Evo 425T User manual

www.evofitness.net.au
0
425T TREADMILL

www.evofitness.net.au
1
IMPORTANT SAFETY INSTRUCTIONS
Important-: Please read all instructions carefully before using your treadmill. Retain this
owner’s manual for your future reference:
WARNING:
1. Position the treadmill on a clear level surface. Do not place the treadmill on thick carpet as it may
interfere with correct ventilation. Do not place the treadmill near water or outdoors.
2. Position treadmill so that the wall plug is visible and accessible.
3. Never start the treadmill while you are standing on the walking belt. After turning the power on and
adjusting the speed control, there will be a 3 second pause before the walking belt begins to move,
always stand on the foot rails on the sides of the frame until the belt is moving.
4. Wear appropriate clothing when exercising on the treadmill. Do not wear long, loose fitting clothing
that may be caught in the treadmill. Always wear running or aerobic shoes with rubber soles.
5. Always unplug the power cord before removing the treadmill motor cover.
6. Keep small children away from the treadmill during operation.
7. Always hold the handrails when initially walking or running on the treadmill until you are comfortable.
8. Always attach the safety cord to your clothing when using the treadmill. If the treadmill should
suddenly increase in speed due to an electronics failure or the speed being inadvertently increased, the
treadmill will come to a sudden stop when the safety cord is disengaged from the console.
9. When the treadmill is not being used the safety cord should be unplugged and removed.
10. Before starting any exercise program, consult with your physician or health professional. He or she
can help establish the exercise frequency, intensity (target heart zone) and time appropriate for your
particular age and condition. If you have any pain or tightness in your chest, an irregular heartbeat,
shortness of breath, feel faint or have any discomfort while you exercise, STOP! Consult your physician
before continuing.

www.evofitness.net.au
2
TOOLS:
5# ALLEN WRENCH 5mm 1pcs
6# ALLEN WRENCH 6 mm 1pcs
WRENCH W/SCREW DRIVERS= 13, 14, 15 1pcs
Note: Do not plug into the mains power before completing the assembly
ASSEMBLY STEP 1:
ASSEMBLY STEP 2:
ASSEMBLY STEP 3:
To attach the right posts (3) to the frame
(1) use bolt (75) and lock washer (88)
using the 6# Allen wrench
Notice: When you insert the post
sections ensure that the wires do not
get caught and become damaged.
Connect the stranded wire (102) from the
post with wire from the main frame. Slide
left post (4) onto MAIN FRAME (1)
To attach the upright posts (4) to the
frame use bolt (75) and lock washer (88)
using the 6# Allen wrench
Open the carton and remove all foam and
cardboard packaging. Place the treadmill on
the ground as per diagram.

www.evofitness.net.au
3
ASSEMBLY STEP 4:
ASSEMBLY STEP 5:
1. Connect the strand wire (101) from
the computer (97) with wire (102) from
right post. And slide the computer (97)
into post (3 and 4). Do as the label (9)
shows
2. To attach the computer (97) onto the
post (3 and 4) use bolt (73) and (116)
using the 5# Allen wrench.
Attach the R&L deck covers (47, 48)
onto the main frame; use the bolt (87)
using the Allen wrench.

www.evofitness.net.au
4
ASSEMBLY STEP 6:
ASSEMBLY STEP 7:
1. Slide the left handlebar covers R
(19) onto the computer (97)
handlebar, and then slide the left
handlebar covers L (18) in. Put the
left handlebar covers L and left
handlebar covers R together
2. Repeat the same steps above
with the right handlebar covers
1. Slide the cover L (20) into the
gap of left handlebar R (19) until
the key of L (20) slides into the
groove A.
2. Repeat the same steps above
as the right handlebar L (22)

www.evofitness.net.au
5
ASSEMBLY STEP 8:
ASSEMBLY STEP 9:
1. Bolt the left and right handlebar
onto the computer with the bolt
(87).
1. Slide the support (14) into the
holes on console (97)

www.evofitness.net.au
6
FOLDING INSTRUCTION
Pulling up:
Pulling up:
Mainframe as the picture show.

www.evofitness.net.au
7
Pulling down:
Pull the main frame up as the arrow
shows until the lock (54) locates
into the holes.
Note: Do as the small pictures
show.
1. Pull the locking system out, and
hold (A) and push a little bit as the
arrow shows.

