Extech Instruments EMF450 User manual

USER MANUAL
Multi-Field EMF Meter
Model EMF450
Additional User Manual Translations available at www.extech.com

EMF450-en-GB_V1.47/17
2
Safety Information
CAUTIONS
•Before making a measurement, check if the low battery symbol is shown on the display
when the meter is switched on. Replace the battery if the symbol is displayed.
•In the case of prolonged storage, remove the battery from the meter to prevent damage.
•Do not expose this device to direct sunlight or to extreme temperatures and humidity.
•The accuracy and function of the meter may be adversely affected if the specified limits are exceeded or if
the meter is handled improperly.
•Clean the device with a soft, dry cloth. Moisture can damage the meter.
•Electric field measurement precautions: Perform tests according to the indicated directions.
WARNINGS
•Use caution when working in the vicinity of powerful radiation sources.
•Persons with electronic implants (e.g. cardiac pacemakers) should avoid powerful radiation sources.
•Observe all relevant safety regulations.
•Carefully read the operating instructions for equipment generating or conducting electromagnetic
energy that will be measured.
•Do not operate near combustible gases or in damp environments.
•Be aware that the field strength in the near vicinity of radiators increases proportionally to the inverse
cube of the distance. This means that enormous field strengths can result in the immediate vicinity of
small radiation sources (e.g. leaks in waveguides or inductive ovens).
•Field strength measurement devices can underrate pulsed signals, particularly with radar signals, in which
case significant measurement errors can result.
•All field strength measuring devices have a limited specified frequency range. Fields with spectral
components outside of this frequency range are generally incorrectly evaluated and tend to be
underrated. Before using field strength measuring devices be certain that all field components to be
measured lie in the specified frequency range of the measuring device.
•For indoor use; Pollution level II
•Operating altitude below 2000’ (6562’)

EMF450-en-GB_V1.47/17
3
Introduction
This meter simultaneously measures and displays Magnetic Field, Electric Field, and RF Strength.
The unit of measurement and the measurement types are expressed in units of electrical and
magnetic field strength and power density. This meter is ideal for EMF measurements of power
lines, electrical appliances, industrial devices, cell phones, base stations, and microwave leakage.
This device is shipped fully tested and calibrated and, with proper use, will provide years of
reliable service. Please visit our website (www.extech.com) to check for the latest version of this
User Guide, Product Updates, Product Registration, and Customer Support.
Features
•Data hold (HOLD)
•Overload display “OL”.
•Brightness options: low-medium-high
•Selectable Auto Power off (APO) Time: 1; 3; 5; 10; 15; 30 minutes
•Key press Sounds / Alarm Sounds: On ; Off with programmable tone selections
•Information screen shows software version
•Languages: English, Traditional Chinese, Simplified Chinese, Japanese, Spanish
•Magnetic units selection：Gauss (mG) or Tesla (μT)
•Electric field strength: V/m
•RF Strength Units selection: (μW/m² ~mW/m²) (μW/cm²) (m V/m ~V/m) (mA/m) (dBm).
•Low-Frequency EMF Readings: Individual and aggregated XYZ axial readings:
•High-frequency EMF Readings
•RF Historical Records; up to 20 groups.
•Low battery indication：HIGH LOW

EMF450-en-GB_V1.47/17
4
Definitions
Electromagnetic Radiation
This meter is used to indicate radiated electromagnetic fields wherever there is a voltage,
current, electric (E) or magnetic (H) field. Examples include the electromagnetic fields from
radio broadcasting, TV transmitters and power lines.
Electric Field Strength
This is a field vector quantity that represents the force (F) on an infinitesimal unit positive
test charge (q) at a point divided by that charge. Electric field strength is expressed in units
of volts per meter (V/m). Use the units of electric field strength for measurements in near-
field power measurements.
Magnetic field strength (H)
This is a field vector that is equal to the magnetic flux density divided by the permeability of
the medium. Magnetic field strength is expressed in units of amperes per meter (A/m).
This measurement is for near-field power measurements.
Power density (S)
Power per unit area in the direction of propagation; usually expressed in units of watts per
square meter (W/m2) or, for convenience, milli-watts per square centimeter (mW/cm2).
The characteristic of electromagnetic fields
Electromagnetic fields propagate as waves and travel at the speed of light (c).
The wavelength is proportional to the frequency.
λ(wavelength) =
c (speed of light)
f (frequency)
Near-field is assumed if the distance to the field source is less than three wavelengths. For
far-fields, the distance is more than three wavelengths. In the near-field, the ratio of
electric field strength (E) and magnetic field strength (H) is not constant, so measure each
separately. In the far-field, however, it is enough to measure one field quantity, and
compute the other accordingly.
Descriptions
Front Panel Description
1. 2.4” Color TFT display (240*320 resolution)
2. Select and Down button
3. Power and Menu button
4. Hold and Enter button
5. Battery compartment cover and
measurement chart on back of meter
Figure 1 – Meter Description

