ES2446-51
24-port Gigabit PoE+ with 4 Combo SFP Rack-mount Web Smart PoE
Switch
User’s Manual
Copyright © EverFocus Electronics Corp,
Release Date: March, 2015
Notice: This content is subject to be changed without notice.

E V E R F O C U S E L E C T R O N I C S C O R P O R A T I O N
ES2446-51
User’s Manual
2015 EverFocus Electronics Corp
www.everfocus.com
All rights reserved. No part of the contents of this manual may be reproduced or transmitted in any
form or by any means without written permission of the Everfocus Electronics Corporation.
Release Date: March, 2015
QuickTime is a registered trademark of the Apple Computer, Inc.
Windows is a registered trademark of the Microsoft Corporation.
Linksys is a registered trademark of the Linksys Corporation.
D-Link is a registered trademark of the D-Link Corporation.
DynDNS is a registered trademark of the DynDNS.org Corporation.
Other product and company names mentioned herein may be the trademarks of their respective
owners.

ii
Safety Precautions
FCC Warning
This Equipment has been tested and found to comply with the limits for a Class-A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. It may cause harmful interference
to radio communications if the equipment is not installed and used in accordance with the
instructions. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

iii
TABLE OF CONTENTS
1. Introduction.................................................................................................................. 1
1.1 Product Overview .......................................................................................................... 1
1.2 General Features............................................................................................................ 1
1.3 Software Features.......................................................................................................... 1
1.4 Package Contents........................................................................................................... 2
2. Hardware Description ................................................................................................... 3
2.1 Dimensions..................................................................................................................... 3
2.2 Appearance & Front Panel............................................................................................. 3
2.3 LED Indicators ................................................................................................................ 4
2.4 Rear Panel ...................................................................................................................... 4
2.5 Hardware Installation .................................................................................................... 5
3. Preparation for Web Interface....................................................................................... 6
4. Web UI Configuration.................................................................................................... 9
4.1 Configuration ................................................................................................................. 9
4.1.1 System Configuration.......................................................................................... 9
4.1.2 Ports .................................................................................................................. 11
4.1.3 VLAN.................................................................................................................. 12
4.1.4 Aggregation....................................................................................................... 14
4.1.5 LACP .................................................................................................................. 14
4.1.6 RSTP................................................................................................................... 16
4.1.7 802.1X Configuration ........................................................................................ 18
4.1.8 IGMP Snooping.................................................................................................. 19
4.1.9 Mirroring ........................................................................................................... 20
4.1.10 QoS .................................................................................................................. 21
4.1.11 Filter Configuration ......................................................................................... 24
4.1.12 PoE (Power over Ethernet) Configuration....................................................... 24
4.1.13 Rate Limit Configuration ................................................................................. 25
4.1.14 Storm Control .................................................................................................. 26
4.2 Monitorning ................................................................................................................. 28
4.2.1 Statistic Overview ............................................................................................. 28
4.2.2 Detailed Statics ................................................................................................. 28
4.2.3 LACP Status ....................................................................................................... 29
4.2.4 RSTP Status........................................................................................................ 29
4.2.5 IGMP Status....................................................................................................... 31
4.2.6 Ping.................................................................................................................... 31
4.3 Maintenance ................................................................................................................ 32
4.3.1 Warm Restart.................................................................................................... 32
4.3.2 Factory Default.................................................................................................. 32
4.3.3 Software upload................................................................................................ 33

iv
4.3.4 Configuration File Transfer ............................................................................... 34
4.3.5 Logout ............................................................................................................... 34
4.4 Revision History ........................................................................................................... 35
5. Specification ............................................................................................................... 36