www.evofitness.net.au
8
Pulling down:
TECHNICAL PARAMETER
ASSEMBLED SIZE
(mm) 1870*800*1400 INCLINE LEVELS 15%
FOLDABLE SIZE (mm) 900*800*1670 SPEED RANGE 1-18KM/h
RUNNING BOARD
SIZE (mm)
1380*450 Max user weight 140KG
NET WEIGHT 90KG
MAX WEIGHT 0%-15%
1. The main frame will fall down as
the picture shows.

www.evofitness.net.au
9
3 LED DISPLAY SPEED TIME DISTANCE CALORIES PULSE INCLINE
OPERATION GUIDE

www.evofitness.net.au
10
WINDOW DISPLAY:
1. “INCL/PULSE” window: This will display the user’s incline level and user’s pulse; the incline range is
from 0 to 15%. The default setting will start at 0%. When the user places both hands over the palm
pulse, it can track and display the user’s pulse after 5 seconds, the LED screen will indicate the pulse
function. The pulse range will be from 50-200 b/pm.
2. “TIME/ DIST/CAL”: ”TIME’’ window will alternate every five seconds; this is indicated via the LED. The
time is measured in minutes and seconds. During a Pre Set program the window will show a count
down phase, in the default manual setting the time will count on. “DIST’” window is measured in
kilometers. The default setting will start at 1km/h. ‘’CAL’’, in the default manual setting and also during
the Pre Set programs you will have a calorie count available. This will automatically count upward for
the duration of use.
3. “SPEED” window: Displays speed, shows range: 1-18 KM/h.
BUTTON FUNCTION:
1. “PROGRAM” Button: When the treadmill is not running, press SELECT button and set up the exercise
time and program from “0:00”, “ P1->P16, U1->U2”. Manual mode is the default program, the default
speed in kilometres is 1KM/H. (0:00 is manual mode, pre-set program: P1-P16, U1-U2 is the user’s
programs).
2. “MODE” Button: Press this button to choose modes: “0:00” “15:00” “1.0” “50” (“0:00” is manual model,
“15:00” is the time count down, “1.0” is distance count down and “50” is calorie count down); when you
choose every mode, you can press the speed button and incline button to set count, after that, press
the START button to start the treadmill.
3. “START” button: Be sure you have the safety key attached to magnetic connection before
commencing a manual/pre set program.

www.evofitness.net.au
11
4. “STOP” button: This can be pressed during any program or alternatively pull safety key from unit.
5. “SPEED+” “SPEED-” Button: This will adjust your speed during any program setting in 0.1km/h
intervals.
6. “INC+” “INC-” Button: This will adjust your incline during any program setting in 1-section intervals.
7. “SPEED” 3, 6, 9” speed shift button: Set speed quickly
8. “INCLINE” 3, 6, 9” incline shift button: Set incline quickly
START-UP QUICKLY (MANUAL)
1. Switch the unit on, and attach the safety cord on magnetic connection.
2. Press START button, the system will enter into 3 seconds count down, the unit will beep and the
speed window will display count down, the speed will run 0.8 km/hour after 3 seconds.
3、After start-up, the speed function can be adjusted manually via the arrows.
MANUAL MODE:
1. If you do not make any setting and press START button directly, the treadmill will start to run from the
speed 0.8 km/h, the other windows will start to count from positive direction from default, press
“INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” to change the speed.
2. Set Time, press “MODE” button to enter into time count down, the TIME window will display“15：00”
and illuminate. Press “INCLINE+”,”INCLINE-”, “SPEED+”, and “SPEED-” to set up the time what you
need. The setting range is 5:00-99:00.
3. In Time setting model, press “ MODE “ button to enter into distance count down, the DISTANCE
window will display “1.0” and illuminates. Press “INCLINE+”,”INCLINE-”, “SPEED+”, and “SPEED-” to
set up the distance what you need. The setting range is 0.5—99.9.
4. To set up the Calories, press “MODE” button to enter into calories count down, the CAL window will
display “50” and illuminate. Press “INCLINE+”,”INCLINE-”, “SPEED+”, and “SPEED-” to set the
calories to what you need. The setting range is 10-999.
5. When setting is finished, press “START” button to start, the treadmill will run after 3 seconds, press
“INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” to adjust the speed and the incline; press the PAUSE
button, the treadmill will stop.
PRE SET PROGRAMS
Press “PROGRAM” button, “SPEED” window will display P1-P16 to choose the program you like. Setting
of running time, then the SPEED window display illuminating. Display the advance setting time 10:00,
press “INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” to set up the exercise time what you need. Press
“START” button to start the program, the inner install program is divided into 10 sections. Each exercise
time equals the setting time divided by 10. When the system enters into the next section the console will
make 3 sound “B—B—“ and the speed will be changed according to the setting program, then press
“INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” to change the INCLINE and SPEED, When the program
selection is made it will come back to the current speed, and run the one program, the system will beep
three times and change to the manual program automatically.
Program exercise chart
Each program will divide into 10 grades for the exercise time and each time section has the speed and
inclines accordingly.

