evertin DH-D 10L User manual

Before operating this product, please read the instructions
carefully and save this manual for future use.
DEHUMIDIFIER
DH-D 10L DH-D 16L DH-20L

SOCIABLE REMARK
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection
of such waste separately for special treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can
be disposed of at least free of charge to the user.
B) When buying a new product, the retailer will take back the old product at least
free of charge.
C) The manufacture will take back the old appliance for disposal at least free of
charge to the user.
D) As old products contain valuable resources, they can be sold to scrap metal
dealers.
Wild disposal of waste in forests and landscapes endangers your health when
hazardous substances leak into the ground-water and find their way into the food
chain.
When using this dehumidifier in the European countries, the following information
must be followed:

CONTENTS
SAFETY PRECAUTIONS
Warning ..........................................................................................................................................2
Caution ...........................................................................................................................................2
Electrical information ......................................................................................................................3
OPERATIING THE UNIT
When using the unit .......................................................................................................................6
Removing the collected water ........................................................................................................7
CARE AND MAINTENANCE
Care and cleaning of the dehumidifier ...........................................................................................8
TROUBLESHOOTING TIPS
Troubleshooting tips .......................................................................................................................9
CONTROL PADS ON THE DEHUMIDIFIER
Indicator lights................................................................................................................................4
Control pads...................................................................................................................................4
Other features.................................................................................................................................5
IDENTIFICATION OF PARTS
Identification of parts ......................................................................................................................5
Positioning the unit .........................................................................................................................6
1

2
SAFETY PRECAUTIONS
Do not exceed the rating
of the power outlet or
connection device.
Do not modify power cord
length or share the outlet
with other appliances
Disconnect the power if
strange sounds, smell, or
smoke comes from it.
Otherwise, it may cause electric
shock or fire due to excess heat
generation.
It may cause electric shock or
fire due to heat generation.
It may cause fire and electric
shock.
It may cause electric shock or fire
due to heat generation.
It may cause electric shock.
It may cause failure of machine
or electric shock.
It contains contaminants and
could make you sick.
It may cause electric shock or fire.
Plastic parts may melt and cause
a fire.
It may cause electrical shock or
injury.
It may cause an explosion or fire.
Do not operate or stop the
unit by switching on or off
the power.
Do not insert or pull out
plug with wet hands.
You should never try to take
apart or repair the unit by
yourself.
Do not drink or use the
water drained from the unit.
Do not damage or use an
unspecified power cord.
Do not place the unit near
a heat source.
Before cleaning, turn off
the power and unplug the
unit.
Do not use the machine near
flammable gas or combustibles, such
as gasoline, benzene, thinner, etc.
!!
CAUTION
Do not use the unit in small
spaces.
Lack of ventilation can cause
overheating and fire.
Do not put in places where
water may splash onto the
unit.
Water may enter the unit and
degrade the insulation. It may
cause an electric shock or fire.
Place the unit on a
level, sturdy section
of the floor.
If the unit falls over, it may
cause water to spill and
damage belongings, or
cause electrical shock or
fire.
!
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation due to ignoring of instructions may cause harm or damage.
The seriousness is classified by the following indications.
This symbol indicates the possibility of death or serious injury.
Meanings of symbols used in this manual are as shown below.
Always do this.
Never do this.
CAUTION
This symbol indicates the possibility of injury or damage to property.
WARNING
WARNING
It may cause bucket full protect of
the unit and cause electric shock.
Do not take the water buc-
ket out during operation.

