eVision 6500 series Quick setup guide

Rev A April 2016
117-856A
E-Vision Laser 6500 Series
Super High Brightness Digital Video Projector
3 Important Information

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 2
Important Information
Digital Projection
Digital Projection Asia
16 New Industrial Road
#02-10 Hudson Technocentre
Singapore 536204
Tel [phone]
Fax [phone]
www.digitalprojectionasia.com
Digital Projection Inc.
55 Chastain Road, Suite 115
Kennesaw, GA 30144, USA
Tel [phone]
Fax [phone]
[email protected]
www.digitalprojection.com
Digital Projection China
中国 北京市 朝阳区 芍药居北里101号
世奥国际中心A座2006室(100029)
Rm A2006
ShaoYaoJu 101 North Lane
Shi Ao International Center
Chaoyang District
Beijing 100029, PR CHINA
Tel [phone]
Fax [phone]
[email protected]
www.dp-china.com.cn
Digital Projection Limited
Greenside Way, Middleton
Manchester M24 1XX, UK
Registered in England No. 2207264
Registered Ofce: as above
Tel [phone]
Fax [phone]
[email protected]
[email protected]
www.digitalprojection.co.uk

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 3
Important Information
Super High Brightness Digital Video Projector
Important Information
Full information about operating, connecting and setting up the projector can be found in the User
Manual, located on the CD.
Contents
Symbols used in the User Manual...............................................................................................4
Electrical and physical specications........................................................................................5
Laser precautions.............................................................................................................................5
Product labels....................................................................................................................................6
Location of laser aperture..............................................................................................................7
Interlock switches ............................................................................................................................7
General precautions ........................................................................................................................8
Installation precautions ..................................................................................................................9
Operation and conguration precautions ...............................................................................11
Compliance with international standards ...............................................................................12
RF Interference.............................................................................................................................12
Noise .............................................................................................................................................12
European Waste Electrical and Electronic Equipment (WEEE) Directive ..............................12
Basic Operation Instructions ......................................................................................................13
Positioning the screen and projector.........................................................................................13
Connecting the power supply.....................................................................................................14
Switching the projector on..........................................................................................................14
Switching the projector off..........................................................................................................14
Selecting an input signal.............................................................................................................15
Selecting a test pattern................................................................................................................15
Adjusting the image.....................................................................................................................15
Adjusting the lens ........................................................................................................................16
Inserting a new lens.....................................................................................................................17
Removing the lens .......................................................................................................................18
Control Panel Reference...............................................................................................................19
Projector indicators .....................................................................................................................20
Remote Control Reference ..........................................................................................................21

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 4
Important Information
Symbols used in the User Manual
LASER WARNING: this symbol indicates that there is a potential hazard of eye
exposure to laser radiation unless the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical
shock unless the instructions are closely followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself
and/or damage to the equipment unless the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Specications are subject to change without notice.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 5
Important Information
Electrical and physical specications
Main Voltage 100-240 VAC 50/60Hz single phase
Operating Temperature 0°C to 40°C (32 to 104F)
Storage Temperature -20°C to 60°C (-4 to 140F)
Operating Humidity 10% to 85% non-condensing
Weight 25 kg (55.1 lb) without lens
Power Consumption 650 W
Thermal Dissipation 2219 BTU/hr
Laser precautions
CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reected toward other people or
reective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specied herein may result in hazardous radiation exposure.
Laser Parameters:
Wavelength 450nm - 460nm (Blue)
Mode of operation Pulsed, due to frame rate
Pulse width 1.34ms
Pulse repetition rate 120Hz
Maximum laser energy 0.698mJ
Total internal power >100W
Apparent source size >10mm, at lens stop
Divergence >100 mili Radian

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 6
Important Information
Product labels
1 2
3
Hazard Warning Symbol
and Aperture Label
1
Explanatory Label
2
CAUTION
Possibly hazardous optical radiation emitted
from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
ATTENTION
Ce produit peut émettre des rayonnements
optiques dangereux.
Ne pas fixer la lampe en fonctionnement.
Peut être nocif pour les yeux.
RISK GROUP 2
Explanatory Label
3

