BRIO amphora ROP100 User guide

RO Filtration System
with Artesian Pitcher
Setup Manual
Model No.: ROP100

2
Table of Contents
Safety Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Intended Use������������������������������������������������������������������������4
Package Contents � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �4
Product Features/Description� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Materials Needed ��������������������������������������������������������������������5
Installation Overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �6
Installation ��������������������������������������������������������������������������7
Connect to the Cold Water Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Install the Reverse Osmosis Drain Saddle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Install the Pitcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Make the Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation��������������������������������������������������������������������������10
Startup and Flushing Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dispensing Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance ����������������������������������������������������������������������� 11
Filter Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replacing the Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting ��������������������������������������������������������������������13
Warranty���������������������������������������������������������������������������14

3
Safety Information
WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling,
installing, and operating the filtration system.
WARNING: In order to ensure safety and to avoid injury and property loss to you and others, please be sure
to follow the following safety precautions. Misuse with ignoring safety precautions may lead to
accidents.
Installation needs to comply with state and local laws and regulations.
• System must be installed indoors and away from possible environmental damage.
• Avoid exposing and/or storing the pitcher in an environment under 32˚F (O˚C) or in places with strong
sunlight. This could cause parts of the product to age.
• Do not place heavy objects on top of the product.
• Do not place flammable, volatile substances near the product.
• Do not place the product near a heat source or open fire.
• Please install the product as close as possible to the floor drain.
• Do not allow children to operate, touch, approach, or climb on the product without guardians present.
• Strong magnetic devices nearby may cause fire, product damage, or circuit failure. Wet and dusty areas
may cause circuit damage.
• When cutting the power O, do not pull the power cord directly to prevent it from breaking. Keep the plug
clean. Do not plug or unplug with wet hands.
• If the power cord is damaged, it must be replaced by professionals from the manufacturer, its maintenance
department, or other similar departments. Do not squeeze, fold, knot, or damage the power cord.
• The product must be installed or moved by professional personnel. Disassembling at your own discretion
may damage the product or cause electric shock.
• When the water does not meet the municipal water standards (including high sediment content and
excessive residual chlorine, etc.), a professional installer must install a pretreatment device before installing
the pitcher.
• The optimal water pressure of this product is 0.1-0.4 MPa. If the water pressure is lower or higher than this,
install a pressure-boosting or pressure-reducing device accordingly.
• In case of product failure, unplug the pitcher, disconnect it from its water source, and contact customer
service.
• When the ambient temperature is low, the flow rate will decrease, which is an inherent feature of the filter.
• Replace the filter regularly.
• To ensure longevity of the pitcher, only use the parts included with this system. For replacement parts,
contact customer service.
• It is normal for the product to have slight vibration and noise when processing water.
• If you do not use this product for a long period of time, unplug or disconnect from the power source and
shut o the feed water adapter. Upon first use after an extended period of time, run water for 3-5 minutes.

4
Intended Use
This dispenser is intended to be used in household and similar applications such as:
• Sta kitchen areas in shops, oces, and other working environments
• Farm houses
• Hotels and other hospitality venues
• Catering events and similar non-retail applications
Package Contents
AG
H
I
J
K
B
C
E
D
F
Part Description Part Description
A RO Pitcher engine G Pitcher stand
B Feed water adapter with extra nut H Pitcher
C Drain saddle with foam gasket I Adapter
D Blue RO faucet tube J All in one filter (preinstalled)
E Red feed water tube K Plumber’s tape
F Drain saddle tube

5
Product Features/Description
8
5
6
1
2
3
10
11
12
9
7
4
Item Description Item Description
1 Power LED 7 Pitcher base
2 Filter replacement indicator 8 Water dispenser
3 Filter reset button 9 Pitcher lid placement indicator
4 Water processing and filter life indicator 10 Water connection flip lid
5 Water processing switch/Manual water intake button 11 Liquid level sensor
6 Pitcher locating groove 12 Pitcher lid placement groove
Materials Needed
Phillips-Head
Screwdriver
Adjustable Wrench Power Drill 1/4" Drill Bit (for
Drain Saddle Valve)
1/2" Drill Bit
(for RO Faucet)

