Evertz Hd9010tm User manual

HD9010TM

HDTV Time Code Master

Instruction Manual

EVERTZ MICROSYSTEMS LTD.

5288 John Lucas Drive,

Burlington, Ontario, Canada

L7L 5Z9

Phone: 905-335-3700

Sales Fax: 905-335-3573

Support Fax: 905-335-0909

Internet: Sales: sales@evertz.com

Tech Support: service@evertz.com

Web Page: http://www.evertz.com

Version 2.4.1, January 2014

The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely

for the use of purchasers of the HD9010TM High Definition Time Code Master. Evertz Microsystems expressly prohibits the use

of this manual for any purpose other than the operation of the device.

Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS

The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of uninsulated “Dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (Servicing) instructions in

the literature accompanying the product.

•Read and keep these instructions

•Heed all warnings.

•Follow all instructions.

•Do not use this apparatus near water

•Clean only with dry cloth.

•Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than other. A grounding-type plug has two blades and a third

grounding prong. The wide blade or the third prong is provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

•Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles and the point where they exit from the apparatus.

•Only use attachments/accessories specified by the manufacturer

•Unplug this apparatus during lightning storms or when unused for long periods of time.

•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC –

SHOCK, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE

WARNING

DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT

NO OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT

WARNING

TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT

THE POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE

WARNING

THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

INFORMATION TO USERS IN EUROPE

NOTE

This equipment with the CE marking complies with bother the EMC Directive (89/336/EEC) and the Low

Voltage Directive (73/23/EEC) issued by the Commission of the European Community.

Compliance with these directives implies conformity to the following European standards:

•EN60065 Product Safety

•EN55103-1 Electromagnetic Interference Class A (Emission)

•EN55103-2 Electromagnetic Susceptibility (Immunity)

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to the European Union EMC directive. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

INFORMATION TO USERS IN THE U.S.A.

NOTE

FCC CLASS A DIGITAL DEVICE OR PERIPHERAL

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which case the user will be required to correct

the interference at his own expense.

WARNING

Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s

authority to operate the equipment.

Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables

with the shield connected to the chassis ground of the device must be used.

HD9010TM High Definition Time Code Master Manual

Revision 2.4.1

REVISION HISTORY

REVISION DESCRIPTION DATE

0.1 Preliminary Version Oct 03

1.0 First Release - Fix typos – manual updated to conform to firmware version 1v1 Build 66 Mar 04

1.1 Fix Typos - manual updated to conform to firmware version 1v1 Build 214 Mar 04

1.2 Manual updated to conform to firmware version 1v2 Build 44 Aug 04

Added Tri-level sync support

2.0 Manual updated to conform to Hardware Revision 2 and firmware version 2v0 Build 1 May 05

Corrected GPI pin out, added new info for upgrading Rev 2 hardware at 115200 baud.

Added new info for serial port baud rate menu items.

2.1 Manual updated to conform to firmware version 2v0 Build 1 Jul 05

Added GPI Remote Control Encoding, and GPI and COM Port status displays

2.2 Manual updated to conform to firmware version 2v0 Build 37 Oct 05

Added ON AIR Tally and reassigned default GPI functions

2.3 Add description for Drop Frame Conversion mode, document changes Dec 05

to Preset Save and Preset Load functions

2.3.1 Fix Typos in Special Indicators section Feb 06

2.3.2 Add note that unit required Video Input for normal operation Jul 06

2.3.3 Updated overview and Specifications Dec 06

2.3.4 Fixed typos and formatting errors May 07

2.4 Manual updated to conform to firmware version 2v0 Build 285 Nov 09

Added ‘Double Height” character size feature, Remove VANC Line & On/Off control

2.4.1 Minor edits to overview and sections 3.5.2, 3.7.1 Jan 14

Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the

rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz

products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by Evertz in

relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.

Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is

granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.

Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,

please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or

specifications.