www.evofitness.net.au
12
Mode Time Time Interval
1 2 3 4 5 6 7 8 9 10
P1 SPEED 2 4 3 4 3 5 4 2 5 3
INCLINE 1 2 3 3 1 2 2 3 2 2
P2 SPEED 2 5 4 6 4 6 4 2 4 2
INCLINE 1 2 3 3 2 2 3 4 2 2
P3 SPEED 2 5 4 5 4 5 4 2 3 2
INCLINE 1 2 2 3 1 2 2 2 2 1
P4 SPEED 3 6 7 5 8 5 9 6 4 3
INCLINE 2 2 3 3 2 2 4 6 2 2
P5 SPEED 3 6 7 5 8 6 7 6 4 3
INCLINE 1 2 4 3 2 2 4 5 2 1
P6 SPEED 2 8 6 4 5 9 7 5 4 3
INCLINE 2 2 6 2 3 4 2 2 2 1
P7 SPEED 2 6 7 4 4 7 4 2 4 2
INCLINE 4 5 6 6 9 9 10 12 6 3
P8 SPEED 2 4 6 8 7 8 6 2 3 2
INCLINE 3 5 4 4 3 4 4 3 3 2
P9 SPEED 2 4 5 5 6 5 6 3 3 2
INCLINE 3 5 3 4 2 3 4 2 3 2
P10 SPEED 2 3 5 3 3 5 3 6 3 3
INCLINE 4 4 3 6 7 8 8 6 3 3
P11
SPEED 2 5 8 10 6 9 5 3 2 2
INCLINE 1 3 5 8 10 7 6 3 2 3
SPEED 2 5 5 4 4 6 4 2 3 4
INCLINE 3 5 6 7 12 9 11 11 6 3
P13 SPEED 2 7 4 7 8 9 4 5 3 2
INCLINE 5 6 6 4 6 5 8 9 4 2
P14 SPEED 2 6 5 4 8 6 5 2 3 3
INCLINE 5 6 5 8 4 5 5 10 6 3
P15 SPEED 2 6 5 4 8 7 5 3 3 2
INCLINE 3 4 5 6 3 5 5 6 4 3
P16 SPEED 2 5 7 5 8 6 5 2 4 3
INCLINE 1 5 6 8 12 910 9 5 3
USER PROGRAMS
U1, U2. Besides the 16 preset programs, we also set up another 2 user’s programs for the user’s needs:
U1, U2.
1. User programs tune

www.evofitness.net.au
13
Press the “PROGRAM” button until it shows the users program（U1-U2）, then press the “mode” then
enter the set-up for the first time. “SPEED+”, “SPEED-” is to change the speed, and the “INCLINE+”
“INCLINE-” is to change the incline. Pressing “mode” means the completion of the first time setup and
then enters to the second time setup until the ten setups are done. The data will be saved without losing,
due to power off until next time when you reset.
2. Startup of the user programs
A. Press the “PROGRAM” until it shows the user’s program (U1-U2), set the running time required and
press the “start” button
B. After you are finished with the user program and running time setting, press the “start” button it will
work also.
3. User program setup instructions
The program divides each exercise into ten periods; the treadmill cannot run until the speed, incline and
running time of the ten periods are done
RANGE OF PROGAMS
PROGRAM BEGIN SET UP
RANGE
DISPLAY
RANGE
TIME (MIN:
SECOND) 0:00 15:00 10:00-99:00 0:00-99:59
INCLINE (%) 0 0 0-15 0-15
SPEED (K/h) 1 1 1-18.0 1-18.0
DISTANCE (K) 0 1.0 0.5-99.9 0.00-99.9
PULSE (hypo/min) P N/A N/A 50-200
CALORIE (THERM) 0 50 10-999 0-999
BODY FAT PROGRAM:
To begin, press “ PROGRAM” until you reach the ‘’FAT’’ setting, press “MODE“ enter F-1, F-2, F-3, F-4,
F-5 ( F-1 SEX, F-2 AGE, F-3 HEIGHT, F-4 WEIGHT, F-5 BODY FAT TESTER),

