Thank you for selecting an EVEREST product
A Step Above the Standard
Owner’s Manual for models:
www.EVEREST .ref
com
Solid Silde Glass & Plate Chillers EGC37, EGC50, EGC65

When installing the unit, be careful that the
electrical cord is not under the unit or
pressed against the wall.
This could cause a damage
to the cord.
time, make sure the unit
is free from all packaging.
Packaging left
on the unit
during
operation may
To prevent electrical shock, please do
not plug or unplug the cord
with wet hands.
WARNING - When using your appliance, always follow basic precautions, including
the following :
Install the unit on a hard
and level surface.
Before cleaning or maintaining the unit,
please unplug it. Do not use any
around the unit.
Please do not store temperature
sensitive items in the unit,
such as medical or
science research
related materials.
If you suspect a refrigerant leak,
unplug the unit and
immediately contact an
authorized service
technician.
Please do not hang or climb
on the unit as this may
cause the unit to fall.
Safety Notices
Safety Notices
REFRIGERATION
1

Safety Notices
Safety Notices
not to overload the outlet into which the
unit is plugged into. A dedicated circuit of
To prevent electrical shock and
malfunction, do not spray the
unit with water.
Clean the pronges of the electrical plug
with a soft cloth or brush before plugging
it into an electrical receptacle to prevent a
WARNING - Read and follow all safety notices in this installation guide.
information. Failure to do so may lead to serious injury and /
or damage to the unit.
When it is time to salvage the unit, make
sure to remove the the doors to prevent
the risk of children or animals getting
trapped inside the unit.
REFRIGERATION
2

Caution!
Caution!
To prevent electrical shock and damage to
the electrical cord, please hold
the plug head
when plugging
and unplugging
the unit.
Do not use the
electrical cord
or plug if they
are damaged
in any way.
REFRIGERATION
To avoid personal injuries
from broken glass,
please do not
place glass items
in the freezer.
After unplugging the unit, please wait at
least 6 minutes before re-plugging
it in. Failure to do so could
cause extensive damage
to the compressor.
If the unit will not be used for an
extended period of
time, please unplug
it from the outlet.
The refrigerator compartment temperature
should be set at -5°F~5°F (See page 9).
Setting the temperature out of the
recommended ranges will void the unit’s
warranty.
Do not put your hands under the unit when
moving it. You could be injured by sharp
edges, protruding parts,
crushing, etc.
Please do not attempt to remove or repair any
components unless
you are an
authorized
service technician.
Avoid touching frozen foods or
containers, especially metal
containers, with wet hands.
It could cause
frostbite.
Avoid installing the
unit where it could
be exposed to
water or
moisture.
Caution!
Caution!
3

Installation Guide
Installation Guide
Install the unit on a hard and level surface
or the unit could produce undesired noises.
The unit should be at least 2” away from the
wall.
Indoor Use Only
Outdoor use may cause a decrease in
unit.
Dusty and High Humidity Areas
Dusty environments will cause the
condenser coil to prematurely clog which
will require it to be cleaned more often.
High humidy environments could cause the
unit to rust.
Do not build an enclosure or cabinet
around the unit.
condenser area will cause the compressor to
work harder, which can result in compressor
failure and the unit not being able to
maintain the desired temperature.
Select a location away from other heat
and moisture generating equipment
such as stoves, ovens, dish washers, etc.
High ambient temperatures cause the
compressor to work harder, which can result
in compressor failure and the unit not being
able to maintain the desired temperature.
REFRIGERATION
4

Maintenance Guide
Maintenance Guide
Shelf Cleaning
Periodically remove the shelves from the unit and clean them
with mild soap and warm water.
Do not use the following products when cleaning
Clean the exterior of the product with mild soap and warm water.
Never use steel wool, strong acids, abrasive cleaners or degreasers.
Acidic products and products containing vinegar must
be stored in sealed containers to prevent acid damage
to the interior of the unit and the evaporator coil. (Rust
resulting from the lack of or improper maintenance will
not be covered under warranty.)
Interior Cleaning
Clean the interior surface of the unit with mild soap and warm
water. Do not let water accumulate inside the unit. To prevent
water damage, wipe the interior of the unit with a dry cloth as
needed. Do not use abrasive cleaners, concentrated detergents,
bleaches, cleaning waxes, solvents or polishes to clean the interior
of the unit.
Condenser Coil Cleaning
Poor condensing unit performance is caused by heavy dust
build-up on the condenser coil. The condenser coil should be
condenser with a soft brush or a vacuum with a brush
attachment. The condenser coil should be cleaned in the
REFRIGERATION
5