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 7
Important Information
Location of laser aperture
The laser aperture is located as indicated below. Be careful not to expose the eye to direct
laser light.
1Laser aperture
Interlock switches
Three interlock switches installed at the main frame, inside the cover, will power-off the system
individually when activated.
1 Will be activated when the projection lens is removed or misplaced.
2 Will be activated when the top cover is removed.
1
1 2

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 8
Important Information
General precautions
The unit is never to be operated if the unit is defective or the cover or seal is damaged.
No maintenance allowed by end user.
Do not open the cabinet. There are no user serviceable parts inside.
No service is allowed except by authorized personnel.
Use only the power cable provided.
Ensure that the power outlet includes a Ground connection, as this equipment MUST be
earthed.
Take care to prevent small objects such as paper or wire from falling into the projector.
If this does happen, switch off immediately, and have the objects removed by
authorised service personnel.
Do not expose the projector to rain or moisture, and do not place any liquids on top of
the projector.
Unplug before cleaning, and use a damp, not wet, cloth.
Do not touch the power plug with wet hands.
Do not touch the power plug during a thunder storm.
Handle the power cable carefully and avoid sharp bends. Do not use a damaged power
cable.
Do not touch the ventilation outlets, as they will become hot in use.
Do not cover or obstruct the ventilation outlets or inlets.
Do not cover the lens whilst the projector is switched on. This could cause a re
Always allow the projector to cool for 5 minutes before disconnecting the power or
moving the projector.
Never use strong detergents or solvents such as alcohol or thinners to clean the
projector and lens.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 9
Important Information
Installation precautions
Connect the LAN cable only to a computer LAN connection. Other similar connectors
may have a dangerously high voltage source.
The projector must be installed only by suitably qualied personnel, in accordance with
local building codes.
The projector should be installed as close to the power outlet as possible.
The power connection should be easily accessible, so that it can be disconnected in an
emergency.
There is no limit on tilt angle.
Allow at least 50cm (19.7in) of space between the ventilation outlets and any wall, and
30cm (11.8in) on all other sides.
For portrait installation, a customized stand is required to be attached to the projector.
See Reference drawings for customized stand - portrait mode in the user manual.
Do not install the projector close to anything that might be affected by its operational
heat, for instance, polystyrene ceiling tiles, curtains etc.
Minimum 500 mm
(19.69 inch)
Minimum 500 mm
(19.69 inch)
Minimum 500 mm
(19.69 inch)
Minimum 100 mm
(3.94 inch)
Minimum 500 mm
(19.69 inch) Minimum 300 mm
(11.81 inch)