ES2446-51
1
1.Introduction
1.1 Product Overview
The switch is 24-port 10/100/1000M PoE+ with 4 Combo SFP Rack-mount Web
Smart PoE Switch, the switch supports IEEE 802.3at Power over Ethernet standard,
maximum 400W power consumption per system. The switch also provides
exceptionally smart Web management features, such as VLAN, QoS, RSTP, IGMP
Snooping, LACP, IEEE 802.1X, Storm Control…etc.
The switch is standard 19”rack-mount design to fit into the rack environment.
With these features, the switch is a superb choice for medium or large network
environment to strengthen its network connection and efficiency.
1.2 General Features
•24-Port 10/100/1000BaseT(X) PoE+ with 4 Combo SFP Open Slots
•IEEE 802.3at, up to 30W per port
•Maximum 400W power consumption
•48Gbps Non-Blocking Switching Performance
•500 Kbits Packet Buffer
•8K MAC Address Table, Up to 12.2K Jumbo Frame
•Web-based Configuration and Management
•802.1Q VLAN, QoS, Link Aggregation, RSTP, IGMP Snooping and IEEE 802.1X
1.3 Software Features
•VLAN: 16, VLAN ID: 1~ 4094
•Rapid Spanning Tree Protocol
•IGMP Snooping V1&V2
•LACP/Trunk: up to 8 groups
Chapter
1

ES2446-51
2
•Quality of Service: up to 4 queues, 802.1p
•PoE Control: PoE Port Enabled/Disable, Status
•IEEE 802.1X, Source IP Filter
•Storm Control: Broadcast, Multicast, Flood Unicast
•Port: Port State, Speed/Duplex, Flow Control
•Rate Limiting, Port Mirroring
•Management: Web GUI, SNMP, Password protection, Configuration
upload/download, Firmware upgrade
Note: Please see the most updated datasheet for the detail product specification.
You can check the web site or contact the sales of the supplier.
1.4 Package Contents
Before you start to install this switch, please verify your package that contains
the following items:
1. One Switch
2. One Power Cord
3. User Manual CD
4. One pair Rack-mount kit + 8 Screws

ES2446-51
3
2. Hardware Description
This part primarily presents hardware of the web-smart switch, physical dimension,
appearance, front panel, rear panel and LED indicator.
2.1 Dimensions
44 × 440 × 331 mm (H × W × D)/4.7kg
2.2 Appearance & Front Panel
The front Panel of the web-smart Switch consists of 24 gigabit RJ-45 ports, 4 of the
gigabit RJ-45 ports (Port 1~4) combo with 4 gigabit SFP open slot. The LED Indicators
are also located on the front panel.
Appearance
Chapter
2
LED Display
RJ-45 Port
IEEE 802.3at PSE
4 RJ-45/SFP
Combo ports
Reset Button

ES2446-51
4
Front Panel
Note 1: The SFP ports are shared with normal RJ-45 ports 1,2,3 and 4. For example:
The RJ-45 Port 1 can not be used when SFP Port 1 link up.
Note 2: Click the Reset button for 5 seconds, the system configuration will be reset
to default.
2.3 LED Indicators
The LED Indicators present real-time information of systematic operation status. This
table provides description of LED status and the meaning.
Table 1-1 LED Indicators
LED
Status
Description
Power
On
Power on
Off
Disconnect to Power Source
Link/ ACT
On
Link
Flashing
Data activating
Off
No device is attached
PoE
On
Port is linked to Power Device
Off
No Power Device is connected
2.4 Rear Panel
The 3-pronged power plug is placed at the rear panel of the switch right side
shown as below. This is reserved for AC Power Input.

ES2446-51
5
2.5 Hardware Installation
The switch is usually mounted in the 19” rack, the rack is usually installed in IT
room or other secured place. The switch supports AC power input and
rackmount mounting. Make sure all the power cables, Ethernet cables, screws
and the air circulation are well prepared and installed as below description.
The port 1~24 are the copper ports, it requests UTP/STP cable. These port are
also PoE ports, choose CAT 5/5E or above for the PoE application.
The port 1~4 are the combo SFP ports, shared with the copper port 1~4. Please
purchase the suitable fiber transceiver from your supplier and connect the fiber
cable for the link.
Ethernet cable Request
The wiring cable types for data transmission are as below.
10 Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
100 Base-TX: 2-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
1000 Base-T: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
The wiring cable types for data transmission and power delivery in any speed
are Cat. 5 or above.
SFP Installation
While install the SFP transceiver, make sure the SFP type of the 2 ends is the
same and the transmission distance, wavelength, fiber cable can meet your
request. It is suggested to purchase the SFP transceiver with the switch provider
to avoid any incompatible issue.
The way to connect the SFP transceiver is to Plug in SFP fiber transceiver fist.
The SFP transceiver has 2 plug for fiber cable, one is TX (transmit), the other is
RX (receive). Cross-connect the transmit channel at each end to the receive
channel at the opposite end.
PD Installation plan
When planning the PD installation, please share the PD load to the different
ports.
Internal Power Supply 1: Maximum 130W for Port 1~8 + System (max. 20W)
Internal Power Supply 2: Maximum 130W for Port 9~16
Internal Power Supply 2: Maximum 130W for Port 17~24
You can check the power consumption of the PD device or check the Web GUI
of the switch to see the percentage of the power usage of the ports.
Rackmount Installation
Attach the brackets to the device by using the screws provided in the Rack
Mount kit.
Mount the device in the 19‟rack by using four rack-mounting screws provided
by the rack manufacturer.

