Ewbank Steam Dynamo SC1000 Manual

Care and Use Instructions
For service and further information, please contact:
Earlex Inc. 8261 Highway 73, uite F, tanley, NC 28164
Tel: [phone]
www.ewban usa.com
Steam Dynamo
Model SC1000
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:07 Page 1

Steam Dynamo
1
3
4
2
5
66 7
Pac contents:
• Steam Dynamo
• Jug
• Funnel
• Towel
• Adaptor
• Steam Cap
• Extension Wands
• Floor Tool and Adaptor
• Window/Tile Cleaner
• Angled Nozzle
• Plastic Brush
Read the instruction boo before using
the Steam Dynamo and ma e sure
that…
• The cable is in perfect condition.
• All packaging materials are removed from
the product.
Thank you for purchasing your team Dynamo,
we hope you enjoy using it.
Please read the manual carefully to get the most
out of your product.
2
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:07 Page 2

Warning - Risk of inj ry
Ca tion! - Steam 100 C - Don’t direct at people or animals
Cleaning Fabrics:
A number of materials and fabrics are NOT suitable to be cleaned by steam for example:
Do not use on leather, wax polished furniture or floors, synthetics fabrics, velvet, Dralon or
other delicate, steam-sensitive materials.
Cleaning Glass/Mirrors:
Thermal shock can shatter glass. Before cleaning glass surfaces, carefully warm the sur-
face by directing the steam jet on the glass from a distance of no less than 6” or 15cm.
Steam Dynamo
Safety Instructions - CAUTION
•Do not direct steam at people, animals or
at electrical devices.
•Do not operate machine without water in
the tank.
•Do not allow machine to run unattended
at any time.
•Close supervision is necessary when this
machine is used near children. Do not
allow it to be used as a toy.
•The machine is designed for household
use only, do not expose to rain.
•Do not overfill the water tank. The
machine contains a maxium of 50 fl.oz of
water only. Excessive filling of the water
tank may cause damage or injury.
•Never turn the machine over or tilt more
than 5 when it is switched on or if it’s
still producing steam.
•Never use this machine to clean
electronic devices or installations.
•Use extra care when cleaning on stairs.
•To provide continued protection against
the risk of electric shock connect
properly grounded outlets only.
•Do not immerse cord, plug or machine in
water or any other liquid.
•Do not operate with a damaged cord,
keep feet and all parts of body away
from the jet of steam. Do not operate
machine in bare feet or when wearing
open toe shoes or sandals.
•Do not pull or carry by cord, use as a
handle, close door on cord or pull cord
around sharp edges or corners. Keep
cord away from heated surfaces.
•Unplug cleaner when not in use. Turn all
controls off before unplugging from
electrical outlet.
•Do not unplug by pulling on cord. Always
grasp the plug, not the cord. Never
handle plug or appliance with wet hands.
•Store in a dry place. Do not expose
machine to freezing temperatures.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
O
o
3
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:07 Page 3

Steam Dynamo
Towel grips
Floor tool
Swivel-adaptor
Floor brush/mop
tool
Window/tile cleaner
Angle, and
Plastic brushes
Handle
Extension
wands x 2
Adaptor
How to p t yo r Steam Dynamo together
4
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:08 Page 4

Steam Dynamo
Cleaning Floors
Instr ctions for Use
•Make sure the machine is unplugged from
the electrical outlet.
•Unscrew the safety cap (1) by turning
counterclockwise.
Please note the cap cannot be un
screwed when the unit is pressurized.
•Using the measuring jug and funnel (6) fill
the machine with up to 50 fl.oz (1500ml)
of water. This should be sufficient to
steam clean for approximately 5
minutes.
•Once full, replace the safety cap by
turning clockwise and fasten tightly.
•Attach the accessory or floor cleaning
tool you require to the machine. (See
page )
•Now plug the machine into the electrical
outlet and switch on. Two lights should
illuminate. The red light (3) is a power
indicator. The orange light ( ) indicates
that the machine is building steam
pressure. When the machine is first
turned on this light will illuminate. The
machine takes up to 12 minutes to reach
the correct pressure level depending on
the amount of water in the tank.
•Once the orange light has gone out the
machine is ready to use. The orange light
may come back on when the machine is
in use. If this happens, release the safety
trigger and allow the steam pressure to
build up once again. This should take no
longer than 0 seconds. If the safety
trigger is pressed when the orange light is
on, hot water may come out of the
machine.
Refilling the water tank
•Switch the machine off using the on/off
button (2).
•Disconnect the power cable from the
electrical outlet. Wait 5 minutes before
squeezing the safety trigger to make sure
the machine is no longer under pressure
before unscrewing the safety cap. DO NOT
unscrew the safety cap until the steam has
stopped.
•Fill the water tank as necessary using the
funnel provided. DO NOT exceed 50 fl.oz
(1500ml) of water before replacing the
safety cap by turning clockwise. Fasten
cap tightly.
•You are now ready to switch the machine
on and resume steam cleaning.
RED ORANGE
1
3
4
2
5
66 7
34
5
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:08 Page 5

