USERGUIDE


ElectronicCountingScale/Balance

ModelSC600


2SC600‐EU‐ENv1.34/14
Introduction

ThankyouforselectingtheExtechInstrumentsModelSC600ElectronicCountingScale/Balance.

TheSC600ismicroprocessorcontrolledandusesaloadcelltransducerforhighaccuracyand
optimumperformance.TheSC600offersalargemeasurementcapacity,highresolution,andlarge
easytoreaddisplay.Theslideswitchonthebackofthescaleallowsfortheselectionof
measurementunits(gramorounce).

Aself‐calibrationutilityisbuilt‐inandthecalibrationdataisstoredinternallyevenuponpower
down.TheRS‐232PCinterfaceallowsforthetransferofmeasurementdatabetweentheSC600
andaPC.

TheSC600includes‘bubble’level,adjustablerubberfeetforleveling,andheavydutyABSplastic
housing.AnACadaptormaybeusedtopowertheunitortheunitmaybeusedonbatterypower.

Thisdeviceisshippedfullytestedandcalibratedand,withproperuse,willprovideyearsofreliable
service.Pleasevisitourwebsite(www.extech.com)tocheckforthelatestversionofthisUser
Guide,ProductUpdates,andCustomerSupport.

3SC600‐EU‐ENv1.34/14
MeterDescription

1. 5‐digitmulti‐functionLCDDisplay
2. ‘Bubble’Leveler
3. WeightPlatform
4. ACAdaptorjack(9V/300mA)
5. 3.5mmRS‐232PCinterfacejack
6. UnitofMeasureselectswitch(gramsorounces)
7. PowerON‐OFFswitch
8. TAREbutton
9. CAL(Calibration)button

Batterycompartmentandadjustablelevelinglegslocatedonbottomofunit.
1
2
3
4
5
6
7
8
9

4SC600‐EU‐ENv1.34/14
Operation

PreparingtheSC600
PlacetheSC600onafirm,levelsurface.Adjusttherubberpadlegsonthebottomoftheunitto
level;ensurethattheSC600islevelbeforeuse.The‘bubble’levellocatedonthetopofthe
SC600canbeusedasanaccuratelevelguide.
Removetheprotectivetapefromtheweightplatformareaandinstalltheweightplatformas
showninthediagramusingthe4screws(supplied).


5SC600‐EU‐ENv1.34/14
Poweringthemeter
Installsix(6)1.5VAAbatteriesintothebatterycompartmentlocatedonthebottomoftheunit.
TheACAdaptorcanalsobeusedtopowertheunit.TheACadaptorjackislocatedontherearof
theSC600.
PowertheunitONorOFFusingtheON‐OFFswitchlocatedontherightsideoftheSC600.
Themeterwillperformashortself‐testduringwhichthedisplaywillcountdowntozero;the
unitwillswitchONinitsnormaloperatingmode.
Pleaseallow30minutesofwarm‐upandstabilizationtimebeforeusingtheSC600.

Selectingtheunitsofmeasure(gramsorounces)
Usetherecessedselectorswitchontherearoftheunittoselectthedesiredunitofmeasure
gramsorounces.TheLCDdisplaywillreflecttheselectedunitofmeasure.

Scale(Weighing)Operation
FollowtheinstructionsaboveforSC600preparationand,whentheunitisready,gentlyplacean
objectontheweightplatformandreadtheweightmeasurementontheLCDdisplay.Ensurethat
theweightdoesnotexceedthemaximumcapacityoftheSC600aspublishedinthe
specificationsofthisUserGuide.Iftheweightofanobjectexceedsthemeasurementcapacityof
theSC600,thedisplaywillshowalldashesontheupperpartoftheLCDdisplay(‐ ‐ ‐ ‐ ‐).For
under‐rangemeasurementsthedisplayshowsdashesonthelowerpartofthedisplay(____).