www.evofitness.net.au
14
Press “SPEED+” “SPEED -” to set F-1 – F4 (refer to the following chart), after that, press “MODE” to set
F-5, grasp the palm pulse, the window will then display your body fat index (BMI) after 3 seconds. The
body fat index is testing the relationship between height and weight. The body FAT test is suited to males
and females. The ideal (BMI) should be 20-25, if under 19, it would mean you may be too thin. If you are
between 25 and 29, it could mean you are overweight, if over 30, it is indicating obesity. (The data is just
for reference, and cannot be used as medical data).
F-1 Sex 01 male 02 female
F-2 Age 10------99
F-3 Height 100----200
F-4 Weight 20-----150
F-5
FAT ≤19 Underweight
FAT =(20---25) Normal weight
FAT =(25---29) Overweight
FAT ≥30 Obesity
SAFETY FUNCTION:
In an emergency, pulling out the safety key can be used as an emergency stop, the treadmill will urgently
stop when all the windows show buzzer sounded "---", "BB" of the alarm sound 3; the treadmill can’t
carry out any operation except it is to be turned off. Replace the safety key correctly, the treadmill will
re-enter the standby mode, waiting for input.
POWER SAVE FUNCTION:
Without any operation for ten minutes the unit will begin to hibernate, and the display will dim. Press
any button to wake up the display.
CAUTION:
1. We recommend that you maintain a slow speed at the beginning of a session and hold on to the
handrails until you become comfortable and familiar with the treadmill.
2. Attach the magnet end of the safety pulling rope to the computer and also attach the clip of the safety
pulling rope to your clothing.
3. To end your workout safely, press the PAUSE button or pull out the safety cord, then the treadmill will
stop immediately.
EXERCISE INSTRUCTIONS
1. The Warm Up Phase

www.evofitness.net.au
15
This stage helps get the blood flowing around the body and the muscles working properly. It will also
reduce the risk of cramp and muscle injury. It is advisable to do a few stretching exercises as shown
below. Each stretch should be held for approximately 30 seconds, do not force or jerk your muscles into
a stretch - if it hurts, STOP.
2. The Exercise Phase
This is the stage where you put the effort in. After regular use, the muscles in your legs will become
stronger. It is very important to maintain a steady tempo throughout. The rate of work should be sufficient
to raise your heartbeat into the target zone shown on the graph below.
This stage should last for a minimum of 12 minutes though most people start at about 15-20 minutes
3. The Cool Down Phase
This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the warm up
exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching exercises should
now be repeated, again remembering not to force or jerk your muscles into the stretch.
As you get fitter you may need to train longer and harder. It is advisable to train at least three times a
week, and if possible space your workouts evenly throughout the week.
To tone muscle while on your treadmill you will need to have the resistance set quite high. This will put
SIDE BENDS
FORWARD
BENDS
OUTER THIGH
INNER THIGH
CALF/ ACHILLES

www.evofitness.net.au
16
more strain on our leg muscles and may mean you cannot train for as long as you would like. If you are
also trying to improve your fitness you need to alter your training program. You should train as normal
during the warm up and cool down phases, but towards the end of the exercise phase you should
increase resistance, making your legs work harden than normal. You may have to reduce your speed to
keep your heart rate in the target zone.
The important factor here is the amount of effort you put in. The harder and longer you work the more
calories you will burn. Effectively this is the same as if you were training to improve your fitness, the
difference is the goal.
MAINTENANCE INSTRUCTIONS
WALKING BELT CENTERING AND TENSION ADJUSTMENT
DO NOT OVERTIGHTEN the walking belt. This may cause reduced motor performance and excessive
roller wears.
TO CENTER WALKING BELT:
●Place treadmill on a level surface
●Run treadmill at approximately 5KPH
●If the belt has drifted to the right, turn the right adjusting bolt 1/2 turn clockwise and the left adjusting
bolt 1/2 turn counterclockwise See pic A
●If the belt has drifted to the left, turn the left adjusting bolt 1/2 turn clockwise and the right adjusting bolt
1/2 turn clockwise and the right adjusting bolt 1/2 turn counterclockwise See pic B
Picture A If the belts have drifted to the LEFT PictureBIf the belts have drifted to the RIGHT
WARNING: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE
CLEANING OR SERVICING THE UNIT CLEANING
General cleaning or servicing the unit will greatly prolong the treadmill. Keep treadmill clean by dusting
regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the
side rails. This reduces the build up of foreign material underneath the walking belt.
The top of the belt may be cleaned with a wet, soapy cloth. Be careful to keep liquid away from inside the
PIC A PIC B