HD9010TM High Definition Time Code Master Manual

Revision 2.4.1

This page left intentionally blank

HD9010TM High Definition Time Code Master Manual

Revision 2.4.1 Page i

TABLE OF CONTENTS

1. OVERVIEW............................................................................................................................... 1-1

1.1. HOW TOUSE THIS MANUAL............................................................................................ 1-2

1.2. DEFINITIONS.................................................................................................................... 1-3

2. INSTALLATION......................................................................................................................... 2-1

2.1. REAR PANEL ................................................................................................................... 2-1

2.1.1. Video Connections..................................................................................................2-1

2.1.2. GenLock Reference Connections............................................................................. 2-1

2.1.3. Linear Timecode.....................................................................................................2-1

2.1.4. Parallel I/O Connections.......................................................................................... 2-2

2.1.5. Serial I/O Connections............................................................................................ 2-2

2.1.6. Power Connections................................................................................................. 2-3

2.2. MOUNTING....................................................................................................................... 2-3

2.3. POWER REQUIREMENTS................................................................................................ 2-3

2.4. CONNECTING THE VIDEO............................................................................................... 2-4

2.4.1. High Definition Video Input...................................................................................... 2-4

2.4.2.High Definition Video Output................................................................................... 2-4

2.5. CONNECTING THE LINEAR TIME CODE..........................................................................2-5

2.5.1. Connecting the Primary LTC Generator................................................................... 2-6

2.5.2. Connecting the Primary LTC Reader .......................................................................2-6

2.6. CONNECTING THE AUXILLIARY TIME CODE.................................................................. 2-6

2.6.1. Connecting the Auxiliary LTC Generator .................................................................. 2-6

2.6.2. Connecting the Auxiliary LTC Reader ...................................................................... 2-6

2.7. CONNECTING THE HD9010TM TOACOMPUTER ........................................................... 2-7

2.7.1. Physical Connections.............................................................................................. 2-7

3. HOW TO OPERATE THE TIME CODE MASTER.......................................................................3-1

3.1. AN OVERVIEW OF KEY AND DISPLAY FUNCTIONS........................................................ 3-1

3.1.1. The Setup Menu Pushbutton Group ........................................................................3-1

3.1.2. The Display Button Group....................................................................................... 3-2

3.1.3. Panel Lock Key Functions.......................................................................................3-2

3.1.4. The Character Window Pushbutton Group...............................................................3-2

3.1.5. The Function Button Group.....................................................................................3-3

3.1.6. The Preset Button Group ........................................................................................ 3-3

3.1.7. An Overview of the SHIFT Key functions................................................................. 3-4

3.1.8. Shaft Encoder Knob................................................................................................ 3-4

3.1.9. An Overview of the Status Indicators.......................................................................3-5

3.2. FRONT PANEL DISPLAY FUNCTIONS............................................................................. 3-6

3.2.1. Front Panel Displays............................................................................................... 3-6

3.2.2. Special Front Panel Indicators.................................................................................3-6

HD9010TM High Definition Time Code Master Manual

Page ii Revision 2.4.1

3.3. AN OVERVIEW OF THE SETUPMENU SYSTEM ..............................................................3-6

3.4. CONFIGURING THE GENERATOR ...................................................................................3-8

3.4.1. Configuring the Generator Mode...............................................................................3-9

3.4.2. Setting the Generator Time....................................................................................3-10

3.4.3. Setting the Generator User Bits..............................................................................3-10

3.4.4. Jam Syncing the Generator to the Primary reader...................................................3-11

3.4.5. Turning the ATC Generator On..............................................................................3-12

3.4.6. Setting the ATC Packet Type.................................................................................3-12

3.4.7. Selecting the Generator Drop Frame Mode (29.97 and 59.94 FPS video standards only)

.............................................................................................................................3-13

3.4.7.1. Conversion Between Drop Frame and Non Drop Frame Counting Modes....3-13

3.4.8. Generator LTC Parity Mode Selection.....................................................................3-15

3.4.9. Configuring how the Continuous Jam Sync Mode Works when there is no Primary

Reader Code.........................................................................................................3-16

