Exhausto CX3000 User manual

CX3000
Assembly, installation, and maintenance instructions
Original instructions
3006554-2023-01-12 CX3000 Montage, installation og vedligeholdelse
EXHAUSTO A/S
Odensevej 76
DK-5550 Langeskov
Tel. [phone]
Fax [phone]
[email protected]
www.exhausto.dk

1. Product information
Symbols, warnings and terms...............................................................................................................4
Information plate, location and Serial number.................................................................................... 5
Information plate............................................................................................................................. 5
Location of information plate...........................................................................................................5
Searching via web for the latest update of the instruction.............................................................. 5
1.1. Model overview....................................................................................................................................... 6
1.2. Terms used in these instructions..........................................................................................................7
1.2.1. Simplified diagram.......................................................................................................................... 7
1.3. General Unit Specifications................................................................................................................... 9
1.4. Application............................................................................................................................................ 10
1.5. Location requirements......................................................................................................................... 10
1.5.1. Space requirements......................................................................................................................10
1.5.2. Ceiling requirements..................................................................................................................... 12
1.5.3. Requirements for duct system...................................................................................................... 12
1.6. Description............................................................................................................................................ 12
1.6.1. Construction of the CX3000 unit................................................................................................... 12
1.6.2. Parts of the CX3000 unit...............................................................................................................14
1.7. Principal dimensions............................................................................................................................15
1.7.1. CX3000, left units..........................................................................................................................15
1.7.2. CX3000, right units....................................................................................................................... 19
2. Handling
2.1. Unpacking............................................................................................................................................. 23
2.1.1. Weight...........................................................................................................................................24
2.2. Transport............................................................................................................................................... 24
2.2.1. Passage through openings........................................................................................................... 24
2.2.2. Internal transport with reduced weight.......................................................................................... 24
3. Mechanical assembly
3.1. Positioning of unit................................................................................................................................ 25
3.1.1. Mounting on ceiling....................................................................................................................... 25
3.2. Condensation drain.............................................................................................................................. 26
4. Maintenance, hygiene and servicing
4.1. Operating readings via the HMI panel................................................................................................ 28
4.2. Maintenance.......................................................................................................................................... 28
4.2.1. CX3010-CX3060 with hinged doors..............................................................................................28
4.2.2. CX3000 with sliding rails...............................................................................................................29
4.2.3. Overview of maintenance intervals............................................................................................... 30
4.3. Hygiene..................................................................................................................................................30
4.4. Servicing and cleaning.........................................................................................................................31
4.4.1. Filter change................................................................................................................................. 31
4.4.2. Servicing and cleaning the motor..................................................................................................32
4.4.3. Removing and cleaning the bypass damper.................................................................................33
4.4.4. Removing and cleaning the counterflow heat exchangers........................................................... 33
5. Technical data
5.1. Weight, corrosion class, temperature ranges, etc.............................................................................36
5.2. Compact filters......................................................................................................................................37
5.3. Capacity diagram..................................................................................................................................38
5.3.1. Capacity diagram, CX3000 series................................................................................................ 38
6. Unit Accessories
6.1. Overview................................................................................................................................................39
Assembly...................................................................................................................................... 39
6.2. Packaging..............................................................................................................................................40
6.2.1. Packaging components.................................................................................................................40
6.3. Electrical Pre-Heater & Post-Heater....................................................................................................42
6.3.1. Electrical Pre-Heater, description..................................................................................................42
6.3.2. Electrical Post-Heater, description................................................................................................ 43
6.3.3. Electrical Pre-Heater & Post-Heater, dimensions......................................................................... 43
6.3.4. Electrical heaters, technical data.................................................................................................. 45
6.3.5. How to connect the electrical pre-heater to the unit......................................................................46
6.3.6. How to connect the electrical pre-heater to the air duct................................................................48
6.3.7. How to connect the electrical post-heater to the unit.................................................................... 49
6.3.8. How to connect the electrical post-heater to another accessory.................................................. 51
6.3.9. How to connect the electrical post-heater to the air duct.............................................................. 53
6.4. Changeover Coil Box........................................................................................................................... 53
6.4.1. Changeover Coil Box, description.................................................................................................53
6.4.2. Changeover Coil Box, dimensions................................................................................................54
6.4.3. Changeover coils, technical data.................................................................................................. 55
6.4.4. How to connect the changeover coil box to the unit..................................................................... 55
6.4.5. How to connect the changeover coil box to another accessory....................................................55
6.4.6. How to connect the changeover coil box to the air duct............................................................... 56
6.4.7. How to service the coil box........................................................................................................... 57
6.5. Filter Box............................................................................................................................................... 59
6.5.1. Filter Box, description................................................................................................................... 59
3006554-2023-01-12
2/80