www.evofitness.net.au
17
motorized treadmill frame or from underneath the belt.
Warning：Always unplug the treadmill from the electrical outlet before removing the motor cover.
At least once a year remove the motor cover and vacuum under the motor cover. Be careful not to
interfere with any of the wires or circuits.
WALKING BELT AND DECK LUBRICATION
This treadmill is equipped with a pre-lubricated, low maintenance deck system. The belt/ deck
friction may play a major role in the function and life of your treadmill, thus requiring periodic
lubrication. We recommend a periodic inspection of the deck.
We recommend lubrication of the deck according to the following timetable:
Light use (less than 3 hours/ week) annually
Medium use (3-5 hours/ week) every six months
Heavy use (more than 5 hours/ week) every three months
NOTE: APPLY HEALTHSTREAM TREADMILL LUBRICANT AS INSTRUCTED ABOVE.
EXPLODED DRAWING

www.evofitness.net.au
18
PARTS LIST
# DESCRIPTION SPEC
Qty # DESCRIPTION SPEC Qty
1 MAIN FRAME 1 38 CUSHION PAD 3 BALCK 2
2 BASE FRAME 1 39
MOVING WHEEL END
CAP 2

www.evofitness.net.au
19
3 LEFT UPRIGHT 1 40 FLAT FOOT PAD 4
4 RIGHT UPRIGHT 1 41 BLACK CUSHION PAD 2
5 MOTOR BASE 1 42
MIDDLE-EMPTY INNER
TUBE CAP 4
6 ADJUST BRACKET 1 43 PLASTIC BEARING 2
7 SUPPORTING BRACKET 1 44 SLIDE BLOCK 2
8 COMPUTER SUPPORT 1 45 DRIVING BELT 1
9 LABEL 2 46 SAFETY LOCK 1
10 Regular Washer 8 47 LEFT END CAP 1
11 COMPUTER COVER 1 48 RIGHT END CAP 1
12 COMPUTER PANEL 1 49 TRANSFORMER 1
13 BOTTLE RACK 1 50
LOWER CONTROL
BOARD 1
14 BRACKET 1 51 HAND END CAP 2
15 LEFT MOTOR LIGHT COVER 1 52 FOAM 2
16 RIGHT MOTOR LIGHT COVER 1 53 PLASTIC FIXED BLOCK 1
17 MOTOR COVER 1 54 KNOB 1
18 LEFT END CAP L 1 55 WHEEL END CAP 4
19 LEFT END CAP R 1 56 FRONT ROLLER 1
20 SMALL END CAP L 1 57 BOTTOM ROLLER 1
21 SMALL END CAP R 1 58 OILINESS AXIS SET 2
22 RIGHT END CAP L 1 59 AIR PRESSURE BAR 2
23 RIGHT END CAP R 1 60 5#wrench 5mm 1
24 MOTOR COVER FRONT CAP 1 61 6#wrench 6mm 1
25 RUNNING MAT 1 62 Wrench S=13，14，15 1
26 SIDE RAIL 2 63 “Z “inductor connector 1
27 BOTTOM BOARD 1 64 SLIDE RAIL AXIS CORE 1
28 BOTTOM END CAP 1 65 LIMIT DIGIT CORE AXIS 1
29 MOVING WHEEL 4 66 SPRING WASHER 8 6
30 ADJUST WHEEL 2 67 SCREW M8*30 4
31 RUNNING BOARD 1 68 BOLT M8*40 1
32 LEFT END CAP 1 69 BOLT M8*65 2
33 RIGHT END CAP 1 70 BOLT M8*25 6
34 END CAP 2 71 BOLT M8*30*20 2
35 RING PROTECTING WIRE
PLUG 2 72 BOLT M8*42*20 5
36 CUSHION PAD 1 RED 4 73 BOLT M8*48*20 4
37 CUSHION PAD 2 BLUE 2 74 BOLT M8*50*20 2
75 BOLT M10*25 8 113
AC SINGLE WIRE 1
76 BOLT M10*45*20 1 114
SINGLE WIRE 1 1
77 BOLT M10*62*20 1 115
AC SINGLE WIRE 1
78 BOLT M8*30 1 116
BOLT M8*16 2
79 BOLT M6*22 14
80 BOLT M5*6 7