3.5. CONFIGURING THE READERS.......................................................................................3-16

3.5.1. Setting the Primary reader.....................................................................................3-17

3.5.2. Setting the ATC Reader Packet Type.....................................................................3-17

3.5.3. Selecting the Format of the ATC Reader Time and User Bit Data............................3-18

3.5.4. Selecting the Format of the LTC Reader Time and User Bit Data ............................3-18

3.5.5. Selecting the Format of the Auxiliary LTC Reader Time and User Bit Data...............3-18

3.6.CONFIGURING THE CHARACTER GENERATOR FUNCTIONS.......................................3-18

3.6.1. Selecting the Character Style.................................................................................3-19

3.6.2. Selecting whether the Frames, Fields and Symbols will be displayed on the VCG ...3-19

3.6.3. Selecting and Positioning the Individual Character Inserter Windows ......................3-20

3.6.4. Positioning the Overall Character Display and Turning it On and Off........................3-20

3.6.5. Special VCG Indicators .........................................................................................3-21

3.7. GENERAL CONFIGURATION ITEMS...............................................................................3-21

3.7.1. Selecting the Video Standard.................................................................................3-22

3.7.2. Selecting the Generator Framing Reference ...........................................................3-23

3.7.3. Adjusting the Output Level of the LTC Generators..................................................3-23

3.7.4. Adjusting the Baud Rate of the Serial Ports ............................................................3-23

3.7.5. Working with System Parameters..........................................................................3-24

3.7.6. Viewing the Hardware Version ...............................................................................3-24

3.7.7. Viewing the Firmware Version ...............................................................................3-24

3.7.8. Upgrading the Firmware........................................................................................3-25

3.7.9. Resetting the HD9010TM to its Factory Defaults.....................................................3-25

3.8. CONFIGURING THE GENERAL PURPOSE INPUTS AND OUTPUTS...............................3-25

3.8.1. GPI Remote Control Mode.....................................................................................3-25

3.8.2. Assigning the Functions of the General Purpose Inputs...........................................3-26

4. TECHNICAL DESCRIPTION......................................................................................................4-1

4.1. SPECIFICATIONS .............................................................................................................4-1

4.1.1. HDTV Serial Digital Video Input...............................................................................4-1

4.1.2. HDTV Serial Digital Video Outputs...........................................................................4-1

4.1.3. Reference Input.......................................................................................................4-1

4.1.4. LTC Generators.......................................................................................................4-1

4.1.5. LTC Readers...........................................................................................................4-1

HD9010TM High Definition Time Code Master Manual

Revision 2.4.1 Page iii

4.1.6. Serial Ports............................................................................................................. 4-2

4.1.7. System Latency......................................................................................................4-2

4.1.8. Physical .................................................................................................................4-2

4.1.9. Electrical................................................................................................................ 4-2

4.2. UPGRADING THE FIRMWARE ......................................................................................... 4-2

4.2.1. Overview................................................................................................................ 4-2

4.2.2. Terminal Program Setup.........................................................................................4-3

4.2.3. Initiating Firmware Upgrade Mode Via The Front Panel............................................4-3

4.2.4. Initiating Firmware Upgrade Mode From The Terminal Program ...............................4-3

4.2.5. Uploading the New Firmware..................................................................................4-4

4.2.6. Completing the Upgrade......................................................................................... 4-5

4.3. SERVICING INSTRUCTIONS............................................................................................ 4-5

4.3.1. Changing the Fuses................................................................................................4-5

4.3.2. Changing DIP Switch Settings................................................................................4-6

4.3.2.1. Enabling the Time Code Broadcast Data Output..........................................4-6

Figures

Figure 1-1: HD9010TM Block Diagram.........................................................................................................1-2

Figure 2-1: HD9010TM Rear Panel..............................................................................................................2-1