6.5.2. Filter Box, dimensions...................................................................................................................60
6.5.3. How to connect the filter box to the unit........................................................................................61
6.5.4. How to connect the filter box to another accessory...................................................................... 61
6.5.5. How to connect the filter box to the air duct..................................................................................61
6.5.6. How to service the filter box..........................................................................................................63
6.6. Water Heating Coil (HCW).................................................................................................................... 64
6.6.1. Water Heating Coil (HCW), description.........................................................................................64
6.6.2. Water Heating Coil (HCW), dimensions........................................................................................64
6.6.3. Water Heating coils (HCW), technical data...................................................................................65
6.6.4. How to connect the water heating coil to the unit......................................................................... 66
6.6.5. Principles for connecting the water heating coil............................................................................68
6.6.6. How to service the heating coil..................................................................................................... 69
6.7. Sliding Rails.......................................................................................................................................... 71
6.7.1. Sliding Rail, description.................................................................................................................71
6.7.2. Sliding Rail, dimensions................................................................................................................71
6.7.3. How to connect the sliding rails to the unit....................................................................................72
6.8. Extension E-Box................................................................................................................................... 73
6.8.1. Extension E-Box, description........................................................................................................ 73
6.8.2. How to service the electrical heater e-box.................................................................................... 73
6.8.3. How to service the electrical heater resistances...........................................................................73
6.9. External/Duct Damper With Motor.......................................................................................................74
6.9.1. External/Duct Damper With Motor................................................................................................ 74
6.10. HMI cable............................................................................................................................................... 74
6.10.1. HMI Cable..................................................................................................................................... 74
7. EC Declaration of Conformity
7.1. EC Declaration of Conformity..............................................................................................................75
8. Ordering spare parts
8.1. Ordering spare parts............................................................................................................................ 76
3006554-2023-01-12
3/80

1. Product information
Symbols, warnings and terms
Prohibition symbol Failure to observe instructions marked with a prohibition symbol may result in
serious or fatal injury.
Danger symbol
Failure to observe instructions marked with a danger symbol may result in per-
sonal injury and/or damage to the unit.
Scope
This instruction manual is for use with EXHAUSTO CX3000 air handling units. Please refer to the prod-
uct instructions regarding accessories and extra equipment.
The instructions must be fully observed to ensure personal safety and to protect the equipment and
ensure its correct operation. EXHAUSTO A/S accepts no liability for accidents caused by equipment
not used in accordance with the manual’s instructions and recommendations.
Warnings
Opening the unit
Do not open the service doors until the supply voltage has been disconnected at
the isolation switch and the fans have stopped.
Prohibited uses The CX3000 unit is not to be used to transport solid particles or in areas where
there is a risk of explosive gases.
No duct connection If one or more of the inlets/outlets is not connected to a duct: Fit a protective net
to the inlets/outlets with a maximum mesh width of 20 mm.
Placement The CX3000 is only for use inside buildings. It is designed to be mounted on the ceiling.
3006554-2023-01-12 Product information
4/80