EMF450-en-GB_V1.47/17
5
Display description
1. Data Hold
2. Auto power off (APO)
3. Audible alert
4. Battery status
5. Magnetic Field bargraph
6. Magnetic Field digital reading
7. XYZ axes values
8. Electric Field bargraph
9. Electrical Field digital reading
10. RF strength bargraph
11. RF strength histogram display
12. Select
13. Menu
14. Hold / Enter
15. RF electronic field color alert*
16. RF strength digital reading
17. RF Strength indication area
18. LF Electrical field color alert*
19. Electrical field indication area
20. LF electromagnetic field color alert*
21. Magnetic field indication area
*Color Coded Alert Table (for reference purpose only) see items 16, 19, and 21 above.
Magnetic Fields
Electrical Fields
RF Strength
Low 0~10.00mG 0~500V/m 0~0.99mW/m2
(0~0.59V/m)
Medium 10.01~100mG 501~1000V/m 1~9.99 mW/m2
(0.6~1.9V/m)
High
101~2000mG
>1001V/m
>10 mW/m
2
(>2V/m)
Note: Alarm beeper sounds when readings enter the red region.
Conversions
1W/m² = 0.1mW/Cm² = 100μW/Cm². 1mW/m² = 0.1μW/Cm²
Figure 2 – Display Description

EMF450-en-GB_V1.47/17
6
Operation
Power ON/OFF
1. Press the power button to power the meter. The display will show the main
measurement screen. If the meter does not power on, check that the batteries are
installed correctly and are fresh (see battery installation/replacement section later in
this guide).
2. Press and hold the Power button for 3 seconds to power off the meter.
Data hold (HOLD)
Press the HOLD button to freeze the current readings on the display. The HOLD display icon
will appear when this mode is active. To release the data press the HOLD button again.
Electric Field Measurements
The EM450 measures the electric field (Electrical Power) in the atmosphere of the sensor’s
surroundings. The sensor orientation is printed on the back of the meter.
Perform all tests according to the indicated direction of the electric field sensor.
Hold the meter at the bottom and at arm’s length, as shown in Figure 3.
Figure 3 – Orienting the meter for Electrical Field Measurements

EMF450-en-GB_V1.47/17
7
Low Frequency EMF Readings (Magnetic field)
Point the front section of the meter toward the desired electromagnetic field to take a
measurement. The meter simultaneously displays the electromagnetic field readings of
individual (XYZ) and the aggregated Magnetic field readings.
The aggregated calculation equation is expressed as:
Due to environment related magnetic field factors, this electromagnetic field (EMF) meter
may display a reading of under 0.50mG prior to testing. This is caused by the magnetic noise
in the environment, rather than meter failure.
The Magnetic and Electric field will also display a bar indicator based on the measured value.
Important: If the sensor is moved quickly, excessive field strength values will be displayed
which do not reflect the actual field conditions. This effect is caused by electrostatic charges.
Measurement considerations:
1. Hold the meter at arm’s length.
2. Point the front face of the meter toward the source of power.
3. Hold the meter steady during the measurement.
4. Make several measurements at various locations in the work place or other areas of
interest. This is particularly important if the field conditions are unknown.
5. Pay special attention to measuring the neighboring vicinity for possible radiation sources.
Apart from active sources, those components connected to a source may also act as
radiators.
For example, the cables used in diathermy equipment may also radiate electromagnetic
energy.
Note that metallic objects within the field may locally concentrate or amplify the field
from a distant source.
RF strength meter readings
Point the front face of the meter toward the desired RF field to take a measurement.
The RF signal strength will be displayed with the units of measure set from the menu mode.
The RF strength portion of the display will also show a RF strength history histogram and a
bar indicator based on the measured value.
Measurement considerations:
1. Hold the meter at arm’s length.
2. Point the front face of the meter toward the source of power.
3. Hold the meter steady during the measurement.