Figure 3-1: HD9010TM Front Panel Layout..................................................................................................3-1

Figure 3-2: Overview of the Setup Menu.......................................................................................................3-7

Tables

Table 2-1: Parallel I/O Connector Pin Definitions – Normal GPIO Functions................................................2-2

Table 2-2: Parallel I/O Port Pin Definitions – Time RCTL Mode....................................................................2-2

Table 2-3: COM1 Pin Definitions.................................................................................................................2-3

Table 2-4: AUX COM Pin Definitions...........................................................................................................2-3

Table 2-5: High Definition Video Input Formats...........................................................................................2-5

Table 3-1: Top Level of the Generator Setup Menu .....................................................................................3-8

Table 3-2: Top Level of the Reader Setup Menu........................................................................................3-16

Table 3-3: Top Level of the VCG Setup Menu ...........................................................................................3-19

Table 3-4: Top Level of the Utility Setup Menu...........................................................................................3-21

Table 3-5: Remote Control Mode GPI I/O Mapping ...................................................................................3-26

Table 3-6: Parallel I/O Connector Pin Definitions – Normal GPIO Functions (Rev 2 Versions)...................3-26

Table 3-7: Parallel I/O Connector Pin Definitions – Normal GPIO Functions (Rev 1 Versions)...................3-27

Table 4-1: DIP Switch Functions.................................................................................................................4-6

HD9010TM High Definition Time Code Master Manual

Page iv Revision 2.4.1

This page left intentionally blank

HD9010TM High Definition Time Code Master Manual

OVERVIEW Revision 2.4.1

CHAPTER 1

TABLE OF CONTENTS

1. OVERVIEW............................................................................................................................... 1-1

1.1. HOW TOUSE THIS MANUAL............................................................................................ 1-2

1.2. DEFINITIONS.................................................................................................................... 1-3

Figures

Figure 1-1: HD9010TM Block Diagram.........................................................................................................1-2

HD9010TM High Definition Time Code Master Manual

Revision 2.4.1 OVERVIEW

This page left intentionally blank

HD9010TM High Definition Time Code Master Manual

OVERVIEW Revision 2.4.1 Page 1-1

1. OVERVIEW

The HD9010TM HDTV Time Code Master is a full function time code reader/generator system for high

definition serial digital video. The HD9010TM is a combination dual generator/ dual reader for SMPTE

12M Linear Time Code (LTC) and RP188 Ancillary Time Code (ATC), and contains a high resolution

character inserter which can burn the generator or reader numbers directly into the high definition serial

digital program output.

The HD9010TM requires a SMPTE 292M (1.5 Gb/s) high definition serial digital video for normal operation.

The HD9010TM time code generators can be referenced to the input video or to an analog colour black

reference to provide stable output timing during momentary disruptions of the input video. When

generating 24Fps time code it will also lock the generator count sequence to a 6 Hz pulse

The HD9010TM generators can be slaved to incoming LTC or ATC or can be set to free run. The

generators may also be momentarily synchronized to one of the readers, and then it continues to increment

normally regardless of the reader code. The second LTC output normally follows the primary output,

however the two generators can be operated at different frame rates to supply both 24Fps and 30Fps time

code when shooting in a 1080p/24 environment.

The high-resolution character inserter provides independently positional windows to show time and user

bits for the generator and readers simultaneously. The choice of white or black characters with or without

contrasting background mask is available.