Supply air/extract
air
This instruction manual uses the following terminology:
● Supply air (air blown in)
● Extract air (air removed)
● Outdoor air
● Exhaust air
Left/Right See definition of Left/Right in Section 1.1 Model overview.
Dimensions Dimensions given in all sections of the manual are in millimeters (mm).
Information plate, location and Serial number
Information plate
The CX3000 unit information plate shows:
1. CX3000 Type & model.
2. Serial number.
NB Always have the serial number ready when contacting EXHAUSTO A/S.
Location of information plate
Information plate is located on the side of the unit.
Searching via web for the latest update of the instruction
IMPORTANT! Always check whether the latest version of the instruction is available.
Search EXHAUSTO’s website under Downloads via the instruction number on the top left-hand
side of the instructions.
3006554-2023-01-12 Product information
5/80

1.1 Model overview
Elements Description
Fan
Compact filter
1,1 Extract air inlet
1,2 Exhaust air outlet
2,1 Outdoor air inlet
2,2 Supply air outlet
Air direction, extract air
Air direction, supply air
Fan placement Air directions
CX3000, left unit from above
CX3000, right unit from above
3006554-2023-01-12 Product information
6/80

1.2 Terms used in these instructions
1.2.1 Simplified diagram
CX3010L/CX3020L,
top view
CX3010R/CX3020R,
top view
Component Function Standard/Accessory
DPTH, P2 Extract air filter pressure drop measurement Standard
TE11 Extract air temperature measurement Standard
TE12 Exhaust air temperature measurement
(used for de-icing purposes)
Standard
M1 Exhaust air motor Standard
Main Board Control box Standard
DPTH, P1 Outdoor air filter pressure drop measurement Standard
TE21 Outdoor air temperature measurement Standard
M2 Outdoor/Supply air motor Standard
BP Outdoor air bypass damper Standard
M3 Bypass damper motor Standard
TE22 Supply air temperature measurement Standard
3006554-2023-01-12 Product information
7/80

CX3030L/CX3040L
CX3050L/CX3060L,
top view
CX3030R/CX3040R
CX3050R/CX3060R,
top view
3006554-2023-01-12 Product information
8/80

Component Function Standard/Accessory
DPTH, P2 Extract air filter pressure drop measurement Standard
TE11 Extract air temperature measurement Standard
DPTH, P1 Measure the heat exchanger pressure drop Standard
TE12 Exhaust air temperature measurement Standard
M1 Extract/Exhaust air motor Standard
DPTH, P3 Exhaust air flow measurement Standard
Main Board Control box Standard
DPTH, P3 Outdoor air filter pressure drop measurement Standard
TE21 Outdoor air temperature measurement Standard
M2 Outdoor/Supply air motor Standard
BP Outdoor air bypass damper Standard
M3 Bypass damper motor Standard
DPTH, P2 Supply air flow measurement Standard
TE22 Supply air temperature measurement Standard
1.3 General Unit Specifications
Unit Model Nominal Air
Volume Flow
Rate (m³/h)
External Static
Pressure @
Nominal Air
Flow Rate (Pa)
Phase Voltage
(V)
Frequency
(Hz)
Max. Power
Current (A)
Max. Power
Consumption
(W)
CX3010LC/CX3010RC 500 100 1 230 50 3.4 452
CX3010LM/CX3010RM 500 100 1 230 50 3.0 406
CX3020LC/CX3020RC 900 150 1 230 50 4.2 560
CX3020LM/CX3020RM 900 150 1 230 50 3.2 668
CX3030LC/CX3030RC 1400 200 1 230 50 5.0 1120
CX3030LM/CX3030RM 1400 200 1 230 50 6.2 1020
CX3040LC/CX3040RC 2000 300 1 230 50 7.0 1580
CX3040LM/CX3040RM 2000 300 1 230 50 7.2 1620
CX3050LC/CX3050RC 2500 300 3 400 50 4.0 2320
CX3050LM/CX3050RM 2500 300 3 400 50 4.8 2860
CX3060LC/CX3060RC 3300 300 3 400 50 4.0 2320
CX3060LM/CX3060RM 3300 300 3 400 50 4.8 2860
3006554-2023-01-12 Product information
9/80