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 10
Important Information
Place the projector in a dry area away from sources of dust, moisture, steam, smoke,
sunlight or heat.
The projector is heavy. Use safe handling techniques when lifting the projector.
Do not drop or knock the projector.
Before installation, make sure that the surface, ceiling or rigging that is to support the
projector is capable of supporting the combined weight of the projector and lens.
When stacking projectors, the stack MUST be vertical, to ensure that the stresses are
distributed to all four chassis corners.
Do not stack more than 3 projectors.
Do not place heavy objects on top of the projector chassis. Only the chassis corners
and the optional rigging frame are capable of withstanding the weight of another
projector.
Backup safety chains or wires should always be used with ceiling mount installations.
Ensure that the intake vents do not recycle hot air from the exhaust vent.
When operating the projector in an enclosed space, ensure that the surrounding air
temperature within the enclosure does not exceed operation temperature while the
projector is running, and the air intake and exhaust vents are unobstructed.
All enclosures should pass a certied thermal evaluation to ensure that the projector
does not recycle exhaust air, as this may cause the device to shutdown even if the
enclosure temperature is with the acceptable operation temperature range.
Turn on Altitude Mode when located in high altitude areas.
The projector can only be installed upright or inverted.
When installing the bracket, make sure the weight limit is not exceed and the projector
is rmly secured.
Avoid installing near an air conditioner duct or a subwoofer.
Avoid installing at high temperature, insufcient cooling and heavy dust locations.
Keep your product away from uorescent lamps (>1 Meter) to avoid malfunction caused
by IR interference.
The VGA IN connector should be connected to the VGA IN port. Note that it should
be inserted tightly, with the screws on both sides securely fastened to ensure proper
connection of the signal wire for achieving optimal display effect.
The AUDIO IN connector should be connected to the AUDIO IN port and CANNOT be
connected to AUDIO OUT or other ports like BNC, RCA; otherwise, it will lead to mute
output and even DAMAGE the port.
Install the projector above 200cm to avoid damage.
The power cord and signal cable should be connected before the projector is powered
on. During startup and operation, DO NOT insert or remove the signal cable or the
power cord to avoid damaging the projector.
The projector generates a massive amount of heat during use. The internal fan
dissipates the heat of the projector when shutting down, which could continue for a
certain period. After the project enters STANDBY MODE, press the AC power button
to turn off the projector and remove the power cord. DO NOT remove the power cord
during shutdown as it may cause damage to the projector and may affect the service
life of the projector.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 11
Important Information
Operation and conguration precautions
Do not make changes to the networking conguration unless you understand what you
are doing, or have taken advice from your Network Manager. If you make a mistake,
it is possible that you will lose contact with the projector. Always double-check your
settings before pressing the APPLY button. Always keep a written note of the original
settings, and any changes you have made.
Software update should NOT be carried out except by, or with the supervision of, Digital
Projection Service personnel.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 12
Important Information
Compliance with international standards
RF Interference
FCC
The Federal Communications Commission does not allow any modications or changes to the unit
EXCEPT those specied by Digital Projection in this manual. Failure to comply with this government
regulation could void your right to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference, in which case the
user will be responsible for correcting any interference.
Noise
GSGV Acoustic Noise Information Ordinance
The sound pressure level is less than 41 dB (A) according to ISO 3744 or ISO 7779.
European Waste Electrical and Electronic Equipment (WEEE) Directive
Digital Projection Ltd is fully committed to minimising Waste Electrical and Electronic
Equipment. Our products are designed with reuse, recycling and recovery of all components
in mind. To this end, at end of life, your projector may be returned to Digital Projection Ltd or
its agent so that the environmental impact can be minimised.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 13
Important Information
Basic Operation Instructions
Positioning the screen and projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll
the screen. Set the adjustable feet so that the projector is level, and perpendicular to the screen.
The drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling
mounting.
1Two adjustable feet (front)
2Six M4 holes for ceiling mount
The screws should not penetrate more than 15 mm into the body of the projector.
3 Two xed length feet (rear)
1
2
3
1
3
2
2
2
2
2