Features:

•Video formats supported: 1080i/60, 1080i/50, 1080p/30sF, 1080p/25sF, 1080p/24sF, 720p/60,

720p/50 and the 1/1.001 divisor versions where applicable

•Reads RP188 LTC and VITC ancillary time code (ATC) from incoming video - read line auto detected

•Generates RP188 LTC and VITC ancillary time code on output video

•Two LTC readers and two LTC generators operate at 24, 25 or 30 Fps nominal rate in accordance with

SMPTE 12M specification

•Generates 24 Fps and 30 Fps simultaneously

•RP-188 ATC LTC translator

•Genlocks to NTSC/PAL colour black or HD Tri-level sync

•Locks to 6 Hz pulse when generating 24 Fps nominal rate code

•Drop frame Non drop frame converter

•Character windows for the reader and generator time and user bit data. Windows can be positioned

and turned off and on independently, Independent control of one of two character sizes

•White or black characters on contrasting background

•Front panel display and control using menu system

•Optional dual power supply configuration

•Parallel GPI/O control of common functions

•GPI Remote Control mode allows user to pass remote control contact closure information in RP188

user bits

•Field upgradeable firmware as new features become available

•Optional input relay bypass for power failure bypass protection

HD9010TM High Definition Time Code Master Manual

Page 1-2 Revision 2.4.1 OVERVIEW

Sync

Extraction

S / P RP-188

ANC

Reader

Tri Level

or Bi Level

Reference

Input Loop

LTC Input 1 LTC Output 1

Equalizer Serial Outputs

1.5 Gb/s

(SMPTE 292M)

+ RP188 Time Code

and

Characters

Serial Input

1.5Gb/s

(SMPTE 292M)

Cable

Driver

P / S

RP-188

ANC

Inserter

Character

Keyer

Central

Processing

Unit

Serial Control

RS 232 / RS 422

Parallel I/O

LTC Output 2LTC Input 2

Aux Serial Port

RS 232 / RS 422

Optional

Bypass Optional

Bypass

Front Panel Control

Figure 1-1: HD9010TM Block Diagram

1.1. HOW TO USE THIS MANUAL

This manual is organised into 5 chapters: Overview, Installation, Calibration, System Parameters, and

Technical Description. The overview section contains a brief overview of the HD9010TM operation and

features, and a glossary to define concepts and terms used throughout the remainder of the manual. We

highly recommend taking the time to become familiar with the terms and concepts described here before

proceeding into the rest of the manual.

Chapter 2 gives a detailed description of the rear panel connectors, and how the HD9010TM should be

connected into your system.

Chapter 3 shows how to calibrate the system timing and verify that the HD9010TM is accurately

numbering the film and video frames.

Chapter 4 gives a discussion of how the default operation of the HD9010TM can be changed using System

Parameters. The system parameters can affect the system timing through the Afterburner, placement of

characters on the raster, 2:3 cadence control, functions of parallel inputs and outputs to name a few.

Chapter 5 gives technical information such as the specifications and how to update the firmware in the

HD9010TM.



This symbol is intended to alert the user to important operating instructions.

HD9010TM High Definition Time Code Master Manual

OVERVIEW Revision 2.4.1 Page 1-3

The exclamation point within an equi-lateral triangle is intended to alert the user

to the presence of important safety related operating and maintenance

(Servicing) instructions in this manual.

1.2. DEFINITIONS

24p: A progressively scanned high definition video format with 1920 pixels and 1080 lines. (See also

description sF.)

4:2:2 The sampling ratio used in the HDTV digital video signal. For every 4 samples of luminance

there are 2 samples each of R-Y (Red minus Luminance) and B-Y (Blue minus luminance).

4:4:4 A sampling ratio that has equal amounts of the luminance and both chrominance channels.

16x9 A wide screen television format such as HDTV in which the aspect ratio of the screen is 16

units wide by 9 high as opposed to the 4x3 of normal TV.

AES/EBU:(Sometimes abbreviated as AES) Refers to the digital audio standard (AES3-1992) set by the

Audio Engineering Society and European Broadcast Union and used by most forms of digital

audio from CDs to professional digital video.

Aspect Ratio: The ratio of width to height in a picture. Theatre screens generally have an aspect ratio of

1.85 to 1, widescreen TV (16x9) is 1.77 to 1, and normal TV (4x3) is 1.33 to 1.

CCIR (International Radio Consultative Committee) An international standards committee. (This

organisation is now known as ITU.)

