1. GB - BESB/FSB – Product information
EXHAUSTO BESB/FSB box ventilators are used in air supply and extraction systems.
The ventilator is not to be used to transport solid particles, nor in areas
where there is a risk of explosive gases.
The ventilator must not be started with the service door open.
Description BESB/FSB is available in four different sizes, is completely insulated, and has a low-
noise centrifugal fan with cast aluminium backward-bent blades (B-impeller):
• BESB250-4-1EC/FSB250-4-1EC
• BESB315-4-1EC/FSB315-4-1EC
• BESB400-4-1EC/FSB400-4-1EC
• BESB500-4-1EC/FSB500-4-1EC
• BESB500-4-3EC
The ventilator has an internal insulated housing and an external cabinet, both made of
sheet aluminium.
Main components
Min. operating temperature: -12°C max. operating temperature +80°C
Ambient temperature when running: min. -30°C max. +40°C
1.1 Main parts
Pos. Part
a Cabinet
b Service door
c Motor
d B-impeller
e Fan housing
f Locking screws (supplied with screwdriver)
g Handle
h Mounting bars with vibration damper
i Self-tapping screws
j Hinges
k EC control/terminal box
m Air flow measuring probes (not included with BESB/FSB250)
ab
c
d
e
ih
k
-12°C - +80°C
-30°C - +40°C
+
-
m
g
f
j
RD13284-01
Fig. 1

3004348_2020_06_11.fm GB - BESB/FSB – Product information
5/82
The ventilator is delivered packaged and can be transported on a pallet. Once unpacked
the ventilator should be handled carefully, especially the spigots etc. Deformation could
result in internal damage to the moving parts.
If there is not a lot of space to move the ventilator, the service door can be dismounted
as shown in section 1.1.
NB The ventilator must not be lifted using the service door handle.
Weight
1.3.1 Fitting indoors
There are various ways of fitting the
ventilator indoors (Fig. 2).
With methods B and D the service door
must be kept in the open position during
service. A safety fitting for this purpose can
be supplied (including an assembly kit).
If the ventilator is to run intermittently, there
is a risk of condensation in the motor.
Therefore, use mounting method A or B
only.
Service access Wherever the ventilator is fitted, there
should be space enough to be able to open
the service door to an angle of approx. 80°
and to access the locking screws.
Warning The motor must never be placed vertically under the cabinet and the
motor and EC control must never be covered or they will overheat.
1.2 Transport
BESB/FSB 250 315 400 500
kg 52 57 73 88 91 (-3)
1.3 Fitting
Fig. 2
RD13304-01
D
D
Fig. 3

3004348_2020_06_11.fm GB - BESB/FSB – Product information
6/82
1.3.2 Fitting outdoors (OD)
OD type ventilators are designed for
outdoor use and can be used for
transport of air in the temperature range
up to 200°C. This version is also fitted
with a drain in installation method "A"
A and B fitting methods should be
used for outdoor fitting. Fitting
methods C and D require a specially
designed ventilator (Fig. 4) — contact
EXHAUSTO.
All exterior seams, including spigots
have been jointed to prevent water from
getting inside.
The cabinet is class C4 DS/EN ISO12
944.2 certified and designed for
outdoors.
Service access Wherever the ventilator is fitted, there should
be space enough to be able to open the
service door to an angle of approx. 80° and to
access the locking screws.
1.3.3 Fitting the mounting bars
• Mounting should be done on a stable vibration-resistant base, to minimise any
vibration that might be caused by the ventilator. A cement slab placed on a
wooden base construction is recommended.
• Fit the mounting bars on the cabinet with the supplied fitting screws. The cabinet
has holes already bored for fitting method A.
•BESB/FSB 400 and 500: When using fitting method B (Fig. 2/4) for BESB/FSB
400 and 500, holes (Ø16 - Ø20) are bored in the cabinet for the fitting of the
mounting bars.
• Fit the mounting bars while the ventilator is on the pallet.
• Sit the ventilator on the supporting base. Do not fasten the ventilator to the base.
A
B
C
D
Fig. 4
Fig. 5
RD13304-01
D
D
RD13303-01
Fig. 6

