Everwin CB3-5 User manual

BEFORE OPERATING THIS DEVICE, ALL OPERATORS SHOULD READ AND
STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY
WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE
DEVICE FOR FUTURE REFERENCE.
Counter Balancer Hang er
OPERATIONS and MAINTAINANCE MANUAL
CB3-5 / CB5-7
CB5-9 / CB9-15
Everwin Pneumatic Corp. 19”/3/19

INDEX
CE Declaration of Conformity ----------------------------------------------------------------------- q2
aaaaa Safety Instructions -------------------------------------------------------------------------------------- 3~5
Specifications and Technical Data ----------------------------------------------------------------- 6~7
Installation ------------------------------------------------------------------------------------------------- 8
Check Before Use --------------------------------------------------------------------------------------- 8
CE DECLARATION OF CONFORMITY
2

Do not fasten
the hanger.
Always attach a secondary
support cable or chain.
Bottom Hook
Turn about 1.0 cm
counterclockwise (↶) to decrease
the spring tension. (keep the hex
and turn slowly, don’t adjust
under its capacity)
When the spring
breaks, the safe
pin pops out from
the spring case and
collides with one
of the pins to drop
the drum from
rotating.
(CB5-9 & CB9-15)
Turn clockwise (↷)
for increasing the
spring tension by
allen key.
Models
CB3-5 CB5-7
CB5-9 CB9-15
SAFETY INSTRUCTIONS
3

To avoid severe personal injury or
property damage, READ and STUDY
this manual before use of tool. Never stand under the
counter balancer hanger.
Do not disassemble or
modify the product.
Avoid contact with fluids at all
times.
Do not twist and rub the cordage with
cable during travel. Do not load over the
stated capacity.
SAFETY INSTRUCTIONS
4

Detach tool while removing the
counter balancer hanger to
prevent the device from
dropping.
Make sure to detach counter
balancer hanger and tool when
not in use.
Make sure to remove the
counter balancer hanger and
tool before setting up tension.
Application area: Indoors and
outdoors with normal atmospheric
conditions.
Temperature range: -10℃~+40℃
Leave some slack in the
secondary support cable or
chain to allow the hanger to
rotate freely. The slack must be
a suitable length so that the
hanger will stop within 10 cm
when falling by accident.
Secondary
support cable or
chain
SAFETY INSTRUCTIONS
5

Cover 6m/m Allen
key
Rubber
stop
Casing
Hanger
Bottom hook
Ratchet
Ratchet
screw
Use the allen key
to adjust the
spindle
Model Weight
Capacity Hanger Weight Cable Length Cable Dia.
CB3-5 3~5 kg
6.6~11 lbs. 1.82 kg 4 lbs. 130 cm 52 in 3.2 mm 0.13 in
CB5-7 5~7 kg
11~15.5lbs. 1.85 kg 4.1 lbs. 130 cm 52 in 3.2 mm 0.13 in
SPECIFICATIONS AND TECHNICAL DATA
6

Model Weight
Capacity Hanger Weight Cable Length Cable Dia.
CB5-9 5~9 kg
11~19.8 lbs.
3.59 kg
7.9 lbs. 130 cm 52 in 4.0 mm 0.16 in
CB9-15 9~15 kg
19.8~33 lbs.
3.61 kg
8 lbs. 130 cm 52 in 4.0 mm 0.16 in
Hook
Casing
Rubber
stop
Cover
6m/m Allen
key
Safe pin
Bottom hook
Ratchet
Ratchet
screw
Use the allen key
to adjust the
spindle
SPECIFICATIONS AND TECHNICAL DATA
7

INSTALLATION:
1. Attach the counter balancer hanger to a steady location.
2. Attach a secondary support cable and install it to a steady location.
3. Install tool within the weight capacity to the bottom hook.
4. Adjust tension to appropriate level after tool installation.
CHECK BEFORE USE:
1. The hanger and bottom hook are steady and rotate smoothly.
2. The cable is undamaged.
3. The ratchet, ratchet spring, and spindle are steady.
4. The counter balancer hanger is undamaged and apparently sound.
8