CCIR-601:See ITU-R601.

Cliff effect: (also referred to as the ‘digital cliff’) This is a phenomenon found in digital video systems

that describes the sudden deterioration of picture quality when due to excessive bit errors, often

caused by excessive cable lengths. The digital signal will be perfect even though one of its

signal parameters is approaching or passing the specified limits. At a given moment however,

the parameter will reach a point where the data can no longer be interpreted correctly, and the

picture will be totally unrecognisable.

Component analog: The non-encoded output of a camera, video tape recorder, etc., consisting of the

three primary colour signals: red, green, and blue (RGB) that together convey all necessary

picture information. In some component video formats these three components have been

translated into a luminance signal and two colour difference signals, for example Y, B-Y, R-Y.

Component digital: A digital representation of a component analog signal set, most often Y, B-Y, R-Y.

The encoding parameters are specified by ITU-R709 for HDTV signals. SMPTE 274M and

SMPTE 296M specify the parallel interface.

Composite analog: An encoded video signal such as NTSC or PAL video that includes horizontal and

vertical synchronizing information.

HD9010TM High Definition Time Code Master Manual

Page 1-4 Revision 2.4.1 OVERVIEW

Composite digital: A digitally encoded video signal, such as NTSC or PAL video that includes

horizontal and vertical synchronizing information.

D1: A component digital video recording format that uses data conforming to the ITU-R601

standard. Records on 19 mm magnetic tape. (Often used incorrectly to refer to component

digital video.)

D2: A composite digital video recording format that uses data conforming to SMPTE 244M.

Records on 19 mm magnetic tape. (Often used incorrectly to refer to composite digital video.)

D3: A composite digital video recording format that uses data conforming to SMPTE 244M.

Records on 1/2" magnetic tape.

D5: A component digital video recording format that uses data conforming to the ITU-R601

standard. Records on 1/2" magnetic tape.

HD-D5: A component digital video recording format that uses data conforming to the ITU-R709

standard. Records on 1/2" magnetic tape.

Drop frame: In NTSC systems, where the frame rate is 29.97002618 frames per second, the drop frame

mode permits time of day indexing of the frame numbers by dropping certain frame numbers.

Specifically, frames 0, and 1 at the beginning of each minute except minutes 0,10,20,30,40, &

50, are omitted, to compensate for an approximate timing error of 108 frames (3 seconds 18

frames) per hour. A flag bit is set in the time code to signal when the drop frame mode is in

effect.

EBU (European Broadcasting Union): An organisation of European broadcasters that among other

activities provides technical recommendations for the 625/50 line television systems.

Embedded audio: Digital audio is multiplexed onto a serial digital video data stream.

Gen lock: In order to derive the 6 Hz relationship between 23.98 Fps and 29.97 Fps frame boundaries,

and to ensure that the timecode to 6 Hz relationship is fixed, an NTSC colour black video

reference must be supplied to the HDHD9010TM Film Footage Encoder. Normally, the gen

lock signal is the colour black system reference to which the 24p tri-level sync generator is gen

locked. The gen lock reference is only necessary when the system video type is

1080p/23.98sF.

ITU: The United Nations regulatory body governing all forms of communications. ITU-R (previously

CCIR) regulates the radio frequency spectrum, while ITU-T (previously CCITT) deals with the

telecommunications standards.

ITU-R601: An international standard for standard definition component digital television from which was

derived SMPTE 125M and EBU 3246-E standards. ITU-R601 defines the sampling systems,

matrix values and filter characteristics for both Y, B-Y, R-Y and RGB component digital

television signals.

ITU-R709: An international standard for High definition component digital television from which was

derived SMPTE 274M and SMPTE 296M standards. ITU-R709 defines the sampling systems,

HD9010TM High Definition Time Code Master Manual

OVERVIEW Revision 2.4.1 Page 1-5

matrix values and filter characteristics for both Y, B-Y, R-Y and RGB component digital

television signals.