3004348_2020_06_11.fm GB - BESB/FSB – Product information
7/82
General
The wiring must only be done by a qualified electrician.
The fan and motor specifications are listed
on the type-plates.
Max. fuse rating = 13 Amp.
Max. short circuit current is 10 kA
At start-up and during the initial adjustment of the fan, it is important to control the
direction of rotation of the motor and to check the motor current does not exceed the
manufacturer’s recommended operating current for the motor (to avoid damaging the
motor).
Isolation switch EXHAUSTO A/S would like to draw attention to the fact that, in
accordance with the EU's Machine Directive (appendix 1) all fan
systems shall include a isolation switch.
The isolation switch must ...
• be lockable or positioned in plain sight in the immediate vicinity of the fan
• be able to disconnect all poles from the supply voltage
— contact distance of at least 3 mm in each pole
• Set up as isolation switch in accordance with standard IEC 60947-1 or
IEC 60947-3.
The isolation switch is not supplied by EXHAUSTO.
Lightning
conductor
Any lightning conductor connected to the fan must be in accordance with applicable
regulations and legislation.
1.4 Wiring
RD13301-01
Fig. 7
If the fuse is a ...it must have the characteristic
melting fuse gG or gM.
control fuse B or C, and comply with IEC 90947-2. -

3004348_2020_06_11.fm GB - BESB/FSB – Product information
8/82
1.4.1 Ventilator with EC control
General Ventilators marked “EC” have a built-in EC control system.
Cables The wiring for control signal inputs must be completely insulated from the supply wirings.
ESD
The electrician must be ESD protected when
• detaching the cover on the EC control
• working with the EC control
1.4.1.1 BESB250-4-1EC & BESB315-4-1EC
Cabletype Cables for control signals must be with twisted pair conductors. As a minimum, the cable
type must be CAT5e Ethernet cable.
Diagram
* Not supplied by EXHAUSTO.
Key to diagram
Terminal Clamp Signal description
J9
A RS485 + (A)
B RS485 - (B)
0V 0 V DC (chassis)
J8
DIR Direction af rotation
RUN Start/Stop
0V 0 V DC (chassis)

3004348_2020_06_11.fm GB - BESB/FSB – Product information
9/82
Positioning of dip
swiches
J7
U Out 10V DC
U In 0-10V DC
0V 0 V DC (chassis)
J5
NC Alarm NC
COM Alarm C
NO Alarm NO
Terminal Clamp Signal description
Fig. 9

3004348_2020_06_11.fm GB - BESB/FSB – Product information
10/82
1.4.1.2 FSB250-4-1EC, FSB315-4-1EC, BESB/FSB400-4-1ECog BESB/FSB500-4-1EC
Cabletype Cables for control signals must be shielded.
Diagram
* Not supplied by EXHAUSTO.
Key to diagram
Leakage current When operating the EC control converters have a leakage current of less than 3.5 mA.
The leakage current must be earthed, as there is a risk of the motor becoming live.
Fig. 10
Terminal Signal description
100 10 V DC
101 0-10 VDC
102 0 V DC (chassis)
103 Direction of rotation
104 Start/Stop
105 0 V DC (chassis)
106 RS485 + (A)
107 RS485 - (B)
108 0 V DC (chassis)
11 Alarm C
12 Alarm NC
13 Alarm NO