6
Installation Overview
H
C
F
I
BE
D
A

7
Installation
1� Connect to the Cold Water Supply
CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE. The water supply to the
unit MUST be from the COLD WATER LINE. Using HOT WATER will severely damage your filters.
A� Turn o and then disconnect the current cold
water supply line.
B� Connect the feed water adapter (B) to the cold
water supply line.
C� Twist the cold water supply line clockwise
on top of the feed water adapter (B) until it is
securely connected.
NOTE: An extra adapter nut is included on top
of the feed water adapter (B) to attach to
a 3/8 in. or 1/2 in. feed plumbing line.
B
D� Insert the red feed water tube (E) straight into
the quick connector piece of the feed water
adapter (B). B
E
E� Gently tug on the tube (E) to ensure a secure
connection with the feed water adapter (B).
B
E

8
2� Install the Reverse Osmosis Drain Saddle
The “RO” filter assembly requires a drain line connection to
be installed, which removes rejected water to the sewer. The
drain saddle connects the drain line from the dispenser to
your drain pipe. The drain saddle is designed to fit around a
standard 1.5 in. OD (outer diameter) drain pipe.
Always install the drain saddle before the P-trap (1).
Ensure the drain saddle is in place on the vertical or
horizontal section of the pipe.
To avoid clogging the drain line with debris, do not
install the drain saddle on a section of piping that is
located after the drain pipe meets a garbage disposal
or dishwasher drain.
To install the Reverse Osmosis (RO) drain saddle:
A� Determine the location for your drain saddle (C) and
then make a mark on the drain pipe for the opening (1).
B� Use your drill and a 1/4 in. drill bit to create a hole at
the mark, ensuring you only drill through one side of
the drain pipe.
C� Find the half of the drain saddle (C) with the hole in
the center, remove the backing from the foam gasket,
align the gasket with the hole on the drain saddle (C),
and stick the adhesive side of the gasket to the drain
saddle (C).
D� Position both halves of the drain saddle (C) on the
drain pipe with the saddle’s opening aligned over the
drilled hole, and insert your drill bit through the saddle
(C) and drilled hole to ensure proper alignment.
E� Secure both ends of the drain saddle (C) together
using the bolts and nuts, but do not over tighten.
F� Connect the drain saddle tube (F) to the drain
saddle(C).




1
F
C
1

9
3� Install the Pitcher
IMPORTANT: If your sink does not have a second
faucet hole, please contact a licensed
professional to create one. Do NOT
attempt to drill a faucet hole yourself
as this may damage the sink.
A� Remove the screw nut (1) and directional cap (2)
from the adapter (I) and insert the adapter (I) into
the mounting hole on your sink/counter.
B� Loosely secure the adapter (I) in place from
underneath the sink/counter using the screw nut (1).
C� Pass the blue feed tube (D) into the bottom of the adapter (I) and through the top of the adapter (I).
D� Remove the cover (3) from the bottom of the pitcher
stand (G) and connect the blue feed tube (D) to the
pitcher stand (G). Replace the cover (3).
E� Place the pitcher stand (G) in its final location on the
counter and position the pitcher (H) into the pitcher
stand (G).
F� Adjust the blue feed tube (D) to your desired length, replace
the directional cap (2) on the adapter (I) and securely tighten
the screw nut (1).
1D
2
I
I
D
3
G
H
I

10
4� Make the Connections
A� Connect the three colored tubes (D, E, and F) to the engine
(A).
Operation
Startup and Flushing Water
Flush the filter in the engine (A) upon first use and each time you change the filter.
1� Open the feed water adapter (B).
2� Plug the engine (A) into a GFCI outlet. The engine automatically turns on.
3� Complete the steps in the Dispensing Water section below and allow the water to fill the pitcher (H) at least
three times and until black spots no longer appear in the water before drinking.
Dispensing Water
1� Before dispensing water, ensure the flip lid (1) on the pitcher (H)
is open, the lid (2) is closed, and that the liquid level sensor in the
lid is in the correct position with the pitcher body groove.
2� Press the water processing switch/manual water intake button (5)
to turn the water dispensing on and o. When the water is turned
On (the indicator light is on), water dispenses automatically after
you place the pitcher (H) in the base (G).
3� The water turns o automatically when the pitcher is full.
Removing the pitcher and pressing the water processing switch/
manual water intake button (5) will also turn the water o.
NOTE: Do not block the liquid level sensor in the lid.
E
F
A
D
1
H
G
5
2