Jam sync: Refers to the operation of slaving the generator to data coming from the reader. Jam sync

should be used when dubbing time code from one tape to another, as the quality of the time

code signal deteriorates with each generation, and will become unusable after the third

generation.

In the jam sync mode, the generator and reader times are compared with each other during

each frame, automatically compensating for the decoding offsets. If for any reason they are not

equal, the jam is bypassed, and the generator substitutes the next frame number. If the

number of consecutive jam bypass errors exceeds 5, the last valid reader time is jammed into

the generator again. In the absence of valid reader data within the last 5 frames, the generator

continues to increment normally until valid reader code resumes. At this time it will be re-

jammed to the reader, thus repairing large dropouts on the reader tape.

Letterbox: Placing a wide screen image on a conventional TV by placing black bands at the top and

bottom of the screen.

Linear time code: (Also known as Longitudinal Time Code) A digital code used for timing and control

purposes on videotape and associated audio tape machines. It is recorded on a linear track with

audio characteristics and is referred to as LTC. Each 80 bit code word is associated with one

television frame, and consists of 26 time bits, 6 flag bits, 32 user bits and 16 sync bits. This

time code may run at 24, 25 or 30 frames per second depending on the video format. See also

SMPTE 12M

LTC: See Linear Time Code

NTSC: National Television Standards Committee established the television and video standard in use

in the United States, Canada, Japan and several other countries. NTSC video consists of 525

horizontal lines at a field rate of approximately 60 fields per second. (Two fields equals one

complete Frame). Only 487 of these lines are used for picture. The rest are used for sync or

extra information such as VITC and Closed Captioning.

PAL: Phase Alternating Line. The television and video standard in use in most of Europe. Consists of

625 horizontal lines at a field rate of 50 fields per second. (Two fields equals one complete

Frame). Only 576 of these lines are used for picture. The rest are used for sync or extra

information such as VITC and Teletext.

Pixel: The smallest distinguishable and resolvable area in a video image. A single point on the

screen. In digital video, a single sample of the picture. Derived from the words picture

element.

Serial digital: Digital information that is transmitted in serial form. Often used informally to refer to serial

digital television signals.

SMPTE (Society of Motion Picture and Television Engineers): A professional organisation that

recommends standards for the film and television industries.

HD9010TM High Definition Time Code Master Manual

Page 1-6 Revision 2.4.1 OVERVIEW

SMPTE 12M: The SMPTE standard for Time and address code. SMPTE 12M defines the parameters

required for both linear and vertical interval time codes.

SMPTE 274M: The SMPTE standard for bit parallel digital interface for high definition component video

signals with an active picture of 1080 lines x 1920 pixels.

SMPTE 291M: The SMPTE standard for encoding ancillary data packets in serial digital video signals.

SMPTE 292M: The SMPTE standard for high definition serial digital component interfaces.

SMPTE 296M: The SMPTE standard for bit parallel digital interface for high definition component video

signals with an active picture of 720 lines x 1280 pixels.

SMPTE 299M: The SMPTE standard for embedding audio in serial digital high definition

(SMPTE 292M) video signals.

SMPTE RP188: The SMPTE recommended practice for embedding SMPTE 12M timecode into ancillary

data packets in serial digital video signals.

sF: (Also known as segmented frame) The picture is progressively scanned, however divided into

two segments, containing the odd and even lines. The segments are then sent out the serial

digital interface in the same way that the fields of an interlaced video signal are. This format is

often used at nominal frame rates of 24, 25 or 30 frames per second.

TRS: Timing reference signals used in composite digital systems. (It is four words long).

TRS-ID: Abbreviation for "Timing Reference Signal Identification". A reference signal used to maintain

timing in composite digital systems. (It is four words long.)

User bits: 32 bits in the time code are user assignable. They typically are used to contain reel numbers,

scene and take numbers, or other user-oriented data.