3
SAFETY PRECAUTIONS
Do not cover the intake or
exhaust openings with
cloths or towels.
A lack of air flow can lead
to overheating and fire.
Never insert your finger or
other foreign objects into grills
or openings. Take special care
to warn children of these
dangers.
Do not use in areas
where chemicals are
handled.
This will cause the unit
deterioration due to
chemicals and solvents
dissolved in the air.
Care should be taken when
using the unit in a room with
the following persons:
Infants, children, elderly people,
and people not senstive to
humidity.
You may be injured if you
fall or if the unit falls over.
Water may spill inside the
unit, causing insulation
failure and electrical
shock or fire.
!
!
It may cause failure of
appliance or accident.
There is danger of fire or
electric shock.
Do not place heavy object on the
power cord and take care so that
the cord is not compressed.
Operation without filters
may cause failure.
Always insert the filters
securely. Clean filter
once every two weeks.
CAUTION
Do not climb up on
or sit on the unit.
If water enters the unit, turn
the unit off and disconnect the
power , contact a qualified
service technician.
!
Do not place flower
vases or other water
container on top of
the unit.
The manufactures nameplate is located on the rear panel of the unit and contains electrical and other
technical data specific to this unit.
Be sure the unit is properly grounded. To minimize shock and fire hazards, proper grounding is important.
The power cord is equipped with a three-prong grounding plug for protection against shock
hazards.
Your unit must be used in a properly grounded wall receptacle. If the wall receptacle you intend to use is
not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualified electrician
install the proper receptacle.
Ensure the receptacle is accessible after the unit installation.
Do not use extension cords or an adapter plugs with this unit. However, if it is necessary to use an
extension cord, use an approved Dehumidifier extension cord only (available at most local hardware
stores).
To avoid the possibility of personal injury, always disconnect the power supply to the unit, before installing
and/or servicing.
Electrical Information
It may cause electric shock
or failure of appliance.

4
CONTROL PADS ON THE DEHUMIDIFIER
Control panel(1) Control panel(2)
3
1
2
5
Indicator lights
Power on indicator light(green)
Continuous operation on indicator light(green)
Bucket full indicator light(red)
Display
Shows the set % humidity level while setting, then shows
the actual(+5% accuracy) room % humidity level.
Error Codes:
E1- Humidity sensor error--Unplug the unit and plug
it back in. If error repeats, call for service.
E2- Temperature sensor error-- Unplug the unit and
plug it back in. If error repeats, call for service.
Protect Codes:
P1- Unit is defrosting-- Allow the unit to automatically
defrost. The portect will clear after the unit self defrosts.
P2- Bucket is full or bucket is not in the right position--
Empty the bucket and replace in the right position.
6
POWER Pad
Press to turn the dehumidifier on and off.
7
Continue Pad
Select for the dehumidifier to operate
continuously for maximum dehumidification
until the bucket is full. The Humidity set
control pads cannot be used when
Continuous operation is on.Press this pad
again to cancel Continuous operation.
8
Humidity Set Control Pads
The humidity level can be set within a
range of 35%RH(Relative Humidity) to 80%
RH(Relative Humidity) in 5% increments.
For drier air, press the pad and set to a
lower percent value(%).
For damper air, press the pad and set to
a higher percent value(%).
Control pads
The control panel of the dehumidifier you purchased may be look like one of the following:
Full PowerFull Power
2
3
56
1
8
7
1
2
6
Cont . Working
4
4
Dehumidify operation on indicator light(green)
Power

5
IDENTIFICATION OF PARTS
Identification of parts
Other features
Bucket Full Light
Glows when the bucket is ready to be
emptied, or when the bucket is removed
or not replaced in the proper position.
Auto Shut Off
The water level control switch shuts off the
dehumidifier when the bucket is full, or when
the bucket is removed or not replaced in the
proper position. When the setting humidity
is reached, the unit will be shut off automatically.
When frost builds up on the evaporator coils, the
compressor will cycle off and the fan will continue to
run until the frost disappears.The Auto Defrost indicator
light will glow.
Auto-Restart(on some models)
If the unit breaks off unexpectedly due to the power cut,
it will restart with the previous function setting automa-
tically when the power resumes.
Auto Defrost
Power Cord
Air Outlet grille
Drain hose outlet (see page 7)
Air filter (behind the air intake grille)
Power Plug
Power cord band (Used only when storing the unit.)
Front
Rear
Control panel
Air intake grille
Water bucket
Handle
9
10
7
5
6
8
3
1
2
4
Fig.1
Fig.2
Wait 3 minutes before resuming operation
After the unit has stopped, it can not be restart
opertation in the first 3 minutes. This is to protect
the unit. Operation will automatically start after
3 minutes.
NOTE: All the pictures in the manual are
for explanation purposes only.Your unit
may be slightly different.The actual shape
shall prevail.The operations and functions
are the same.
4
1
2
3
5
6
7
8
9
10