3004348_2020_06_11.fm GB - BESB/FSB – Product information
11/82
Earth leak circuit
breakers
If current earth leak circuit breakers are fitted in the installation, they must be of
a type that meets the following requirements:
• PFI type A breaker that breaks the circuit when a vagrant current with DC
content (pulsating DC) in accordance with EN 61008.
• The circuit breakers must be marked with the following symbol:
Requirements • Disconnection time of max 0.3 seconds
Dimensioning of
the neutral
conductor.
Multiple one-phase BESB/FSB with EC installations in a shared network with a common
neutral, require special dimensioning of the neutral, as the current is not a pure sine
wave.
Example For example if three EC motors are installed, sharing 3-phases, the neutral current is
the sum of the three motors’ current.
Existing
installations
If you are fitting motors to an existing installation, check that the neutral conductor can
cope with the resultant load.
1.4.1.3 BESB/FSB500-4-3EC
Cabletype Cables for control signals must be shielded.
Diagram
* Not supplied by EXHAUSTO.
Fig. 11

3004348_2020_06_11.fm GB - BESB/FSB – Product information
12/82
Key to diagram
Dipswitch 1 • Dip 1-6: Modbus address
• Dip 7-8: Always OFF
• Dip 9: Analog source(0-10V) or EFC1P
• Dip 10: Always OFF
Leakage current The EC control produces a leakage current when running. The leakage current must be
earthed, as there is a risk of the motor becoming live.
A leakage current of up to 150 mA can be generated.
To comply with EN50178, the fan must be suitably earthed.
Earth leak circuit
breakers
If current earth leak circuit breakers are fitted in the installation, they must be of
a type that meets the following requirements:
• PFI type B breaker according to EN 61008, that breaks the circuit when a
vagrant current with DC content (pulsating DC) or smooth vagrant current
is registered.
• The circuit breakers must be marked with the following symbols:
Terminal Signal description Comments
1 Alarm in EFC1P panel A
2 0 V DC (chassis) EFC1P panel B
3 Start/stop EFC1P panel 2
4 0 V DC (chassis) EFC1P panel 3
5 0-7 V DC EFC1P panel 4
6 7 V DC EFC1P panel 5
7 0-10 V DC
8 0 V DC (chassis)
9 RS485 + (A)
10 RS485 - (B)
11 0 V DC (chassis)
12 Alarm NO
13 Alarm C
14 Alarm NC
Dip 9
0-10 Volt OFF
EFC1P panel ON

3004348_2020_06_11.fm GB - BESB/FSB – Product information
13/82
1.4.2 Fault finding 1-phase and 3-phase EC control
1-phase NOVA EC-control
1-phase EC-control
3-phase EC control
Diodes • Diode 1: Red
• Diode 2: Yellow
• Diode 3: Green
Troubleshooting
chart
• Green diode lights up: no errors
• Red diode lights up: there is an error. Alarm relay has been tripped.

3004348_2020_06_11.fm GB - BESB/FSB – Product information
14/82
• Yellow diode: blinks for error type
NB When the error has been remedied, the LED indicator (LED blink) on the EC control can
be reset by temporarily cutting the power until the LED goes out.
EXHAUSTO provides a two-year manufacturer's warranty on the fan.
Error code Green Red Yellow Error Relay
None + - -
1 Reserved Not implemented
2 - + Blinks twice/pause 4 seconds Below voltage 170 v +
3 - + Blinks 3 times/pause 4 seconds Above voltage 255 v +
4 + - Blinks 4 times/pause 4 seconds Overcurrent: Reduced
rpm
-
5 Reserved Not implemented
6 + - Blinks 6 times/pause 4 seconds Overheating:
Reduced rpm
-
7 - + Blinks 7 times/pause 4 seconds Overheating: Stop +
8 - + Blinks 8 times/pause 4 seconds Hardware error +
9 - + Blinks 9 times/pause 4 seconds MCE Fault (IRF Chip
general fault)
+
10 - + Blinks 10 times/pause 4 seconds Motor blocked +
11 - + Blinks 11 times/pause 4 seconds Motor phase missing +
12 Reserved Not implemented
13 Reserved Not implemented
14 Reserved Not implemented
15 Reserved Not implemented
16 - + Blinks 16 times/pause 4 seconds Communication error +

