Extech Instruments EC210 User manual

UserGuide

ConductivityMeter

ModelEC210




































EC210-en-GB_V1.1 11/14
2
Introduction
ThankyouforselectingtheExtechEC210conductivitymeterwhichsimultaneouslydisplays
conductivityandTemperature.Conductivityismeasuredwitharemoteelectrodethatincludesa
thermistorformeasuringtemperature.Thisdeviceisshippedfullytestedandcalibratedand,with
properuse,willprovideyearsofreliableservice.Pleasevisitourwebsite(www.extech.com)to
checkforthelatestversionofthisUserGuide.
Features
Threeranges2000uS,20mS,and100mSwithautorangefunctionality
Conductivity,TDSandtemperaturemeasurementfunctions
Detachableprobeforeaseofuseinavarietyofmeasurementenvironments
Useradjustableautomatictemperaturecompensation(setto‘0’foruncompensated
Conductivitymeasurements)
Carbonrodelectrodetypeforlongevity
LCDdisplayshowsConductivityandTemperaturesimultaneously
DATAHOLDforholdingdisplayedreading
RecordandviewMINMAXreadings
ProgrammingmodeforselectingoC/oFtemperatureunits,enabling/disablingtheauto
poweroffutility,andprogrammingthetemperaturecompensationfunctionality


EC210-en-GB_V1.1 11/14
3
3
1
2
4
5
6
7
89
MeterDescription

1. Mainmeasurementdisplay
2. Temperaturereading
3. Power/Escapebutton
4. Function/Hold/Uparrowbutton
5. Record/Enterbutton
6. Setting/downarrowbutton
7. Batterycompartment(rear)
8. Probeconnection
9. Probe




EC210-en-GB_V1.1 11/14
4
ConductivityCalibration
1. ConnecttheConductivityelectrodetotheinputsocketatthebottomofthemeter.
2. SwitchthemeterONbypressingthePOWER/ESCbutton.
3. PrepareaConductivityStandardSolution(forexample,1.413uS).
4. Holdtheprobebyitshandleandimmersethesensingelectrodecompletelyinthe
standardsolution.Shake/stirthesensingelectrodetoallowtheelectrode’sinternalair
bubblestoescapefromthesensingelectrode.
5. PresstheHOLDbuttonandthedisplaywillshowtheHOLDicon.
6. PresstheRECbuttonandtheupperdisplayareawillshowCALandthelowerdisplayarea
willshowYES.Toabortatthispoint,simplywaitandthemeterwillreverttothenormal
operatingmode.
7. Tocontinue,presstheENTERbuttonandthedisplaywillshowtheConductivityreading,
themeasurementunit,and,shortlyafter,theflashingCALicon.Notethatthemeterwill
showENDiftheelectrodedoesnotdetectanappropriatesolutionvalue.
8. WhiletheCALiconisflashingusethearrowbuttonstoadjustthedisplayedConductivity
readingtomatchtheConductivityvalueofthesolution.
9. AfterafewsecondsthemeterwilldisplayEND.Calibrationiscomplete.
ConductivityMeasurements
MeasurementPreparation
Beforetakingmeasurements,performthecalibrationdescribedaboveifnecessary.
TakingConductivityMeasurements
1. Connecttheelectrodetotheprobeinputsocket.
2. SwitchthemeterONbypressingthePOWER/ESCbutton.
3. IfthedisplaydoesnotshowConductivityunits(uSormS),pressandholdtheFUNCTION
buttonuntiltheConductivityunitsaredisplayed.
4. Thelowerdisplaywillindicatethetemperaturevalue.
5. Theupperdisplayshowstheconductivityvalue.
6. Holdtheelectrodeinhandandfullyimmersethesensingheadinthestandardsolution.
7. Theupperdisplaywillshowtheconductivityvalueofthemeasuredsolution.Thebottom
displaywillshowthetemperaturevalueofthemeasuredsolution.
8. Rinsetheprobewithdistilledwateraftereachuse.


EC210-en-GB_V1.1 11/14
5
TDSMeasurements
1. Connecttheelectrodetotheprobeinputsocketatthebottomofthemeter.Immersethe
probeinthemeasurementsolution.
2. SwitchthemeterONbypressingthePOWER/ESCbutton.PressandholdtheFUNCTION
buttonuntiltheppmunitsaredisplayed.
3. Thelowerdisplayshowsthetemperaturevalue.
4. TheupperdisplayindicatestheTDSvalue(measuredinppm).
5. Holdtheelectrodeinhandandfullyimmersethesensingheadinthestandardsolution
6. Theupperdisplaywillshowtheppmvalueofthemeasuredsolution.Thebottomdisplay
willshowthetemperaturevalueofthemeasuredsolution.
7. Rinsetheprobewithdistilledwateraftereachuse.
8. PressandholdtheFUNCTIONbuttonforatleast2secondstoreturntotheconductivity
measurementmode.

SolutionTemperature
Thelowerdisplayindicatesthetemperatureofthemeasuredsolution.RefertotheSetupMode
sectionforinstructionsonselectingoC/oFtemperatureunitsandforadjustingtheautomatic
temperaturecompensation.

DataHold
PresstheFunction/Holdkeytofreezethedisplayedvalue.TheLCDwilldisplayHOLDalongwith
theheldreading.PresstheHoldkeyagaintoreleasethedataholdfunction.