REFRIGERATION
Please check the following before requesting service.
a. Check to see if the electrical cord has
been connected.
b. Check to see if the unit is turned on.
a. Check to see if the temp. control setting is
too high, then adjust as necessary.
b. Aviod installing the unit next to heat
generating equipment and direct sunlight.
c. Avoid storing hot contents.
d. Make sure that the doors are fully closed.
a. Adjust the temperature control to a warmer
setting.
a. Check for loose parts.
b. Check for tubing rattle.
c. Check for a bent fan blade.
d. Check for damaged fan motor bearings.
e. Check if the unit is stable.
f. Check if the cabinet is level.
a. Condensation on the exterior surface of the
unit is perfectly normal during periods of high
humidity.
b. Check door alignment and gaskets for proper
seal.
a. This is the sound of the refrigerant circulating
during the compressor rest period and it is
normal.
a. Heaters have been placed around the door
openings to prevent condensation build up.
This is normal.
a. Condensation can occur during hot and
bumid weather with frequent or prolonged
door opening. This is normal.
b. The doors might not be closed properly.

Ratchet Lock & Shelves Installation
Ratchet Lock & Shelves Installation
REFRIGERATION
Ratchet lock Assembly
Insert the ratchet [A] into the
hole [B] of the door handle.
Push the ratchet [A] all
the way in until it is fully
attached to the surface
of the product.
[A]
[B]
[C]
Insert the lock [C] into the
ratchet [A] until the lock [C]
hits the door handle [E].
Then turn the key to lock it.
[A]
[E]
Step 1
Step 2 Step 3
[A]
[Ratchet Lock Installation]
7
Temperature Setting
Temperature Setting
OFF
( )
5
6
7
89
4
32
1
℉
[Temperature Setting Range]
1 ~ 3
3 ~ 5
6 ~ 9
On
O
On
O
On
O
FZR (℉)
11
4
0.5
-6.5
-9.5
-17.5
Setting Range
Comp.
•Factory Recommended Setting: “5”

Specifications
Specifications
REFRIGERATION
Model
Capacity(Cu.Ft.)
Door
# of Floor Shelves
Compressor (HP)
Power (V-Hz-Ph)
Temp. Range(F)
Refrigerant
Crated Weight(LBS)
Amps(A)
13.60
2
5
1/3 + 1/3 +
115 -60-1
246
5.20
9.30
1
3
1/3
115-60-1
R-134A
-5 ~ 5 -5 ~ 5 -5 ~ 5
R-404A R-404A
202
5.20
18.90
2
7
115-60-1
282
5.40
EGC37 EGC50 EGC65
Dimensions
(W x D x H inches) 36 3/4 x 26 3/4 x 33 3/4
Specications subject to change without notice.
49 1/2 x 26 3/4 x 33 3/4 64 1/2 x 26 3/4 x 33 3/4
8
Product Drawings
Product Drawings
Side View
12 1/2"14 1/4" 2"
2 1/4"
26 3/4"
33 3/4"
29 1/4"
EGC37
36 3/4"
26 3/4"
29"
12 1/2"
31 3/4"
33 3/4"
2"
EGC50
31 3/4"26 3/4"
29" 33 3/4"
2"
49 1/2"
12 1/2"
EGC65
31 3/4"26 3/4"
29" 33 3/4"
2"
64 1/2"
12 1/2"

9
CONDENSER COIL MAINTENANCE
Failure to maintain a clean condenser coil will eventually result in compressor failure and product loss.
Mechanical failures due to a lack of or improper maintenance are not covered under warranty.
Keeping the condenser coil clean will maximize energy savings.
Cleaning of the condenser coil is part of regular maintenance and is not covered under warranty.
CONDENSER COIL CLEANING PROCEDURE
Please use the following steps to clean the condenser coil. If you have any questions regarding this
procedure, please call the Everest customer service department at [phone].
1. Unplug the unit from the wall.
2. Remove the front right bottom grill (when facing the unit). It is attached with Philips head screws.
3. Clean the condenser coil using a vacuum or brush. The ns of the condenser coil should only be
cleaned and swept in the direction of the ns, which is up and down. Be careful not to bend the ns.
4. In some instances, the condenser coil may require professional cleaning due to a buildup of grease
and dust. In this case, contact a local refrigeration company to take care of this for you.
5. Ensure no tools or parts have been left in the condensing unit area.
6. Replace the front right bottom grill.
Critical Information
Critical Information
REFRIGERATION
The warranty card below must be submitted to Everest within thirty (30) days of purchase.
WARRANTY REGISTRATION CARD
Business Name : Telephone : ( )
Address :
City : State : Zip :
Place of Purchase : Date Purchased : Date Installed :
Model No : Cabinet Serial No :
3 YEAR PARTS and LABOR WARRANTY
(Applicable to units purchased after July 1, 2014.)
5 YEAR COMPRESSOR WARRANTY
Name of Business Owner : Date :
Signature of Business Owner :