3004348_2020_06_11.fm GB - BESB/FSB – Product information
15/82
Flexible
connections
The ventilator must always be connected to the duct system with FLF, to avoid any
chance of vibrations being transmitted. The spigots on the ventilator are standard-sized
and fitted with rubber seals.
To achieve maximum performance with minimal energy consumption the ventilator
should be connected to the duct system with the specified lengths of duct before and
after the ventilator. The FLF connections must always be fitted as shown.
Sound pressure
level
The ventilator is fitted with sound dampers suited to the requirements of the operating
area. The sound pressure for all types of BESB/FSB is less than 70 dB (A). The duct
system is insulated against sound propagation, heat loss, fire and condensation.
No Duct A protective net (accessory) with mesh size of 12 mm must be fitted if the ventilator is
not fitted to a duct. It should be noted that:
• such fittings result in a pressure drop in the system
• Air volume measurements cannot be measured correctly when there is no duct
fitted on the suction side
1.5 Connecting to duct system:
RD11360-01
Fig. 12
RD11361-01
Fig. 13
Fig. 14

3004348_2020_06_11.fm GB - BESB/FSB – Product information
16/82
The box ventilators, apart from model BESB/FSB250, have measuring points for
determining air flow. A manometer is connected to the test points and the air flow (qv)
can be calculated by using the formula and diagrams.
Margin of error < ± 8% of actual air flow with the duct system on the suction side is as
shown on the diagrams.
Calculations are based on the following conditions:
Temperature: 20°C
Density: 1.2 kg/m3
Pressure measurement, pm [Pa], at 20°C
1 m3/s = 1000 l/s = 3600 m3/h
1.6 Airflow measurement
BESB/FSB315:
BESB/FSB400:
BESB/FSB500:
qv59 pm l s =
qv85 pm l s =
qv91 pm l s =

3004348_2020_06_11.fm GB - BESB/FSB – Product information
17/82
EXHAUSTO provides a two-year factory warranty on the box ventilator, valid from
invoice date. The motor in an EXHAUSTO box ventilator is fitted with special ball
bearings that are lubricated and sealed, and maintenance-free. Any replacement of
these bearings should be carried out by technicians from EXHAUSTO SERVICE or
similarly qualified professionals.
The ventilator must be cleaned at least once a year. To clean the ventilator:
• Switch off the power supply to the
ventilator using the isolation switch.
Open the service door when the fan
has stopped running.
• Wash the ventilator housing and the
centrifugal impeller thoroughly with
soap and water. The parts must be
dry and the service door closed
before the ventilator is restarted.
• The centrifugal impeller can be
dismounted and cleaned. Measure
the exact position of the impeller on
the axle before removing it. The
factory position of the impeller is
shown on the cabinet behind the
service door. If there are weights on
the centrifugal impeller do not remove
them.
• Check that cooling air can move
freely through the motor cover.
Product
description
EXHAUSTO BESB/FSB is a an easily serviced radial fan with backward curved blades.
The fan is insulated against fire, noise and heat with 50 mm of mineral wool. The fan
impeller is directly mounted on the motor shaft, thus reducing losses and wear and
resulting in lower repair costs.
Servicing and cleaning are performed by opening the hinged door for access to all parts
in contact with the air. The motor is mounted outside the airstream.
The fan is supplied with mounting rails with vibration dampers. The fan is CE approved
and EMC tested in accordance with the applicable directives.
Materials used Cabinet, fan housing and mounting rails are made of recycleable hot-dip galvanised
steel sheet. Fan impellers are made of recycleable pressure-cast aluminium.
The insulation consists of mineral wool which can be recycled after dismantling the fan.
The gaskets consist of CFC and HCFC free cellular rubber.
The motor consists of aluminium, steel and copper, and in some cases a plastic cooling
jacket. The packaging consists of corrugated cardboard and a wooden disposable
pallet.
1.7 Service and cleaning
RD13302-01
Fig. 15
1.8 Environmental declaration