11
Maintenance
Filter Specifications
Filter Name Filter Layer Function Suggested
Lifespan
Integral
Composite Filter
PAC Filters mud, sand, rust, suspended solid, and other large-
grained substances.
12-24
months
RO Membrane Filters organics (trichloromethane and carbon tetrachloride)
and heavy metals (arsenic, lead, and cadmium).
Post-positional
Carbon Rod
Filters organics, remaining chlorine, and odor.
Replacing the Filter
When the filter indicator lights on the machine and pitcher base begin to flash, it is time to change your filter.
Tochange your filter:
1� Close the feed water adapter (B) attached to the cold water supply line.
2� Disconnect the power from the engine(A).
3� Open the top cover of the engine (A) and lift to remove the old filter (J).
4� Place the new filter into the engine (A) and replace the top cover of the engine (A).
5� Open the feed water adapter (B).
6� Plug the engine (A) back into the outlet.
7� Press and hold the filter button (3) on the front of the engine (A) for 3 seconds to reset the filter.
A3
J

12
Routine Maintenance
• Periodically check all connections for leaks.
• Replace any connectors and filter housings with proper replacement parts. Contact Customer Service to
order replacement parts.
• Always use the proper replacement filter with the correct size and length.
• Replace the plumber’s tape on all threaded connections and fittings annually.
Care and Cleaning
• Avoid using strong volatile solvents such as soap, detergent, diluent, gasoline, or ethyl alcohol when
cleaning the product. These solvents result in cracking, scratching, and turning colors.
• If the pitcher will not be in use for an extended amount of time, ensure you close the valves and remove
power from the engine.
• Do not lay the engine on its side.
• Do not place the product in direct sunlight.
• Do not wash the pitcher lid with high temperature water or place the pitcher lid in a high-temperature
environment.
• Wipe the pitcher base with a cloth. Do not wash the pitcher base directly with water or soak it in water.

13
Troubleshooting
Problem Probable Cause Solution
The product will not dispense
water or stop dispensing
water.
• Liquid level sensor inside the
pitcher lid is blocked.
• The pitcher lid is in the incorrect
position.
• The product is in protected
mode.
• Check to see if the liquid level
sensor is blocked. If there is
blockage, remove the blockage.
• Check the position of the pitcher lid
in the pitcher.
• If the power light and the filter
element light flicker at the same
time, it indicates the product is in
protected mode. Disconnect the
pitcher from the power source, then
reconnect the power.
The amount of water being
dispensed decreases
significantly.
• The filter is blocked.
• The filter needs to be replaced.
• The feed water adapter is not
completely open.
• Clean or replace the filter.
• Ensure the feed water adapter is
fully open.
The water quality is poor. • The filter needs to be replaced.
• The product has not been used
in a long time.
• The quality of water and source
is poor.
• Replace the filter.
• Dispense water for at least 3 minutes
to flush out any impurities.
• Ensure your water source is
municipal tap water.
The engine leaks water. A component in the engine has
failed.
Shut o the water at the main source,
disconnect the power, and report this
issue to customer service.
The product is not dispensing
water after changing the filter.
Air is being blocked. Disconnect the pitcher from the power
source, shut o the water, replace the
filter, turn the water on, and then restore
power to the engine.