10
Warranty Certificate
Warranty Certificate
REFRIGERATION
REFRIGERATION
EVEREST warrants to the original purchaser of every new EVEREST unit, the cabinet and all parts thereof, to be free from defects in
material or workmanship, under normal and proper use and maintenance service as specied by EVEREST and upon proper
installation and start-up in accordance with the instruction packet supplied with each unit. Our obligation under this warranty is
limited to a period of three (3) years from the date of original installation or thirty six (36) months after shipment date from EVEREST,
which ever occurs rst. This is applicable to units purchased after July 1, 2014. Any part covered under this warranty that is determined
by EVEREST to have been defective within three (3) years of original installation or thirty six (36) months after shipment date from the
manufacturer, which ever occurs rst, is limited to the repair or replacement, including labor charges, of defective parts or assemblies.
The labor warrranty shall include standard straight time labor charges only and reasonabletravel time, as determined by EVEREST.
All warranty claims for labor or parts must be made directly through EVEREST. All claims shall include: unit model number,
cabinet serial number, proof of new product purchase, installation date, and all pertinent information related to the alleged
defect. For compressor warranty claims, the compressor tag shall be returned to EVEREST with the above listed
information.
EVEREST's sole obligation under this warranty is limited to either the repair or replacement of parts, subject to the
additional limitations below. This warranty neither assumes nor authorizes any person to assume obligations other than
thoseexpressly covered by this warranty.
A. INDIRECT OR CONSEQUENTIAL DAMAGE
EVEREST does not warrant economic loss, prot loss, or special, indirect or consequential damages including without
limitation, losses ordamages arising from food or product spoilage claims caused by refrigeration failure.
B. IMPROPER USAGE
EVEREST is not responsible for parts or labor coverage for component failure and or other damages resulting from
improper usage, installation or failure to clean and/or maintain product as set forth in the user's manual provided with this
unit. All EVEREST products are designed for commercial usage, not for residential use. Therefore, the warranty will not be
honored if product is installed in a residential house.
C. WARRANTY IS NOT TRANSFERABLE
Warranty is limitedto only the original purchaser/user to whom delivered. It is not transferable.
D. ALTERATION, NEGLECT, MISUSE, ABUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS
OF GOD.
EVEREST is not responsible for malfunctions due to alteration, neglect,misuse, abuse, accident, damage during transit or
installation, re, ood, storm, and/or other acts of God. And EVEREST is not responsible for any improper electrical
connections resulting from electrical power failure, the use of extension cords, and low voltage or voltage drops to the unit.
E. UNAUTHORIZED MODIFICATION
EVEREST is not responsible for the repair or replacement of failed or damaged components resulting from unauthorized
modications to units or the use ofnon-standard parts without prior writtenapproval from EVEREST.
F. RESIDENTIAL, NON-COMMERCIAL USE
This warranty doesnot apply to aunit installed in a residential setting. This unit is for commercial use only.
G. OUTSIDE THE U.S.
This warranty does not apply to any parts and/or labor warranty claims made on units sold or used outside of the United
States.
TWO(2)
These warranties are exclusive and in lieu of all other warranties, expressed or implied, and all other obligations or liabilities on our
part, and we neither assume nor authorize any other person to assume for us any other obligation or liability in connection with
thesaleofsaid refrigeration units or any part thereof.
In addition to the warranty set forth above, EVEREST warrants the hermetically sealed compressor for an additional two (2) years, not
to exceed sixty (60) months from the date of shipment from EVEREST, provided upon receipt of the compressor, manufacturer
examination shows the sealed compressor to be defective. This compressor warranty does not apply to any other parts of the unit.

201 W. Artesia Blvd., Compton CA 90220
Visit our website at www.EVERESTref.com
Tel : [phone]
Fax : [phone]
REFRIGERATION
A Step Above the Standard
REFRIGERATION