3004348_2020_06_11.fm GB - BESB/FSB – Product information
18/82
Materials in %
BESB/
FSB250
BESB/
FSB315
BESB/
FSB400
BESB/
FSB500
BESB500
3-phase
Aluminium 11% 13% 14% 14% 14%
Fe 74% 70% 70% 70% 70%
Copper 1% 1% 1% 2% 2%
Mineral wool 9% 11% 12% 12% 12%
PCB;
electronic
components
3% 3% 2% 1% 2%
Plastic, cellular
rubber
1% 1% 1% 1% 1%
Other 1% 1% 1% < 1% 1%

3004348_2020_06_11.fm DK - BESB/FSB - Produktvejledning
19/82
1. DK - BESB/FSB - Produktvejledning
EXHAUSTO boxventilator BESB/FSB anvendes til transport af luft i indblæsnings- og
udsugningsanlæg.
Ventilatoren må ikke anvendes til transport af faste partikler, eller hvor
der er risiko for eksplosive gasarter.
Ventilatoren må ikke startes med åben servicelåge.
Beskrivelse BESB/FSB findes i 4 størrelser og er en totalisoleret og lyd-svag centrifugalventilator
med bagudbøjede skovle (B-hjul) i støbt aluminium:
• BESB250-4-1EC/FSB250-4-1EC
• BESB315-4-1EC/FSB315-4-1EC
• BESB400-4-1EC/FSB400-4-1EC
• BESB500-4-1EC/FSB500-4-1EC
• BESB500-4-3EC
Ventilatoren består indvendigt af et ventilatorhus, som er isoleret, og udvendigt af et
kabinet, begge dele af aluzink.
Hoved-
komponenter
Temperatur medie min.: -12°C max.: +80°C
Temperatur omgivelser, drift min.: -30°C max.: +40°C
1.1 Opbygning
Pos. Part
a Kabinet
b Servicelåge
c Motor
d Centrifugalhjul (B-hjul)
e Ventilatorhus
f Låseskrue (værktøj medleveres)
g Håndtag
h Bæreskinne med svingningsdæmpere
i Selvskærende skrue
j Hængsel
k EC-styring/klemkasse
m Målestudse til luftmængde måling (ikke BESB/FSB250)
Fig. 1
ab
c
d
e
ih
k
-12°C - +80°C
-30°C - +40°C
+
-
m
g
f
j
RD13284-01

3004348_2020_06_11.fm DK - BESB/FSB - Produktvejledning
20/82
Ventilatoren leveres emballeret og kan transporteres på træpalle. Efter udpakning skal
ventilatoren transporteres og behandles således, at kabinet og studse m.v. ikke
deformeres, da dette kan forårsage berøring imellem roterende dele og heraf følgende
behov for efterjustering/reparation.
Ved transport gennem trange passager ind til opstillingsstedet, er der mulighed for
demontering af servicelågen som vist i afsnit 2.1” Opbygning”.
Bemærk Ventilatoren må ikke løftes i håndtaget på servicelågen.
Vægt
1.3.1 Indendørs placering
Ventilatoren kan indendørs monteres på
forskellige måder (fig. 2).
Ved monteringsmetode B og D skal
servicelågen kunne fastholdes i åben
position ved servicering. Til dette formål
kan leveres et sikkerhedsbeslag incl.
monteringssæt som tilbehør.
Ved intermitterende drift, hvor der er risiko
for kondensvand i motoren, må kun
monteringsmetode A eller B benyttes.
Serviceadgang Ved udvælgelse af den nøjagtige placering
skal der være plads til, at servicelågen kan
åbnes ca. 80° og der skal være adgang til
låseskruerne.
Advarsel Motoren må aldrig placeres lodret under kabinettet og desuden skal det
sikres, at motor og EC-styring ikke tildækkes, da det vil kunne forårsage
overophedning.
1.2 Transport
BESB/FSB 250 315 400 500
(kg) 52 57 73 88 91(-3)
1.3 Montage
Fig. 2
RD13304-01
D
D
Fig. 3