TAREFunction
1. Afterweighingthefirstitem,presstheTAREbutton;thedisplaywillresettozero
automaticallyandthedisplaywillshowtheTAREicon.
2. Removethefirstitemfromtheplatformandplacetheseconditemontheplatform.
3. TheSC600willnowdisplayonlytheweightoftheseconditem.
4. TheTAREdisplayiconwillswitchOFFthenexttimethattheSC600isswitchedOFF.
TareConsiderations:Ifthedisplayshowsanegativeweight(minussignshown)oralldashes
onthelowerareaoftheLCD_____(weightvaluebelowzero)anerrormayhaveoccurred
andtheTareprocedureshouldberepeated.


6SC600‐EU‐ENv1.34/14
CounterOperation
Foracollectionofobjectsorpieces(eachpiecehavingthesameweightasthenext),theSC600
cancalculatethenumberoftheseobjectsinacollection.Agroupofpiecescanbeusedasa
sampleexampleingroupsof10,20,50,or100pieces.
1. Prepareagroupofpieces(inagroupsizeof10,20,50,or100pieces).Thiswillbethe
‘standard’thattheSC600usestocountsubsequentcollectionsofpieces.Donotplace
anypiecesonthescaleyet.
2. WiththeSC600poweredOFF,pressandholdtheCALbuttonwhileswitchingtheSC600
ON
3. HoldtheCALbuttonuntilonebeepisheard
4. ThedisplaywillcountdowntozeroandthebottomofthedisplaywillshowtheCOUNT
andPCS(pieces)icons
5. Thedisplaywillscrollthroughthegroupsizes(10,20,50,and100)onegroupsizeper
second
6. Placethegroupofpieces(fromstep1)ontotheweightplatform
7. PresstheCALbuttonwhentheappropriategroupsize(10,20,50,and100)isdisplaying.
Thedisplaywillflashtwiceandfreezethegroupsizenumber.
8. Removethegroupofpiecesfromtheplatform.TheSC600isnowreadyforcounting.
9. Placeanunknownnumberofpieces(ofthesameweightastheonesfromstep1)and
theSC60willdisplaythenumberofpiecespresentlyontheplatform.

ChangetheCountSampleNumber
1. RemoveallitemsfromtheSC600platform
2. PresstheCALbuttononce;thedisplaywillscrollthepiecegroupsizes(10,20,50,and
100)oncepersecond
3. Placeagroupofpieces(10,20,50,or100)ontotheweightplatformandwhenthe
numberontheSC600displaymatchesthenumberofpiecesontheplatformpresstheCAL
button
4. Thedisplaywillflashtwiceandfreezethecountnumber
5. Removethegroupofpiecesfromtheplatform.TheSC600isnowreadyforcounting.
6. Placeanunknownnumberofpieces(ofthesameweightastheonesfromstep3)andthe
SC60willdisplaythenumberofpiecespresentlyontheplatform.

CounterOperationConsiderations
Theonepieceweightshouldbelargerthan0.1gotherwiseerrorsmayoccurincounting.The
accuracyofthecounterdependsonthenumberofunitscounted.Itisstronglyrecommended
thatmoresamples,forexample50unitsormore,becountedforthebestaccuracy.



7SC600‐EU‐ENv1.34/14
Calibration

PreparingtheCalibration
Standardweightsarerequiredforcalibration(notsupplied).A200gramora400gramstandard
canbeused.
WarmuptheSC600foratleast30minutesbeforestartingthecalibration.

IMPORTANTCALIBRATIONNOTE:
BeforecalibratingtheSC600determinetheexpectedweightmeasurementsthatwillbe
encounteredduringnormaluse.Forexpectedweightmeasurementsupto200gramsplease
performa200gramcalibration.Forexpectedweightsabove200gramspleasecalibratetothe
400gramstandard.

400gramcalibration:
1. AftertheSC600iswarmedup,gentlyplacethe400gramstandardweightonthecenterof
theweightplatform.Iftheweightdisplaydoesnotshowexactly400gramsthencontinue
withtheprocedure,otherwisecalibrationisnotrequiredandtheprocedurecanendat
thispoint
2. PresstheCALbuttononceandthedisplaywillshow‘200grams’
3. PresstheTAREbuttononceandthedisplaywillshow‘400grams’
4. PresstheCALbuttononceagainandthedisplayvalue(400g)willflashsix(6)times.
5. Calibrationisnowcomplete.Calibrationdatawillbestoredinternallyinnon‐volatile
memorymeaningthatcalibrationdatawillbesavedevenwhentheSC600ispowered
OFF.