A
C
B
Steam Dynamo
How to se the handle
A. Press the button in to attach the straight
adapter or the extension tubes.
B. Squeeze the trigger on the handle for
steam.
C. Lock the trigger for constant steam.
How to se the nozzles
•The angled nozzle and the brush tool can
be used to get into awkward corners that
are normally difficult to clean.
•Use the brush tool to scrub and loosen
stubborn dirt from hard surfaces.
•Use the window/tile cleaner to clean grime
from tiles and windows.
•To use these tools first fit the straight
adapter and then the jet-nozzle adaptor
(see the diagram on page ).
•First, depress the button on top of the
handle and push the straight adaptor (see
page ) on to the handle.
•Secondly push and twist the jet-nozzle
adapter to lock onto the straight adaptor
(see page 3).
•Now you can push any of these three
tools onto the tip of the jet-nozzle.
6
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:08 Page 6

•Attach the floor brush to the extension
wands, which snap together. Then attach
the extension wand to the steam gun. Do
ensure the extension wands are firmly
connected.
•Before cleaning always remove dust from
the surface you wish to clean.
•To release the extension wands depress
the button on the hose connection.
Cleaning floors & carpets with cleaning
cloth.
•While the machine is switched off attach
the cleaning cloth to the floor brush via
the spring-loaded clips, Make sure the
edges of the cleaning cloth are secure.
DO NOT attempt to do this while the
machine is still hot.
•Never remove the cleaning cloth while the
safety trigger is released or the machine is
warm to the touch.
WARNING - Ris of injury!
Fitting the Accessories
•The nozzle accessories may be fitted to
the steam gun (5) using adaptor 7.
Cleaning and Maintenance
•Cleaning and maintenance operations
should be carried out with the appliance
disconnected from the power supply.
•The machine should be allowed to
completely cool down before it is stored
away or cleaned.
•Clean the machine and its accessories
with a slightly damp cloth only.
•Never use a cleaning product or detergent.
•To ensure that your machine operates
correctly over a long period, rinse out the
water tank once a month to remove
lime-scale deposits. A vinegar solution or
de-scaler solution can be used to clean
inside the water tank.
•There are no customer service parts to the
boiler unit, all repairs must be carried out
by a qualified person or an appointed
agents.
Steam Dynamo
1
3
4
2
5
66 7
7
Steam Dynamo 12-09 us:Layout 1 22/12/09 14:08 Page 7

•Water comes out of the Nozzle
The team Cleaner creates a large
amount of steam. This may condense as
water or water droplets in the team
Hose, tools and Nozzle are expelled when
used after a period of cooling. This is
normal and not a cause for concern.
•No Steam comes out
Check that the hose has not become
kinked or blocked. Also check the power
supply and water level.
•I can’t get the Pressure Cap off
Make sure that you have fully
de-pressurized the Boiler. ee the section
‘Refilling the water in use’.
Troubleshooting
Steam Dynamo
Your Warranty
For service and further information, please contact:
Earlex Inc. 8261 Highway 73, Suite F, Stanley, NC 28164
Tel: [phone]
[email protected] www.earlex.com
This product is guaranteed for a period of 12 months against faulty materials and workmanship.
While every possible care is taken by Earlex to ensure that our products leave the factory in good
working order, Earlex cannot under any circumstances accept liability for problems or damage
caused by their subsequent use. It is the responsibility of the user to ensure the surfaces to be
treated or cleaned are suitable for steam. This guarantee does not affect your statutory rights. This
guarantee excludes the use for rental. In the event of a fault occurring please contact our helpline
before returning the unit to our Service Department at the address below together with a copy of
your purchase receipt. All repairs will be dealt with speedily. Some States do not allow limitations on
how long an implied warranty lasts and some States do not allow the exclusion or limitation
of incidental or consequential damages, so part or all of the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from
State to State.
• 8.2 ft power cord
• Water capacity - 50 Fluid ounces
(1500ml)
• Steam-up time – up to 12 minutes
depending on volume of water
• Working time – 5 minutes
• Tank material - Stainless Steel
• Power - 1500W
Technical data
•Steam flow is erratic; sometimes it
wor s well, other times it does not
If you have not used distilled or deionized
water, you may have a small blockage
inside your team Cleaner. Try descaling
your unit.
Check all attachments are fitted correctly.
•I live in a hard water area, my Steam
Cleaner does not wor as well
Empty the machine after use. In hard
water areas your team Cleaner may
benefit from occasional descaling. This
can be done by using a kettle descaler
solution. You can also use distilled or
deionized water to extend the life of the
product.
EB0029 12/09
Made in China
8