ES2446-51
6
3. Preparation for Web Interface
The web management page allows you to use a standard web-browser such as
Microsoft Internet Explorer, Google Chrome or Mozila Firefox, to configure and
interrogate the switch from anywhere on the network.
Before you attempt to use the web user interface to manage switch operation, verify
that your Switch is properly installed on your network and that every PC on this
network can access the switch via the web browser.
1. Verify that your network interface card (NIC) is operational, and that your
operating system supports TCP/IP protocol.
2. Wire the switch power and connect your computer to the switch.
3. The switch default IP address is 192.168.2.1. The Switch and the connected PC
should locate within the same IP Subnet.
4. Change your computer's IP address to 192.168.2.XX or other IP address which is
located in the 192.168.2.x (For example: IP Address: 192.168.2.30; Subnet Mask:
255.255.255.0) subnet.
5. Launch the web browser and Login.
Chapter
3

ES2446-51
7
6. Launch the web browser (Internet Explorer or Mozila Firefox) on the PC.
7. Type http://192.168.2.1 (or the IP address of the switch). And then press Enter.
8. The login screen will appear next.
9. Key in the password. Default password is no password. Click “Apply” directly.
Login Screen
The figure shows the login screen.
The factory default password is no password, just click the Apply button to login
directly.
After the login process is completed. The web interface comes out the sign
“Password successfully entered”.
Note: To secured your switch’s security, please go to the System Configuration
page and setup the new password.
Below is the main screen, the left side of the web shows the function list and
the right side of the web shows the configuration parameters.

ES2446-51
8
Trouble Shooting
If you can't login the switch, the following steps can help you to identify the
problem.
1. Switch to DOS command mode and type the "ipconfig" to check the NIC's
setting. Type the "ping 192.168.2.1"to verify a normal response time.
2. Check the security & firewall settings of your computer.
3. Try different Web-browser, like the Mozila.

ES2446-51
9
4. Web UI Configuration
This part instructs user how to set up and manage the switch through the web user
interface. Please follow the description to understand the procedure.
4.1 Configuration
This part shows how to configure the switch settings.
4.1.1 System Configuration
This page shows system configuration information. User can configure information
as below:
MAC Address: Displays the unique hardware address assigned by manufacturer
(default).
S/W Version: Displays the switch’s firmware version.
H/W Version: Displays the switch’s Hardware version.
Active IP Address: The current active IP address of the switch.
Active Subnet mask: The current active subnet mask of the IP Address.
Active Gateway: The current active Gateway of the switch.
Chapter
4

ES2446-51
10
DHCP Server: The IP of the DHCP Server. Display after DHCP Client enabled.
Lease Time Left: The least received from the DHCP server. Display after the DHCP
Client enabled.
DHCP Enabled: Click the box to enable DHCP Client mode.
Fallback IP address: Manually assign the IP address that the network is using. The
default IP is 192.168.2.1
Fallback Subnet Mask: Assign the subnet mask to the IP address
Fallback Gateway: Assign the network gateway for industrial switch. The default
gateway is 192.168.2.254.
Management VLAN: ID of a configured VLAN (1-4094) through which you can
manage the switch. By default, all ports on the switch are members of VLAN 1.
However, if the management VLAN is changed, the management station must be
attached to a port belonging to this VLAN.
Name: Type in the new user name information.
Password: Type in the new password (The default value is no password).
SNMP Enabled: Enables or disables SNMP on the switch. Supports SNMP version