MIN‐MAXDataRecording
Whenselected,theDataRecordingfunctionrecordstheMinandMaxreadings:
1. PresstheRECbuttononce.TheRECindicatorwillappearonthedisplay.PressRECbutton
onceagainandRECMAXwilldisplayonthescreenalongwiththemaximumvalue.
2. PressRECagainandthedisplaywillshowRECMINandtheminimumvaluewillbe
displayed.
3. ToreleasetheheldMAXorMINreading,presstheHOLDbuttonwhileeithertheRECMAX
orRECMINiconsarevisible;nowonlytheRECiconwillbevisible.Themeterisnow
continuingtomonitorthehighest(MAX)andlowest(MIN)readingsbutisdisplayingreal
timemeasurements.ToviewtheMAXandMINvaluesagainusetheRECbuttonas
describedearlier.
4. ToexittheRecordmode,pressandholdtheRECbuttonforatleast2seconds.Thedisplay
willreturntothenormaloperatingmode.


EC210-en-GB_V1.1 11/14
6
Setupmode
Note:IftheHOLDorMIN/MAXfunctionsareactivetheSetupmodecannotbeaccessed.

ToentertheSetupModepressandholdtheSETTINGbuttonforatleast5seconds(untilthebeep
isheard)andthenusetheSETTINGbuttontoscrollthroughthesetupoptions.Theoptionsare:
SEtAutomatictemperaturecompensationpercentage;settablefrom0.00to5.00%per°C
(thedefaultis2.00%).Setto0.00%totakeuncompensatedConductivitymeasurements.
Whenpoweriscycledthisparameterwillreverttothedefault2.00%
°C/FSelectthetemperatureunits(°C°F)
OFF/ONAutopoweroffdisable/enable

Continuewiththeinstructionsbelow:

TemperatureCompensationPercentSetting(SEt)
WhenthedisplayshowsSEtpressENTER.SEtwillflashandtheupperdisplaywillshowthe
temperaturecompensationpercent.Usethe▲and ▼buttonstosetthedesired
temperaturecompensationpercentage.Afterselectingthedesiredvalue,pressENTERto
savethedata.Thedisplaynowshowsthetemperatureunits.Continuebelow:
TemperatureUnitsSelect
ThelowerdisplayshowsCorF.Usethe▲buttontoselectthedesiredunitofmeasureand
thenpressENTERtosave.ThelowerdisplayshouldnowshowOFFYESorNO.Continue
below:
AutoPowerOFFEnable/Disable
ThedisplaywillshowOFFYESorOFFNO.Usethe▲buttontoselectYESorNO.
YES:AutopowerOFFisenabled(meterswitchesoffautomaticallyafter10minutes)
NO:AutopowerOFFisdisabled
PressENTERtosavetheselection.Themeterwillreturntothenormaloperatingmode.


EC210-en-GB_V1.1 11/14
7
BatteryReplacement
The9Vbatterythatpowerstheinstrumentrequiresreplacingwhenthebatteryiconflasheson
thedisplay.Toreplacethebatteryfollowthestepsbelow:
1. Disconnecttheprobefromtheinstrument.
2. OpentherearbatterycompartmentusingascrewdrivertoremovethetwoPhillipshead
screwsthatsecurethecompartment.
3. Carefullyremovetheoldbatteryfromthecompartmentlidchamberandgentlyunsnap
thebattery’sterminalsfromthewired(red/black)connectors.
4. Installanew9Vbatterybysnappingthebatteryterminalsontothewiredconnectors
(observingcorrectpolarity)andinsertingthebatteryintothecompartmentlidchamber.
5. Installthecompartmentlidchamberintothemeterhousingandsecurewiththetwo
screws.

Neverdisposeofusedbatteriesorrechargeablebatteriesinhouseholdwaste.
Asconsumers,usersarelegallyrequiredtotakeusedbatteriestoappropriate
collectionsites,theretailstorewherethebatterieswerepurchased,orwherever
batteriesaresold.
Disposal:Donotdisposeofthisinstrumentinhouseholdwaste.Theuserisobligatedtotake
end‐of‐lifedevicestoadesignatedcollectionpointforthedisposalofelectricalandelectronic
equipment.



EC210-en-GB_V1.1 11/14
8
Specifications
GeneralSpecifications
CircuitCustomone‐chipLSImicroprocessorcircuit
DisplayDualfunctionLCD
Dimensions:44mmX29mm(1.73x1.14”)
MeasurementsConductivity,TDS,Temperature
DataholdDataholdfreezesdisplayedreading
MemoryrecallMin/Maxreadingsstoreandrecall
AutopoweroffMeterswitchesoffafter10minutes(canbedisabled)
Samplerate1second(approx.)
OperatingconditionsTemperature:0to50°C(32to122°F);Humidity:<80%RH
Batterypower9Valkalinebattery
PowerConsumptionApprox.6.0mADC
Weight295g(0.65lbs.)includingbatteries&probe
DimensionsMeter:135x60x33mm(5.3x2.4x1.3")
Probe:22mm(0.87”)diameterx120mm(4.72”)length


ElectricalSpecifications
MeasurementRangeResolutionAccuracy
Conductivity20.00mS/100.0mS/2000uS0.01mS/0.1mS/1uS+(2%FS+1dgt)
TDS1,200/12,000/66,000ppm1/10/100ppm+(2%FS+1dgt)
Automatic
Temperature
Compensation
range
0to50oC(32to122oF)



Copyright©2014FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
www.extech.com



