the above process to install remaining
vertical rail joiners and lower vertical rails.
SCENARIO 2: CONCRETE
□Tear the drilling template box (P) according
to the dashed line (see Fig. 8).
□Align the drilling template box (P) as a
locator as shown and mark the holes on the
wall (see Fig. 9).
□Drill 1/4 in. holes and insert wall anchors
(1/4 in.) into hole B, C and D (see Fig. 10).
□Push vertical rail joiner (I) up into upper
vertical rail (A) as shown, secure the
vertical rail joiner (I) on hole B with
panhead screw (#12 x 2 in.) (see Fig. 11).
□Put the lower vertical rail (B) as shown and
secure it on the hole C and D with panhead
screw (#12 x 2 in.) (see Fig. 12).
□Use remaining screw holes in lower vertical
rail (B) to secure to wall with appropriate
hardware, just as you did for upper vertical
rail (A) installation (see Fig. 13).
□Use provided spacer (P) to line up the next
lower vertical rail (B) . It is CRITICAL to
install vertical rails at the correct spacing
using spacer (P) for the system to work.
□Repeat the above process to install
remaining vertical rail joiners and lower
vertical rails.
Fig. 8 Fig. 9
Fig. 5
Push
Hole B
I
Hole B
Hole C
Hole D
P
Fig. 6
Hole C
Hole D
Hole B
Fig. 10
Hole C
Hole D
Hole B
Fig. 12
Hole C
Hole D
Hole B
Fig. 11
Push
Hole B
I
Hole C
Hole D
Install Vertical Rail Joiners and Lower Vertical Rails
3
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
7
Fig. 7
Fig. 13
B
B
A
B
A
AA
A
B
A
B
B
A
A

Install Brackets
□Insert shelf brackets (H) to the vertical rails (A - B).
□Insert back tabs of bracket into vertical rail slots at desired position.
□Pull down on front of bracket and ensure bracket is locked in place.
□Ensure shelf brackets are inserted at same height on vertical rails so shelf
will be level once installed.
4
H
A / B
1
2
Installation (continued)
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
8
SCENARIO 3: DRYWALL
□Tear the drilling template box (P) according
to the dashed line (see Fig. 14).
□Align the drilling template box (P) as a
locator as shown and mark the holes on
the wall (see Fig. 15).
□Drill 1/4 in. holes for hole B and C, drill 1/2
in. hole for hole D. Insert wall anchors (1/4
in.) into hole B and C (see Fig. 16).
□Push vertical rail joiner (I) up into upper
vertical rail (A) as shown, secure the
vertical rail joiner (I) on hole B with
panhead screw (#12 x 2 in.) (see Fig. 17).
□Put the lower vertical rail (B) as shown and
secure it on hole C with panhead screw
(#12 x 2 in.) and on hole D with toggle
(3/16 in.) and bolt (3 in.) (see Fig. 18).
Make sure the toggle (3/16 in.) and the bolt
(3 in.) are installed on lower vertical rail (B)
before secure.
□Use remaining screw holes in lower
vertical rail (B) to secure to wall with
appropriate hardware, just as you did for
upper vertical rail (A) installation (see Fig.
19).
□Use provided spacer (P) to line up the next
lower vertical rail (B) . It is CRITICAL to
install vertical rails at the correct spacing
using spacer (P) for the system to work.
□Repeat the above process to install
remaining vertical rail joiners and lower
vertical rails.
Fig. 17
Hole B
PushPush
Fig. 14 Fig. 15
Hole B
Hole C
Hole D
P
I
Fig. 16
Hole C
Hole D
Hole B
Fig. 18
Hole C
Hole D
Hole B
Hole C
Hole D
Fig. 19
If creating a larger kit (which ships in several boxes) install all vertical rail joiners and lower vertical rails from boxes labeled ‘EXTENSION’
BEFORE installing any brackets, shelves or decorative covers in following steps.
B
A
B
A
B
A
AA

9 HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
Install Shelves
5
□Make sure your shelves (G) t your closet layout design.
□Hold the shelf’s (G) front rod, let it t into the bracket’s (H) front notches as
the diagram shows, then push down the shelf’s rear part allowing the
shelf’s rear horizontal rod to lock into the back clip of bracket.
NOTE: The bracket is supposed to be shared by two shelves in system as
shown on the right. Each end of shelf will take up half of bracket.
G
H
2
1
Two shelves
share one
bracket
NOTE: Closet rod brackets need to be installed BEFORE any decorative shelf
covers are installed on shelf.
Install Closet Rod Brackets and Closet Rod
6
□Count 6 rods or more from one side of the wire shelf and install closet
rod brackets as shown. Maximum spacing between closet rod brackets
is 18 in. for this system (see Fig. 20).
□Put the closet rod support bracket (M) at an angle as shown and place
the back part onto the horizontal rod (B) (see Fig. 21).
□Pull down the closet rod support bracket (M) and snap onto the shelf's
front rod (C) (see Fig. 21 and Fig. 22).
Installation (continued)
Fig. 20
M M
Fig. 21 Fig. 22
M
L
6 rods or more
Max 18 in.
12
3
Rod C Rod B