ES2446-51
11
1and 2c management clients.
SNMP Trap Destination: IP address of the trap manager to receive notification
messages from this switch. Traps indicating status changes are issued by the
switch to specified trap managers. You must specify trap managers so that key
events are reported by this switch to your management station.
SNMP Read Community: A community string that acts like a password and
permits access with Read privilege to the SNMP database on this switch.
Authorized management stations are only able to retrieve MIB objects.
SNMP Write Community: A community string that acts like a password and
permits access with Write privilege to the SNMP database on this switch.
Authorized management stations are able to modify the value of the MIB objects.
SNMP Trap Community: Community string sent with the notification operation.
4.1.2 Ports
In Port Configuration, you can set and view the operation mode for each port.
Enable Jumbo Frames: This switch provides more efficient throughput for large
sequential data transfers by supporting jumbo frames on Gigabit Ethernet ports
up to 12.2KB. Compared to standard Ethernet frames that run only up to 1.5 KB,
using jumbo frames significantly reduces the per-packet overhead required to
process protocol encapsulation fields.
Power Saving Mode: Adjusts the power provided to ports based on the length of
the cable used to connect to other devices. Only sufficient power is used to
maintain connection requirements.
Mode: Allows user to manually set the port speed such as Auto, 10 half, 10 Full,
100 Half, 100 Full, 1000 Full or Disabled. User may press Apply button to complete
the configuration procedure.
Flow Control: Allows user to manually enable or disable the Flow Control feature.
Click the checkbox of the specific ports you and press Apply button to complete
the configuration procedure.

ES2446-51
12
4.1.3 VLAN
A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain,
which would allow you to isolate network traffic, so only the members of the same
VLAN will receive traffic from the ones of the same VLAN. Basically, creating a VLAN
from a switch is logically equivalent of reconnecting a group of network devices to
another Layer 2 switch. However, all the network devices are still plugged into the
same switch physically.
Port Segmentation (VLAN) Configuration

ES2446-51
13
VLAN ID: ID of configured VLAN (1-4094, no leading zeroes). Type the new ID
and click Add. The web UI is directed to the VLAN Setup screen.
VLAN Configuration List: Lists all the current VLAN groups created for this system.
Up to 16 VLAN groups can be defined. VLAN 1 is the default untagged VLAN.
VLAN Setup Configuration
The screen allows user to select the member ports of the VLAN you added.
Select the ports and click “Apply” to activate.

ES2446-51
14
4.1.4 Aggregation
Port trunk allows multiple links to be bundled together and act as a single physical
link for increased throughput. It provides load balancing, and redundancy of links in a
switched inter-network. Actually, the link does not have an inherent total bandwidth
equal to the sum of its component physical links. Traffic in a trunk is distributed
across an individual link within the trunk in a deterministic method that called a hash
algorithm. The hash algorithm automatically applies load balancing to the ports in
the trunk. A port failure within the trunk group causes the network traffic to be
directed to the remaining ports. Load balancing is maintained whenever a link in a
trunk is lost or returned to service.
Aggregation / Trunking Configuration
To assign the ports to a trunk, click the required trunk number ports, then click
Apply.
Below example figure show Port 3 and 4 are the member ports of the Trunk Group 1.
4.1.5 LACP
IEEE 802.3ad Link Aggregation Control Protocol (LACP) increases bandwidth by
automatically aggregating several physical links together as a logical trunk and
providing load balancing and fault tolerance for uplink connections. Once the port is
configured as Static Aggregation port, the area will become gray. It means a port can
only be the member of the Aggregation or LACP.

ES2446-51
15
LACP Port Configuration
Port: The port ID.
Protocol Enabled: Enables LACP Protocol on the associated port.
Key Value: Configures a port's LACP administration key. The port administrative
key must be set to the same value for ports that belong to the same link
aggregation group (LAG). If this administrative key is not set when an LAG is
formed (i.e., it has the null value of 0), this key will automatically be set to the
same value as that used by the LAG.