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 14
Important Information
Connecting the power supply
Firmly push the mains connector
into the socket as shown in the
illustration.
Use only the power
cable provided.
Ensure that the power
outlet includes a ground
connection as this equipment MUST be earthed.
Handle the power cable carefully and avoid sharp bends. Do not use a damaged power
cable.
Switching the projector on
1. Connect the power cable between the mains supply and the projector. (See Connecting the
power supply above.) Switch on at the switch next to the power connector.
2. The POWER indicator lights red to signal that the projector is in STANDBY mode. Press one of
the following buttons:
• On the remote control, the ON button
• On the projector control panel, the POWER button .
The POWER indicator begins ashing green. In approximately 30 seconds, the startup screen
appears and the projector is fully switched on.
The rst time you use the projector, you can set OSD language from the quick menu. (See
Setting the OSD language in the user manual.)
Switching the projector off
1. Press OFF on the remote control or POWER on the control panel, then press again to conrm
your choice.
2. If you need to switch the projector off completely, switch off at the mains power switch next to the
power connector and then disconnect the power cable from the projector.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 15
Important Information
Selecting an input signal
If more than one input source is connected, select the input you want to display. Press the Source
button on the control panel and use the UP ▲ and DOWN ▼ arrow buttons to scroll through the list of
inputs:
• HDMI 1
• HDMI 2/ MHL
• DVI
• VGA 1: analog RGB
DVD input YCbCr / YPbPr, or HDTV input YPbPr via D-sub connector
• BNC: analog RGB
• Composite Video
• HDBaseT
Selecting a test pattern
1. Press the MENU button to open the OSD.
2. Press the LEFT ◄ and RIGHT ► arrow buttons to navigate to the Settings 1 menu.
3. Press the UP ▲ and DOWN ▼ arrow buttons to move to the Advanced 2 submenu and then
press (ENTER) to open the submenu. Once inside, press UP ▲ and DOWN ▼ to highlight
Test Pattern.
4. Use the LEFT ◄ and RIGHT ► arrow buttons to cycle through the available test patterns.
Adjusting the image
Orientation
• This can be set from the Setttings 1 menu.
Highlight Projection and choose from Normal, Rear, Ceiling and Rear+Ceiling.
Keystone
To adjust keystone, press the Keystone button on the remote control to open the Keystone menu,
and then use the arrow buttons for vertical or horizontal keystone corrections.
• Settings such as Gamma, Brightness,Contrast and Sharpness can be set from the Image
menu.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 16
Important Information
Adjusting the lens
Lens shift
The lens shift function can be used to adjust the position of the projected image either horizontally or
vertically.
Use the vertical and horizontal lens shift knobs to move the image across the width or height of the
screen.
1Vertical lens shift knob
2Horizontal lens shift knob
Focus and zoom
Use the focus 1and zoom 2rings
on the projector lens to adjust focus and
zoom.
1 2
1 2

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 17
Important Information
Inserting a new lens
Before changing the lens, always make sure the projector is switched off and fully
disconnected from its power supply.
When changing the lens, avoid using excessive force as this may damage the
equipment.
The lens is shipped separately.
Take care to preserve the original lens packaging and protective caps for future use.
The projector will not power on without the lens tted.
1. Align the ange and position it
correctly at an 11 o’clock angle
as shown in the illustration, then
rmly push the lens into the
socket
2. Turn the lens clockwise until it
clicks into place.
Flange

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 18
Important Information
Removing the lens
Before changing the lens, always make sure the projector is switched off and fully
disconnected from its power supply.
When changing the lens, avoid using excessive force as this may damage the
equipment.
The lens is shipped separately.
Take care to preserve the original lens packaging and protective caps for future use.
The projector will not power on without the lens tted.
1. Push in the lens release button,
and turn the lens anti-clockwise.
2. Slowly pull the lens out of the
socket.

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 19
Important Information
Control Panel Reference
1MENU
Opens and exits OSD menus.
2Keystone LEFT
Navigates and changes settings in the OSD.
Adjusts Horizontal Keystone.
3Keystone UP
Navigates and changes settings in the OSD.
Adjusts Vertical Keystone.
4ENTER
Enters and conrms settings in the OSD.
5POWER
Turns the projector on and off.
6SOURCE
Opens the Source menu.
7Keystone DOWN
Navigates and changes settings in the OSD.
Adjusts Vertical Keystone.
8Keystone RIGHT
Navigates and changes settings in the OSD.
Adjusts Horizontal Keystone.
9AUTO
Optimizes image size, position and resolution.
1 3 52 4
6 7 9
8

Digital Projection E-Vision Laser 6500 Series
Rev A April 2016
Page 20
Important Information
Projector indicators
1Power LED
Displays power on/off sequence status.
2Light source LED
Displays light source status.
3Temp LED
Displays thermal status.
4Filter LED
Displays lter replacing warning message.
1 2 3 4