EMF450-en-GB_V1.47/17
8
Menu Settings
1. Momentarily, press the center MENU key to enter the main menu.
2. Press the right SELECT key to cycle through the list.
3. Press the left ENTER key to enter the selected option.
4. Use the right SELECT key to choose the desired setting.
5. Press the left ENTER key to confirm the setting, the meter will exit the menu unless there
are more settings required for the given parameter (as in the SOUND setting); in which case
continue using the keys in the same manner as described in this section.
6. From the Main Menu screen (Figure 4), the MENU key can be used to exit the Main Menu.
Figure 4 – Main Menu Option Screen
Brightness: Low, Middle, High
Magnetic unit: Gauss/mG, Tesla/ µT
(Used for testing Electrical power (50/60Hz))
RF strength unit: µW/m²-mW/m², µW/cm², mV/m-V/m, mA/m, and dBm
(Used for testing RF energy from 50MHz to 3.5GHz)
Language: English, Traditional Chinese, Simplified Chinese, Japanese, Spanish
Power OFF (Auto):NO (OFF), 1, 3, 5, 10, 15, 30 (minutes). Factory default is 5 minutes.
Sound: Enable/Disable
when ‘enable’ is selected, the keys/alarm sound menu will open.
Keys: 3 options (1, 2, or 3) represent alternate keystroke sounds.
Alarm: 3 options (1, 2, or 3) represent alternate alarm sounds.
Information: Displays the software version

EMF450-en-GB_V1.47/17
9
Battery Installation and Replacement
Battery Installation
Remove the rear battery cover and insert three (3) 1.5V AAA batteries observing correct
polarity.
Figure 5 Battery Installation
Battery Replacement
The battery status icon shows low energy when the battery voltage drops below the
operating level. See installation instructions above for battery insertion.
Never dispose of used batteries or rechargeable batteries in household waste.
As consumers, users are legally required to take used batteries to appropriate
collection sites, the retail store where the batteries were purchased, or wherever
batteries are sold.
Disposal: Do not dispose of this instrument in household waste. The user is
obligated to take end-of-life devices to a designated collection point for the disposal
of electrical and electronic equipment.
Other Battery Safety Reminders
oNever dispose of batteries in a fire. Batteries may explode or leak.
oNever mix battery types. Always install new batteries of the same type.

EMF450-en-GB_V1.47/17
10
Specifications
Sensor Type: LF - Magnetic Fields
Range: 20mG /200mG /2000mG, 2µT /20µT /200µT
Display resolution: 0.02/0.1/1
Frequency range: 50/60Hz
Accuracy: ± (15% + 100 digits)
Sensor Type: LF- Electric Field Sensor
Range: 50V/m to 2000V/m
Display resolution: 1V/m
Frequency range: 50/60Hz
Accuracy: ± (7% + 50 digits)
Sensor Type: RF Strength
Range: 0.02µW/m² to 554.6mW/m²
0.02µW/cm² to 55.4µW/cm²
36.1mV/m to 14.46V/m
0.02mA/m to 38.35mA/m
-51dB to 16dBm
Display resolution: 0.02µW/m², 0.2µA/m, 0.2mV/m, 0.002µW/cm², 2dB
Frequency range: 50MHz to 3.5GHz
Accuracy: ± 2dB at 2.45GHz
Display: 4 digits Triple color TFT display
Sample rate: 6 seconds
Sensors: Triple axes (XYZ) ELF and RF and Electric field sensor
Over range condition: The EM450 is equipped with three individual aerial
sensors to measure EMF. Overload indication (OL)
applies to all three axes (X, Y, and Z)
Battery: Three (3) 1.5V alkaline batteries
Battery Life: Approx. 8 hours
Alarm: Beeps when readings are in the red display region
Operating temperature and RH%: 5°C~40°C (41°F ~104°F); < 80%RH
Storage temperature and RH%: -10°C to 60°C (14°F ~140°F); < 70%RH
Weight: Approx. 120g (4.2 oz.)
Dimensions: 115 x 60 x 21mm (4.5 x 2.4 x 0.08”)
Copyright ©2015-2017 FLIR Systems, Inc.
All rights reserved including the right of reproduction in whole or in part in any form
www.extech.com