200gramcalibration:
1. AftertheSC600iswarmedup,gentlyplacethe200gramstandardweightonthecenterof
theweightplatform.Iftheweightdisplaydoesnotshowexactly200gramsthencontinue
withtheprocedure,otherwisecalibrationisnotrequiredandtheprocedurecanendat
thispoint
2. PresstheCALbuttononceandthedisplaywillshow‘200grams’
3. PresstheCALbuttononceagainandthedisplayvalue(200g)willflashsix(6)times.
4. Calibrationisnowcomplete.Calibrationdatawillbestoredinternallyinnon‐volatile
memorymeaningthatcalibrationdatawillbesavedevenwhentheSC600ispowered
OFF.








8SC600‐EU‐ENv1.34/14
RS‐232PCInterface
TheSC600canstreamdatatoaPCviatherear3.5mmRS232Outputjack,theoptional407001‐
USBkit(RS232toUSBcableanddriverCD)alongwiththe407001software(availablefreeat
www.extech.com)arerequired.
Oncetheequipmentlistedaboveisobtained,setthe407001‐USBtochannelnumber2and
connectittotheSC600.Openthesoftwareapplicationandfollowtheon‐screenprompts.
BatteryReplacement

WhenthelowbatteryiconappearsontheLCD(LO),thebatteriesmustbereplaced.
ThebatterycompartmentislocatedonthebottomoftheSC600.
Openthebatterycompartmentusingthebatterycompartmentlatches.
Replacethebatteriesobservingcorrectpolarityandreplacethecompartmentcarefully.

Neverdisposeofusedbatteriesorrechargeablebatteriesinhouseholdwaste.
Asconsumers,usersarelegallyrequiredtotakeusedbatteriestoappropriate
collectionsites,theretailstorewherethebatterieswerepurchased,orwherever
batteriesaresold.
Disposal:Donotdisposeofthisinstrumentinhouseholdwaste.Theuserisobligatedtotakeend‐
of‐lifedevicestoadesignatedcollectionpointforthedisposalofelectricalandelectronic
equipment.

ACPowerAdaptor

TheACadaptorcanbeusedtopowertheSC600froma110/220/240VACpowersource.The
adaptorcapacityis300mA.TheACadaptorplugsintotheSC600viathejackattherearofthe
instrument.



9SC600‐EU‐ENv1.34/14
Specifications

Display  5‐digitmulti‐functionLCD
Digitheight:20.9mm(0.8”)
RangesandResolution0.10to600g(resolution:0.01g)
0.005to9.9995oz.(resolution:0.0005oz.)
10.000to21.164oz.(resolution:0.001oz.)
Unitofmeasure Selectableviarearswitch(grams/ounces)
Accuracy  ±(0.05%+0.04g);within2hoursofcalibration
Accuracyappliesat23oC±5oC(specificationstestedunderthe
followingRFenvironmentalconditions:fieldstrength<3V/Mand
frequency<30MHzonly)
Samplingtime Approx.1measurementpersecond
TareControl 600gmaximum(approx.)
Transducertype Loadcell
UserCalibration Using200gor400gstandardweights(notsupplied)
Dataoutput RS232PCinterfacejackonrearofinstrument
OptionalPCinterfacecableandsoftwarePN407001
OptionalUSBadaptorPN407001‐USB
OverrangeindicationUpperdashes‐‐‐‐‐‐appearontheLCD
UnderrangeindicationLowerdashes____appearontheLCD
Lowbatteryindication‘LO’BatteryiconappearsontheLCD
Powersupply6x1.5VAAbatteriesorpoweradaptor9V/300mA(suppliedwith
multi‐plugs)
Powerconsumption17mADCapproximately
OperatingTemperature0to50oC(32to122oF)
OperatingHumidity<80%RH
Dimensions Base:250x190x70mm(9.8x7.5x2.8”)
Platformdiameter:120mm(4.7”)
Weight  1kg(2.2lbs.)



