1. OVERVIEW
The 7705OE-3 offers three independent channels of optical to electrical conversion, economically, in a
single module. Each independent channel accepts one optical input, complying with SMPTE 297M
carrying SMPTE 259M (143-360Mb/s), SMPTE310M (19.4Mb/s), SMPTE344M (540Mb/s), M2S or DVB-
ASI (270Mb/s) signals, and provides one reclocked BNC output. The module can also be set to operate in
SMPTE310M (19.4Mb/s) mode.
The 7705OE-3 is designed as a companion to the 7705EO-3 electrical to optical converter. The
7705OE-3 can be housed in either a 1RU frame, that will hold up to three modules, or a 3RU frame, that
will hold up to fifteen modules, providing 45 channels of optical conversion in a single 3RU frame.
Features:
•Triple SDI optical to electrical converter for 3 independent channels
•Provides 45 independent channels of optical conversion, in a single 3RU frame
•Supports all SMPTE 259M standards with operation from 143Mb/s-360Mb/s
•Supports additional standards of SMPTE 305M (SDTi), SMPTE 310M (19.4Mb/s), SMPTE 344M
(540Mb/s), M2S and DVB-ASI (270Mb/s)
•Supports multi-mode or single-mode fiber
•Fully hot-swappable from front of frame, with no fiber or BNC disconnect/reconnect required
•Occupies one card slot and can be housed in either a 1RU frame which will hold up to 3 modules,
a 3RU frame which will hold up to 15 modules, 3RU portable frame that holds up to 7 modules or a
standalone frame which will hold 1 module
•Comprehensive signal and card status monitoring via four digit card edge display
Inputs:
•Three independent fiber inputs
•1270nm to 1610nm input wavelength range
•Input sensitivity to -32dBm
•SC/PC, ST/PC, FC/PC connector options
Outputs:
•Three independent, reclocked, serial digital BNC outputs
•Wideband jitter < 0.2 UI
Status LEDs:
•Signal presence indication for each channel
•Input carrier weak indication for each channel
•Module status indication

7700 MultiFrame Manual
7705OE-3 Triple SDI Optical to Electrical Converter, 19.4Mb/s or 143-540Mb/s
7705OE-3 - 2 Revision 1.2
CONTROL/
INDICATION
RATE
259M/310M
SIGNAL
PRESENT
OPTICAL
RECEIVER
CABLE
DRIVER
RECLOCK
OPTICAL
RECEIVER
CABLE
DRIVER
RECLOCK
OPTICAL
RECEIVER
CABLE
DRIVER
RECLOCK
11
22
33
SDI Outputs
Optical Inputs
SIGNAL
WARNING
MODULE
STATUS
Figure 1-1: 7705OE-3 Block Diagram

7700 MultiFrame Manual
7705OE-3 Triple SDI Optical to Electrical Converter, 19.4Mb/s or 143-540Mb/s
Revision 1.2 7705OE-3 - 3
2. INSTALLATION
The 7705OE-3 comes with a companion rear plate that has three BNC connectors and three SC/PC
(shown), ST/PC or FC/PC optical connectors. For information on mounting the rear plate and inserting the
module into the frame see section 3 of the 7700FR chapter.
Figure 2-1: 7705OE-3 Rear Panel
SDI INPUT: There are three SC/PC (shown), ST/PC or FC/PC female optical connectors for 3
separate channels of SMPTE 297M optical 10-bit serial digital video signals
compatible with the SMPTE 259M, SMPTE 305M SMPTE 344M, DVB-ASI or
SMPTE 310M (19.4 Mb/s) standards.
SDI OUTPUT: There are three BNC connectors each with a reclocked serial component video output
converted from the corresponding channel. The output signals are compatible with the
SMPTE 259M, SMPTE 305M SMPTE 344M, DVB-ASI or SMPTE 310M (19.4 Mb/s)
standards. See section 5.2 for information about operating the module with SMPTE
310M signals.