6
OPERATING THE UNIT
When using the unit
When first using the dehumidifier, operate the unit continuously 24 hours.
OO OO
This unit is designed to operate with a working environment between 5 C(41 F) and 35 C(95 F).
If the unit has been switched off and needs to be switched on again quickly, allow approximately
three minutes for the correct operation to resume.
Do not connect the dehumidifier to a multiple socket outlet, which is also being used for other electrical appliances.
Select a suitable location, making sure you have easy access to an electrical outlet.
Plug the unit into a 115V~ 60Hz/220~240V 50Hz (Refer to the nameplate located on the side/rear of the unit ) electrical
socket-outlet with earth connection.
Make sure the Water bucket is correctly fitted otherwise the unit will not operate properly.
A dehumidifier operating in a basement will have little or no
effect in drying an adjacent enclosed storage area, such as a
closet, unless there is adequate circulation of air in and out of
the area.
Air outlet grille
Air intake
grille
20cm or more
20cm or more 20cm or more
20cm or more
40cm or
more
Positioning the unit
Do not use outdoors.
This dehumidifer is intended for indoor residential
applications only. This dehumidifier should not be used
for commercial or industrial applications.
Place the dehumidifier on a smooth, level floor strong
enough to support the unit with a full bucket of water.
Allow at least 20cm of air space on all sides of the unit
for good air circulation.
Place the unit in an area where the temperature will not
OO
fall below 5 C(41 F). The coils can become covered with
OO
frost at temperatures below 5 C(41 F), which may reduce
performance.
Place the unit away from the clothes dryer, heater or radiator.
Use the unit to prevent moisture damage anywhere books
or valuables are stored.
Use the dehumidifier in a basement to help prevent
moisture damage.
The dehumidifier must be operated in an enclosed
area to be most effective.
Close all doors, windows and other outside openings
to the room.
Fig.4
Casters(Install at four points on the bottom
of unit)
Casters can only move laterally.
Do not force casters to move over carpet,
nor move the unit with water in the bucket.
(The unit may tip over and spill water.)
NOTE:Casters is optional,some models without.

7
Removing the collected water
There are two ways to remove collected water.
1. Use the bucket
When the bucket is full, the unit will automatically
stop running, and the Full indicator light will flash.
Slowly pull out the bucket. Grip the left and right
handles securely, and carefully pull out straight so
water does not spill. Do not put the bucket on the floor
because the bottom of the bucket is uneven.
Otherwise the bucket will fall and cause the water
to spill.
Throw away the water and replace the bucket. The
bucket must be in place and securely seated for
the dehumidifier to operate.
The machine will re-start when the bucket is restored
in its correct position.
NOTES:
When you remove the bucket, do not touch any parts
inside of the unit. Doing so may damage the product.
Be sure to push the bucket gently all the way into the
unit. Banging the bucket against anything or failing to
push it in securely may cause the unit not to operate.
2. Continuous draining
Fig.5
Fig.6
Fig.7
1. Pull out the bucket a little.
2. Hold both sides of the bucket
with even strength, and pull it
out from the unit.
3. Pour the water out.
Water can be automatically emptied into a floor
drain by attaching the unit with a water hose
( 12mm) (not included).
NOTE: When the continuous drain feature is not
being used,remove the drain hose from the outlet
and attach the rubber plug back to the drain outlet.
Pull out the rubber plug from the drain outlet in the back of the unit.
Insert the water hose into the unit from the drain outlet in the
back of the unit as shown in Fig.8. Attach the water hose to the
drain hose outlet of the unit.Make sure the connection of the water
hose and the drain hose outlet of the unit is tight and do not let the
water leak.
Then lead the water hose to the floor drain or a suitable drainage
facility.The drainage facilify should be lower than the drain outlet
of the unit.
Be sure to run the water hose sloping downward and let the
water to flow out smoothly.Do not install the water hose as
shown in Fig.9a and Fig.9b.
OPERATING THE UNIT
Fig.9a Fig.9b
Do not block water flow by a rise. Do not block water flow by a retortion.
Insert the water
hose from the
drain outlet
Pull out the
rubber plug
Fig.8