1.4 Application
Comfort ventilation EXHAUSTO CX3000 is used for comfort ventilation purposes. The CX3000 unit is designed for ceiling
mounting and must be used as such.
Operating temperature range for the unit – see section "technical data".
Prohibited uses The CX3000 unit is not to be used to transport solid particles or in areas where there is a risk of
explosive gases.
1.5 Location requirements
Positioning The CX3000 unit is designed for indoor fitting. The unit may be positioned with the side opposite the
connection box up against a rear wall.
1.5.1 Space requirements
CX3000 with hinged
doors (standard)
The cabinet has three hinged doors. The drawing below indicates how much space is needed for
opening the doors and servicing the unit, i.e. changing filters, cleaning, servicing, etc.
3006554-2023-01-12 Product information
10/80

Model a (mm) b (mm) c (mm) d (mm)
CX3010 1580 940 1010 -
CX3020 1720 1000 1260 -
CX3030 1800 1160 1610 -
CX3040 2000 1300 1760 -
CX3050 2100 1365 1760 -
CX3060 2250 1275 2080 1450
NB: For all units in CX3000 Range, dimensions are identical for both left and right units.
CX3000 with sliding
rails (accessory) The cabinet has 2/3 doors which can be individually released and slide sideways allow filter change
and cleaning.
3006554-2023-01-12 Product information
11/80

Model a (mm) b (mm) c (mm)
CX3010 1580 475 1010
CX3020 1720 505 1260
CX3030 1800 585 1610
CX3040 2000 670 1760
CX3050 2100 685 1760
CX3060 2250 685 2080
NB: For all units in CX3000 Range, dimensions are identical for both left and right units.
See also ● Section "Principal dimensions of CX3000" for additional measurements.
● Section "Maintenance" for information on opening the doors.
1.5.2 Ceiling requirements
When fitting the unit to a ceiling, the ceiling must be:
● flat
● resistant to vibration
● horizontal or sloping towards the condensation outlet
● designed to bear the weight of the unit
1.5.3 Requirements for duct system
Silencers The duct system must be fitted with silencers specified by the Project Manager, which meet the re-
quirements of the operating area.
Insulation The duct system must be insulated to prevent
● condensation
● sound leakage
● heating/cooling losses
Prerequisites Adequate insulation of the duct system in the operating area is a prerequisite for achieving the calcula-
ted sound data during operation.
Condensation Condensation in the ducts may occur when the exhaust air has high humidity. EXHAUSTO recom-
mends a condensation outlet is also fitted at the lowest point in the ducts.
No duct connection If one or more of the inlets/outlets is not connected to a duct: Fit a protective net
to the inlets/outlets with a maximum mesh width of 20 mm.
1.6 Description
1.6.1 Construction of the CX3000 unit
Construction of the
CX3000 unit
The drawings below shows an overview of the CX3000 unit construction. First two drawings show a
CX3000 unit with circular inlets / outlets. Last two drawings show a CX3000 unit with rectangular.
3006554-2023-01-12 Product information
12/80

3006554-2023-01-12 Product information
13/80

Pos. Part Function
1 Isolation Switch Connects/disconnects current.
2 Excon Control Control system.
3 Connection box Connection of accessories and power supply.
4 Exhaust Air Fan Removes the stale air.
5 Supply Air Filter Filters the supply air.
6 Additional Condensation Tray "Collects condensed water and drains it from the counterflow
heat exchanger to the condensation tray."
7 Bypass Motor Opens/closes bypass damper.
8 Bypass Duct Directs air around the counterflow heat exchanger.
9 Bypass Damper Opens/closes bypass duct and heat exchanger.
10 Counterflow Heat Exchanger Enables heat exchange between stale and fresh air.
11 Supply Air Fan Blows fresh air into the room.
12 Exhaust Air Filter Filters the exhaust air.
13 Suspention Clamps Clamps for fitting the unit to the ceiling (2 or 3 at each side de-
pending on unit size).
14 Condensation Outlet Pipe Transfers condensed water from the condensation tray. Exter-
nal condensation outlet is connected to it via siphon.
15 Condensation Tray Collects condensed water and drains it from the counterflow
heat exchanger to the condensation outlet.
16 Middle Panel/Door Counterflow heat exchanger cover for inspection and service.
17 Door Sliding doors/hinged doors for inspection and service (Hinged
doors can open left or right side, depending on user’s choice).
1.6.2 Parts of the CX3000 unit
Cabinet The inside and outside of the cabinet is made of galvanized steel. The cabinet is insulated with 50 mm
mineral wool.
Fans The unit contains two centrifugal fans with backward curved blades for exhaust air and supply air.
Counterflow heat
exchanger
The unit's counterflow heat exchangers are made of aluminium and are highly efficient. The counter-
flow heat exchangers can be taken out and cleaned.
Filters The unit includes integral panel filters for both exhaust air and supply air.
Condensation
outlet
The condensation outlet is located on the CX3000 unit door (see previous drawing in this section). The
condensation tray is positioned internally in the door.
Bypass damper The unit has an integral variably adjustable bypass, allowing for precise control of the supply air tem-
perature.
3006554-2023-01-12 Product information
14/80