7700 MultiFrame Manual
7705OE-3 Triple SDI Optical to Electrical Converter, 19.4Mb/s or 143-540Mb/s
7705OE-3 - 4 Revision 1.2
2.1. CARE AND HANDLING OF OPTICAL FIBER
2.1.1. Safety
!
Never look directly into an optical fiber. Non-reversible damage to the eye can occur
in a matter of milliseconds.
The laser modules used in the Evertz fiber optic modules are Class I, with a maximum output power of
7mW, and a wavelength of 1270 to 1610nm.
2.1.2. Handling and Connecting Fibers
"Never touch the end face of an optical fiber.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that you maintain a minimum bending radius of 3 cm to avoid fiber-bending loss that will
decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with
cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the
frame that does not have a suitable I/O module. For further information about care and handling of fiber
optic cable see section 3 of the Fiber Optics System Design chapter of this manual.

7700 MultiFrame Manual
7705OE-3 Triple SDI Optical to Electrical Converter, 19.4Mb/s or 143-540Mb/s
Revision 1.2 7705OE-3 - 5
3. SPECIFICATIONS
Standards: SMPTE 259M A, B, C, D, SMPTE 297M, SMPTE 305M, SMPTE 310M,
SMPTE344M, M2S, DVB-ASI
3.1. OPTICAL INPUTS
Number of Inputs: 3 (independent channels)
Connector: SC/PC, ST/PC, FC/PC female housing
Operating Wavelength: 1270nm to 1610nm
Max. Input Power: 0dBm
Optical Sensitivity: -32dBm
3.2. SERIAL VIDEO OUTPUTS
Number of Outputs: 3 reclocked (independent channels)
Connector: 3 (1 per input channel) reclocked
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise/Fall Time: 900ps nominal
Overshoot: < 10% of amplitude
Return Loss: > 15dB up to 540Mb/s
Jitter: < 0.2 UI
3.3. ELECTRICAL
Voltage: +12VDC
Power: 6 Watts
EMI/RFI: Complies with FCC Part 15, Class A
EU EMC Directive
3.4. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1

7700 MultiFrame Manual
7705OE-3 Triple SDI Optical to Electrical Converter, 19.4Mb/s or 143-540Mb/s
7705OE-3 - 6 Revision 1.2
4. STATUS INDICATORS AND DISPLAYS
FRAME STATUS
ON/OFF
/ MODULE OK
LOCAL FAULT
PRESENT
CH1
PRESENT
CH2
PRESENT
CH3
RATE
259M/310M
CH1
CH2
CH3
Figure 4-1: Location of Status Indicators and Jumpers
4.1. STATUS INDICATOR LEDS
Two large LEDs on the front of the board indicate the general health of the module:
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of a
valid input signal on all 3 inputs, if any input detects a weak optical carrier, or if a local
input power fault exists (i.e.: a blown fuse). The LOCAL FAULT indication can also be
reported to the frame through the FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid input signal is
present on at least one of the input channels and board power is good.
There are three small LEDs that indicate the status for each channel.
PRESENT: This Green LED indicates the presence of a valid input video signal.

7700 MultiFrame Manual
7705OE-3 Triple SDI Optical to Electrical Converter, 19.4Mb/s or 143-540Mb/s
Revision 1.2 7705OE-3 - 7
5. JUMPERS AND LOCAL CONTROLS
5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper determines whether local faults (as shown by the Local Fault indicator) will
be connected to the 7700FR frame's global status bus.
FRAME STATUS: To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this
jumper in the On position. (default)
When this jumper is installed in the Off position local faults on this module will not be
monitored.
5.2. SELECTING THE RECLOCKING RATE
The RATE SELECT jumpers J18, J21, and J22, determine whether the channel 1, 2 or 3 respectively will
operate as a distribution amplifier with SMPTE 259M (143 to 540 Mb/s), SMPTE 305M, SMPTE 344M or
DVB-ASI video signals or with SMPTE 310M (19.4 Mb/s) signals.
RATE SELECT: To set the module to operate with SMPTE 259M, SMPTE 305M, SMPTE 344M or
DVB-ASI signals install the jumper in the 259M position.
To set module to operate with SMPTE 310M signals install the jumper in the 310M position.