8
After turning off the unit, wait one day before emptying
the bucket.
Clean the main unit, bucket and air filter.
Wrap the cord and bundle it with the band(see Fig.13).
Cover the unit with a plastic bag.
Store the unit upright in a dry, well-ventilated place.
4. When not using the unit for long time periods
CARE AND MAINTENANCE
Care and cleaning of the dehumidifier
Turn the dehumidifier off and remove the plug
from the wall outlet before cleaning.
1. Clean the Grille and Case
Use water and a mild detergent. Do not use
bleach or abrasives.
Do not splash water directly onto the main
unit. Doing so may cause an electrical shock,
cause the insulation to deteriorate, or cause
the unit to rust.
The air intake and outlet grilles get soiled easily,
so use a vacuum attachment or brush to clean.
Fig. 10
Fig. 11
3. Clean the air filter
The air filter behind the front grille should be checked and cleaned
at least every 30 daysor more often if necessary.
NOTE: DO NOT RINSE OR PUT THE FILTER IN AN AUTOMATIC
DISHWASHER.
To remove:
Pull the water bucket out as shown in Fig.10.
Pull out the filter downward.(see Fig.11).
Clean the filter with warm, soapy water. Rinse and
let the filter dry before replacing it. Do not clean the
filter in a dishwasher.
To attach:
Insert the filter into the unit,then push the filter
upward.(See Fig.12).
CAUTION:
DO NOT operate the dehumidifier without a filter
because dirt and lint will clog it and reduce performance.
Pull out the filter
downward.
Fig. 12
Insert the filter
and push it upward.
Band
Power cord
Fig. 13
2. Clean the bucket
Every few weeks, clean the bucket to prevent
growth of mold, mildew and bacteria. Partially
fill the bucket with clean water and add a little
mild detergent. Swish it around in the bucket,
empty and rinse.
NOTE: Do not use a dishwasher to clean the
bucket. After clean, the bucket must be in place
and securely seated for the dehumidifier to
operate.

9
TROUBLESHOOTING TIPS
Before calling for service, review the chart below first yourself.
Problem What to check
Unit does not start Make sure the dehumidifier s plug is pushed completely into the
outlet.
Check the house fuse/circuit breaker box.
Dehumidifier has reached its preset level or bucket is full.
Bucket is not in the proper position.
Dehumidifier does not
dry the air as it should
Did not allow enough time to remove the moisture.
Make sure there are no curtains, blinds or furniture blocking the
front or back of the dehumidifier.
The humidity selector may not be set low enough.
Check that all doors, windows and other openings are securely
closed.
Room temperature is too low, below 5 C(41 F).
There is a kerosene heater or something giving off water vapor
in the room.
,
The unit makes a loud
noise when operating
The air filter is clogged.
The unit is tilted instead of upright as it should be.
The floor surface is not level.
Frost appears on the
coils This is normal. The unit has Auto defrost feature.
Water on floor Hose to connector or hose connection may be loose.
Intend to use the bucket to collect water, but the back
drain plug is removed.
Power indicator light
flashes at 5 times per
second.
Temperature sensor or error. Unplug the unit
and plug it back in.If error repeats, call for service.
Humidity sensor

CD014IU-T3
202000192425
20110802
The design and specifications are subject to change without prior notice for
product improvement. Consult with the sales agency or manufacturer for details.
