EVERFOCUS
Color Dome Camera
Operation Instructions
Model: ECD230
Please read this manual first for correct installation and operation. This manual should be retained
for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.
PRECAUTIONS
1. Do not have camera immersed in water.
2. Do not disassemble it or place it on an unstable base.
3. Do not touch the surface of CCD sensor by hand directly.
4. Never face the camera toward the sun.
5. Use proper power source otherwise the camera will not function correctly.
6. Use the camera at temperatures within 0℃~ 50℃/32℉~122℉and humidity between 20%~
80%. The input power sources is 12VDC only.

1
PREFACE
These cameras are compact, full functioned CCD cameras. Their stylish appearance can be
applied as per installer's ideal locations. These dome cameras can be mounted either on the
ceiling or on the wall easily. The camera uses high sensitive 1/3" color interline transfer CCD
sensor with DSP. The camera is featured withAuto Electronic Shutter, Automatic Gain Control,
and Auto White Balance functions.
FEATURES
zThe high sensitivity is achieved by using 1/3” SONY Super HAD interline transfer color
CCD
zThe electronic shutter and AGC functions allow the camera to be used in environment with
varying light levels.
zBuilt-in anti-aliasing and IR-cut optical filter
zCompact size: 87 mm (D). x 58 mm (H) / 3.48” (D) x 2.31” (H)
zSystem available for NTSC or PAL
STANDARD ACCESSORIES
zCamera Unit
zOperation Instructions (this document)

2
LENS AVAILABLE
* Standard board lens f=3.6 mm, F=2.0 mm.
* Other available lens : 4 Lens f=4.3 mm, F=2.0 mm
6 Lens f=6.0 mm, F=2.0 mm
8 Lens f=8.0 mm, F=2.0 mm
INSTALLATION
1. Remove the plastic dome cover.
2. Loosen the two screws of the supporting bracket to remove the camera body.
3. Using four screws to fix the camera base on the ceiling.
4. Put the camera body back to the supporting bracket, the connector of the back panel
should always be placed to camera’s left lower corner, in order to obtain the image of best
quality. Tighten the 2 screws to fix the camera. Please refer to the back panel diagram
shows as below:
a. Floor Mount b. Ceiling Mount
c. Wall mount, aim to the right d. Wall mount, aim to the left
Main
Board Bottom Connector

3
5. Connect the BNC connector of the camera to a color monitor, or other video device
through a 75 ohm type coaxial cable with BNC female connector at cable extension.
6. Connect the DC +12V regulated power source of the camera (DC Jack) to the DC 12V
Power-in jack with 2 mm, center+, outer- plug.
7. Once the image appears on the monitor, loosen the fixing screw located at the lens mount
then adjust the focus and diaphragm of the lens to obtain the best picture. When the ideal
picture is obtained, secure the lens mount by fixing screw firmly again.
8. Put the plastic cover back on the Dome Camera.

4
SPECIFICATIONS
Model Standard Resolution High Resolution
Pickup Device 1/3'' SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec.
Picture Elements NTSC: 510(H) x 492(V)
PAL: 500(H) x 582(V)
NTSC: 768(H) x 494(V)
PAL: 752(H) x 582 (V)
Horizontal Resolution 380 TV Lines 480 TV Lines
Sensitivity 0.3 Lux/F=1.2 0.4 Lux/F=1.2
S/N Ratio Over 48dB (AGC Off)
Electronic Shutter 1/50(1/60)~1/100,000
Lens Type f=3.6mm; f=4.3mm; f=6.0mm; f=8.0mm
*Lens vary in different regions
Back Light Comp. Yes
Auto Gain Control Yes
Auto White Balance Yes
Gamma Correction 0.45
Video Output BNC 1.0Vp-p, 75ohm
Sync. Mode Internal sync
Power Source 12VDC
Power Consumption 12VDC: 1.5W max
Dimensions 87 mm (O.D.) x 58 mm (H) ; 3.48” (O.D.) x 2.31” (H)
Weight 0.1kg ; 0.22 lbs
Operating Temperature 0°C~50°C ; 32°F~122°F (20%~80% Humidity)
Certifications FCC/CE

5
EverFocus Electronics Corp.
Head Office:
12F, No.79 Sec. 1 Shin-Tai Wu Road,
Hsi-Chih, Taipei, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
USA L.A. Office:
1801 Highland Ave. Unit A
Duarte, CA 91010, U.S.A.
TEL: [phone]
FAX: [phone]
www.everfocus.com
USA N.Y. Office:
415 Oser Avenue Unit S
Hauppauge, NY 11788
TEL: [phone]
FAX: [phone]
www.everfocus.com
Europe Office:
Albert-Einstein-Strasse 1
D-46446 Emmerich, Germany
TEL: [phone]
www.everfocus.de
China Office:
Room B-05D-1, KESHI PLAZA , Shangdi
Information Industry Base,
Haidian District, Beijing China
100085
TEL: [phone]/38/39
FAX: [phone]
www.everfocus.com.cn
Japan Office:
1809 WBG MARIBU East 18F,
2-6 Nakase.Mihama-ku.
Chiba city 261-7118, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.com