Installation (continued)
NOTE: Make sure to complete joiner assembly (if needed based on layout) before
adding end caps to the nished ends of closet rod.
Install Closet Rod End Caps
7
□Measure length of closet rod assembly needed based on your closet layout.
□Push end caps (N) into both ends of closet rod (L) (see Fig. 9).
□Position closet rod assembly at desired location and snap into closet rod
brackets (M) (see Fig. 10 and Fig. 11).
If creating a larger kit (which ships in several boxes) install all brackets,
shelves, and closet rods from each box BEFORE installing decorative hang
track covers and vertical rail covers in the following steps.
Fig. 9
Fig. 10
Fig. 11
Max 18 in.
N
L
M
HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
10
Install Vertical Rail Covers
9
□Measure open areas of the vertical rail, this includes: bottom of hang track
cover to top of shelves, bottom of shelf brackets to top of shelves, bottom of
brackets to end of vertical rails, etc.
□Cut the vertical rail cover (E-F) to your desired length with hacksaw.
□Push and press one end of the vertical rail cover (E-F) to the rail to lock onto
the rail. Press and move the other end to make sure the whole vertical rail
cover is securely in place.
NOTE: For safety, please remember to wear safety gloves, goggles and
strictly follow the instructions of your hacksaw during the cutting.
8
Care and Cleaning
□To remove dust, stains, and other deposits: Use a soft cloth (or soft brush) with a diluted solution mix of warm water and a mild
detergent (such as liquid dishwashing detergent). DO NOT use solvents.
□Make sure you thoroughly rinse the surface(s) with clean fresh water after cleaning to remove all residue.
□Thoroughly dry the surface(s) before reuse.
EverbiIt closet organizer is powder coated. Clean following these steps:
Install Hang Track Covers
□Place the hang track cover (D/K) with the direction as shown then push to
snap and lock. Slide from left to right to make sure the whole cover is
secured.
□Make sure to put longer hang track cover (D) on the longer hang track (C). A
D/K
C/J
Line up and press
onto rail
Cut to your t
E-F
Measure
and cut
Measure
and cut
Measure
and cut
Fig. 8
Fig. 9
Fig. 10
Max 18 in.
JL
M
K

9
Retain this manual for future use.
Questions, problems, missing parts? Before returning to the store,
call Everbilt Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-305-1726
HOMEDEPOT.COM

Installation
24 in. White / Gray / Birch Décor Shelf Cover (2-Pack)
Item #1006-841-112 / 1006-841-104 / 1006-841-024
Model #90442 / 90444 / 90446
Warranty
1
2 PUT ON ENDCAPS (B) AS SHOWN BELOW (SINGLE OR CONNECTED).
This product is guaranteed to be free of defects in materials and workmanship for 2 years from the date of purchase. If this product is defective, call
1-800-305-1726 or return the product to the store from which it was purchased for a replacement. Guarantee does not include normal wear and tear.
PARTS LIST
A
B
24 in. Décor Shelf Cover
Décor Shelf Cover Endcap Set (both ends)
2
2
Part QuantityDescription
A
B (Left)
B (Right)
B (Left)
B (Right)
A
B (Left)
B (Right)
A
REMOVE PROTECTIVE FILM (TWO SIDES) BEFORE INSTALLATION.
No endcap here
Single Connected
HOMEDEPOT.com
Please contact 1-800-305-1726
for further assistance.
WARNING: Thisproduct can expose you to chemicals, including lead, which
is known to the State of California to cause cancer and birth defects or other
reproductiveharm. For more information go to www.P65Wamings.ca.gov
3 PLACE A DÉCOR SHELF COVER (A) ONTO WIRE SHELF AND PUSH ALL THE WAY TO THE REAR SO THAT THE FRONT LIP OF
THE COVER IS FLUSH AGAINST THE FRONT LIP OF THE WIRE SHELF.
SNAP DOWN REAR OF THE DÉCOR SHELF COVER (A) OVER BACK OF THE BRACKET AT EACH INTERSECTION WITH VERTICAL
RAILS.
AA
2
1
B (Left) B (Left)
Assembly and Installation Guide
