Extech Instruments RF20 User manual

User's Guide
Portable Salinity Refractometer with ATC
Model RF20
Introduction
Congratulations on your purchas e of the Extech RF20 Handheld Salinity Refractometer
with Automatic Temperature C ompensation. This precision optical instrument should be
handled gently; avoid touching the optical surface. Careful use of this instrument will
provide years of reliable service.

RF20 Version 1.1 September 2003
2
Warranty
EXTECH INSTRUMENTS CORPORATION warrants this instrument to be free of defects in parts and
workmanship for one year from date of shipment (a six month limited warranty applies on sensors and
cables). If it should become necessary to return the instrument for service during or beyond the warranty
period, contact the Customer Service Department at [phone] ext. 210 for authorization or visit our
website at www.extech.com (click on ‘Contact Extech’ and go to ‘Service Department’ to request an RA
number). A Return Authorization (RA) number must be issued before any product is returned to Extech. The
sender is responsible for shipping charges, freight, insurance and proper packaging to prevent damage in
transit. This warranty does not apply to defects resulting from action of the user such as misuse, improper
wiring, operation outside of specification, improper maintenance or repair, or unauthorized modification.
Extech specifically disclaims any implied warranties or merchantability or fitness for a specific purpose and
will not be liable for any direct, indirect, incidental or consequential damages. Extech's total liability is limited
to repair or replacement of the product. The warranty set forth above is inclusive and no other warranty,
whether written or oral, is expressed or implied.
Specifications
Scale Range Resolution
Parts Per Thousand 0 to 100
0
/
00
1
0
/
00
Specific Gravity 1.000 to 1.070 d
20
/
20
0.001 d
20
/
20
Dimensions 7.6 x 1.5 x 1.5" (194 x 38 x 38mm)
Weight Approx. 8.0 oz. (227g)
Description
1. Prism
2. Cover Plate
3. Adjustment Screw
4. Mirror Tube
5. Eyepiece
1 2 3 4 5

RF20 Version 1.1 September 2003
3
Operation
The instrument measures the refractive index of the sample and displays the result in parts
per thousand (
0
/
00
) and specific gravity (d
20
/
20
).
1. Zero Adjustment
Put distilled water on the prism; e nough to cover the entire prism. Close the cover plate
and rotate the adjusting screw so that the lig ht/dark boundary line (known as the
shadow-line) evens up with the zero line. After the zero adjustment, clean the prism wit h
soft cloth.
2. Sample Preparation and Reading
To take a reading, place a fe w drops of a sample liquid on the measurement prism.
Ensure that enough solution is added to the p rism in order to cover the entire prism.
Close the prism so that the liquid spreads across the entire surface of the prism without
air bubbles or dry spots (see diag rams below). Allow the sample to remain on the prism
for approximately 30 seconds.
While holding the instrument u nder a light
source, look through the e yepiece. The
salinity concentration is determined b y the
intersection of the bounda ry of the light
and dark fields (known as the shado w-
line) on the printed scale. The lef t side of
the scale indicates the specific gravity and
the right side p arts per thousand. If the
scale appears out of focus, the eyepiece
may be adjusted by rotating the knurled
portion. The instrument also features an
eye guard to prevent stray li ght from
entering the eyepiece and causing
reflections.
It ma y be necessary to adjust the position of the light source to maximize the contrast of
the shadow-line. Under normal conditions, optimal contrast is obtained by holding the
instrument underneath and perpendicular to a light source.
Once a reading has been taken, wipe dry with a clean cloth (do not wash or rinse) and
place the instrument in the supplied plastic case. Store the instrument in a safe, dry
environment.
Temperature is the single most important facto r influencing refractometer readings and
is one of the largest sources of measurement erro r. However, this device incorporates
automatic temperature compensation and the conc ern for temperature fluctuations in
sample liquids is alleviated. When ambient temperature varies from 68°F (20°C ),
readings are automatically adjusted to compensate for temperatu re variance between
50°F to 86°F (10 °C to 30°C).
Bad Bad Good

Support Hotline [phone]
Tech support: Ext. 200; Email: [email protected]
Repair/Returns: Ext. 210; Email: [email protected]
Website: www.extech.com
Calibration and Repair Services
Extech oers complete repair and calibration services for most of the products we sell.
For periodic calibration, NIST certication or repair on most Extech products, call customer
service for details on services available. Extech recommends that calibration be performed
on an annual basis to ensure calibration integrity.
Copyright © 2003 Extech Instruments Corporation.
All rights reserved including the right of repr oduction in whole or in part in any form.