14
Warranty
Brio (“Vendor”) warrants to the original purchaser of the Brio Water Filtration System (the “Product”), and to
no other person, that if the Product is assembled and operated in accordance with the printed instructions
accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free
from defects in material and workmanship. This Limited Warranty shall be limited to repair or replacement of
parts, which prove defective under normal use and service and which Vendor shall determine in its reasonable
discretion upon examination to be defective. To take advantage of this Limited Warranty, please follow these
steps:
1. Please retain your sales slip or invoice, as Vendor may require reasonable proof of your date of purchase.
2. Contact Vendor’s Customer Service Department using the contact information listed below.
3. Return parts to Vendor, per Vendor’s instructions, at your cost and expense.
4. Upon receipt by Vendor, Vendor shall advise you in writing whether a defect covered by this Limited Warranty
exists in any returned part and whether your claim has been approved or denied.
5. Upon Vendor’s approval of your claim, Vendor will replace such defective part without charge to you.
WHAT THIS LIMITED WARRANTY DOES NOT COVER: This Limited Warranty does not cover any failures
or operating diculties of the Product due to accident, abuse, misuse, alteration, misapplication, improper
installation or improper maintenance or service by you or any third party, or failure to perform normal and routine
maintenance on the Product, as set out in the User’s Manual. In addition, this Limited Warranty does not cover
damages to the finish, such as scratches, dents, discoloration or rust after purchase.
This Limited Warranty is the only express warranty given on the Product and is in lieu of all other express
warranties. Vendor disclaims all warranties for products that are purchased from seller other than authorized
retailers or distributors. THIS LIMITED WARRANTY RESTRICTS THE DURATION OF ANY AND ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, THE IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE TO THE ONE (1) YEAR TERM OF THIS LIMITED WARRANTY. UPON THE
EXPIRATION OF THE ONE (1) YEAR TERM OF THIS LIMITED WARRANTY, VENDOR DISCLAIMS ANY AND ALL
IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, THE PRODUCT BEING THUS SOLD AS-IS, WITH ALL FAULTS.
FURTHER, VENDOR SHALL HAVE NO LIABILITY WHATSOEVER TO PURCHASER OR ANY THIRD PARTY
FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. OTHER THAN THIS
LIMITED WARRANTY, THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE
FACE HEREOF. Vendor assumes no responsibility for any defects caused by third parties. This Limited Warranty
gives you specific legal rights, and you may have other rights which vary from state to state. State law may also
override statements in this Limited Warranty regarding the restriction on the duration of implied warranties.
Some jurisdictions do not allow exclusion or limitation of special, incidental or consequential damages, or
limitations on how long awarranty lasts, so the above exclusion and limitations may not apply to you.Qui
odia voluptaturio odissunt harum faceperis sum nonse nienis eritae re, ut ut quo inciet ut etur aria quatquisita
conserum quis pe pliscilis rem is accus.
Ro quo ius rerum ne simodi ut la est, con es aut excere essim voluptae nulluptus eum faccus, vellant est,
quamus.
Xero omnis maionsedis iumquo cus iditis ut rem vollorest laborem a quatiusam dolorpor aut ad quiae plit lab
ipsa quatibe archit odioribus molessundus molorib erchill antibea sequi cullupt aepuda voloratur? Qui non
et eium ipsam fugia dit dic torro cor maio ma cor autatin ctassum re cus, to tem eossunt oreium et lissit quas
rerume adiaestrunt.

