Evocare LM9121B User manual
Shopper Wheelchair Walker
LM9121B Shopper Wheelchair Walker
Thank you for purchasing this Shopper Wheelchair Walker. It is
strongly recommended that you read through this user manual prior
to using your Shopper Wheelchair Walker for the first time. Your
Shopper Wheelchair Walker should provide years of trouble-free use,
provided that you adhere to these recommendations.
LM9121B 136kg
Page 3.
Evocare is a quality endorsed company and supplies equipment listed with the
Therapeutic Goods Administration.
The ARTG numbers for the LM9121B Shopper Wheelchair Walkers is 218602.
Shopper Wheelchair Walker—Model LM9121B
Height-adjustable push
hand grips
Swing away leg rests
Easy-to-adjust push-button leg rests
Seat dimensions:
480mm x 380mm
(19” x 15”)
Convenient side
carrying case
Leg rests lock into
sides of walker
when not in use
Convenient cup holder
Breathable nylon
upholstery
Memory foam for
comfort
Comfortable hand brakes
Desk style permanent
armrests
Large under seat
basket
190mm TPR rear
wheels
150mm Polyurethane
front castors
Flip up footrests
Safety Seat Belt
Frame Colour: Dusty Blue
Weight 9.5
Flip over backrest
Overall
Width
(mm)
Folded
Width
(mm)
Between
Arms
(mm)
Rear
Wheel dia.
(mm)
Front
Wheel dia.
(mm)
Seat
Height
(mm)
Overall
Length
(mm)
Height to
Grips
(mm)
580 250 440 190 150 490 1050 820-920
Seat Width
(mm)
Seat Depth
(mm)
Backrest
Height (mm) SWL (kg) Gross Weight
(kg)
Net Weight
(kg)
480 380 370 136 11.9 9.5
Specifications:
Link to the LM9121B on the Evocare website
Wheelchair Leg
rests lock into
frame clips on
sides when used
as a Walker
Convenient side
carrying case
Page 3.
Note: Maximum user weight for this Shopper Wheelchair Walker is 136kg
Combines the functionality of a walker and transport wheelchair in one unit
Wheelchair
Padded Backrest
flips over when
used as a Walker
LM9121B Shopper
Wheelchair Walker—
Set up for use as a
Wheelchair
LM9121B Shopper
Wheelchair Walker—
Set up for use as a
Walker
Page 5.
Safety / Handling of Shopper Wheelchair Walkers
Safety and handling of the Shopper Wheelchair Walker requires the close
attention of the Shopper Wheelchair Walker user as well as the assistant. This
manual points out the most common procedures and techniques involved in the
safe operation and maintenance of the Shopper Wheelchair Walker. It is
important to practice and master these safe techniques until you are comfortable
in manoeuvring around the frequently encountered architectural barriers.
Use this information only as a basic guide. The techniques that are discussed on
the following pages have been used successfully by many users.
Individual Shopper Wheelchair Walker users often develop skills to deal with daily
living activities that may differ from those described in this manual. All warnings
and cautions given in this manual MUST be followed.
Techniques in this manual are a starting point for the new Shopper Wheelchair
Walker user and assistant with safety as the most important consideration for all.
Stability and Balance
To assure stability and proper operation of your Shopper Wheelchair Walker, you
must at all times maintain proper balance. Your Shopper Wheelchair Walker has
been designed to remain upright and stable during normal daily activities as long
as you do not move beyond the centre of gravity.
Virtually all activities which involve movement in the Shopper Wheelchair Walker
have an effect on the centre of gravity. Use the adjustable seatbelt for additional
safety.
DO NOT lean forward out of the Shopper Wheelchair Walker any further than the
length of the armrests. Make sure the castors are pointing in the forward position
whenever you lean forward. This can be achieved by advancing the Shopper
Wheelchair Walker and then reversing a little in a straight line.
Page 6.
Operating Instructions
To determine and establish your particular safety limits, practice bending, reaching
and transferring activities in several combinations in the presence of a qualified
health professional before attempting active use of the Shopper Wheelchair Walker.
ALWAYS check hand grips for looseness before using the Shopper Wheelchair
Walker. If loose and/or worn, replace immediately.
If the Shopper Wheelchair Walker is exposed to extreme temperature (above 38°C or
below 0°C), high humidity and/or becomes wet, prior to use, ensure hand grips DO
NOT twist on the Shopper Wheelchair Walker handle—otherwise damage or injury
may occur.
DO NOT attempt to reach objects if you have to move forward in the seat as this may
tip the wheelchair.
DO NOT attempt to reach objects if you have to pick them up from the floor by
reaching down between your knees as this may tip the wheelchair.
DO NOT lean over the top of the back upholstery to reach objects behind you, as this
may tip the wheelchair.
DO NOT shift your weight or sitting position toward the direction you are reaching, as
this may tip the wheelchair.
DO NOT tilt the Shopper Wheelchair Walker without assistance.
DO NOT use an escalator to move a wheelchair between floors—serious injury may
occur.
NEVER leave an unoccupied Shopper Wheelchair Walker on an incline.