1.7 Principal dimensions
1.7.1 CX3000, left units
CX3010L/CX3020L
Model a (mm) b (mm) c (mm)
CX3010L 1580 900 370
CX3020L 1720 1150 400
CX3030L/CX3040L/
CX3050L/CX3060L
Model a (mm) b (mm) c (mm)
CX3030L 1800 1500 480
CX3040L 2000 1650 565
CX3050L 2100 1650 580
CX3060L 2250 1970 580
3006554-2023-01-12 Product information
15/80

NB: In the above figure, dashed lines indicate duct connection dimensions.
Model d (mm) e (mm) f (mm) g (mm) h (mm) i (mm) j (mm) k (mm) l (mm) m (mm)
CX3010L 110 675 225 185 200 370 - - - -
CX3020L 110 863 288 200 250 370 - - - -
CX3030L 110 1125 375 267 517 300 550 600 370 226
CX3040L 110 1238 413 367 567 400 600 650 370 283
CX3050L 110 1238 413 367 567 400 600 650 370 290
CX3060L 110 1478 493 367 717 400 750 800 370 290
3006554-2023-01-12 Product information
16/80

Top view: CX3010L/
CX3020L
Model a (mm) b (mm) c (mm) d (mm) e (mm) f (mm) g (mm) h (mm) i (mm) j (mm) k (mm) l (mm)
CX3010 950 675 225 40 25 105 1500 1290 900 110 260 852
CX3020 1200 863 288 60 25 105 1600 1390 1150 110 260 852
3006554-2023-01-12 Product information
17/80

Top view: CX3030L/
CX3040L/CX3050L/
CX3060L
Model a (mm) b (mm) c (mm) d (mm) e (mm) f (mm) g (mm) h (mm) i (mm) j (mm) k (mm)
CX3030 1550 1125 375 25 105 1800 1590 1500 110 260 852
CX3040 1700 1238 413 25 105 2000 1790 1650 110 260 927
CX3050 1700 1238 413 25 105 2100 1890 1650 110 260 927
CX3060 2020 1478 493 25 105 2250 2040 1970 110 260 1002
3006554-2023-01-12 Product information
18/80

1.7.2 CX3000, right units
CX3010R/CX3020R
Model a (mm) b (mm) c (mm)
CX3010R 1580 900 370
CX3020R 1720 1150 400
CX3030R/CX3040R/
CX3050R/CX3060R
3006554-2023-01-12 Product information
19/80

Model a (mm) b (mm) c (mm)
CX3030R 1800 1500 480
CX3040R 2000 1650 565
CX3050R 2100 1650 580
CX3060R 2250 1970 580
NB: In the above figure, dashed lines indicate duct connection dimensions.
Model d (mm) e (mm) f (mm) g (mm) h (mm) i (mm) j (mm) k (mm) l (mm) m (mm)
CX3010R 110 675 225 185 200 370 - - - -
CX3020R 110 863 288 200 250 370 - - - -
CX3030R 110 1125 375 267 517 300 550 600 370 226
CX3040R 110 1238 413 367 567 400 600 650 370 283
CX3050R 110 1238 413 367 567 400 600 650 370 290
CX3060R 110 1478 493 367 717 400 750 800 370 290
3006554-2023-01-12 Product information
20/80