15
Culpa quam sedisinimus eatur as resseque natesto reperunt.
Sus estis pratus. Pit es as et quisque praere alit veria sitatis autectam et es alibusa quaspis aliquam, is ne lam
voluptibus sam, ipsant, cus reiunt harit faccupiende et omnissit atiur solorpor moditin ctecus as sit volo bea
corest, iumeniet audist adio veliquist, ut lant, sim volum solut et et quam undus aspit doluptio omnim eostrum
quidelit, velisci volest, odignim quiae dolo tem quatem si doluptatem quam volore, nem as ratem quiam et ad
maionsequi andessum quis dias delis anim quae volorep uditiss itatem re essequatur simi, odit et facea volorem
volupta tincte velectatur sam harumqui quis estruptatem. Itate plibeatem rem ut ommo eatur? Vit, quidell atiati
dusandel moluptum audantiorio. Et evenis voloressunt.
Temquas asperit omnimus explanimusto voluptatem ra audam est, inulliquam estios natus que sum dellore
icienis esti volessu nditas nihilit, aligendis nos int la ducia dolorenitas mo berrum dolorunt molorrovid quibusdae
conseque pedisquunt audaepro ocab oriorro mossumet volorpore volenimod quatum eribere ceatum
architatus core odiam dolum nos volorem. Pissecerum res eiuscim quasper feriamus ut voluptae preptatet dolut
et, et quat reiuribusae repraecus vellabo. Enti doluptae dolor sus et autenim intur?
At hiliam lautem veles ant alictur? Equia quatemolorum est, optat ea sin commodis sedisi derorestrum ipicipis
quis etur, tempor as is eariam quia velignit et autesciate cum volorit, sit atius ut et as nit laboreste velia vellaut
liatio. Uptas accusdae volorunt res alia quiat acia dolor adissi ommoditae cuscietur? Ma sime nobitas aliquosam
sum quas sum veritassin nobis plabo. Itatur as aut fuga. Met et volende re perferempe es ex estis nullatiat
rerehenis animaximped modigente exerum que simet vollani tiuntibus re vid quos re volor mint ad quiaeri
cuptam, id essit des dest, illore venihil iquamus.
Beaqui rem eruptae caerum explabores rat aspere, sum ipsam ratem eium nis moloriberi ipsaperem viduciis
volorat eicit volorep erchite es endi a qui blaut laut octatet aliquam, sint et octat.
Ihillat volor reptam sundita turione et volupta tessimus.
Videl id experiant quod ut eum dolendi beritat maiores ipsum nossimus esti aboremod ulpa cum cuscim si
blabores ut oditati aut aut lignimi, nonserianda del ilita plaborae nis et inveliquo optatis et repture mporepre, odi
consequi volut quid et aliqui beria alitat laborer ibusdae quias aut ex et venimil ipsum sum eturest, odit estem
quaturit litinit octium acia dolupta ecabore hendisime dollupt atemperunt quam accatas aut late rehendandis
et autenectam, omnis rempore nescim exerior iamus, sedit ex et, optiatu scienesci blabore ribeaquos nis
deleseria ne simet et lab int quosam eturemporio. Itatus aut quatem quam, sunto ipsumquias est et arum, que
magnitas comni cuscia iducimus res ullorent ad quis ut inctorundis essitis et volorrorem ipsam fugitas esto
everae sequi quis quia venempo rereium volore sequi ut quis cone aut reptatusam, consedici tem ium raestium
quo et ea dolenih ictatem is doluptatem fuga. Ut es ea quia ium as aped magnatis dita et odis alignam apicipsam
sequi omniatatem nisto omni odipis de con cus samust vendele ctectec ullatibus mo omnis rae cus dolorror
apernatiatem eatur, at odignim agnatus qui ipicat eos quis explias piento iur?
Erum coribus aerumet que veliquunt.
Estiasi nctur? Num arcia into berrovit voloremperum dolorporum vellab in cone enihit eum doluptatur aligenima
sum lique venim cuptatur repudamus as eum, acesciditio. Ita ipsumqui occus aut ipsam dis eos coratus volectur,
totatur sit qui cupti quunt ex et ommolestrum re porum qui dolupicae verrunt delluptatur, solorrore pore
ipienducil ipsant, vel eiur aut audicip sandam fugiae nos enimoluptas eaquiat.
Dem facepra tioriat invelia praturestem voluptatem quaspictur, soleniatem repudia plia qui volupta ventin re
esciisti dios susciistrum eaquisin culparu ptiniss equodignate conem rat re nus dest doluptaquis des ratat.
Asimusc iassusd anditas audiatem qui cum fugiae poreius ciunt, eicia doluptatusam dolesserit velitis adisque
nullesto et ut everferum ea as vento debitis dolo tem hit ilicit et lique pelenimi, culluptatiis autatis modi ipicilit
velias exeria voluptat ut fugia dero doluptaque eum ressit, quid eosam quam rest aute es seque sam, ea
quam quos essunt inis pore con comnis eos aspere namus es et est, apitis ilis et eum es dolore et intest pore,
accuptatat exerum fugit laccus.Sequi delitem ossime siminte mporum voluptae is simust maximint eatibus
peruptiae voloreratur maio quibus eum voluptame culpa et et ullaborepero voluptat ad moluptatur rem estotae

©2020 DTWUSA
Contact Us
Call: [phone]