DO NOT attempt to stop a moving Shopper Wheelchair Walker with the wheel locks.
Wheel locks are not brakes.
Before attempting to transfer in or out of the Shopper Wheelchair Walker, every
precaution should be taken to reduce the gap distance. Turn both castors parallel to
the object you are transferring onto. When transferring to and from the Shopper
Wheelchair Walker, ALWAYS lock both hand brakes (locks) before transferring to and
from the Shopper Wheelchair Walker.
DO NOT sit or transfer into the Shopper Wheelchair Walker unless it is fully open.
DO NOT operate on roads, streets or highways.
DO NOT climb, go up or down ramps or traverse slopes greater than 9°.
DO NOT attempt to move up or down an incline which has a film of water, ice or oil
on it.
DO NOT attempt to ride over kerbs or obstacles. Doing so may cause your Shopper
Wheelchair Walker to tip, causing bodily harm or damage to the wheelchair.
DO NOT over tighten hardware attaching to the frame. This could cause damage to
the frame tubing.
Page 7.
WARNING
After any adjustments, and before use, make sure all attaching hardware is
tightened securely. Otherwise, injury or damage may result.
As with any vehicle, the wheels and tyres should be checked periodically for
cracks and wear, and should be replaced when necessary.
Page 8.
1. Evocare provides consumers with the following warranty in relation to this Product, in addition to complying
with the requirements of any relevant legislation, including the Competition and Consumer Act2010 (Cth) in
Australia and the Consumer Guarantees Act 1993 in New Zealand (the Acts), except where a New Zealand
consumer acquires the Product for the purposes of a business.
2. In this warranty, we have used the following definitions:
(a) Form means a warranty claim form issued by Evocare in respect of Products;
(b) Evocare or our means Evocare Australia Pty Limited, ABN 98 078 566 604 of Level 19, 144 Edward Street,
Brisbane 4000;
(c) Products means the goods manufactured for Evocare (including products manufactured by its contract
manufacturers);
(d) Material means a material or component used by Evocare in the manufacture of the Products;
(e) Retailer means the authorised dealer of Products from whom the Product was purchased;
(f) Warranty Period means the warranty period commencing from the date of purchase of the relevant Product.
If the Product or part (as the case may be) is repaired or replaced, there will be no extension to the original
warranty period; and
(g) Workmanship means the handling, assembly and manufacturing processes performed by or on behalf of
Evocare in order to manufacture the Products.
3. Evocare warrants that for the duration of the Warranty Period, all Products will be free of faults arising from
defects in Workmanship or Materials, on the terms and conditions set out in this warranty.
4. Evocare undertakes that if during the Warranty Period any Product, or any part of a Product, has failed to
operate correctly due to faulty Workmanship or defective Material, it will repair or replace the Product or part
(as the case may be) free of charge provided that the following procedures are met :
(a) The consumer must contact the Retailer or Evocare upon becoming aware of any defect to a Product upon
which the consumer will be required to complete a Form and provide satisfactory proof of purchase.
(b) Evocare will review the Form to determine whether there is a defect, and if so Evocare agrees to (at its option)
repair, replace or supply equivalent goods, or pay the cost of any of those remedies to the consumer.
(c) If Evocare requests the return of the applicable Product or part, the consumer will be responsible for the
collection and freight costs of returning that Product or part to Evocare.
(d) The consumer acknowledges that it is also responsible for the freight costs to deliver any new Product or
replacement part to it.
5. This warranty is in addition to any non-excludable legal rights or remedies conferred on the consumer under
any applicable Act and any similar laws. To the extent permitted by law, Evocare's liability for any non-
excludable condition or warranty is limited to rectifying any defect at its option, as set out in paragraph 4(b).
6. Subject to the requirements of any applicable Act or legislation and to the extent permitted by law, no liability
(whether expressed or implied) of any nature whatsoever, is accepted by Evocare for any consequential loss,
damage or injury arising as a result of any fault in the Products.
7. This warranty does not extend to damage to Products which occurs during transit or transportation, or which is
caused by any abuse, accident or improper installation, connection, use, adjustment or repair or use of goods
otherwise than in accordance with instructions issued by Evocare.
8. The warranty on Products is waived if any addition or attachment to the Products do not have Evocare's
approval or are not sold as Evocare products. The Products are designed to perform specific tasks under
established test loads and unauthorised attachments may produce stresses for which the design is not
appropriate.
9. The following applies to consumers who purchased a relevant Product in Australia:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to
a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Page 9.
Your Evocare Shopper Wheelchair Walker is warranted to be free of defects in material
and workmanship for 12 months, for the original consumer.
This warranty does not cover device failure due to owner misuse, negligence, or normal
wear and tear.
The warranty does not extend to non-durable components such as rubber accessories,
brakes and grips, which are subject to normal wear and tear. Non-durable components
are warranted for 3 months.
For more information about your LM9121B Shopper Wheelchair Walker, warranty or to
order parts call 07 3355 8007.
Manufactured for:
Evocare Australia Pty Limited, 260 South Pine Road, Enoggera. QLD. 4051.
Phone: 07 3355 8000 FAX: 07 3355 5043
Website www.evocare.com.au
