Exitronix 400 Series User manual

EMERGENCY EXIT SIGN
400 SERIES
Die Cast Aluminum LED
IMPORTANT
SAFEGUARDS
READ AND FOLLOWALL
SAFETY
INSTRUCTIONS
Do not use outdoors.
Do not mount near gas or electric heaters.
Equipment should be mounted in locations and at heights
where it will not readily be subjected to tampering by un-
authorized personnel.
The use of accessory equipment not recommended by the
manufacturer may cause an unsafe condition.
Do not use equipment for other than intended use.
SAVE THESE INSTRUCTIONS
MEETS OR EXCEEDS UL 924
MANUFACTURED BY:
A DIVISION OF
BARRON MANUFACTURING
CORPORATION
2019 W. LONE CACTUS DRIVE
PHOENIX, AZ 85027
(623) 580-EXIT
800-LED-EXIT
FAX [phone]
www.exitronix.com
10070009-7/27/04
WARRANTY
25 YEAR LIMITED*
EXITRONIX, A Division of Barron Manufacturing
Corp. will replace or repair any components,
which fail due to manufacturer’s defects or work-
manship, for a period of 25 years. The warranty
does not cover physical damage or abuse, and
Barron Manufacturing reserves the right to
charge for such repairs if deemed
necessary.
*Battery is covered separately by a 5 year
warranty through manufacturer.
NEVER CHANGE
ANOTHER
BULB!!!
LISTED
9801680

WARNING: Installation and servicing should be performed by qualified service personnel only!
For indoor use only, unless model number is suffixed with DR. Connect no other accessories of any kind to this product.
Please review instructions and determine knockout locations before beginning installation.
TESTING
♦When AC power is applied, the word “EXIT“ will illu-
minate. For units with batteries, the green “AC On”
indicator will also illuminate, indicating the charging
circuit is functioning.
♦Pressing the “Test” button will disconnect AC power,
during emergency operation, the green “AC On” LED
will extinguish.
DOUBLE FACE
SIGNS
SINGLE FACE SIGNS
SINGLE FACE MOUNTING INSTRUCTIONS
1 Remove faceplate by pulling it away from the enclo-
sure.
2 Carefully remove red or green diffuser from faceplate
and knock-out desired arrow(s) from the inside out,
replace diffuser.
3 Remove four (4) screws from Pan Reflector/
Electronics assembly and remove from enclosure.
4 Mount enclosure to wall or ceiling using knockouts
provided and/or included canopy kit.
5 Make electrical connections in accordance with local
building codes using knockouts provided.
For 120V Use Black & White Wires
For 277V Use Orange or Blue and White Wires
6 Replace Pan Reflector/Electronics assembly in enclo-
sure and secure with four (4) screws.
7 Be sure all wiring is routed behind pan to avoid shad-
owing on Faceplate.
8 Close unit by snapping Faceplate onto Enclosure.
DOUBLE FACE MOUNTING INSTRUCTIONS
1 Remove faceplate by pulling it away from the enclo-
sure at the top edge of the sign.
2 Carefully remove red or green diffuser from faceplate
and enclosure and knock-out desired arrow(s) from the
inside out, replace diffusers.
3 Mount Canopy to Enclosure using threaded pipe and
nuts.
4 Route Battery (if equipped) and Transformer leads
from electronics mounted on Canopy Plate into enclo-
sure and plug them into LED strip, be sure to route
wires near edges of enclosure to avoid shadowing the
Faces of the sign.
5 Secure Mounting Plate to junction box on wall or ceil-
ing.
6 Make electrical connections in accordance with local
building codes using knockouts provided.
7 Secure Enclosure/Canopy assembly to Mounting Plate
screws using two (2) acorn nuts provided..
8 Close unit by snapping Faceplate onto Enclosure.
FLASHING SPECIFICATIONS
♦Units suffixed with FB and FL have a flashing legend
during emergency operation.
♦Units suffixed with A1 and A2 will flash when trig-
gered by an external fire alarm relay. The flash rate is
40 cycles/minute with a 50% duty cycle.
